Summary of Contents for ALIGATOR A890

  • Page 1 A890 Quick Guide...

  • Page 2: Table Of Contents

    Contents Important instructions......3 Putting into operation......5 Insert SIM, memory card + battery..5 Battery charging.........6 Switch on / off........8 Mobile controls........9 Icons on the screen......15 Screen unlock........18 SOS function........18 SMS messages.......26 Alarm clock, Calendar, Calculator. . .27 Bluetooth connectivity......27 SIM toolkit, Multimedia....28 PC connection.........30 Safety and ecology......31 Declaration of conformity....32...

  • Page 3: Important Instructions

    Important instructions  Do not switch on and use the mobile phone in the prohibited areas. Do not use the mobile phone while driving the car  Do not use the mobile phone near the medical appliances without having the confirmation that the radio waves do not influence its function ...
  • Page 4 mobile phone) Do not throw the battery in the fire nor expose it to the temperatures over +60°C. Danger of explosion or fire !!  SAR – mobile phone meets all prescriptions for maximal emision of electromagnetic radiation  Please keep the mobile phone 2.5 cm away from the body while calling.

  • Page 5: Putting Into Operation

    children. It contains small parts that could be swollowed or they may hurt  Sometimes, the top of the external display, including battery and signal icons, may not appear. In this case, turn the phone off and on to display it correctly.

  • Page 6: Battery Charging

    Insert phone or two SIM cards at the prepared slots. Insert SIM and also MicroSD memory cards (if you have) as per the picture instruction. Insert the battery. The three metal contacts must point toward the top of the phone. Make sure that the battery clicks smoothly into the slot in the mobile phone.
  • Page 7 charger and the charging will start automatically. Mobile phone can be charged if it is in switched on or switched off mode. Charging level is indicated on the mobile screen. Discharged Fully charged Sometimes it happens that after the battery is fully discharged phone will not start charging the battery by connecting the charger.

  • Page 8: Switch On / Off

    can lead to its destruction, which is not covered by warranty! Basic manipulation Switch On / Off to SWITCH ON the phone - press and hold the red button, till the phone turns on. (Now you can be asked to enter the PIN code in case the PIN protection is activated)

  • Page 9: Mobile Controls

    to SWITCH OFF - press and hold the red button, untill the mobile turns off. then you must confirm the shutdown by pressing the left button Yes (2). Before Switch On – make sure that the battery is inserted at the mobile phone and that it is fully charged.
  • Page 11 Description of Mobile controls No Name Function -starts contacts in standby mode -return from menu or exit from current Right function functional -other functions button depending on context (current function is shown on display above the key) -displays Messages in standby mode Left -confirms selection...
  • Page 12 (current function is shown on display above the key) Navigation - display phone menu button Up / -move in menu and in Down phone list -long press to Switch On / Off -stop or reject a call Red button -return from the menu or exit current function on the main screen -press the button to...
  • Page 13 write „0“, when writing text enables to write „gap“ long press to turn on/off flashlight - inserts # when writing numbers - in text writing mode Button # toggles method of character imput - by long press turns on/off the silent mode - inserts *,+, p, w when writing numbers Button *...
  • Page 14 Connector Used to connect the Micro USB charger cable or PC powerful LED flashlight is placed on top of the phone 11 Flashlight long press of button „0“ to turn on/off the flashlight 12 Earphone used to listen the call Used to connect Earphone headphones / mini-...

  • Page 15: Icons On The Screen

    Icons on the screen Battery charge level Signal strenght  Alarm activated Unread SMS message Missed calls Ringer Off...
  • Page 16 Making calls Dialing Insert required phone number on the mobile keypad and press the green button (5). Mobile will start to dial required number. If you have dialled by mistake a wrong number, just press the right button „Delete“ (1) and the last digit will be deleted.
  • Page 17  adjust the Volume (during the call) by pressing of navigation button Up/Down (3)  to activate hands free – press left button (during the call) Option (2) and select StartRep Dialing from the contact list The simplest way to display the contact list is to press the right button (1).

