[CTRL UNIT]
REF ORDER
NO. NO.
C97 4030006880 S.CERAMIC
C98 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C100 4030011570 S.CERAMIC
C101 4030006880 S.CERAMIC
C102 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C105 4030011540 S.CERAMIC
C107 4010005580 CERAMIC
C108 4010005560 CERAMIC
C109 4030011600 S.CERAMIC
C209 4030006900 S.CERAMIC
C210 4030006900 S.CERAMIC
C211 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C212 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C213 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C214 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C215 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C216 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C217 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C218 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C220 4030006880 S.CERAMIC
C228 4030005040 S.CERAMIC
C301 4030007060 S.CERAMIC
C302 4610002210 TRIMMER
C303 4610002210 TRIMMER
RL1 6330001450 RELAY
RL2 6330001450 RELAY
RL3 6330000800 RELAY
RL4 6330000470 RELAY
J3 6510017150 CONNECTOR
J4 6510017150 CONNECTOR
J7 6510022590 S.CONNECTOR
J8 6510022590 S.CONNECTOR
J10 6510003410 CONNECTOR
J11 6510003410 CONNECTOR
J12 6910001040 CONNECTOR
J13 6510022620 S.CONNECTOR
J14 6910001040 CONNECTOR
W1 7120000490 JUMPER
W2 7120000490 JUMPER
W3 7120000490 JUMPER
W4 7030003860 S.JUMPER
WS1 8970023531 CABLE
EP1 0910051826 PCB

[MEMORY BOARD]

REF ORDER
NO. NO.
IC1 1140009990 S.IC
IC2 1140008470 S.IC
R1 7030003680 S.RESISTOR
R2 7030003680 S.RESISTOR
C1 4030011600 S.CERAMIC
C2 4030006860 S.CERAMIC
C3 4550006250 S.TANTALUM
C4 4030011600 S.CERAMIC
J1 6510022070 S.CONNECTOR
J2 6510022070 S.CONNECTOR
EP1 6910012350 S.BEAD
EP2 0910052263 PCB
DESCRIPTION
C1608 JB 1H 472K-T-A
CM105 CH 101G 50AT
C1608 JB 1H 472K-T-A
C1608 CH 1H 750J-T-A
HM60SJ SL 070D 500V
HM60SJ SL 050C 500V
C1608 JB 1C 104KT-N
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1H 472K-T-A
C2012 CH 1H 271J-T-A
C1608 CH 1H 270J-T-A
TZ03Z500FR169 50P
TZ03Z500FR169 50P
FXE-12G
FXE-12G
G5A-237P DC12V
NR-HD (12V) AE5343
TMP-S01X-C1
TMP-S01X-C1
22FMN-BMTTR-A-TBT
22FMN-BMTTR-A-TBT
B05B-EH-S
B05B-EH-S
IPS-1136
10FMN-BMTTR-A-TBT
IPS-1136
ERD25T0
ERD25T0
ERD25T0
ERJ3GE JPW V
SX2178 1.5D COAXIAL TUBE (2)/CT
B 5300F
DESCRIPTION
MBM29F400BC-90PFTN SC-1388
IDT71256SA20PZ
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
C1608 JB 1C 104KT-N
C1608 JB 1H 102K-T-A
TEMSVA 1A 106M-8L
C1608 JB 1C 104KT-N
AXK6S30635P
AXK6S30635P
MMZ1608Y 102BT
B 5418C
[RF-A UNIT]
REF ORDER
NO. NO.
