ESTeem 195Ea User Manual

Hide thumbs Also See for 195Ea:
Table of Contents

Advertisement

Quick Links

Download this manual
ESTeem MODEL 195Ea
USER'S MANUAL
Manual Revision 1
July 2011
Electronic Systems Technology, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 195Ea and is the answer not in the manual?

Questions and answers

Related Manuals for ESTeem 195Ea

Summary of Contents for ESTeem 195Ea

  • Page 1 ESTeem MODEL 195Ea USER’S MANUAL Manual Revision 1 July 2011 Electronic Systems Technology, Inc.
  • Page 2 ESTeem MODEL 195Ea USER’S MANUAL Manual Revision 1.0 Firmware Version XXX and above July 2011 Prepared by: Date: Eric P. Marske Name: Product Manager Title: Approved by: Date: Tom L. Kirchner Name: President Title:...
  • Page 3 This manual and the firmware described in it are copyrighted by EST, with all rights reserved. Under the copyright laws, this manual or the firmware internal to the ESTeem unit may not be copied, in whole or part, without the written consent of EST. Under the law, copying includes translating into another language.

  • Page 4: Table Of Contents

    Router Modes --------------------------------------------- Mobile Client Modes --------------------------------------------- Access Point Modes --------------------------------------------- Programming Examples Using ESTeem Network Configuration (ENC) Utility --------------------------------------------- Example 1 – Point to Point Ethernet Bridge --------------------------------------------- Example 2 – Point to Point Ethernet Bridge with Repeater --------------------------------------------- 3-10 Example 3 –...
  • Page 5 Using RS-232 Programming Port Using RS-232 Data Port Serial Connections Second Ethernet Port --------------------------------------------- Serial Configuration CHAPTER 7 – Repeating and Mesh Networking ESTeem Mesh Network Configuration --------------------------------------------- Rapid Spanning Tree Protocol (RSTP) Spanning Tree Protocols (STP) Overview --------------------------------------------- Phases...
  • Page 6 Antenna Diversity Antenna Port Selection Assembling the AA195PM Outdoor Pole Mounting Kit 8-11 195E Grounding Procedure 8-12 Fresnel Zone 8-13 Model 195Ea Antenna Configurations APPENDIX A – FCC INFORMATION APPENDIX B – SPECIFICATIONS 195Ea Specifications --------------------------------------------- Case Diagram --------------------------------------------- Antenna Specifications --------------------------------------------- APPENDIX C –...

  • Page 7: Chapter 1 - Introduction

    Figure 1: ESTeem Model 195Ea wireless modem for your application. The ESTeem 195Ea is a very versatile wireless Ethernet networking device. To keep the manual usably short, many of the application descriptions and programming details assume the user has a good working knowledge of the following network concepts: Throughout this User’s Manual are...

  • Page 8: Model 195Ea Configuration Modes

    Access Point Repeater mode to provide overlapping, seamless Ethernet communication for mobile devices. The ESTeem Model 195Ea in Access Point Bridge mode will pass all network traffic between connected devices including global network broadcasts.

  • Page 9: Access Point Repeater

    Ethernet network to devices on the wireless network will be rejected similar to the operation of a “firewall”. The 195Ea will hide all the IP addresses connected on the wireless link. You should use this mode of operation if Model 195Ea is connected directly to the Internet with a static IP address (DSL, T1, etc.) and you want the wireless clients to access the information through the Model 195Ea (Figure 3).

  • Page 10: Serial Applications

    Device, the Model 195Ea will provide wireless mobile access to that device through a canopy of Access Points. The 195Ea will seamless roam under the radio canopy of Access Point and can provide greatly increased range for mobile Ethernet devices such as vehicles, forklifts, cranes, etc (Figures 1-3).

