Control 4 InfinityEdge Installation Manual

InfinityEdge™ 5" and 7" In-Wall

Touch Screen

Installation Guide

Introduction
The Control4 InfinityEdge™ 5" or 7" In-Wall Touch Screens offer complete system control
®
in an elegant and compact design. These Touch Screens are equipped with a capacitive
Touch Screen surface and four (4) programmable shortcut buttons. The power options
are AC power or Power-Over-Ethernet (PoE). The device may be connected via WiFi or
Ethernet. Available for new construction or retrofits.
Supported Models
• C4-TSWMC5 – InfinityEdge 5" In-Wall Touch Screen
• C4-TSWMC7 – InfinityEdge 7" In-Wall Touch Screen
Associated SKUs:
• C4-TSWMC5-EG-WH – InfinityEdge 5" In-Wall Touch Screen, White
• C4-TSWMC5-EG-BL – InfinityEdge 5" In-Wall Touch Screen, Black
• C4-TSWMC7-EG-WH – InfinityEdge 7" In-Wall Touch Screen, White
• C4-TSWMC7-EG-BL – InfinityEdge 7" In-Wall Touch Screen, Black
What's in the Box
Carefully unpack the contents of the box, and make sure the following items are included
in the box. If any item is missing or damaged, please contact your Control4 Reseller.
• InfinityEdge 5" or 7" In-Wall Touch Screen
• InfinityEdge power box (used to power the Touch Screen)
• Two (2) Orange wire nuts and two (2) screws to attach the power box.
• InfinityEdge 5" and 7" In-Wall Touch Screens Installation Guide (this document)
Wall Box Kit Options
There are four (4) wall box options available to install this Touch Screen. Metal and plastic
wall boxes are available for new construction or retrofit installations.
•
InfinityEdge 5" or 7" In-Wall Touch Screen Wall Box Kits - New Construction
Plastic Model (C4-NWB57C-P)
Metal Model (C4-NWB57C-M)
•
InfinityEdge 5" or 7" In-Wall Touch Screen Wall Box Kit - Retrofit
Plastic Model (C4-RWB57C-P)
Metal Model (C4-RWB57C-M)
Refer to the Control4 InfinityEdge 5" or 7" In-Wall Touch Screen Wall Box Installation
Guide - New Construction or InfinityEdge 5" or 7" In-Wall Touch Screen Wall Box Installa-
tion Guide - Retrofit for your wall box installation instructions.
Accessories
• Control4 Power Over Ethernet Injector, sold separately (AC-POE1-B)
• InfinityEdge 5" and 7" In-Wall Touch Screens Wall Box New Construction, Plastic
(C4-NWB57C-P)
• InfinityEdge 5" and 7" In-Wall Touch Screens Wall Box New Construction, Metal
(C4-NWB57C-M)
• InfinityEdge 5" and 7" In-Wall Touch Screens Wall Box Retrofit, Plastic
(C4-RWB57C-P)
• InfinityEdge 5" and 7" In-Wall Touch Screen Wall Box Retrofit, Metal
(C4-RWB57C-M)
Important Safety Instructions
1. Read and keep these instructions.
2. Heed all warnings and follow all instructions.
Do not use this apparatus near water.
3.
4. Clean only with a dry cloth.
5. Install in accordance with the manufacturer's instructions.
Install in accordance with all national and local electrical codes.
6.
7. This product is also designed for IT power systems with phase-to-phase voltage
120V or 240V.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.
9. Only use attachments/accessories specified by Control4.
10. If applicable, unplug this apparatus during lightning storms or when unused for long
periods of time.
11. This product is to be installed by qualified professionals only.
12. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is dam-
aged, liquid has been spilled or objects have fallen into the apparatus, the appara-
tus has been exposed to rain or moisture, does not operate normally, or has been
dropped.
WARNING! The Touch Screen must be protected by an external circuit breaker
or a fuse rated at 6A maximum when used in Europe.
Avertissement! Pour réduire le risque du feu ou de choc électrique, n'exposez
pas cet appareil à la pluie ou à l'humidité.
Warnung! Die Berührungseingabe muß durch einen externen Circuit breaker
oder eine Sicherung geschützt werden, die am Maximum 6A veranschlagen wird,
wenn sie in Europa verwendet wird.
WARNING! Do not place the Touch Screen near sources of heat or expose to
direct sunlight for an extended period of time.
Avertissement! Ne placez pas l'unité près des sources de chaleur ou exposition
pour diriger la lumière du soleil pendant une période prolongée.
Warnung! Setzen Sie Maßeinheit nicht nahe Quellen der Hitze oder des Expo-
sés, um Tageslicht während eines ausgedehnten Zeitabschnitts zu verweisen.
IMPORTANT! Do not use pens or sharp objects to navigate or make selections
on the Touch Screen. To select an item or scroll through a list, use your fingertip.
Important! N'employez pas les stylos ou les objets pointus pour diriger ou pour
faire des choix sur l'écran. Pour choisir un article ou un rouleau par une liste,
employez votre bout du doigt.
Wichtig! Benutzen Sie nicht Federn oder scharfe Gegenstände, um oder Vor-
wähleren auf dem Schirm zu bilden zu steuern. Um ein Einzelteil oder eine Rolle
durch eine Liste vorzuwählen, benutzen Sie Ihre Fingerspitze.
IMPORTANT! Improper use or installation can cause LOSS/DAMAGE OF
PROPERTY.
Important! L'utilisation ou l'installation inexacte peut causer LOSS/DAMAGE DE
PROPRIÉTÉ.
Wichtig! Unsachgemäßer Gebrauch oder Installation können LOSS/DAMAGE
DER EIGENSCHAFT verursachen.
IMPORTANT! Using this product in a manner other than outlined in this document
voids your warranty. Further, Control4 is NOT liable for any damage incurred with
the misuse of this product. See "Warranty."
Important! Utilisant ce produit en quelque sorte autre que décrit dans ce docu-
ment vide votre garantie. De plus, Control4 n'est pas responsable d'aucun dom-
mage encouru avec l'abus de ce produit. Voyez que «Warranty.»
Wichtig! Das Verwenden dieses Produktes in gewissem Sinne anders als
umrissen in diesem Dokument hebt Ihre Garantie auf. Weiter ist Control4 NICHT
für irgendeine Beschädigung verantwortlich, die mit der Fehlanwendung dieses
Produktes genommen wird. Sehen Sie, daß "Warranty."
WARNING! Install in accordance with all national, state, and local electrical
codes.
Avertissement! Installez selon tous les national, état, et codes électriques
locaux.
WARNING! This product generates heat. The room must have adequate
ventilation or the ability to dissipate heat effectively.
Avertissement! Ce produit produit de la chaleur. La salle doit avoir à
ventilation proportionnée ou la capacité d'absorber la chaleur efficacement.
WARNING! This product must be grounded in accordance with the National
Electrical Code (NEC) requirements.
Avertissement! Ce produit doit être fondu selon les conditions électriques
nationales de code (NEC).
WARNING! Use this product only in dry locations.
Avertissement! Employez ce produit seulement dans des endroits secs.
CAUTION! This product is for residential use only.
Attention! Ce produit est pour à l'usage résidentiel ou commercial seulement.