  • Page 18: Screen Unlock

    When viewing the contact list, the distinguishing icon appears to show if the contact is stored on the SIM card or at the mobile phone. Contacts Select Contacts at the main menu of the phone. Select New Contact to create a new contact. Screen unlock Select in menu to set : Settings...
  • Page 19 alarm begins and the phone will begin automatically to dial the preset numbers from the list until it can reach any of them. The phone repeats max. 3 times to dial all preset numbers. The phone also sends an emergency SMS message with a preset text to all preset phone numbers.

  • Page 20: Sos Function

    calls and automatically activates the handsfree - speakerphone. Inscription „SOS“ appears on the display. To deactivate the SOS function – just rurn off and on the mobile phone. SOS function is only available if it is enabled in the settings of the phone and if the numbers are set up at the phone that the mobile should...
  • Page 21 1. Organizer  SOS Setting  SOS SMS  Send SMS / SOS calls 2. Select On / Off SOS Locator – mobile localisation Your phone has a special function that allows you, after pressing the SOS button, to determine the location of the phone and and send it via SMS to recipients in the form of a link to view the map - if the recipient is using an...
  • Page 22 of the network at a given position, eg. in the cities the position can be determined with an accuracy of tens to a few hundred meters, outside the buildings/cities but a focus accuracy usually decreases. This service is provided without any guarantee, at the own risk of an user and the accuracy of the results or the availability of services is not...
  • Page 23 SMS control. It is sufficient to send just a command via SMS with a text SOSLOCATOR on your ALIGATOR phone. Your ALIGATOR phone then responds by sending of your current position via SMS.
  • Page 24 stored in phone for emergency calls. Setting of emergency SOS function Setting of emergency SOS function To set the SOS Locator , select in menu: Organizer  SOS Set. The menu appears : 1. SOS regime – Allows to switch SOS function.
  • Page 25 2. SOS SMS – allows you to enable / disable the sending of emergency SMS messages after pressing the SOS button and to set the text of emergency SMS 3. Siren – determines whether the siren is triggered when the SOS button is pressed 4.

  • Page 26: Sms Messages

    7. GPS Module - Turn on / off the built-in GPS module SMS Messages Your phone can receive and send text SMS and MMS messages.The new message you receive will be notified by a symbol on the phone screen.If you have a new, unread message, a notification will appear on the screen.

  • Page 27: Alarm Clock, Calendar, Calculator

    Alarm Clock - Your phone comes with several independent alarm clocks Calendar Allows you to view the calendar by months or weeks. Insert of notes + reminders is possible. Calculator Your phone has a simple and practical calculator. Select in the menu: Organizer ...

  • Page 28: Sim Toolkit, Multimedia

    sound or send files or receive files from another device. Select in menu: Organizer  Bluetooth SIM toolkit services Select inmenu Organizer  Services  SIM Toolkit for mobile banking, timetables and other SIM services of your operator. Music player – plays music files Multimedia...
  • Page 29 Multimedia-> Camera Security Select in menu: Settings Security Allows you to set the SIM card PIN, phone password: Telephone – to turn on / off the phone with a password and its change. The default factory password is 1122 Select operator network Select in menu: Settings...

  • Page 30: Pc Connection

    ATTENTION! Requires Windows Vista, 7, 10 and up! If you use other operating systems, you may need to use special drivers. The ALIGATOR A890 mobile phone is designed for use in EU countries.

  • Page 31: Safety And Ecology

    Changes to all parameters are reserved. Check with the dealer for the current values of the listed parameters. Safety and Ecology Used electric devices Mobile phone is an electronic appliance.It means it must not be manipulated as a common residential waste. Never throw the used device away at the common municipal waste!!! It must be, after the use, handed over to the...

  • Page 32: Declaration Of Conformity

    Danger of explosion or fire !!! Handling with the used batteries in contradiction with given instructions is illegal! Declaration of Conformity Hereby ADART COMPUTERS s.r.o. declares that the type of ALIGATOR A890 is in compliance with Directive 2014/53 / EU.
