General Information
The Generator
A
N
A.
Exhaust Enclosure
B.
Automatic Voltage
Regulator (AVR)
C.
Engine Air Filter
D.
AVR Air Filter
6
B
L
M
Figure 2-1. Component Locations
E
Data Label
F.
Control Pad
G.
Circuit Breakers
H.
Fuel Inlet (Back)
C
D
K
I.
Fuel Regulator
J.
Battery Compartment
K.
Oil Filter
L.
Oil Tank
Owner's Manual for 60 Hz EcoGen™ Generator
E
F
G
H
I
J
001380
M.
Oil Dipstick
N.
Composite Base
