Page 1 ESTeem MODEL 195E SERIES USER’S MANUAL Models 195Eg – 195Ed - 195Ep – 195Ea Manual Revision 1.0 October 2012 Electronic Systems Technology, Inc.
Page 2 415 N. Quay Street Kennewick, WA 99336 Phone: 509-735-9092 Fax: 509-783-5475 E-mail: market@esteem.com Web Site: www.esteem.com Copyright© 2013 by Electronic Systems Technology, Inc. All rights reserved. Printed in the United States of America. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Electronic Systems Technology.
Page 3: Product Warranty
ADDITIONAL SERVICE: If EST releases an improvement update to firmware internal to the ESTeem unit during the 90 day period after the unit was purchased by the first user/customer, EST will update the applicable unit with the revised version at no charge other than for UPS handling and shipping to and from your location to the EST factory.
Page 4: Table Of Contents
--------------------------------------------- Mobile Client Modes --------------------------------------------- 802.11 Access Point Modes --------------------------------------------- Programming Examples Using ESTeem Network Configuration (ENC) Utility --------------------------------------------- Example 1 – Point to Point Ethernet Bridge --------------------------------------------- Example 2 – Point to Point Ethernet Bridge with Repeater --------------------------------------------- 3-10 Example 3 –...
Page 5 --------------------------------------------- Redundant Backup Redundant Master Configuration --------------------------------------------- CHAPTER 8 – Antenna Setups Antenna and Cable Configurations Model 195Eg/195Eg-lp Antenna and Cable Configuration --------------------------------------------- Model 195Ea Antenna and Cable Configuration --------------------------------------------- Model 195Ed Antenna and Cable Configuration --------------------------------------------- Model 195Ep Antenna and Cable Configuration...
Page 6 Viewing RF Data Rates --------------------------------------------- Signal Strength vs Data Rates --------------------------------------------- Setting Maximum Distance Value --------------------------------------------- Troubleshooting Tips --------------------------------------------- APPENDIX F – 195Eg Specifications 195Eg Specifications --------------------------------------------- Case Diagram --------------------------------------------- Antenna Specifications --------------------------------------------- APPENDIX G – 195Ea Specifications 195Ea Specifications...
Page 7: Chapter 1 - Introduction
CHAPTER 1 INTRODUCTION BEFORE YOU BEGIN Thank you and congratulations on your purchase of the ESTeem Model 195E Wireless Ethernet Radio Modem! This manual was written to help both the first time and advanced user of the 195E to configure the wireless modem for your application. If this is your...
Page 8: Access Point Modes
Access Point Bridge Mode An ESTeem Model 195E in Access Point Bridge mode will both provide wireless access to mobile clients (Access Point) and bridge all Ethernet data connected to the Ethernet ports. The AP Bridge mode will pass all network traffic between connected devices including global network broadcasts.
Page 9: Access Point Repeater
Access Point Repeater The Access Point Repeater is a unique enhancement of the ESTeem Model 195E series. The Access Point Repeater can be used with any of the above Access Point modes. With this repeater feature enabled, the Model 195E Access Points do not have to be hardwired together on the same physical LAN to provide seamless Ethernet communication for roaming clients.
Page 10: Station (802.11G Client) Modes
Station Masquerade Mode The Station Masquerade mode is another case multiple devices will be connected to a single ESTeem in a mobile or client application. However, unlike the Station Router mode, the Station Masquerade will consolidate all connected Ethernet devices to a single IP address on the network. The devices connected to the Station Masquerade 195E will be able to access information from both the wireless and wired LAN, but will be inaccessible the other way similar in application to a firewall.
Page 11: Rs-232 Serial Applications
RS-232 Serial Applications The ESTeem 195E is installed with an RS-232 data port for serial data applications run over the broadband link (Figure 6). The serial over broadband network can be used in a point-to-point or point-to-multi-point application for networking serial (RS-232C) devices, providing serial connections to legacy hardware in a new Ethernet network or providing for high-bandwidth devices (such as Video or Voice over IP) in an existing serial network.
Page 12: Chapter 2 - Starting Out
Determining the correct mode of operation for the ESTeem 195E is the first step. Chapter 3 of this User’s Manual details the modes of operation and applications where each would be used.
Page 13: Starting Out
CHAPTER 2 STARTING OUT Figure 1: 195E Front Panel Overview Figure 2: 195E Antenna Overview Revised: 19 Oct 12 EST P/N AA107E...
Page 14: Model 195Eg Hardware Configuration
The following steps should be completed to begin configuration of the ESTeem Model 195E: Connect the antenna to the antenna connector on the ESTeem Model 195E (Figure 3). For a single antenna use Antenna Port A and connect both if using dual antennas.
Page 15: Chapter 3 - Example Applications
The ESTeem Model 195E is a sophisticated wireless networking device that can be configured for multiple modes of operation. Determining the correct mode of operation for the ESTeem is the first step in creating a reliable wireless network. This chapter will explain each mode of operation, provide example applications and detailed programming information for each mode.