  • Page 11: Chapter 2 - Starting Out

    Determining the correct mode of operation for the ESTeem 195Ea is the first step. Chapter 3 of this User’s Manual details the modes of operation and applications where each would be used.
  • Page 12 Reset Switch Configuration Data Port Ethernet Port Port Status Aux Power Receive 12 VDC Input Transmit Power over (Auxiliary Ethernet LED Connector ) Figure 1: 195Ea Front Panel Overview Figure 2: 195Ea Antenna Overview Revised: 23 Aug 11 EST P/N AA107A...

  • Page 13: Model 195Ea Hardware Configuration

    The following steps should be completed to begin configuration of the ESTeem Model 195Ea: Connect the antenna to the antenna connector on the ESTeem Model 195Ea (Figure 3). For a single antenna use Antenna Port A and connect both if using dual antennas.

  • Page 14: Chapter 3 - Example Applications

    The most commonly used mode of operation with the ESTeem Model 195Ea is the Ethernet bridge mode. The Ethernet bridge mode will connect two or more ESTeem 195Ea’s while passing all network traffic that arrives in both the wireless and connected Ethernet ports; including all global network traffic (Figure 1). This mode will work in most wireless applications of the 195Ea to wirelessly connect two or more remote Ethernet devices or networks.
  • Page 15 CHAPTER 3 EXAMPLE APPLICATIONS Figure 2: Ethernet Bridge with Repeater Figure 3: Multipoint Bridge with Mesh Networking Revised: 6 Sep 11 EST P/N AA107A...

  • Page 16: Router Modes

    Router Modes (AP Router and AP Masquerade) The ESTeem 195Ea can be configured as a network router or network firewall between the Ethernet LAN connection and the wireless network of remote locations. The router modes are used to limit the network traffic from a busy Ethernet network connection to only those specific IP address used on the wireless network (see Figure 4).

  • Page 17: Mobile Client Modes

    Mobile Client Modes (EtherStation, Station Router or Station Masquerade) The ESTeem 195Ea can also be configured to function as a mobile client. The client modes will allow the 195Ea to seamlessly roam between other 195Ea configured as Access Points (AP). These Access Points can be ESTeem 195Ea’s configured in one of the three Access Point modes (AP Bridge, AP Router or AP Masquerade –...

  • Page 18: Programming Examples

    Consult the ENC Utility’s User Guide on how the create a new wireless network. Once you have a blank network configuration page (Figure 6), select , select ESTeem from the menu items to display the drop down menu, then select New>New ESTeem.
  • Page 19 Figure 8: Main Office ESTeem 195Ea To change the name of the ESTeem 195Ea from the WLAN MAC address to “Main Office” (or any other location name) to match the example configuration, Right-Mouse click on the ESTeem icon and select Change>Change Modem ID (Figure 9).
  • Page 20 (2) ESTeem Model 195Ea Serial Numbers: E-14000 (Main Office) and E-14001 (Remote Office) Add the two ESTeem Model 195Eas to the network using the above procedure. Once both ESTeem 195Eas are on the configuration page, create a wireless link by clinking on one of the two connection boxes and dragging a line to the other modem (Figure 10).
  • Page 21 ESTeem 195Ea’s, network connections. the status box around the ESTeem‘s will change from yellow to blue. This indicates that the configuration was completed successfully and the ESTeem 195Ea’s are ready to be installed in the application. Figure 13: Example 2 Layout...
  • Page 22 195Eas for this example and rename by location. Your layout should appear like Figure 14. Move the ESTeem 195Ea icons on the screen Figure 14: Example 3 Modems to simulate the layout of the diagram. Draw connection lines between the primary wireless links modems in the same order as the network layout (Figure 15).
  • Page 23 ESTeem>ESTeem Configuration>Send Configuration to All ESTeems. Once the ENC Utility has downloaded the configuration for both ESTeem 195Ea’s, the status around ESTeem‘s will change from yellow to blue. This indicates that configuration completed successfully and the ESTeem 195Ea’s are ready to...
  • Page 24 ESTeem 195Eas for this example and rename by location. Your layout should appear like Figure 18. Move the ESTeem 195Ea icons on the screen to simulate the layout of the diagram. Draw connection lines between Figure 18: Router Mode Example Modems the wireless links modems in the same order as the network layout (Figure 19).
  • Page 25 CHAPTER 3 EXAMPLE APPLICATIONS By default, the ENC Utility sets all ESTeem modems in AP Bridge mode. To change the Plant Router ESTeem to AP Router mode, double-click on the icon to bring up the ESTeem Summary window and press the Edit button (Figure 20).
  • Page 26 E-14001 (Station Router) E-14002 (Station Masquerade) Setting the ESTeem for Mobile Client (station) mode with the ENC Utility is different than the Bridge/Router or Access Point (AP) modes. ESTeem modems configured in as a Mobile Client will not link with a specific fixed modem; but will roam between any 802.11 Access Point with the correct Network Name (SSID) and Encryption.
  • Page 27 Finish button to return to the configuration page. 10. Verify all ESTeem modems are connected to the same switch as the computer running the ENC Utility and send the configuration to all modems at the same time by selecting ESTeem>ESTeem Configuration>Send Configuration to All ESTeems.

