Summary of Contents for Uniden ANA 9310

  • Page 2: One Year Limited Warranty

    One Year Limited Warranty WARRANTOR: UNIDEN AMERICA CORPORATION (“Uniden”) ELEMENTS OF WARRANTY: Uniden warrants, for one year, to the original retail owner, this Uniden Product to be free from defects in materials and craftsmanship with only the limitations or exclusions set out below.

  • Page 4: Rechargeable Nickel-Metal-Hydride Battery Warning

    Before you read anything else, please observe the following: WARNING! Uniden America Corporation DOES NOT represent this unit to be waterproof. To reduce the risk of fire, electrical shock, or damage to the unit, DO NOT expose this unit to rain or moisture.

  • Page 5: Handset Controls & Functions

    Handset Controls & Functions 1. Headset Jack 2. Display 3. Hold ( hold ) Key 4. Talk ( TALK ) Key 5. Numeric Keypad 6. Pause ( pause ) Key 7. Redial ( redial ) Key 8. Microphone 9. Transfer ( xfer ) Key 10.

  • Page 6: Base Unit Controls & Functions

    Base Unit Controls & Functions 21 22 18. Hold ( hold ) Key 19. Hold LED 20. Status LED 21. Page LED 22. Page/find ( page/find ) Key...

  • Page 7: Table Of Contents

    Transferring a Call to the ANA 9310........

  • Page 8: Important Safety Instructions

    Important Safety Instructions When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electrical shock, and injury to persons, including the following: Read and understand all instructions. Follow all warnings and instructions marked on the product. Unplug this product from the wall outlet before cleaning.

  • Page 9: Save These Instructions

    D. If the product does not operate normally when following the operating instructions. Adjust only those controls that are covered by the operating instructions. Improper adjustment of other controls may result in damage, and will often require extensive work by a qualified technician to restore the product to normal operation.

  • Page 10: About Your Ana 9310

    It is designed to work with a PBX system. To get the most from your ANA 9310, please read this Operating Guide thoroughly. To help familiarize you with the features of your cordless phone, refer to the Handset illustration foldout from the front cover, and the Base Unit illustration foldout from the rear cover.

  • Page 11: Important Electrical Considerations

    This phone is no exception. Caution: Changes or modifications to this product not expressly approved by Uniden, or operation of this product in any way other than as detailed by this Operating Guide, could void your authority to operate this product.

  • Page 12: Radio Interference

    Radio Interference Radio interference may occasionally cause buzzing and humming in your cordless Handset, or clicking noises in the Base Unit. This interference is caused by external sources such as a TV, refrigerator, vacuum cleaner, fluorescent lighting, computer equipment, or electrical storm. Your unit is NOT DEFECTIVE. If these noises continue and are too distracting, please check around your office to see what appliances may be causing the problem.

  • Page 13: Ana 9310 Features

    ANA 9310 Features Long Range 900MHz Digital 2-line, 16-digit LCD Display Ringer Volume Control Handset Volume Control Single button access to: CONFERENCE, HOLD, and TRANSFER features Four Function Keys: PAUSE, FLASH, REDIAL, SEARCH 30 Simultaneous Conversations 20 Number Memory Store and Search...

  • Page 14: Installing Your Ana 9310

    Selecting the Installation Location Select a location for the ANA 9310 to avoid excessive heat or humidity. The Base Unit of your ANA 9310 can be placed on a desk or tabletop near a standard 120V AC outlet and telephone line jack.

  • Page 15: Connecting The Telephone Cords

    Connecting the Telephone Cords The ANA 9310 must be connected to an analog PBX port or a standard analog telephone line. CAUTION: Never install telephone wiring during a lightning storm. Never touch uninsulated telephone wires or terminals unless the telephone line has been disconnected at the network interface.

  • Page 16: Tone/Pulse Switch

    Tone/Pulse Switch Be sure the TONE/PULSE switch is in the TONE position. Note: Most systems are Tone dialing. Check with your PBX Administrator if you are not sure whether your system is Tone or Pulse dialing. Applying Power to the Base and Charger Units Use only the supplied AC Adapter: EXP9704...
  • Page 17 Note: If you cannot plug the AC Adapter into the outlet, contact someone about replacing the outlet. The unique design of your ANA 9310 allows you to place the Handset in the Charging Unit with or without the Belt Clip attached.

