55" Full HD 100/120Hz Multi System LED TV
Model No.: AET55100UM
Attention;
Please Kindly refer to "TV Broadcasting system"(Page 9 of User's manual) for choosing suitable
TV broadcasting system as per your living area when you use this unit firstly.TV Color system is
automatically searched regardless of your living area.
Advertisement
Table of Contents
Related Manuals for Avol AET55100UM
Summary of Contents for Avol AET55100UM
- Page 1 55" Full HD 100/120Hz Multi System LED TV Model No.: AET55100UM Attention; Please Kindly refer to "TV Broadcasting system"(Page 9 of User's manual) for choosing suitable TV broadcasting system as per your living area when you use this unit firstly.TV Color system is...
-
Page 3: Table Of Contents
Contents Contents Caution Safety Information Accessories Technical Specification Product Introduction Front View Wall Mounting Connections Remote Control Basic Operation OSD Menu 9-14 1. Channel menu 9-10 2. Picture menu 3. Sound menu 4. Time menu 5. OPTION menu Multimedia Operation 15-18 Simple Troubleshooting... -
Page 4: Caution
Caution Caution The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of un-insulated “dangerous voltage” within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to the persons. The exclamation point within an equilateral triangle is intend to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. -
Page 5: Safety Information
Safety Information Safety Information To ensure reliable and safe operation of this equipment, please read carefully all the instructions in this user guide, especially the safety information below . Electrical safety • The TV set should only be connected to a main supply which matches that stated on the label on the mains adaptor. -
Page 6: Accessories
Accessories & Technical Specification Accessories SOURCE CH.list PICTURE SOUND SLEEP DISPLAY VOL+ MUTE Din to F Connector Converter cable for VOL- EXIT MENU YPbPr video ROOT TV/TXT HOLD NICAM/A2 SLOW ZOOM LANGUAGE SUBPAGE INDEX SIZE REVEAL SUBTITLE REPEAT GOTO User’s Manual Remote control 220V Power Socket Converter cable for... -
Page 7: Product Introduction
Product Introduction Product Introduction Front View SOURCE: MENU: CH+/-: Press to scan through channels. VOL+/-: POWER: Led Indicator Remote Control window (Keep clear) POWER to turn on and off. Indicator on(Green) Power on mode Wall Mounting The TV is provided with mounting holes 400x400mm for a VESA approved wallmounting bracket (NOT SUPPLIED). -
Page 8: Connections
Connections Connections AC POWER IN HDMI3 HDMI2 HDMI1 SCART COAX AC POWER IN : Connect to an earth 100-240V~ 50/60Hz outlet with the Power Cable. USB : For service (software update) and MEDIA. HDMI1/2/3 : Connect it to the HDMI output of the external devices. SCART Connect to the scart input / output of external devices. -
Page 9: Remote Control
Remote Control Remote Control The remote control is using Infra-Red(IR). Point it towards the front of the TV. The remote control may not work correctly if it is operated out of range or out of angle. SOURCE POWER : Turn on/standby the TV SOURCE : Source select. - Page 10 Remote Control Remote Control SOURCE CH.list PICTURE SOUND SLEEP DISPLAY VOL+ MUTE VOL- ROOT: Come back to the home page. FAV: Display the favourite channel list. EXIT MENU : Play/Pause program : Stop program : fast reverse : fast forward : previous chapter : next chapter A-B: Select and play the preferable paragraph of USB program...
-
Page 11: Basic Operation
Basic Operation Basic Operation Power on/off 1. Connect to the power supply with the power cord. 2. -To turn on the TV Press POWER button on the TV or remote control. -To turn off theTV Press POWER button on the TV or remote control. Input Source select Press Source button on the TV set or on the remote control to display SCART... -
Page 12: Channel Menu
OSD Menu OSD Menu 1. CHANNEL menu Description Auto Scan Press OK button to start auto tuning. You could press MENU/EXIT button to exit the process of tuning, there will be a hint on the screen, and you should press button to confirm, or press button to cancel the operation. -
Page 13: Osd Menu
OSD Menu OSD Menu Programme Edit Press OK button to enter the Programme Edit menu as the following picture. Delete: Select a channel and press RED button to delete. Swap: Select a channel, and press YELLOW button to highlight the channel, then you can use buttons to select the channel you want to be swapped, press OK button to confirm. -
Page 14: Picture Menu
OSD Menu OSD Menu 2. PICTURE menu Description Picture Mode: Choose from Standard, Dynamic, User and Mild. Note: Contrast, Brightness, Color and sharpness are only available and can be adjusted in the User mode option in the Picture Mode Settings. Contrast: Controls the difference between the brightest and darkest regions of the picture. -
Page 15: Sound Menu
OSD Menu OSD Menu 3. SOUND menu Description Sound Mode: Allows you to select among: Standard, Music, Movie, Sports and User. Treble(Can be adjusted when the sound mode is User): Controls the relative intensity of higher pitched sounds. Bass (Can be adjusted when the sound mode is set to User): Controls the relative intensity of lower pitched sounds. -
Page 16: Time Menu
OSD Menu OSD Menu 4. TIME menu Description Clock: Use the buttons to select the position, and use the buttons to set the time. Off Time: Press OK button to enter the submenu, you could set the time when the TV set will be turned off automatically, you could also set the frequency. -
Page 17: Option Menu
OSD Menu OSD Menu 5. OPTION menu Memc Mode Description OSD Language: Allows you to select menu language. TTX Language: Allows you to select teletext language. OSD Duration: Allows you to select the time for the OSD display on the screen. Blue Screen: Turn on/off the blue screen function when there’s no signal. -
Page 18: Multimedia Operation
Multimedia Operation Multimedia Operation Basic Operation 1). Press the SOURCE button on the remote control to display the input source menu, select USB source by the buttons, and press OK button to enter the Multimedia menu seen below. SCART YPBPR HDMI1 HDMI2 HDMI3... - Page 19 Multimedia Operation Multimedia Operation 1. Photo Play the photo Press DISPLAY button to display playing list. Press button to select the option on the table, and press OK button to change. Repeat: Select the repeat mode from Repeat All, Repeat 1, Repeat None. Playlist: Display the playlist on the screen, and you can select the photo by button, and press OK button to program.
- Page 20 Multimedia Operation Multimedia Operation 3. Movie Play the movie Press button to select the option on the table, and press OK button to change. Repeat ALL: Select the repeat mode from Repeat All, Repeat 1, Repeat None. None A-B: Select and play the preferable paragraph of the program by seting A and B at the beginning and end, and there will be a sign on the left screen, press OK button again to cancel.
- Page 21 Multimedia Operation USB Memory Device Compatiblity Supported Codec Remark Type File format The max Resoultion And Frame Rate:720p@30fps MJPEG MP3, Max Data Rate : 10Mbps WMA, MPEG-4 Movie file format AAC, MPEG-2 The max Resoultion And Frame MP2, XVID Rate:720p@30fps MPEG-1 Max Data Rate : 20Mbps MPEG-2...
-
Page 22: Simple Troubleshooting
Simple Troubleshooting Simple Troubleshooting If the display fails or performance dramatically deteriorates check the Display in accordance with the following instructions.Remember to check the peripherals topinpiont the source of the failure. If the display still fails to perform as expected,connect your helpline for assistance. No power - Check SWITCH on rear cabinet of TV.