  • Page 28: Router Addressing Examples

    CHAPTER 3 EXAMPLE APPLICATIONS ROUTER ADDRESSING EXAMPLES The following are examples of the IP addressing and subnets required for the ESTeem Router modes. Point to Point Access Point Router to Station Router AP Router Station Router Wireless IP Address: 172.16.1.6 Wireless IP Address: 172.16.2.22...
  • Page 29 Stand-Alone Access Point Router and Single Station Router Computer IP Address = 172.17.1.1 Netmask = 255.255.0.0 Default Route = 172.17.1.6 ESTeem 195Ea in Access Point Router Mode Ethernet IP Address = 172.17.1.6 Wireless IP Address 172.16.1.6 Netmask = 255.255.0.0 Default Route = 172.17.1.6...
  • Page 30 Netmask 255.255.0.0 Wireless IP Address 172.16.2.21 Ethernet IP Address ESTeem 195Ea in 172.19.2.20 Station Router Gateway(Route) ESTeem 195Ea in Station Router Mode Mode 172.16.1.6 Netmask 255.255.0.0 Netmask 255.255.0.0 Wireless IP Address 172.16.2.20 Wireless IP Address Ethernet IP Address Connected Ethernet 172.16.2.22...

  • Page 31: Esteem Network Configuration (Enc) Utility

    ESTeem Model 195E wireless Ethernet network. The ENC Utility will allow graphical, point-and-click configuration of your network routing, then configure each ESTeem wireless modem for the network as designed (Figure 1). The ENC Utility will eliminate the need to program or update each ESTeem wireless modem individually. The ENC Utility can send all wireless modem configuration changes simultaneously to a new or existing network.
  • Page 32 ESTeem Utility Program are available on the disk. 1. Place the ESTeem Utility CD in your CD-ROM drive. The CD will auto load the ESTeem main page Note: If the page does not auto load, open your web browser and set your address line to D:\index.html (Where D: is the drive letter for your CD-ROM drive).
  • Page 33 5. Double-click on the 195Ea you want to program and the Configure IP Address window will be displayed (Figure 5). Enter an IP address and Subnet Mask for the 195Ea that matches your network subnet and press the OK button to save this to the ESTeem.
  • Page 34 195’s MAC address and select Open Browser from the menu (Figure 6). If your computer is configured for the same IP subnet at the ESTeem 195 wireless modem, you will be asked to sign in with the Username and Password (Figure 7).
  • Page 35 3. Double click on the 195EStatusSetup.exe file listed in the window to install the program. 4. Connect the Model 195Ea to your computer either directly to the Ethernet card or through a Switch using a CAT-5e Ethernet cable. The Ethernet port on the 195Ea supports Auto-Negotiation so either a patch cable or crossover cable will work.