Page 16 CHAPTER 3 EXAMPLE APPLICATIONS Figure 2: Ethernet Bridge with Repeater Figure 3: Multipoint Bridge with Mesh Networking Revised: 19 Oct 12 EST P/N AA107E...
Page 17: Router Modes
Router Modes (AP Router and AP Masquerade) The ESTeem 195E can be configured as a network router or network firewall between the Ethernet LAN connection and the wireless network of remote locations. The router modes are used to limit the network traffic from a busy Ethernet network connection to only those specific IP address used on the wireless network (see Figure 4).
Page 18: Mobile Client Modes
EXAMPLE APPLICATIONS Mobile Client Modes (EtherStation, Station Router or Station Masquerade) The ESTeem 195E can also be configured to function as a mobile client. The client modes allow the 195E to seamlessly roam between fixed Access Points. These Access Points can either be ESTeem 195E wireless modems configured in one of the three Access Point modes (AP Bridge, AP Router or AP Masquerade –...
Page 19: Access Point Modes
Masquerade). The Access Point mode will provide either a single wireless connection (Figure 6) or overlapping coverage (Figure 7) to create a “canopy” of wireless coverage for 802.11 devices. The ESTeem 195E in AP mode can function as both an Ethernet bridge or router and 802.11 AP simultaneously (Figure 8).
Page 20 CHAPTER 3 EXAMPLE APPLICATIONS Figure 7: Overlapping Access Point Coverage Figure 8: Access Point and Ethernet Bridge Revised: 19 Oct 12 EST P/N AA107E...
Page 21: Programming Examples
Consult the ENC Utility’s User Guide on how the create a new wireless network. Once you have a blank network configuration page (Figure 9), select ESTeem from the menu items to display the drop down menu, then select New>New ESTeem.
Page 22 Figure 11: Main Office ESTeem 195E To change the name of the ESTeem 195E from the WLAN MAC address to “Main Office” (or any other location name) to match the example configuration, Right-Mouse click on the ESTeem icon and select Change>Change Modem ID (Figure 12).
Page 23 (2) ESTeem Model 195E Serial Numbers: E-14000 (Main Office) and E-14001 (Remote Office) Add the two ESTeem Model 195Es to the network using the above procedure. Once both ESTeem 195Es are on the configuration page, create a wireless link by clinking on one of the two connection boxes and dragging a line to the other modem (Figure 13).
Page 24 ESTeem 195E’s, network connections. the status box around the ESTeem‘s will change from yellow to blue. This indicates that the configuration was completed successfully and the ESTeem 195E’s are ready to be installed in the application. Figure 15: Example 2 Layout...
Page 25 195Es for this example and rename by location. Your layout should appear like Figure 16. Move the ESTeem 195E icons on the screen Figure 16: Example 3 Modems to simulate the layout of the diagram. Draw connection lines between the primary wireless links modems in the same order as the network layout (Figure 17).
Page 26 ESTeem>ESTeem Configuration>Send Configuration to All ESTeems. Once the ENC Utility has downloaded the configuration for both ESTeem 195E’s, the status around ESTeem‘s will change from yellow to blue. This indicates that configuration completed successfully the ESTeem 195E’s are ready...
Page 27 ESTeem 195Es for this example and rename by location. Your layout should appear like Figure 18. Move the ESTeem 195E icons on the screen to simulate the layout of the Figure 18: Router Mode Example Modems diagram. Draw connection lines between the wireless links modems in the same order as the network layout (Figure 19).
Page 28 CHAPTER 3 EXAMPLE APPLICATIONS By default, the ENC Utility sets all ESTeem modems in AP Bridge mode. To change the Plant Router ESTeem to AP Router mode, double-click on the icon to bring up the ESTeem Summary window and press the Edit button (Figure 20).
Page 29 E-14001 (Station Router) E-14002 (Station Masquerade) Setting the ESTeem for Mobile Client (station) mode with the ENC Utility is different than the Bridge/Router or Access Point (AP) modes. ESTeem modems configured in as a Mobile Client will not link with a specific fixed modem; but will roam between any 802.11 Access Point with the correct Network Name (SSID) and Encryption.
Page 30 Finish button to return to the configuration page. 10. Verify all ESTeem modems are connected to the same switch as the computer running the ENC Utility and send the configuration to all modems at the same time by selecting ESTeem>ESTeem Configuration>Send Configuration to All ESTeems.
Page 31 CHAPTER 3 EXAMPLE APPLICATIONS Encryption (Figure 27). Revised: 19 Oct 12 3-17 EST P/N AA107E...
Page 32: Router Addressing Examples
CHAPTER 3 EXAMPLE APPLICATIONS ROUTER ADDRESSING EXAMPLES The following are examples of the IP addressing and subnets required for the ESTeem Router modes. Point to Point Access Point Router to Station Router AP Router Station Router Wireless IP Address: 172.16.1.6 Wireless IP Address: 172.16.2.22...
Page 33 Stand-Alone Access Point Router and Single Station Router Computer IP Address = 172.17.1.1 Netmask = 255.255.0.0 Default Route = 172.17.1.6 ESTeem 195E in Access Point Router Mode Ethernet IP Address = 172.17.1.6 Wireless IP Address 172.16.1.6 Netmask = 255.255.0.0 Default Route = 172.17.1.6...
Page 34 Gateway (Route) = 172.16.1.6 Netmask 255.255.0.0 Wireless IP Address 172.16.2.21 Ethernet IP Address ESTeem 195E in 172.19.2.20 Station Router ESTeem 195E in Station Router Mode Gateway(Route) Mode Netmask 255.255.0.0 172.16.1.6 Netmask 255.255.0.0 Wireless IP Address 172.16.2.20 Wireless IP Address Ethernet IP Address Connected Ethernet 172.16.2.22...
