ESTeem MODEL 195Eg
USER'S MANUAL
Manual Revision 1.0
June 2004
Electronic Systems Technology, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 195Eg and is the answer not in the manual?

Questions and answers

Related Manuals for ESTeem 195Eg

Summary of Contents for ESTeem 195Eg

  • Page 1 ESTeem MODEL 195Eg USER’S MANUAL Manual Revision 1.0 June 2004 Electronic Systems Technology, Inc.
  • Page 2 ESTeem MODEL 195Eg USER’S MANUAL Manual Revision 1.0 Firmware Version 3.3.0 and above June 2004 Prepared by: Date: Name: Eric P. Marske Title: Manager Customer Support Approved by: Date: Name: Tom L. Kirchner Title: President...
  • Page 3 ADDITIONAL SERVICE: If EST releases an improvement update to firmware internal to the ESTeem unit during the 90 day period after the unit was purchased by the first user/customer, EST will update the applicable unit with the revised version at no charge other than for UPS handling and shipping to and...

  • Page 4: Table Of Contents

    --------------------------------------------- Figure 3: Access Point Repeater Mode Diagram --------------------------------------------- CHAPTER 2 – STARTING OUT Model 195Eg Hardware Layout Figure 1: Model 195Eg Hardware Layout Diagram --------------------------------------------- Model 195Eg Configuration Figure 2: Model 195Eg Front Panel Description --------------------------------------------- Figure 3: RS-232 Port Log-in Screen...
  • Page 5 --------------------------------------------- CHAPTER 6 – ANTENNA SETUPS Antenna and Cable Configurations Coaxial Cable Attenuation Model 195Eg Series with Direct Mount Dual Diversity Antennas Model 195Eg Series with External Mount Antenna Fresnel Zone APPENDIX A – FCC INFORMATION APPENDIX B – SPECIFICATIONS...

  • Page 6: Chapter 1 - Introduction

    Access Point Bridge Mode. When the Model 195Eg is configured as an Access Point it will provide a wireless bridge from a hardwired Local Area Network (LAN) to laptops, office computers, Personal Digital Assistants (PDA’s), video cameras, PLC’s, etc.

  • Page 7: Figure 3: Access Point Repeater Mode Diagram ---------------------------------------------

    802.11g Access Point. This mode would be used where multiple Ethernet devices will be connected to a single Model 195Eg in a mobile application and the IP addresses for each device will be visible on the LAN connected to the Access Point.

  • Page 8: Chapter 2 - Starting Out

    Hyper Terminal. Configure your RS-232C port for a Baud Rate to 38,400, Data Bits to 8, Parity to None, Stop Bits to 1 and Handshaking to None. Once your ESTeem has an IP address, you can attach the ESTeem to your network and use the Web Server for further programming.

  • Page 9: Model 195Eg Configuration

    Once the ESTeem boot sequence is complete (approximately 1 minute) you will receive this message: “Please press Enter to active this console.” If you don’t see this message press the Reset button on t he front panel of the Model 195Eg and/or check the programming of your RS-232 port.

  • Page 10: Figure 3: Rs-232 Port Log-In Screen ---------------------------------------------

    9. If this is not the first time configuration of the Model 195Eg, see your network systems administrator for the password. 10. At the 195Eg login prompt type admin for the login name and press the Enter key (<Enter>). The login name is defined at the factory and is not changeable by the user.

  • Page 11: Figure 4: Rs-232 Welcome Screen ---------------------------------------------

    CHAPTER 2 STARTING OUT 12. The ESTeem Configuration Welcome Screen (Figure 4) will now be displayed. Note: The configuration menu will function the same as the Web Configuration Manager, but requires moving the arrows to change fields Figure 4: RS-232 Welcome Screen...

  • Page 12: Figure 5: Setup Ethernet Only Screen ---------------------------------------------

    13. Select SETUP and ETHERNET ONLY. You will see the screen in Figure 5. Program the basic operating parameters such as assigning the Model 195Eg an IP Address, IP Net Mask, Gateway IP Address, Domain Name, or DNS IP Address. When you have completed entering the basic operating parameters as required for your application, answer Yes, to save your changes to flash memory.

  • Page 13: Figure 6: Commit Changes Screen ---------------------------------------------

    STARTING OUT 14. After the basic parameters have been entered into the Model 195Eg you will need to commit the commands to the Model 195Eg (Figure 6). The changes will be saved to flash memory. You can use the higher level programming features in the ESTeem Web Configuration Manager to configure the unit for your application.

  • Page 14: Chapter 3 - Web Configuration

    Switch. Figure 2 shows a typical hardware configuration if you are accessing the ESTeem Web page from a computer interfaced directly to the Model 195Eg Ethernet port. 1. Connect the antenna/s to the antenna connector on the Model 195Eg. Plug the Model AA175 power...

  • Page 15: Logging On To The Esteem Web Page

    • The factory default Password is also admin. Enter admin for the Password and press the Enter key (<Enter>). • Note: All characters are lower case. 5. After Log-in the next screen displayed will be the Model 195Eg Top Menu page (Figure 4). This example screen shows the Top Menu screen.

  • Page 16: Status Menu Screens

    An example is shown below in Figure 5: Figure 5: Status Screen SYSTEM LOG SCREEN The Log Screen is a trouble-shooting tool that shows the current log of Model 195Eg system messages. See Figure 6. Figure 6: System Log Screen Revised: 2 Jul 04...

  • Page 17: Figure 7: Setup Screen ---------------------------------------------

    CHAPTER 3 WEB CONFIGURATION SETUP SCREEN The Setup screen allows the step-by-step configuration of the Model 195Eg. Please see Chapter 4 for complete description on System Configuration. See Figure 7. Figure 7: Setup Screen ADVANCED CONFIGURATION SCREEN The Advanced screen allows the user to access all configuration parameters. The parameters are grouped based upon their variable.

  • Page 18: Figure 9: Backup Screen ---------------------------------------------

    CHAPTER 3 WEB CONFIGURATION BACKUP SCREEN The Backup Screen saves the current configuration in the Model 195Eg to a file on the computer. See Figure 9. Figure 9: Backup Screen RESTORE SCREEN The Restore screen is used to access the configuration files that were backed up to the computer. See Figure 10.

  • Page 19: Figure 11: Software Update Screen ---------------------------------------------

    WEB CONFIGURATION SOFTWARE UPDATE SCREEN The Software Update feature allows the user to update the latest Model 195Eg operating system software from the factory via the Ethernet port to the Model 195Eg’s flash memory. See Figure 11. Figure 11: Software Update Screen SYSTEM REBOOT SCREEN The Reboot Password screen allows the user to reset the Model 195Eg.