  • Page 36: Setting Local Time

    UTILITIES & FEATURES SETTING LOCAL TIME The ESTeem Model 195Ea will be shipped from the factory with the internal real-time clock set to Pacific Time. To change the clock settings to the local time for accurate log file entries: 1. Select Advanced from the top...

  • Page 37: Configuring Time Server

    UTILITIES & FEATURES CONFIGURING TIME SERVER Enabling NTP time synchronization services on the ESTeem 195Ea will allow usage of time services from upstream services to keep the time on the system accurate. To allow time synchronization, the Model 195Ea must be configured with the NTP Daemon enabled and the appropriate IP address of the upstream network NTP server.
  • Page 38 CHAPTER 4 UTILITIES & FEATURES 3. The NTP daemon is enabled by selecting YES for NTP ENABLE (Figure 12). When enabled, the NTP daemon will use time services from upstream services to keep the time on this system accurate. 4. Next, the NTP SERVICE ENABLE should be configured to “YES,” if you want to allow the system to provide NTP service for clients wishing time synchronization (Figure 12).

  • Page 39: Vlan Operation

    Virtual LAN (VLAN) systems are rapidly becoming the desired configuration on larger Ethernet networks. The ESTeem 195Ea software will allow the Ethernet modems to transparently pass the VLAN packets for these networks. The 195Ea currently can not be used as a VLAN switch, but will pass VLAN tagged Ethernet packets through the wireless bridge.

  • Page 40: Igmp Snooping

    Ethernet Bridge and mobile devices communicating to these fixed points. The fixed point Ethernet bridge communication in the 195Ea is through Repeater Peer links, while the mobile communication is from the Client modes (EtherStation, Station Router and Station Masquerade) to the Access Points (Fixed Locations) in the network.
  • Page 41 UTILITIES & FEATURES When the ESTeem 195Ea is configured as a repeater peer, all multicast traffic is “wrapped” in a Unicast frame and sent to all other repeater peers. (Figure 14) This operation allows the ESTeem network to receive an acknowledge packet and retransmit the data if the packet is lost during transmission.
  • Page 42 Ethernet Bridge Mode (Repeater Peers) With IGMP Snooping When the ESTeem 195Ea is configured as a repeater peer, IGMP Snooping is enabled and the network supports IGMP protocol, the 195Ea will begin to identify the connected Ethernet devices using Multicast transmissions and report this information to the network.
  • Page 43 UTILITIES & FEATURES Client Modes When the ESTeem 195Ea is configured as a mobile client (EtherStation, Station Router or Station Masquerade), there are two configurations that will increase the reliability of Multicast traffic. The first phase is encapsulation of the multicast packets, as described in the Repeater Peer, and the second is IGMP Snooping if the network will support the protocol.
  • Page 44 Figure 18: Multicast Enable Enabling IGMP Snooping To enable the ESTeem 195Ea for IGMP Snooping, select Advanced>Bridge Variables and press the Next Button (Figure 19). Select IGMP Snoop to YES, press the Accept Button and then Commit and Reboot. Figure 19: Repeater Peer with IGMP Enabled...

  • Page 45: Simple Network Management Protocol (Snmp)

    SNMP server to view the status of the wireless network while the system is in operation. The following are a list of the Management Information Base (MIB) items that are supported in the ESTeem 195Ea and their MIB location:...
  • Page 46 Downloading MIB Tables To download the MIB items listed above and import into your SNMP server, log into any ESTeem 195Ea and select the About page (Figure 20). Press the Download MIB Files hyperlink on the page and save the files to your computer.
  • Page 47 (<Enter>).  Note: All characters are lower case. 5. After Log-in the next screen displayed will be the Model 195Ea Top Menu page (Figure 2). This example screen shows the Top Menu screen. Note: Throughout the Configuration Manager are Help Screens that can be accessed for further information on each item.