Page 35: Esteem Network Configuration (Enc) Utility
The ENC Utility will be used for all wireless network programming in this User’s Manual. For detailed instructions on the use of the ESTeem Network Configuration (ENC) Utility please refer the ENC Utility User’s Guide available on the ESTeem Resource CD or in the application itself.
Page 36 Disk is as simple as using your web browser. All technical documentation, User’s Manuals and the ESTeem Utility Program are available on the disk. 1. Place the ESTeem Utility CD in your CD-ROM drive. The CD will auto load the ESTeem main page Note: If the page does not auto load, open your web browser and set your address line to D:\index.html...
Page 37 Enter an IP address and Subnet Mask for the 195E that matches your network subnet and press the OK button to save this to the ESTeem. You will receive notification that the Configuration was Successful and the 195E will reboot.
Page 38 195’s MAC address and select Open Browser from the menu (Figure 6). If your computer is configured for the same IP subnet at the ESTeem 195 wireless modem, you will be asked to sign in with the Username and Password (Figure 7).
Page 39 When configured for EtherStation mode, the Web Configuration Manger is turned off. To gather information from the 195E on Access Point, link status and received signal strength you will need to install the ESTeem 195E Status Utility. The EtherStation Status Utility version 2.0.0.0 or greater provides a new feature that will automatically program the connected ESTeem 195E to match up with the computer running the software.
Page 40: Setting Local Time 195Eg
UTILITIES & FEATURES SETTING LOCAL TIME The ESTeem Model 195E will be shipped from the factory with the internal real-time clock set to Pacific Time. To change the clock settings to the local time for accurate log file entries: 1. Select Advanced from the top...
Page 41: Configuring Time Server
UTILITIES & FEATURES CONFIGURING TIME SERVER Enabling NTP time synchronization services on the ESTeem 195E will allow usage of time services from upstream services to keep the time on the system accurate. To allow time synchronization, the Model 195E must be configured with the NTP Daemon enabled and the appropriate IP address of the upstream network NTP server.
Page 42 CHAPTER 4 UTILITIES & FEATURES 3. The NTP daemon is enabled by selecting YES for NTP ENABLE (Figure 12). When enabled, the NTP daemon will use time services from upstream services to keep the time on this system accurate. 4. Next, the NTP SERVICE ENABLE should be configured to “YES,” if you want to allow the system to provide NTP service for clients wishing time synchronization (Figure 12).
Page 43: Vlan Operation
Virtual LAN (VLAN) systems are rapidly becoming the desired configuration on larger Ethernet networks. The ESTeem 195E software will allow the Ethernet modems to transparently pass the VLAN packets for these networks. The 195E currently can not be used as a VLAN switch, but will pass VLAN tagged Ethernet packets through the wireless bridge.
Page 44: Igmp Snooping
UTILITIES & FEATURES IGMP SNOOPING Internet Group Management Protocol (IGMP) Snooping allows the ESTeem 195E to operate more efficiently in networks with high Multicast (UDP, etc.) traffic. IGMP Snooping will define the destination for the Multicast traffic and send the data to the correct wireless Ethernet modem, not the entire network. This limiting of Multicast traffic to specific destinations greatly increases the overall network efficiency.
Page 45 Ethernet Bridge Mode (Repeater Peers) When the ESTeem 195E is configured as a repeater peer, all multicast traffic is “wrapped” in a Unicast frame and sent to all other repeater peers. (Figure 14) This operation allows the ESTeem network to receive an acknowledge packet and retransmit the data if the packet is lost during transmission.
Page 46 Ethernet Bridge Mode (Repeater Peers) With IGMP Snooping When the ESTeem 195E is configured as a repeater peer, IGMP Snooping is enabled and the network supports IGMP protocol, the 195E will begin to identify the connected Ethernet devices using Multicast transmissions and report this information to the network.
Page 47 UTILITIES & FEATURES Client Modes When the ESTeem 195E is configured as a mobile client (EtherStation, Station Router or Station Masquerade), there are two configurations that will increase the reliability of Multicast traffic. The first phase is encapsulation of the multicast packets, as described in the Repeater Peer, and the second is IGMP Snooping if the network will support the protocol.
Page 48 Figure 18: Multicast Enable Enabling IGMP Snooping To enable the ESTeem 195E for IGMP Snooping, select Advanced>Bridge Variables and press the Next Button (Figure 19). Select IGMP Snoop to YES, press the Accept Button and then Commit and Reboot. Figure 19: Repeater Peer with IGMP Enabled...
Page 49: Simple Network Management Protocol (Snmp)
SNMP server to view the status of the wireless network while the system is in operation. The following are a list of the Management Information Base (MIB) items that are supported in the ESTeem 195E and their MIB location:...
Page 50 Downloading MIB Tables To download the MIB items listed above and import into your SNMP server, log into any ESTeem 195E and select the About page (Figure 20). Press the Download MIB Files hyperlink on the page and save the files to your computer.
