- Page 1 Instruction Book for HD8000 and HC8024 Wire Closers...
-
Page 2: Table Of Contents
Table of Contents Topic: Page Number: Safety Alert Symbols Safe operating guidelines Proper machine placement HD8000 Setup Book Preparation Select and insert wire Closing height adjustment Closing the wire Wire sizing chart HC8024 Differences... -
Page 3: Safety Alert Symbols
Make sure you read this section very carefully! Learn to recognize these Safety Alert Symbols. The HD8000 and HD8024 have been designed to provide a high level of protection to an operator. Follow the guidelines below while installing, operating and maintaining your machine. -
Page 4: Hd8000 Setup
HD8000 Setup: The HD8000 comes with the handle attached to the right side of the machine. The handle can be removed and re-attached with the handle facing away from the machine or it can be attached to the left side of the machine to suit operator needs. If the handle is changed from its original position make sure to retighten the handle bolt securely to ensure proper operation of the handle. -
Page 5: Select And Insert Wire
Select Wire: Refer to chart on page 8 and choose the correct wire size. Insert the narrow wire loop into the book starting from either the left or right side of the book using a slight rotating action. Rotate the entire wire forward into the book so that the seam of the wire is on top ①... -
Page 6: Closing Height Adjustment
Setting the closer bar height: The closing bar is adjustable on each end allowing the operator to achieve a uniform close at each end of the book. Pull the handle on the closer all the way down ⑤ ⑥ and keep held down as you adjust both knobs so the top edge of the closing bar ⑦... -
Page 7: Closing The Wire
Closing the Wire: Return handle to the full upright position, place the book so the open mouth of ① the wire is firmly pressed against the back plate inside the closing machine. The ② narrow, open loop of the wire should be on top of the book while pushing against the ①... -
Page 8: Wire Sizing Chart
Wire Diameter Book Thickness Number of Sheets Diamètre du fil Ėpaisseur du Livre Numéro de Feuilles Diámetro del alambre Grosor del Libro Número de Hojas Inch Inch 20lb 80gsm 3/16 ¼ 3/16 5/16 ¼ 5/16 7/16 11.1 ½ 12.7 7/16 11.1 9/16 14.3... -
Page 9: Hc8024 Differences
HC8024 Wire closer is 24” long, has two closing halndles for ease of use and has an extendable table to help support larger format applications. Setup of the HC8024 for closing wire follows the same instructions as the HD8000. - Page 10 IMPORTANT Be sure to fill out and return your Product Warranty Registration Card or Register online www.Rhin-O-Tuff.com/warranty_registration.asp Part Number 983001 Rev.3 Janurary 2011...