  • Page 48: Web Configuration Manager

    Model 195Ea and allow changing of the default password. This page will also display the Modem ID field that can be used to easily identify the 195Ea you are programming. This Modem ID field can be set to any text combination for example, location name, GPS coordinates or addresses.

  • Page 49: Status Menu

    Peer Status Table The Peer Status submenu lists the connected wireless devices (Model 195Ea’s), their signal strength, data rate and time of last packet sent. Press the View Peer Table link and Repeater Peer Status Table will be displayed (Figure 6).
  • Page 50 Chapter 6 – Repeating Features. Access Points – This section will list all other 195Ea Access Points that are sharing the operating channel (frequency) of the 195Ea. You can also note that the Repeater Peers listed above are also included in this list.

  • Page 51: System Log Screen

    System Log Screen The Log Screen is a trouble-shooting tool that shows the current log of Model 195Ea system messages. See Figure 7. The System Details button will display a more detailed system diagnostics that may be requested by ESTeem technical support.

  • Page 52: Advanced Configuration Screen

    Figure 9: Advanced Features Screen Backup Screen The Backup Screen saves the current configuration in the Model 195Ea to a file on the computer or network. See Figure 10. Pressing the Backup Button will create a configuration file that can be saved to the computer. This saved file can then be later opened, if necessary, by the Restore menu to quickly replace a Model 195Ea with a spare modem.

  • Page 53: Restore Screen

    WEB CONFIGURATION Restore Screen The Restore screen is used to restore the 195Ea to factory defaults, return to the last saved configuration or to access the configuration files that were backed up to the computer. See Figure 11. Figure 11: Restore Setting Screen Factory Default –...

  • Page 54: Software Update

    The Software Update feature allows the user to update the latest Model 195Ea operating system software from a file supplied by the factory or the Internet to the Model 195Ea’s flash memory. To upload from a file on your computer, select Upload via web browser and a file selection window will be displayed.

  • Page 55: Using Rs-232 Programming Port

    5. Press the Enter key and you will be at the Configuration Menu 195Ea login prompt. See Figure 1. 6. To enter the Model 195Ea Main Menu you will need to log into the system with a login name and password.
  • Page 56 Note: All characters are lower case. 10. To set the IP address in the ESTeem 195Ea, type the letter “A” and press the Enter key. Enter the value for the IP address, Netmask and default route pressing the Enter key after each entry.

  • Page 57: Using Rs-232 Data Port

    Ethernet and serial applications simultaneously. A possible application would be installation of the 195Ea in an existing serial based network that was looking for future upgrade to an Ethernet based system. Another would be using the high-bandwidth Ethernet connections to provide a...
  • Page 58 Figure 6: Serial Configuration Screen Configuration of the serial port is completed during the standard setup of the 195Ea. After completion of the Repeater Peer configuration screen, the Serial Port Setup screen (Figure 6) will be displayed. Each section in the Serial Port...
  • Page 59 SERIAL APPLICATIONS Mode of Operation There are two distinct modes of operation for the serial port in the 195Ea. The Redirector mode will provide two-way serial communication between two or more serial devices, while the Terminal Server mode will allow serial communication to a specific remote site by connecting through telnet or SSH.
  • Page 60 If you are using multiple ESTeem repeater links to send the serial data to remote locations, the value for the maximum bridge link needs to be increased to a number greater than the longest repeater chain. For example, if you are using four repeater (peer) links to send the serial data between two or more sites the number will need to be five (5) or greater (Figure 4).

  • Page 61: Esteem Mesh Network

    When programmed in any of the three Access Point (AP) Repeater Modes, the Model 195Ea will create a wireless network with other Model 195Ea units in radio range that are programmed in the AP Repeater Peer table during setup. This feature adds the increased functionality of repeaters to the typical Ethernet Bridge configuration.