Page 51 CHAPTER 5 WEB CONFIGURATION The ESTeem Model 195E Web Configuration Manager is an internal web server that will allow setup, monitoring and diagnostics of all operating parameters in the Model 195E. The 195E can be configured using any current web browser software such as Internet Explorer, Mozilla, FireFox or Google Chrome®.
Page 52: Web Configuration Manager
CHAPTER 5 WEB CONFIGURATION WEB CONFIGURATION MANAGER SECTIONS The following sections will describe the features in each of the main and sub menu items in the web pages. For step- by-step examples of how to configure the Model 195E in different Modes of Operation, please refer to Chapter 3 – Example Applications.
Page 53: Status Menu
CHAPTER 5 WEB CONFIGURATION Status Menu The Status Menu provides a summary of the current mode of operation, system time, processor usage, internal temperature and status of the communication links to other wireless devices. An example is shown below in Figure 5. Most of the communication troubleshooting is done in this section of the Web Configuration Manager.
Page 54: Web Configuration
CHAPTER 5 WEB CONFIGURATION Associated Station – This section will list all the associated stations that are attached to the Access Point. These could be other Model 195E’s in one of the three Client modes or 802.11 devices. Repeater Peers – This section will list all connected 195E repeater peers by their Wireless MAC address. For detailed information on repeaters, see Chapter 6 –...
Page 55: System Log Screen
System Log Screen The Log Screen is a trouble-shooting tool that shows the current log of Model 195E system messages. See Figure 7. The System Details button will display a more detailed system diagnostics that may be requested by ESTeem technical support.
Page 56: Advanced Configuration Screen
The Advanced screen allows the user to access all configuration parameters. The parameters are grouped based upon their variable. It is recommended that only advanced users of the Model 195E enter this section unless instructed by ESTeem technical support. See Figure 9. Figure 9: Advanced Features Screen Backup Screen The Backup Screen saves the current configuration in the Model 195E to a file on the computer or network.
Page 57: Restore Screen
CHAPTER 5 WEB CONFIGURATION Restore Screen The Restore screen is used to restore the 195E to factory defaults, return to the last saved configuration or to access the configuration files that were backed up to the computer. See Figure 11. Figure 11: Restore Setting Screen Factory Default –...
Page 58: Software Update
CHAPTER 5 WEB CONFIGURATION Software Update Screen The Software Update feature allows the user to update the latest Model 195E operating system software from a file supplied by the factory or the Internet to the Model 195E’s flash memory. To upload from a file on your computer, select Upload via web browser and a file selection window will be displayed.
Page 59: Using Rs-232 Programming Port
Configure your RS-232C port for a Baud Rate to 38,400, Data Bits to 8, Parity to None, Stop Bits to 1 and Handshaking to None. Set the Emulation type to VT100. Once your ESTeem has an IP address, you can attach the ESTeem to your network and use the Web Server for further programming.
Page 60 CHAPTER 6 SERIAL APPLICATIONS To set the IP address in the ESTeem 195E, type the letter “A” and press the Enter key. Enter the value for the IP address, Netmask and default route pressing the Enter key after each entry.
Page 61: Using Rs-232 Data Port
USING THE RS-232 DATA PORT The ESTeem 195E has a serial data port that can provide RS-232 communication between two or more serial devices using the wireless broadband link. The serial data is encapsulated and transferred as a standard Ethernet packet over an operating 195E wireless Ethernet system.
Page 62 CHAPTER 6 SERIAL APPLICATIONS Figure 5: Serial Configuration Screen Data Bits Select the number of data bits on the RS-232 connection to match your serial device. Stop Bits Select the number of stop bits on the RS-232 connection to match your serial device. Parity Select the parity of the RS-232 connection to match your serial device.
Page 63 If you are using multiple ESTeem repeater links to send the serial data to remote locations, the value for the maximum bridge link needs to be increased to a number greater than the longest repeater chain. For example, if you are using four repeater (peer) links to send the serial data between two or more sites the number will need to be five (5) or greater (Figure 4).
Page 64 CHAPTER 6 SERIAL APPLICATIONS Access Point Bridge with Access Point Repeater Bridge with Mode Repeater Mode RS-232 Data RS-232 Data Access Point Remote Site Bridge with Remote PLC Access Point Repeater Bridge with Mode Repeater Mode RS-232 Data NOTE: Remote Site & Repeater Repeater Repeater may be stand- alone or attached to a...
Page 65: Esteem Mesh Network
Ethernet devices. This scenario poses the question, which path will the network select? The ESTeem Mesh Network takes out the guessing games by allowing the user to select and prioritize all communication routes in the system. In our example we would want the primary link to go through Tank B (Repeater) and use the direct link only if this primary link fails.
Page 66: Rapid Spanning Tree Protocol (Rstp)
You can also configure the Mesh networking directly through the web configuration setup (Chapter 5). Figure 3 shows an example repeater peer table from the setup menus. For an ESTeem 195E to communicate with another ESTeem 195E, select Yes must at Enable Repeater Capability. Next, the Wireless LAN (WLAN) MAC address of each Model 195E that will have direct communications must be added to the Repeater Peer List.
