Icom IC-756PROII Service Manual page 47

[PA UNIT]
REF ORDER
NO. NO.
W29 9045201001 WIRE
W30 9021780060 WIRE
W31 9021780060 WIRE
WS1 8970023490 CABLE
WS2 8970023500 CABLE
WS3 8970023510 E.OTHER
EP1 0910051815 PCB
EP2 6910000610 BEAD
EP3 6910000610 BEAD
EP4 6510018330 TERMINAL
EP5 6510018330 TERMINAL
EP8 9001602001 TUBE
EP9 9001602001 TUBE
EP10 9001602001 TUBE
EP11 9034701901 TUBE
EP12 0910052242 PCB
EP13 0910052341 PCB
EP14 0910052351 PCB
[TUNER UNIT]
REF ORDER
NO. NO.
IC1 1120000970 IC
IC2 1120000970 IC
L1 2040000490 COIL
L2 2040000490 COIL
L3 6110003600 COIL
L4 6110003590 COIL
L5 6110003020 COIL
L6 6110003030 COIL
L7 6110003020 COIL
L8 6110003030 COIL
L9 6140003260 COIL
L10 6140003260 COIL
L11 6140002700 COIL
L12 6140002700 COIL
L13 6180003290 COIL
L14 6180003290 COIL
L15 6180003290 COIL
L16 6180003290 COIL
L17 6180003290 COIL
L18 6180003290 COIL
L19 6180003290 COIL
L20 6180003290 COIL
R17 7030003440 S.RESISTOR
R18 7030003440 S.RESISTOR
R19 7030003440 S.RESISTOR
R20 7030003440 S.RESISTOR
R21 7030003440 S.RESISTOR
R22 7030003440 S.RESISTOR
R23 7030003440 S.RESISTOR
R24 7030003440 S.RESISTOR
R25 7030003440 S.RESISTOR
R26 7030003440 S.RESISTOR
R27 7030003440 S.RESISTOR
R28 7030003440 S.RESISTOR
R29 7030003440 S.RESISTOR
R30 7030003440 S.RESISTOR
R31 7030003440 S.RESISTOR
R32 7030003440 S.RESISTOR
C1 4030006880 S.CERAMIC
C2 4030006880 S.CERAMIC
C3 4030006880 S.CERAMIC
C4 4030006880 S.CERAMIC
C5 4030006880 S.CERAMIC
C6 4030006880 S.CERAMIC
C7 4030006880 S.CERAMIC
DESCRIPTION
74/98/040/X98/X98
74/98/018/X98/X98
74/98/018/X98/X98
SX2178 1.5D COAXIAL TUBE (1)/PA
SX2178 1.5D COAXIAL TUBE (1)/PA
SX2178 J BOARD SET (1)/PA
B 5294E
FSOH050RN01
FSOH050RN01
F4053A
F4053A
IRRAX 0.7 (d) L=10 mm
IRRAX 0.7 (d) L=10 mm
IRRAX 0.7 (d) L=10 mm
IRRAX 0.7 (d) L=20 mm
B 5447B
B 5449A
B 5450A
DESCRIPTION
M54562P
M54562P
EXC-ELDR25C
EXC-ELDR25C
LA-555
LA-554
LA-489
LA-490
LA-489
LA-490
LR-363 (T130-6)
LR-363 (T130-6)
LR-307 (T130-2)
LR-307 (T130-2)
BM27-400-6A
BM27-400-6A
BM27-400-6A
BM27-400-6A
BM27-400-6A
BM27-400-6A
BM27-400-6A
BM27-400-6A
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
[TUNER UNIT]
REF ORDER
NO. NO.
C8 4030006880 S.CERAMIC
C9 4030006880 S.CERAMIC
C10 4030006880 S.CERAMIC
C11 4030006880 S.CERAMIC
C12 4030006880 S.CERAMIC
C13 4030006880 S.CERAMIC
C14 4030006880 S.CERAMIC
C15 4030006880 S.CERAMIC
C16 4030006880 S.CERAMIC
C17 4030006880 S.CERAMIC
C18 4030006880 S.CERAMIC
C23 4030006880 S.CERAMIC
C24 4030006880 S.CERAMIC
C25 4030006880 S.CERAMIC
C26 4030006880 S.CERAMIC
C27 4030006880 S.CERAMIC
C28 4030006880 S.CERAMIC
C29 4030006880 S.CERAMIC
C30 4030006880 S.CERAMIC
C31 4030006880 S.CERAMIC
C32 4030006880 S.CERAMIC
C33 4030006880 S.CERAMIC
C34 4010008550 CERAMIC
C35 4010008550 CERAMIC
C36 4010004800 CERAMIC
C37 4010004250 CERAMIC
C38 4010004830 CERAMIC
C39 4010008560 CERAMIC
C40 4010004250 CERAMIC
C41 4010004250 CERAMIC
C42 4010004250 CERAMIC
C43 4010004250 CERAMIC
C44 4620000140 VARIABLE
C45 4620000140 VARIABLE
C46 4030006880 S.CERAMIC
C47 4030006880 S.CERAMIC
C48 4030006880 S.CERAMIC
C49 4030006880 S.CERAMIC
C50 4030006880 S.CERAMIC
C51 4030006880 S.CERAMIC
C52 4030006880 S.CERAMIC
C53 4030006880 S.CERAMIC
C54 4030006880 S.CERAMIC
C55 4030006880 S.CERAMIC
C56 4030006880 S.CERAMIC
C57 4030006880 S.CERAMIC
C58 4030006880 S.CERAMIC
C59 4030006880 S.CERAMIC
C60 4030006880 S.CERAMIC
C61 4030006880 S.CERAMIC
RL1 6330001610 RELAY
RL2 6330001610 RELAY
RL3 6330001610 RELAY
RL4 6330001610 RELAY
RL5 6330001610 RELAY
RL6 6330001610 RELAY
RL7 6330001610 RELAY
RL8 6330001610 RELAY
RL9 6330001610 RELAY
RL10 6330001610 RELAY
RL11 6330001610 RELAY
RL12 6330001610 RELAY
RL13 6330001610 RELAY
RL14 6330001610 RELAY
RL15 6330001610 RELAY
J5 6510022590 S.CONNECTOR
MF1 2710000460 MOTOR
MF2 2710000460 MOTOR
WS1 8970023521 CABLE
EP1 0910052334 PCB
5 - 13
DESCRIPTION
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
DE0607 SL 390J 3KV
DE0607 SL 390J 3KV
DE1210 SL 820J 6KV
DE1007 SL 101J 3KV
DE1510 SL 151J 6KV
DE1107 SL 151J 3KV
DE1007 SL 101J 3KV
DE1007 SL 101J 3KV
DE1007 SL 101J 3KV
DE1007 SL 101J 3KV
UV35A 150P
UV35A 150P
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
NY-12W-K-IE
NY-12W-K-IE
NY-12W-K-IE
NY-12W-K-IE
NY-12W-K-IE
NY-12W-K-IE
NY-12W-K-IE
NY-12W-K-IE
NY-12W-K-IE
NY-12W-K-IE
NY-12W-K-IE
NY-12W-K-IE
NY-12W-K-IE
NY-12W-K-IE
NY-12W-K-IE
22FMN-BMTTR-A-TBT
MP28GA STEPPING MOTOR
MP28GA STEPPING MOTOR
SX2178 1.5D COAXIAL TUBE (2)/TU
B 5408D
S.=Surface mount