  • Page 62: Rapid Spanning Tree Protocol (Rstp)

    This RSTP functions the same as standard Spanning Tree Protocol (STP) listed below, but the network recovery is three times faster. If the 195Ea is used in a network that has any older STP only modems, the entire network will be STP.
  • Page 63 SPANNING TREE PROTOCOL The ESTeem Model 195Ea uses standard Ethernet Rapid Spanning Tree Protocol (RSTP) to determine the radio routing structure of the wireless network. The primary purpose of RSTP is to make sure that “network loops” are not created. A network loop is having two communication paths to the same destination where the remote device would receive the same data multiple times.

  • Page 64: Root Bridge

    If more than one communication path to the Root Bridge is found, the 195Ea must determine which route to take based upon the lowest Path Length. The default path length to all links in the 195Ea network is 1. If the Path Lengths are equal then the lowest MAC address will determine the priority route.

  • Page 65: Redundant Backup

    Model 195Ea’s are installed at the same location (Figure 7). If two Model 195Ea’s are connected to the same switch, one of the Model 195Ea’s will be Blocked when the Spanning Tree Protocol is completed.
  • Page 66 This radio transmitter (ESTeem 195Ea - 2163A-195EA) has been approved by Industry Canada to operate with the antenna types listed above with the maximum permissible gain and required antenna impedance for each antenna type indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.
  • Page 67 ASSEMBLING THE AA195PM TWO HOLE OUTDOOR POLE MOUNTING KIT The AA195PM mounting kit contains everything required for pole mounting and weatherproofing the ESTeem Model 195E for outdoor installations. The 195E with AA195PM mounting kit can be directly mounted to a round pole from 1.25” to a diameter of 2.25”...
  • Page 68 Figure 3: Pole Mount Assembly Place the four supplied 10-24 x 1” Phillips Pan Head screws through the mounting holes of the Heat Shield and attach to the to the top of the ESTeem 195E (Figure 4). Figure 4: Heat Shield Attachment...
  • Page 69 CHAPTER 8 ANTENNA SETUPS Attach the two Pole Mounting Brackets to the ESTeem Model 195E with the 10-24 x 1” Phillips Pan Head screws through the Figure 5: Pole Mount Connection to Case (Heat Shield Removed for Detail) top of the heat shield. Reference Figure 5 (Heat Shield removed for detail).
  • Page 70 Verify that the weatherproof seal on the Face Plate Cover is sealed against the outer rim of the Model 195E. Reference Figure 9. Figure 9: Face Plate Cover Installed on ESTeem 11. Attach the antenna connector boots as show in Figure 10 for either dual attached antennas or external antennas. You are now...
  • Page 71 CHAPTER 8 ANTENNA SETUPS EST Approved Direct Mount Antenna Only EST Approved External Direct Mount Antenna With Factory Antenna Boots Installed Boot Port A Port B Weather Proof Boot NOTE: Remove Plastic Connector Cover Before Installation Face Towards The South (North America) Figure 10: Completed AA195PM Mounts Caution: Outdoor mounting of the 195E requires the use of weatherproof boots.
  • Page 72 Outdoor Ethernet Cable A critical component of this grounding protection system is the ESTeem AA09.1 outdoor, shielded CAT-5E Ethernet cable. This cable provides three, necessary elements; Ethernet data, DC Power over Ethernet (PoE) applications, and a ground from the 195E case to the AA166 surge protector.
  • Page 73 CHAPTER 8 ANTENNA SETUPS Caution: Always mount the 195Ea vertically with the antenna ports on top. Revised: 27 Jan 12 EST P/N AA107A...
  • Page 74 CHAPTER 8 ANTENNA SETUPS Caution: Always mount the 195Ea vertically with the antenna ports on top. Revised: 27 Jan 12 EST P/N AA107A...