Page 67: Spanning Tree Protocols (Stp)
REPEATING FEATURES SPANNING TREE PROTOCOL (STP) The ESTeem Model 195E uses standard Ethernet Spanning Tree Protocol (STP) or Rapid Spanning Tree Protocol (RSTP) to determine the radio routing structure of the wireless network. The primary purpose of STP/RSTP is to make sure that “network loops”...
Page 68: Phases
REPEATING FEATURES STP Phases The following sections describe the process of the STP in the ESTeem Model 195E as how it would happen in the above example. Learning Phase - Once properly configured, each Model 195E will begin to search out the other Model 195E units in radio range that are programmed in the AP Repeater Peer table.
Page 69: Redundant Backup
CHAPTER 7 REPEATING FEATURES site in your AP Repeater application should be the Root Bridge, contact ESTeem Customer Support at 509-735-9092 or e-mail your application to support@esteem.com. The Root Bridge will be selected in one of two ways: the Root Bridge can be manually set (recommended) during the configuration of the Repeater Peer table (Figure 3) or the Root Bridge designation will default to the lowest MAC address of all the Model 195E’s in the network.
Page 70: Chapter 8 - Antenna Setups
195Eg and 195E-lp ANTENNA AND CABLE CONFIGURATIONS (POLE MOUNT) ESTeem offers different types of antennas for both indoor and outdoor configurations. To reduce potential radio interference to other users, the antenna type and its gain should be chosen so that the equivalent isotropically radiated power (e.i.r.p.) is not more than that permitted for successful communication.
Page 71 CHAPTER 8 ANTENNA SETUPS See Warnings. Revised: 19 Oct 12 EST P/N AA107E...
Page 72 A 25-ft. length of RG-8 coax cable or 50-ft. length of ½” Heliax cable are the minimum cable lengths allowed for use with the above antennas (AA20E, AA203ES, AA204ES) when the Model 195Eg is set at Max Power. Listed below are representative cable losses in db/100 ft at the 2.4 GHz frequency range:...
Page 73: Antenna And Cable Configurations
Any other combination of antennas or coax cables is not authorized. ESTeem offers different types of antennas for both indoor and outdoor configurations. This device has been designed to operate with the antennas listed below, and having a maximum gain of 22 dBi. Antennas not included in this list or having a gain greater than 22dBi are strictly prohibited for use with this device.
Page 74 ESTeem offers different types of antennas for both indoor and outdoor configurations. This device has been designed to operate with the antennas listed below, and having a maximum gain of 7 dB. Antennas not included in this list or having a gain greater than 7 dB are strictly prohibited for use with this device.
Page 75 CHAPTER 8 ANTENNA SETUPS 195Ep ANTENNA AND CABLE CONFIGURATIONS ESTeem offers different types of antennas for indoor, outdoor and mobile configurations. Part Number: AA191Ep • Omni-directional, vehicle mount, 5.5dBi gain antenna. • Mobile vehicle mount applications. • The AA191Ep antenna must be installed to provide a...
Page 76: Antenna Diversity
The dual diversity antenna configuration places a physical distance between the antennas where one reflected signal will be out of phase, but the second will be not. The ESTeem Model 195E will sample both antennas and select the best receive signal.
Page 77: Antenna Port Selection
The antenna ports on the Model 195E must be configured for either a single receive antenna (external mount antennas) or dual diversity antenna setup. To access the port configuration open ESTeem Web page using your computer’s Web Browser as per instructions in Chapter 5. Select Advanced from the menu items and Radio Settings- wlan0 device (Figure 1).
Page 78 CHAPTER 8 ANTENNA SETUPS Press the next button and wlan0 configuration menu will be displayed. The receive antenna is configured by selecting the wlan0_dot11CurrentRXAntenna drop down (Figure 3) and selecting the receive antenna. A value of 0 = Dual diversity (Both antenna Ports A & B will be used to receive). A value of 1 = Single receive source (Antenna Port A only).
Page 79 1.25” to a diameter of 2.25” OD. Any mounting structure greater than 2” requires hose clamp strapping run through the Pole Mount Brackets. The mounting kit requires the following assembly: 1. If you purchased an AA195PM mounting kit with your Model 195Eg, the kit will be packed in the same packing box as the ESTeem (Figure 4).
Page 80 Figure 6: Pole Mount Assembly 5. Place the four supplied 10-24 x 1” Phillips Pan Head screws through the mounting holes of the Heat Shield and attach to the top of the ESTeem 195Eg (Figure 7). Figure 7: Heat Shield Attachment...
Page 81 CHAPTER 8 ANTENNA SETUPS 6. Attach the two Pole Mounting Brackets to the ESTeem Model 195Eg with the 10-24 x 1” Phillips Pan Head screws through the top of the heat shield. Reference Figure 8 (Heat Shield removed for detail).
Page 82 10. Plug the CAT-5e Ethernet cable to the Model 195Eg’s Ethernet port and secure the Face Plate Cover with the attached thumb screw. Verify that the weatherproof seal on the Face Plate Cover is sealed against the outer rim of the Model 195Eg.
Page 83 Face Towards The South (North America) Figure 13: Completed AA195PM Mounts Caution: Outdoor mounting of the 195Eg requires the use of weatherproof boots. Improper installation could result in radio failure. Caution: Always mount the 195Eg vertically with the antenna ports on top.
