Summary of Contents for ALIGATOR V650
- Page 1 V650 Quick Guide...
-
Page 2: Table Of Contents
Contents Important instructions........3 Putting into operation........6 lnsert SIM,memory card, battery.......6 Battery charging..........7 Switch On / Off..........8 Mobile controls..........10 Making calls.............18 Dialling.............18 Photo contacts..........19 SOS calls and SMS.........19 SOS Locator ...........21 SMS Messages..........23 FM Radio............24 Bluetooth............24 SIM toolkit............25 Camera............25 Phone set up...........26 Safety and ecology..........27 Used electric device........27 Battery liquidation..........27... -
Page 3: Important Instructions
Important instructions Thank you for buying of our ALIGATOR mobile phone. Before you start please read carefully this instruction manual Do not use the mobile phone in the prohibited areas Do not use the mobile phone while driving the car ... - Page 4 mobile phone or explostion. Do not throw the battery in the fire nor expose it to the temperatures over +60°C. Danger of explosion or fire SAR – mobile phone meets all prescriptions for maximal emision of electromagnetic radiation. Please keep the mobile phone 2.5 cm away from the body while calling.
- Page 5 appear. In this case, turn the phone off and on to display it correctly. Software and hardware of the mobile phone are continuously innovated. The importer reserves the right to alter the instruction manual or particular functions of the mobile phone without a prior notice...
-
Page 6: Putting Into Operation
Putting into operation Insert SIM, memory card and battery Slip your nail at the slot under the battery cover on the back side of the mobile phone and pull down carefully the cover. Insert firstly one or two SIM cards at the prepared slots. Insert SIM and also MicroSD memory cards (if you have) as per the pictures placed near the slots. -
Page 7: Battery Charging
ATTENTION! Turn off the phone and disconnect the charger when handling the battery, card or SIM card. Only use original batteries supplied by your phone manufacturer! Battery charging Be sure that the battery is placed at the mobile phone. Connect the charger and the charging will start automatically. -
Page 8: Switch On / Off
Switch On / Off to SWITCH ON the phone - press and hold the red button, till the phone turns on. (Now you can be asked to enter the PIN code in case the PIN protection is activated). to SWITCH OFF - press and hold the red button, untill the mobile turns off. - Page 9 It is necessary to confirm the shutdown shutdown by pressing the left button Yes (2). Before Switching On be sure that the battery is inserted and is charged. Mobile controls...
-
Page 10: Mobile Controls
Mobile controls... - Page 12 Description of mobile controls No. Buttons Function -starts contacts in standby mode -return from menu or exit Right current function functional -other functions depending button on context (current function is shown on display above the key) -displays message in standby -confirms selection Left in menu or activates...
- Page 13 -press Up in standby mode to display phone menu , Navigation press Down to display button Up / photo contacts Down -move in menu and in phone list -long press to Switch On / -stop or reject a call Red button -return from the menu or exit current function on the main screen...
- Page 14 - in text writing mode toggles method of character imput - long press to turn on/off silent mode „Meeting“ - inserts *,+, p, w when writing numbers Button * - in text writing mode enables to insert special characters Contacts for Please keep the contacts charging clean so that the stand can...
- Page 15 used to listen the call Earphone Used to alert you of charging (red), new indicators messages and missed calls (green) -To control ringtone volume, music playback, or FM radio. -During a call, adjust the Volume +/- volume of the call in the earpiece (or loudspeaker).
- Page 16 -It serves as a quick option to store your favorite phone numbers. The stored numbers can then be quickly dialed by simply pressing the M1 or M2 Button : button. M1, M2 -In some menus you can move to the sides - With the music or recorder mode, you can go to the previous (M1) or next (M2)
- Page 17 Icons on the screen Battery charge level Signal strenght Alarm activated Unread SMS message Missed calls Ringing Off...
-
Page 18: Making Calls
Making calls Dialling Insert required phone number on the mobile keypad and press the green button (5). Mobile will start to dial required number. If you have dialled by mistake a wrong number, just press the right button „Delete“ (1) and the last digit will be deleted. -
Page 19: Photo Contacts
Photo contacts The phone can store up to 10 so-called photo contacts - that is, contacts to which a photo or picture is assigned. You can then quickly and easily dial them by selecting an image. The picture is also displayed when you receive a call. - Page 20 Setting SOS Set.. SOS SMS SMS text). After that the phone will remain in the emergency mode. In this emergency mode the phone will automatically answer incoming calls and automatically activate the handsfree feature - loud listening. The display will show the inscription SOS.
-
Page 21: Sos Locator
1. Settings SOS Set. SOS SMS Send SMS 2. Select On / Off SOS Locator – mobile mobile localisation Your phone has a special function that allows you, after pressing the SOS button, to determine the location of the phone and and send it via SMS to recipients in the form of a link to view the map - if the recipient is using a regular phone with a web browser. - Page 22 Select in menu: Settings SOS Set. SOS regime SOS Locator Remote location request Position of your mobile phone can be remotely detected by using of a special control SMS. It is sufficient to send just a command via SMS with a text OSLOCATOR. Your ALIGATOR...
-
Page 23: Sms Messages
phone then responds by sending of the current position via SMS. Important: Your phone sends location and responds only to SMS messages on numbers that are stored for emergency calls. SMS messages Your phone can receive and send SMS text messages. -
Page 24: Fm Radio
FM Radio Your mobile phone is equipped with FM Radio . Select in menu : Multimedia FM Radio . H Press the volume buttons (14) to adjust the volume.You can change the frequency using the M1 / M2 (16) keys. Press the shutter button (15) repeatedly to turn the sound on / off. -
Page 25: Sim Toolkit
There are available items such as Wiring, Visibility, My Device, Device Search, Device Name, Advanced. SIM toolkit services Choose Organizer SIM Toolkit for mobile banking, timetables and other SIM services for your operator. Photo camera The camera lens is located on the front of the phone. -
Page 26: Phone Set Up
Settings To set other properties, select Settings in the main menu of your phone. You now have several setup options. Mobile phone settings Select in menu: Settings Phone Allows you to set basic phone parameters: Time and date – enables to set time, date and time zone Language –... -
Page 27: Safety And Ecology
Safety and ecology Used electric device Mobile phone is an electronic appliance. It means it must not be manipulated as a common residential waste. Never throw the used device away at the common municipal waste!!! They may contain the substances dangerous to the environment. -
Page 28: Declaration Of Conformity
Do not throw the battery in the fire nor expose it to the temperatures over +60°C. Danger of explosion or fire. Declaration of conformity ADART COMPUTERS s.r.o. declares that the type of ALIGATOR V650 radio device is in compliance with Directive 2014/53 / EU. 0700...