  • Page 75: Fresnel Zone

    CHAPTER 8 ANTENNA SETUPS FRESNEL ZONE The Fresnel zone shows the ellipsoid spread of the radio waves around the visual line-of-sight after they leave the antenna (see figure above). This area must be clear of obstructions or the signal strength will be reduced due to signal blockage. Typically, 20% Fresnel Zone blockage introduces little signal loss to the link.
  • Page 76 CHAPTER 8 ANTENNA SETUPS Caution: Always mount the 195Es vertically with the antenna ports on top. Revised: 17 Jan 12 8-11 EST P/N AA107A...
  • Page 77 CHAPTER 8 ANTENNA SETUPS FRESNEL ZONE The Fresnel zone shows the ellipsoid spread of the radio waves around the visual line-of-sight after they leave the antenna (see figure above). This area must be clear of obstructions or the signal strength will be reduced due to signal blockage. Typically, 20% Fresnel Zone blockage introduces little signal loss to the link.

  • Page 78: Appendix Afcc Information

    APPENDIX A FCC INFORMATION INFORMATION TO USERS Other Information The ESTeem Model 195Ea complies with Part 15 of the Model 195Ea FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful OFDM Spread Spectrum Device...
  • Page 79 APPENDIX A FCC INFORMATION FEDERAL COMMUNICATIONS COMMISSION FIELD OFFICES ALASKA ILLINOIS NEW YORK 1011 E. Tudor Rd. Chicago Office (CG) New York Office (NY) Rm 240 Box 2955 Park Ridge Office Ctr., Room 306 201 Varick Street, Suite 1151 Anchorage, AK 99510 1550 Northwest Highway New York, NY 10014-4870 Park Ridge, IL 60068-1460...

  • Page 80: Appendix Bspecifications

    APPENDIX B SPECIFICATIONS Model 195Ea Specifications LED Indicators Power On/Off Receiver On/Off Carrier Detect On/Off Transmitter On/Off Link Status On/Off I/O Connectors Ethernet 10/100Base T RJ-45 RS-232C Programming/Data Port RJ-45 Dual Antenna input/Outputs TNC Reverse Female Remote Input Power Power Over Ethernet Cable...
  • Page 81 APPENDIX B SPECIFICATIONS Model 195Ea Case Specifications Model AA20DMEg Revised: 17 Jan 12 APX B-2 EST P/N AA107A...

  • Page 82: Antenna Specifications

    APPENDIX B SPECIFICATIONS Antenna Specifications Model: AA20DMEa Applications: Model 195Ea direct case mount Warning Omni-directional antenna Antenna Type: Omni-Directional, Sleeve dipole should not be located within Frequency: 5.735 to 5.835 GHz 23 cm of personnel Polarization: Vertical Impedance: 50 ohms Gain: 4.5 dBi (2.5 dBd)
  • Page 83 APPENDIX B SPECIFICATIONS Antenna Specifications Model No: AA205Ea Applications: Fixed base mounting Antenna Type: Directional, Linear Polarized Panel, DC grounded, Integral Bandpass Filter Frequency: 5.725-5.875 GHz Polarization: Vertical or Horizontal Impedance: 50 ohms Gain: 22 dBi (20 dBd) nominal VSWR: <1.5:1 nominal Front to Back Ratio: ≥...

  • Page 84: Appendix Cinterface Ports

    CAT-5E grade Ethernet cable. The port is compatible with TIA/EIA-568B cable configuration (Figure 1). Figure 1: Ethernet Pin Layout A second Ethernet port will be included in the 195Ea and can be used in Bridge Mode (HUB) or as a router. Revised: 9 Sep 11...

  • Page 85: Configuring Dhcp Server

    CONFIGURING DHCP SERVER The ESTeem 195Ea Ethernet port supports both client and server Dynamic Host Configuration Protocol (DHCP). Figure 2 shows the DHCP host configuration screen that will be shown if DHCP server is selected in the setup screens. Enter the values that match the DHCP configuration for your network.

  • Page 86: Rs-232 Programming Port Pin-Out

    The ESTeem Model 195Ea has an RS-232C interface in a Data Port RJ-45 connector on the front panel that can be installed as an option . To interface the 195Ea to the serial port on the computer, you need serial cable with the following pin-out: ESTeem Model AA0621...