Page 84 Ethernet cable is used to provide the ground connection. Outdoor Ethernet Cable A critical component of this grounding protection system is the ESTeem AA09.1 outdoor, shielded CAT-5E Ethernet cable. This cable provides three, necessary elements; Ethernet data, DC Power over Ethernet (PoE) applications, and a ground from the 195E case to the AA166 surge protector.
Page 85: Fresnel Zone
CHAPTER 8 ANTENNA SETUPS FRESNEL ZONE Figure 15: Fresnel Zone Diagram The Fresnel zone shows the ellipsoid spread of the radio waves around the visual line-of-sight after they leave the antenna (see Figure 15). This area must be clear of obstructions or the signal strength will be reduced due to signal blockage.
Page 86: Appendix Afcc Information
APPENDIX A FCC INFORMATION INFORMATION TO USERS Other Information The ESTeem Model 195E complies with Part 15 of the Model 195Eg FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful Direct Sequence Spread Spectrum Device...
Page 87: Fcc Information
APPENDIX A FCC INFORMATION FEDERAL COMMUNICATIONS COMMISSION FIELD OFFICES ALASKA ILLINOIS NEW YORK 1011 E. Tudor Rd. Chicago Office (CG) New York Office (NY) Rm 240 Box 2955 Park Ridge Office Ctr., Room 306 201 Varick Street, Suite 1151 Anchorage, AK 99510 1550 Northwest Highway New York, NY 10014-4870 Park Ridge, IL 60068-1460...
Page 88: Appendix Binterface Ports
Figure 1: Ethernet Pin Layout A second Ethernet port is included with the ESTeem 195E. This second Ethernet port can be configured to bridge to the primary Ethernet port or configured to communicate on the Wireless or Ethernet side of the 195E in router mode.
Page 89: Configuring Dhcp Server
CONFIGURING DHCP SERVER The ESTeem 195E Ethernet port supports both client and server Dynamic Host Configuration Protocol (DHCP). Figure 2 shows the DHCP host configuration screen that will be shown if DHCP server is selected in the setup screens. Enter the values that match the DHCP configuration for your network.
Page 90: Programming Port Pin-Out
ESTeem cable AA0621 that combines a standard Ethernet patch cable to a 9-pin Female adapter. The serial port on the ESTeem Model 195E can be used to access the configuration menu in the ESTeem for system and network configuration.
Page 91: Appendix C - Radio Configuration
195E FREQUENCIES OF OPERATION In a wireless Ethernet network all of the ESTeem Model 195E’s must be set to the same radio frequency of operation (channel) and bandwidth. The following table shows the channels and corresponding frequencies of operation for each model of ESTeem. The frequency of operation is selectable when configuring the mode of operation of the 195E (reference Chapter 3).
Page 92 It is recommended to use the lowest RF bandwidth and data rate required for your application to increase reliability and number of available frequency channels. Figure 2 shows the available selections. NOTE: All ESTeem radios in the same network MUST be on the same frequency channel and use the same bandwidth selection. Equivalent Wired...
Page 93: Setting Rf Power Level
SETTING RF POWER LEVEL The ESTeem Model 195E peak power is adjustable in output power from the advanced configuration menu. The output power is adjusted on the Advanced Menu>Wireless LAN Settings>Wlan0 Device screen (Figure 4) of the Web Configuration Manager.
Page 94: Average Rf Output Power
The average measurable output power on the ESTeem Model 195E will vary from 20dBm to 30dBm depending upon modulation type and RF data rate. The average power is used when entering the output power level in the ESTeem RF Design program. The...
Page 95 APPENDIX C RADIO CONFIGURATION ESTeem 195Ep RF Data Rate (Mbps) Average Power Modulation Type 33dBm BPSK 33dBm BPSK 33dBm BPSK 33dBm OFDM 33dBm OFDM 33dBm BPSK 32dBm OFDM 32dBm OFDM 31dBm OFDM 31dBm OFDM 28dBm OFDM 28dBm OFDM Revised: 18 Feb 14...
Page 96: Appendix Dsecurity
WPA is server/client relationship from a software driver on a computer’s wireless LAN (WLAN) card to an Access Point. The scope of WPA is limited in use to this configuration only. The ESTeem Model 195E can support WPA Enterprise and PSK as an Access Point, but the level of security on the Bridging layer is configured separately.
Page 97 IEEE governing body to the manufacturer and is the “fingerprint” for all Ethernet devices. Using a combination of both the WPA or 128-Bit WEP encryption and the ACL filter provide the ESTeem an extremely secure wireless networking layer.
Page 98 When the ESTeem Model 195E is configured in either the Access Point Masquerade or the Client Masquerade modes, the wireless modem functions as a network firewall. If access to the wired network is the greatest concern, place the ESTeem in the Masquerade mode and the wireless network will be completely isolated from the wired Ethernet network.
Page 99: Appendix E - Troubleshooting
Status: Summary will be displayed showing the status of all ports and memory in the 195E. Under the Wireless Status heading click on the View Peer Table (Figure 2). The Peer Table will list all other Wifi (195Eg and 195Ea only) or mobile client wireless activity seen by the 195E and how it is classified.
Page 100 APPENDIX E TROUBLESHOOTING Repeater Peers - The Peer Table will display all connected 195Es configured to repeat to this ESTeem by their Wireless (WLAN) MAC address. Received Signal Strength – This is the first of the two numbers listed in the block. This signal strength value is listed in dBm.
Page 101: Viewing Rf Data Rates
