SECTION 6
[FRONT UNIT]
REF. NO. ORDER NO.
DS1 5080000450 SLU2LC1EX5B-TH
ME1 5510000490 Meter ME-41
EP1 6910011090 Sensor unit RMS20-250-201-P
EP2 6450001230 Plate HLJ0999-01-480
EP3 6450001230 Plate HLJ0999-01-480
EP4 6910012500 Unit board TFD50W40-A
MP1 8210018221 1876 front panel (C)-1
MP2 8010016722 1876 sub chassis-2
MP3 8930041380 1876 window plate
MP4 8930056110 1876 power button (A)
MP5 8930050370 1876 4-key (A)
MP6 8930056090 1876 key board (B)
MP7 8930056100 1876 7-key (B)
MP8 8930050380 1876 5-key (A)
MP9 8930056080 1876 10-key (B)
MP10 8930041280 1876 2-key
MP11 8610010720 Knob N273
MP12 8610010260 Knob N252
MP13 8610010270 Knob N253
MP14 8610010650 Knob N268 assembly
MP19 8310052240 2495 A-name plate
MP20 8930041060 1876 brake plate
MP21 8930027470 1296 brake pad
Screw PH BT M3 × 8 NI-ZU
MP23 8810008660
Screw PH BT M2 × 8 NI-ZU
MP24 8810008760
Screw PH BT M2 × 8 NI-ZU
MP25 8810008760
Screw PH BT M2 × 6 ZK
MP26 8810009560
Screw PH BT M2 × 6 ZK
MP27 8810009560
MP29 8820000770 1296 screw
Screw PH BT M3 × 18 NI-ZU
MP30 8810009390
Screw PH BT M2 × 8 NI-ZU
MP40 8810008760
Screw PH BT M2 × 8 NI-ZU
MP41 8810008760
Screw PH BT M2.6 × 6 NI-ZU
MP49 8810008200
Screw PH B0 M2.6 × 14 ZK
MP50 8810007300
MP51 8610010740 Knob N273 (A)
MP52 8610010730 Knob N252 (A)
Flat washer M2.6 (2.6 × 5 × 0.5)
MP53 8850001250
MP54 8930051520 Polyester Tape No.631S #25 W8 L=230
[DISPLAY BOARD]
REF. NO. ORDER NO.
R701 7210002890 Variable register RV-308
R702 7210002890 Variable register RV-308
MP1 8510012630 2178 shield case
MP3 8510010760 1876 DDS case
MP4 8510010770 1876 DDS cover
MP5 8510001081 Shield case (A)-1
MP6 8510001101 Shield cover (A)-1
MP7 8210013980 1876 reflector
[PBT BOARD]
REF. NO. ORDER NO.
R1 7210002970 Variable register RV-314
S1 2250000410 Encoder TP90D96E20-30F-2178-1

MECHANICAL PARTS

DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
3
3
1
1
1
1
1
6
1
2
6
6
1
1
2
2
2
1
1
1
1
1
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
DESCRIPTION QTY.
1
1
[RIT BOARD]
REF. NO. ORDER NO.
S1 2250000340 Encoder EVQ-VCJF0324B
[PHONE BOARD]
REF. NO. ORDER NO.
J2 6450001980 Connector HLJ5815-01-030
[KEY BOARD]
REF. NO. ORDER NO.
J2 6450001790 Connector HLJ7000-01-3010
[MIC BOARD]
REF. NO. ORDER NO.
J1 6510000190 Connector FM214-8SS(P)
[CHASSIS PARTS]
REF. NO. ORDER NO.
J5 6510000370 Connector MR-DS
J6 6510000370 Connector MR-DS
SP1 2510000760 SM-77KY0208
MF1 2710000630 Fan FBA08T12HC
W15 8900007150 Cable OPC-699
EP1 6910000340 Insulation sheet P101 (KD)
EP2 6910000310 Insulation washer B312D
MP1 8410002322 1876 heatsink (A)-2
MP2 8110005931 1876 T-cover-1
MP3 8110007100 2178 L-cover
MP4 8510012530 2178 A-plate
MP5 8510010730 1876 B-plate
MP6 8510010740 1876 C-plate
MP7 8510010751 1876 D-plate-1
MP8 8930041350 1876 main stand
MP9 8930041340 1876 sub stand
MP11 8930002910 Rubber foot (B)
MP12 8930002910 Rubber foot (B)
MP13 8930029730 1413 fan holder
MP15 8930037001 1691 earth plate-1
MP16 8930018520 TR crip (A)
MP17 8930035240 1546 TR-B crip
Screw BiH M3 × 8 ZK
MP20 8810005770
Screw BiH M3 × 8 ZK
MP21 8810005770
Screw PH BT M3 × 8 NI-ZU
MP22 8810008660
Screw PH BT M3 × 8 NI-ZU
MP23 8810008660
Screw PH BT M3 × 8 NI-ZU
MP24 8810008660
Screw PH BT M3 × 8 NI-ZU
MP25 8810008660
Screw PH BT M3 × 8 NI-ZU
MP26 8810008660
Screw PH BT M3 × 8 NI-ZU
MP27 8810008660
Screw PH BT M3 × 8 NI-ZU
MP28 8810008660