IC151 1110001890 S.IC
IC451 1110003970 S.IC
IC841 1110003490 S.IC
IC871 1110000960 S.IC
IC901 1130007700 S.IC
IC902 1130007570 S.IC
IC903 1160000130 S.IC
IC904 1160000130 S.IC
IC905 1130007570 S.IC
IC961 1110004130 S.IC
Q101 1590001150 S.TRANSISTOR
Q131 1590001150 S.TRANSISTOR
Q132 1590001150 S.TRANSISTOR
Q141 1590002710 S.TRANSISTOR
Q143 1590001150 S.TRANSISTOR
Q151 1590002710 S.TRANSISTOR
Q152 1510000510 S.TRANSISTOR
Q153 1590001150 S.TRANSISTOR
Q441 1560000720 S.FET
Q442 1560000720 S.FET
Q445 1590001960 S.TRANSISTOR
Q452 1590001960 S.TRANSISTOR
Q501 1560000720 S.FET
Q502 1560000720 S.FET
Q511 1560000640 S.FET
Q512 1560000640 S.FET
Q513 1560000640 S.FET
Q514 1560000640 S.FET
Q531 1530002060 S.TRANSISTOR
Q551 1560000720 S.FET
Q561 1530003150 S.TRANSISTOR
Q601 1560000720 S.FET
Q602 1560000720 S.FET
Q611 1560000640 S.FET
Q612 1560000640 S.FET
Q613 1560000640 S.FET
Q614 1560000640 S.FET
Q631 1530002060 S.TRANSISTOR
Q651 1560000720 S.FET
Q661 1530003150 S.TRANSISTOR
Q701 1560000560 S.FET
Q721 1580000620 S.FET
Q722 1590001960 S.TRANSISTOR
Q751 1560000560 S.FET
Q801 1530002060 S.TRANSISTOR
Q811 1560000560 S.FET
Q812 1560000560 S.FET
Q831 1560000560 S.FET
Q901 1590002710 S.TRANSISTOR
Q902 1590002710 S.TRANSISTOR
Q903 1590001960 S.TRANSISTOR
Q904 1590001960 S.TRANSISTOR
Q905 1590001960 S.TRANSISTOR
D103 1750000520 S.DIODE
D131 1750000850 S.DIODE
D141 1750000850 S.DIODE
D142 1790000620 S.DIODE
D153 1750000850 S.DIODE
D171 1750000850 S.DIODE
D181 1750000850 S.DIODE
D261 1750000850 S.DIODE
D262 1790000620 S.DIODE
D281 1750000850 S.DIODE
D282 1790000620 S.DIODE
D301 1750000850 S.DIODE
D302 1790000620 S.DIODE
D321 1750000850 S.DIODE
D322 1790000620 S.DIODE
D341 1750000850 S.DIODE
D342 1790000620 S.DIODE
D361 1750000850 S.DIODE
D362 1790000620 S.DIODE
D411 1790000620 S.DIODE
D421 1790000620 S.DIODE
D431 1790000620 S.DIODE
D432 1790000620 S.DIODE
D441 1790000620 S.DIODE
D442 1790000620 S.DIODE
5 - 17
DESCRIPTION
µPC1678G-E2
µPC1658G-E1
TA31136FN (D, EL)
NJM4558M-T1
BU4094BCF-T1
BU4094BCFV-E2
TD62783AF (TP1)
TD62783AF (TP1)
BU4094BCFV-E2
µPC2708T-E3
UN9211 (TX)
UN9211 (TX)
UN9211 (TX)
UMH11NTN
UN9211 (TX)
UMH11NTN
2SA1576A T106R
UN9211 (TX)
2SK2171-4-TD
2SK2171-4-TD
XP4311 (TX)
XP4311 (TX)
2SK2171-4-TD
2SK2171-4-TD
2SK1740-TA
2SK1740-TA
2SK1740-TA
2SK1740-TA
2SC4081 T107 R
2SK2171-4-TD
2SC4673D-TD
2SK2171-4-TD
2SK2171-4-TD
2SK1740-TA
2SK1740-TA
2SK1740-TA
2SK1740-TA
2SC4081 T107 R
2SK2171-4-TD
2SC4673D-TD
2SK882-GR (TE85L)
3SK131-T2 MAS
XP4311 (TX)
2SK882-GR (TE85L)
2SC4081 T107 R
2SK882-GR (TE85L)
2SK882-GR (TE85L)
2SK882-GR (TE85L)
UMH11NTN
UMH11NTN
XP4311 (TX)
XP4311 (TX)
XP4311 (TX)
DAN222TL
MMBV3700LT1
MMBV3700LT1
MA77 (TX)
MMBV3700LT1
MMBV3700LT1
MMBV3700LT1
MMBV3700LT1
MA77 (TX)
MMBV3700LT1
MA77 (TX)
MMBV3700LT1
MA77 (TX)
MMBV3700LT1
MA77 (TX)
MMBV3700LT1
MA77 (TX)
MMBV3700LT1
MA77 (TX)
MA77 (TX)
MA77 (TX)
MA77 (TX)
MA77 (TX)
MA77 (TX)
MA77 (TX)
S.=Surface mount