Figure 3: Peer Summary Table Once loaded, click on View Peer Rate Control Information. (Figure 4) The value of the Current TX rate is the RF data rate between the two ESTeem Model 195E. Figure 4: Rate Control Information Revised: 19 Oct 12...
Page 102: Signal Strength Vs Data Rates
The factory configuration on the 195E is optimized for distances up to 10 miles. If your application has an RF link with a range greater than 10 miles, you will need to set the maximum range value on both ESTeem 195E’s on this communication link.
Page 103: Troubleshooting Tips
Repeater Route as it moves. For example, if a mobile device such as a crane can communicate directly to another ESTeem and will not loose the link in its travel, the AP Repeater Mode could be used.
Page 104 RS-232 port after configuration in this mode. To monitor the link status, you can use the EtherStation Status program. What IP address do I configure the ESTeem in EtherStation mode? – The Model 195E will not have an IP address in EtherStation mode.
Page 105: 195Eg Specifications
APPENDIX F 195Eg SPECIFICATIONS Model 195Eg Specifications LED Indicators Power On/Off Receiver On/Off Carrier Detect On/Off Transmitter On/Off Link Status On/Off I/O Connectors Ethernet 10/100Base T RJ-45 RS-232C Programming/Data Port RJ-45 Dual Antenna input/Outputs TNC Reverse Female Remote Input Power...
Page 106 APPENDIX F 195Eg SPECIFICATIONS Model 195Eg Case Specifications Revised: 19 Oct 12 APX F-2 EST P/N AA107E...
Page 107: Antenna Specifications
Antenna Envelope: 4.25 in. length by 1.75 in width Weight: .08 lbs. Model AA01S Model: AA20DMEg Applications: Model 195Eg direct case mount Antenna Type: Omni-Directional, Sleeve dipole Frequency: 2400 to 2485 MHz Caution Polarization: Vertical Impedance: 50 ohms Omni-directional antenna...
Page 108 APPENDIX F 195Eg SPECIFICATIONS Antenna Specifications Model No: AA20Eg Caution Antenna Type: Omni Directional, DC Grounded To comply with the FCC Applications: Fixed base exposure compliance Frequency: 2400 to 2500 MHz requirements, a separation distance of at least 20 cm...
Page 109 APPENDIX F 195Eg SPECIFICATIONS Antenna Specifications Model No: AA203Eg Caution Antenna Type: Directional, DC grounded To comply with the FCC Applications: Fixed base. exposure compliance Frequency: 2400 to 2485 MHz requirements, a separation Polarization: Vertical or Horizontal distance of at least 20 cm...
Page 110 Use of the AA204Eg, directional antenna is limited to fixed point-to-point applications only. In accordance with FCC Section 15.247(b)iii, this antenna must be professionally installed. The installer must ensure the system is used exclusively for fixed, point-to-point applications and the ESTeem Model 195Eg is set for 0.25 Watts output power (Power Level = Min).
Page 111 APPENDIX F 195Eg SPECIFICATIONS Antenna Specifications Caution To comply with the FCC Model No: AA20E exposure compliance Antenna Type: Omni Directional, DC Grounded requirements, a separation distance of at least 20 cm Applications: Fixed base must be maintained between Frequency:...
Page 112 APPENDIX F 195Eg SPECIFICATIONS Antenna Specifications Model No: AA203ES Caution Antenna Type: Directional, 6 element yagi, DC grounded To comply with the FCC Applications: Fixed base. exposure compliance Frequency: 2400 to 2483.5 MHz requirements, a separation Polarization: Vertical or Horizonal...
Page 113 APPENDIX F 195Eg SPECIFICATIONS Antenna Specifications Model No: AA204ES Applications: Fixed base mounting Antenna Type: 2.4 GHz ISM, Directional, 16 Element Yagi, DC Grounded Frequency: 2400-2483.5 MHz Caution Polarization: Vertical or Horizontal To comply with the FCC exposure Impedance: 50 ohms...
Page 114: 195Ea Specifications
APPENDIX G 195Ea SPECIFICATIONS Model 195Ea Specifications LED Indicators Power On/Off Receiver On/Off Carrier Detect On/Off Transmitter On/Off Link Status On/Off I/O Connectors Ethernet 10/100Base T RJ-45 RS-232C Programming/Data Port RJ-45 Dual Antenna input/Outputs TNC Reverse Female Remote Input Power Power Over Ethernet Cable Direct Input Power Optional, Header Screw Connector...
Page 115 APPENDIX G 195Ea SPECIFICATIONS Model 195Ea Case Specifications Model AA20DMEg Revised: 18 Feb 14 APX G-2 EST P/N AA107E...
Page 116: Antenna Specifications
APPENDIX G 195Ea SPECIFICATIONS Antenna Specifications Model: AA20DMEa Applications: Model 195Ea direct case mount Antenna Type: Omni-Directional, Sleeve dipole Frequency: 5.735 to 5.835 GHz Caution Polarization: Vertical To comply with the FCC Impedance: 50 ohms exposure compliance Gain: 4.5 dBi (2.5 dBd) requirements, a separation distance of at least 113 cm VSWR: <...
Page 117 APPENDIX G 195Ea SPECIFICATIONS Antenna Specifications Model No: AA205Ea Applications: Fixed base mounting Antenna Type: Directional, Linear Polarized Panel, DC grounded, Integral Bandpass Filter Frequency: 5.725-5.875 GHz Polarization: Vertical or Horizontal Impedance: 50 ohms Gain: 22 dBi (20 dBd) nominal VSWR: <1.5:1 nominal Front to Back Ratio: ≥...
Page 118: 195Ed Specifications
APPENDIX H 195Ed SPECIFICATIONS Model 195Ed Specifications LED Indicators Power On/Off Receiver On/Off Carrier Detect On/Off Transmitter On/Off Link Status On/Off I/O Connectors Ethernet 10/100Base T (Port 1) RJ-45 Female Ethernet 10/100Base T (Port 2) RJ-45 Female RS-232C Port RJ-45 Female (2,400 to 115.2K baud) RS-232C Programming Port (38.4 K baud) RJ-45 Female...
Page 119 APPENDIX H 195Ed SPECIFICATIONS Model 195Ed Case Specifications Revised: 19 Oct 12 APX H-2 EST P/N AA107E...
Page 120: Antenna Specifications