  • Page 87: Appendix Dradio Configuration

    RF COMMUNICATIONS DATA RATE The RF data rate of the Model 195Ea can be programmed for operation at 6, 9, 11, 12, 18, 24, 36, 48, or 54 Mbps. The RF data rate can be set for a fixed rate or a specific range that is dynamically scaled by the Model 195Ea from monitoring the received signal quality.
  • Page 88 APPENDIX D RADIO CONFIGURATION Max (Maximum) 1 Watt Hi (High) 700 mw Lo (Low) 500 mw Min (Minimum) 250 mw Figure 3: Advanced Global Variables Figure 4: Power Level Settings Revised: 6 Sep 11 APX D-2 EST P/N AA107A...

  • Page 89: Average Rf Output Power

    The average measurable output power on the ESTeem Model 195Ea will vary from 24dBm to 30dBm depending upon modulation type and RF data rate. The average power is used when entering the output power level in the ESTeem RF Design program. The...

  • Page 90: Appendix Esecurity

    WPA is server/client relationship from a software driver on a computer’s wireless LAN (WLAN) card to an Access Point. The scope of WPA is limited in use to this configuration only. The ESTeem Model 195Ea can support WPA Enterprise and PSK as an Access Point, but the level of security on the Bridging layer is configured separately.
  • Page 91 IEEE governing body to the manufacturer and is the “fingerprint” for all Ethernet devices. Using a combination of both the WPA or 128-Bit WEP encryption and the ACL filter provide the ESTeem an extremely secure wireless networking layer.
  • Page 92 When the ESTeem Model 195Ea is configured in either the Access Point Masquerade or the Client Masquerade modes, the wireless modem will function as a network firewall. If access to the wired network is the greatest concern, place the ESTeem in the Masquerade mode and the wireless network will be completely isolated from the wired Ethernet network.

  • Page 93: Appendix F - Troubleshooting

    Status: Summary will be displayed showing the status of all ports and memory in the 195Ea. Under the Wireless Status heading click on the View Peer Table (Figure 2). The Peer Table will list all other wireless activity seen by the 195Ea and how it is classified.

  • Page 94: Viewing Rf Data Rates

    “stale” data. Current Data Rate – This is the current speed the last data packet received by the Model 195Ea. This may not be the data rate between the radio modems. Note that the speed is listed in kbps, so that 11000 kbps is equal to 11 Mbps.

  • Page 95: Signal Strength Vs Data Rates

    TROUBLESHOOTING Figure 4: Rate Control Information The value of the Current TX rate is the RF data rate between the two ESTeem Model 195Ea. SIGNAL STRENGTH VS DATA RATE The following chart will show the average signal strength required to maintain a data rate. Please note that the data rates listed here can be greatly effected by overall activity on the radio channel and the total background noise.
  • Page 96 LONG RANGE POINT TO POINT APPLICATIONS The factory configuration on the 195Ea is optimized for distances up to 10 miles. If your application has an RF link with a range greater than 10 miles, you will need to set the maximum range value on both ESTeem 195Ea’s on this communication link. To access the Maximum Distance value select Advanced from the top Menu then Wireless LAN Settings>wlan0 device and press...

  • Page 97: Troubleshooting Tips

    ESTeem Web site (www.esteem.com) under the Model 195Ea product page. How and when do I update the Model 195Ea firmware? - You should only update the Model 195Ea firmware if you are having a specific problem and it is recommended that you do so by ESTeem Customer Support personnel. All the update instructions and files are located on the ESTeem FTP site at the following address: ftp://www.esteem.com/195Ea...
  • Page 98 EtherStation How do I access the Model 195Ea web page in EtherStation Mode? The Model 195Ea does not have an active web browser when configured in EtherStation mode. You must access the ESTeem with the ESTeem Discovery Program or through the RS-232 port after configuration in this mode.
