  • Page 1 S5050 Duo 4-core HD Quick Guide...

  • Page 2: Table Of Contents

    Android system........11 Basic control........12 Making calls........17 Messages...........20 Choice of SIM card for 3G....22 Photography........23 PC connection........24 Safety and ecology......26 Before you start Thank you for buying of our ALIGATOR mobile phone. Before you start please read carefully this instruction manual.

  • Page 3: Dual Sim Function

    DUAL SIM function Your mobile phone can be operated with 1 or 2 SIM cards. If you insert only one SIM card the mobile phone works as an ordinary mobile phone. In case you insert 2 SIM cards at the mobile phone both are active at the same time.
  • Page 4 Do not use the mobile  phone while driving the  Do not use the mobile phone near the medical appliances without having the confirmation that the radio waves do not influence its function.  Mobile phone can influence the function of the cardiac pacemakers or other implanted appliances –...
  • Page 5 Do not use mobile phone  near the petrol stations. Always switch off the mobile phone near explosives.  Use only the original batteries supplied by the producer. Danger of damage of the mobile phone or explostion.  Do not throw the battery in the fire nor expose it to the temperatures over +60°C.
  • Page 6 Please keep the mobile  phone 2.5 cm away from the body while calling. You lower by that the quantity of electromagnetic radiation absorbed by your body.  Handle the mobile phone with care, protect it from falling on the ground, from mechanical damage, impurity or high temperatures.

  • Page 7: Insert Battery And Sim Card

    Keep it out of reach of  children. It contains small parts that could be swollowed or may hurt Software and hardware of  the mobile phone are continuously innovated. The importer reserves the right to alter the instruction manual or particular functions of the mobile phone without a prior notice.
  • Page 8 Insert firstly one or two SIM cards at the prepared slots. Insert SIM and also MicroSD memory cards (if you have) as per the picture. Insert the battery. Make sure that the battery clicks smoothly into the slot in the mobile phone.

  • Page 9: Mobile Controls

    Mobile controls 1. Button : Offer 2. Button : Main screen 3. Button : Back 4. Volume 5. Button : Switch On / Off...

  • Page 10: Switch On / Off

    6. Earphones 7. Headphone connector 8. Front camera 9. Micro USB connectorSwitch On / Off Switch On / Off To Switch On - press the button (5). The start of the mobile phone can last few seconds. To Switch Off – press and hold the button (5) till the indicator window of a switch off appears on display.

  • Page 11: Android System

    time of inactivity. You can turn on/off the screen by a short press of the button (5). It is necessary to unlock the screen after the activation. Put your finger on a „Lock“ symbol and move it in the right direction.

  • Page 12: Basic Control

    Basic control Meaning of the touch buttons (1) to (3) (1) Menu – serves to display the offer of items on actual screen or in the launched application. (2) Main screen – a short press serves to return to a main screen.
  • Page 13 System control Your mobile phone can be controlled either by above mentioned buttons or with the help of touch screen. By clicking on them you can choose the items , confirm dialogue windows and graphical buttons on the screen. Google account It is necessary to create the Google account which can be set up in following simple...
  • Page 14 2.Select Accounts and synchronisation in menu and choose Add Account 3. Further follow instructions on the screen Main screen Your main screen is devided into more pages that can be displayed by moving of your finger to the left/right. On the main screen you can place the short cuts of icons of applications and links or widgets.
  • Page 15 Applications All installed applications can be displayed by the button placed in the middle of the lower part of the main screen. In standard equipment of the mobile phone you can find applications for making calls, sending messages and e-mails or many other useful applications.
  • Page 16 works correctly in your mobile phone. Information and display of status So called status bar is placed in the upper part of the screen. You may find here the information about time, battery level and signal but also other useful information. For example the information about new SMS, system or applications.

  • Page 17: Making Calls

    Mobile phone set up All items of the telephone set up are clearly arranged at the settings menu. Press the button Menu (1) and select Set up . Making calls Dialling Click on the earphone icon on the main screen. Screen with keypad for number dialling will be displayed.
  • Page 18 displayed on the buttons so you can enter also the name. The dialled number and all corrresponding items of the tel.directory will be displayed after entering of the letters on keys of the screen. At the bottom part of the screen you may find the button for making calls (head- phone symbol).
  • Page 19 for calling) for your choice by dragging down of the status bar. Indicator of the signal of the selected SIM card is underlined to facilitate the orientation. Answer and reject the call If somebody is calling you the information about his telephone number and a button with the receiver is displayed on the screen (if...

  • Page 20: Messages

    Call flow and finish of the call The screen will automatically switch off when the mobile phone is attached to the ear. After the delay from the ear the screen will swith on within few seconds. The call can be finished by pressing of the red button on the screen.
  • Page 21 A list of conversations containing received and sent SMS and MMS messages will be displayed. 3. Select the icon New message on the left bottom side of the screen. Now you can insert the receiver of the text message. To send the text message press the arrow button placed on the right side of the text.

  • Page 22: Choice Of Sim Card For 3G

    the status bar which SIM card can be used for sending of messages. Choice of SIM card for 3G You can choose which SIM card will be used for internet 3G connection : Press the button Offer and  select System settings Select ...

  • Page 23: Photography

    Photography Press the icon „Camera“ to start the photography. Focus the camera on the subject of the shot. Aim the camera at the scene and tap your finger on the screen to the point that you want to focus on, or wait a moment, the camera automatically focuses on the center.

  • Page 24: Pc Connection

    if you want to accelerate focusing or to focus on a different part of the image, tap the desired location on the screen. Beware! Always wait for focus and then press the shutter button, otherwise the images will be blurred. Press the button to switch the front and rear camera.
  • Page 25 Now the internal storage at the mobile phone and inserted MicroSD card will be connected with the PC at the file Computer, in section Portable Devices , under the name ALIGATOR S5050. The connection can be interrupted by disconnection of the cable.

  • Page 26: Safety And Ecology

    Safety and ecology Used electric device Mobile phone is an electronic appliance. It means it must not be manipulated as a common residential waste. Never throw the used device away at the common municipal waste!!!They may contain the substances dangerous to the environment.

  • Page 27: Declaration Of Conformity

    +60°C. Danger of explosion or fire. 0700 Declaration of conformity No.17/08/2015 Issued in accordance with the prescription EU R&TTE, 1999/5/EC Product: Mobile phone for GSM network Model : ALIGATOR S5050 Duo Importer: ADART COMPUTERS s.r.o., Sokolovská 161, 180 00 Praha 8, Reg.No. 25074547...
  • Page 28 Evaluated product is a mobile phone intended for mobile nets of GSM standard and is planned to be used and stored in standard conditions. The importer declares, that the product is for its use safe and during the production there are taken control and other measurements securing the confirmity of the product with the basic requirements and technical documentation.