APPENDIX H 195Ed SPECIFICATIONS Antenna Specifications Model No: AA191s Antenna Type: Omni-Directional, Permanent Vehicle Mount Applications: Direct mount Frequency: 896 to 940 MHz Polarization: Vertical Caution Impedance: 50 ohms Omni-directional antenna Gain: 7 dBi (5 dBd) should not be located within VSWR: <...
Page 121 APPENDIX H 195Ed SPECIFICATIONS Antenna Specifications Model No: AA20Es900 Caution Antenna Type: Omni Directional, DC Grounded To comply with the FCC Applications: Fixed base exposure compliance Frequency: 902 to 928 MHz requirements, a separation distance of at least 23 cm Polarization: Vertical must be maintained between...
Page 122 Aluminum Mounting Hardware: Heavy duty U bolts for mounting up to 2.0 in. pipe (included). Antenna Connector: TNC-R Male with 2 ft. pigtail with ESTeem weatherproof boot. Maximum Power Input: 50 Watts Antenna Envelope: 1.1 ft. length by 6 in. width...
Page 123: 195Ep Specifications
APPENDIX I 195Ep SPECIFICATIONS Model 195Ep Specifications LED Indicators Power On/Off Receiver On/Off Carrier Detect On/Off Transmitter On/Off Link Status On/Off I/O Connectors Ethernet 10/100Base T RJ-45 RS-232C Programming Port RJ-45 Dual Antenna input/Outputs TNC Reverse Female Direct Input Power Header Screw Connector Transmiter 4.960 &...
Page 124 APPENDIX I 195Ep SPECIFICATIONS Model 195Ep Case Specifications Revised: 19 Oct 12 APX I-2 EST P/N AA107E...
Page 125: Antenna Specifications
APPENDIX I 195Ep SPECIFICATIONS Antenna Specifications Model No: AA191Ep Antenna Type: Omni-Directional, Vehicle Mount Applications: Mobile Frequency: 4.9-5.0 GHz Polarization: Vertical Caution Impedance: 50 ohms Omni-directional antenna Gain: 5.5 dBi should not be located within VSWR: < 1.5 20 cm of personnel. Front to Back Ratio: Horizontal Beamwidth: Vertical Beamwidth:...
Page 126 APPENDIX I 195Ep SPECIFICATIONS Antenna Specifications Model No: AA204Ep Applications: Fixed base mounting Antenna Type: 4.9 GHz, Directional, DC Grounded, Panel Antenna Frequency: 4.940-4.990 GHz Polarization: Vertical or Horizontal Caution Impedance: 50 ohms To comply with the FCC exposure Gain: 21 dBi (19 dBd) nominal compliance requirements, a VSWR:...
Page 127 APPENDIX I 195Ep SPECIFICATIONS Antenna Specifications Application: Fixed base mounting Antenna Type: Omni-Directional, DC grounded Frequency: 4940-4990 MHz Polarization: Vertical Impedance: 50 ohms Gain: 10 dBi (8 dBd) VSWR: 2:1 maximum Vertical Beamwidth: 8.5 degrees Recommended Mounting Hardware: FB2 Bracket Caution Antenna Connector: N female...
Page 128: Appendix J - 195Eg-Lp Specifications
APPENDIX J 195Eg-lp SPECIFICATIONS Model 195Eg-lp Specifications LED Indicators Power On/Off Receiver On/Off Carrier Detect On/Off Transmitter On/Off Link Status On/Off I/O Connectors Ethernet 10/100Base T RJ-45 RS-232C Programming/Data Port RJ-45 Dual Antenna input/Outputs TNC Reverse Female Remote Input Power...
Page 129 APPENDIX J 195Eg-lp SPECIFICATIONS Model 195Eg Case Specifications Revised: 19 Oct 12 APX J-2 EST P/N AA107E...
Page 130 Antenna Envelope: 4.25 in. length by 1.75 in width Weight: .08 lbs. Model AA01S Model: AA20DMEg Applications: Model 195Eg direct case mount Antenna Type: Omni-Directional, Sleeve dipole Frequency: 2400 to 2485 MHz Caution Polarization: Vertical Impedance: 50 ohms Omni-directional antenna...
Page 131 APPENDIX J 195Eg-lp SPECIFICATIONS Antenna Specifications Model No: AA20Eg Caution Antenna Type: Omni Directional, DC Grounded To comply with the FCC Applications: Fixed base exposure compliance Frequency: 2400 to 2500 MHz requirements, a separation distance of at least 20 cm...
Page 132 APPENDIX J 195Eg-lp SPECIFICATIONS Antenna Specifications Model No: AA203Eg Caution Antenna Type: Directional, DC grounded To comply with the FCC Applications: Fixed base. exposure compliance Frequency: 2400 to 2485 MHz requirements, a separation Polarization: Vertical or Horizontal distance of at least 20 cm...
Page 133 APPENDIX J 195Eg-lp SPECIFICATIONS Antenna Specifications Model No: AA204Eg Applications: Fixed base mounting Antenna Type: 2.4 GHz ISM, Directional, DC Grounded, Parabolic Grid Frequency: 2400-2485 MHz Polarization: Vertical or Horizontal Caution Impedance: 50 ohms To comply with the FCC exposure...
Page 134 APPENDIX J 195Eg-lp SPECIFICATIONS Antenna Specifications Caution To comply with the FCC Model No: AA20E exposure compliance Antenna Type: Omni Directional, DC Grounded requirements, a separation distance of at least 20 cm Applications: Fixed base must be maintained between Frequency:...
Page 135 APPENDIX J 195Eg-lp SPECIFICATIONS Antenna Specifications Model No: AA203ES Caution Antenna Type: Directional, 6 element yagi, DC grounded To comply with the FCC Applications: Fixed base. exposure compliance Frequency: 2400 to 2483.5 MHz requirements, a separation Polarization: Vertical or Horizonal...
Page 136 APPENDIX J 195Eg-lp SPECIFICATIONS Antenna Specifications Model No: AA204ES Applications: Fixed base mounting Antenna Type: 2.4 GHz ISM, Directional, 16 Element Yagi, DC Grounded Frequency: 2400-2483.5 MHz Caution Polarization: Vertical or Horizontal To comply with the FCC exposure Impedance: 50 ohms...

This manual is also suitable for:

195ea 195ed 195ep

ESTeem 195Eg User Manual

CHAPTER 1 - Introduction

CHAPTER 2 - Starting out

CHAPTER 3 - Example Applications

CHAPTER 8 - Antenna Setups

Appendix Afcc Information

Appendix Binterface Ports

APPENDIX C - Radio Configuration

Appendix Dsecurity

APPENDIX E - Troubleshooting

APPENDIX J - 195Eg-Lp Specifications

Quick Links

Troubleshooting

Need help?

Questions and answers

Related Manuals for ESTeem 195Eg

Summary of Contents for ESTeem 195Eg

This manual is also suitable for:

Table of Contents
