Chapter 2
•

Share Local Resources in the Internet by Virtual Server

• Open Ports Dynamically by Port Triggering
• Make Applications Free from Port Restriction by DMZ
• Make Xbox Online Games Run Smoothly by UPnP
2. 23. 1. Share Local Resources in the Internet by Virtual Server
When you build up a server in the local network and want to share it on the Internet,
Virtual Server can realize the service and provide it to the Internet users. At the same
time Virtual Server can keep the local network safe as other services are still invisible
from the Internet.
Virtual Server can be used for setting up public services in your local network, such as
HTTP, FTP, DNS, POP3/SMTP and Telnet. Different services applies different service ports.
Port 80 is used for HTTP service, port 21 for FTP service, port 25 for SMTP service and port
110 for POP3 service. Please verify the service port number before the configuration.
I want to:
How can I
do that?
Share my personal website I've built in local network with my
friends through the Internet.
For example: The personal website has been built in my home
computer (192.168.0.100). I hope that my friends in the Internet
can visit my website in some way. The computer is connected to
your Touch P5 with the WAN IP address 218.18.232.154.
Personal Website Router
Home LAN
1. Assign a static IP address to your computer, for example
192.168.0.100.
2. Visit http://tplinkwifi.net, and log in with the username and
password you set for your Touch P5.
3. Go to Advanced >
Add.
4. Click View Existing
this case: HTTP). The
will be automatically filled in. Enter the computer's IP address
192.168.0.100 in the
5. Click OK.
Configure Touch P5 as a Router
INTERNET
WAN: 218.18.232.154
NAT Forwarding > Virtual
Services, and select your
External Port, Internal Port
Internal IP field.
Servers, and click
Service Type (in
and Protocol
49