  • Page 18: Wall Installation

    Wall Installation Standard Wall Plate Mounting These Phones are designed to be mounted on a standard wall plate. To attach the wall mount stand to the Base Unit: 1. Slide the Wall Mount stand into the notches at the top of the Base Unit, push the Wall Mount stand down and snap it into place.
  • Page 19 6. Place the Base Unit on the posts of the wall plate and push down until it’s firmly seated. 7. Plug the AC Adapter into a standard 120V AC wall outlet. Note: Do not use an outlet controlled by a wall switch. Direct Wall Mounting If you do not have a standard wall plate, you can mount your phone directly on a wall.
  • Page 20 1. Insert two mounting screws 3 15/16 inches apart. Allow about 3/16 of an inch between the wall and screw heads for mounting the phone. 2. Plug and secure the AC Adapter cord by following steps 2 and 3 of the Standard Wall Plate Mounting. 3.
  • Page 21 Charging Unit Wall Mounting The Charging Unit is also designed to be wall mounted. Before mounting your charging unit, consider the following: Select a location away from electrical cables, pipes, or other items behind the mounting location that could cause a hazard when inserting screws into the wall.
  • Page 22 3. Slide the wall mount stand into the notches on the bottom of the charging unit. 4. Place the Charging Unit on the posts of the wall screws and push down until it’s firmly seated. 5. Plug the AC Adapter into a standard 120V AC wall outlet.

  • Page 23: Attaching The Belt Clip To The Handset

    Attaching the Belt Clip to the Handset You can use the Belt Clip to attach the Handset to your belt or pocket for convenient portability. 1. Snap the tab out of the Belt Clip notch on the top of the Handset. 2.

  • Page 24: Installing The Handset Battery Pack

    Installing the Handset Battery Pack 1. Remove the battery cover by pressing the latch and sliding the cover down and off of the Handset. 2. Connect the battery pack connector observing correct polarity to the jack inside the battery compartment. Do not exert any force on this connection.

  • Page 25: Charging The Handset Battery Pack

    Charging the Handset Battery Pack The Rechargeable Ni-MH Battery Pack must be fully charged before using your ANA 9310 for the first time. ( Note: Charge the Battery Pack without interruption for 5 hours. ) 1. Place the Handset into the Charging Unit.

  • Page 26: Low Battery Indicator

    Low Battery Indicator When the Battery Pack in the Handset is low and needs to be charged, you will see a message on the display. On a Call All keys and functions are available. Handset beeps once every 3 seconds Complete your call as quickly as possible Replace Battery pack within 20...

  • Page 27: Using Your Ana 9310 Handset

    Using Your ANA 9310 Handset Before using your ANA 9310, be sure to raise the antenna to the vertical position. Note: Operation of the ANA 9310 is performed using the Handset out of the Charging Unit. ANA 9310 Handset Controls...

  • Page 28: Earpiece Volume

    Earpiece Volume Press RING/VOL on the side of the Handset during a call to select the earpiece volume of the handset.

  • Page 29: Handset Ringer Tone And Volume

    Handset Ringer tone and volume Pressing RING/VOL on the side of the Handset in standby mode to select seven ringer tones and volume combinations. Vibrate Mode “Ring off” shown on the above display is the Vibrate Mode. If you set the ringer off and the Handset is not on the charger, the Handset will vibrate when there is an incoming call.

  • Page 30: Using The Handset

    Or, you may see one of the following: Condition No Connection to Base Unit Line in Use If the Handset is at the range limit of the ANA 9310, or no power is going to the Base Unit, you may see: Indicator Error Tone Error Tone...

  • Page 31: Answering A Call

    Answering a Call When you receive a call, the Handset rings and you’ll see: Handset in the Charging Unit Pick up the Handset. The AutoTalk feature allows you to answer the call immediately. When you finish the call, place the Handset back in the Charging Unit. AutoStandby automatically hangs up the phone.

  • Page 32: Feature Buttons

    Note: The exact operation of the Feature Buttons depends on how your PBX system is configured. Contact your PBX Administrator for more information. Placing a call “on hold” Press hold . You will see the following display: To resume the call, press hold or TALK . Transferring a Call Press xfer (TRANSFER).

  • Page 33: Programming The Feature Buttons

    Press 9 . Press memo . Press xfer . Note: For the ANA 9310, conference and transfer keys are operated by the Hook Flash function. Please, program your system transfer or conference code with the assistance of the PBX System Administrator.

  • Page 34: Function Keys

    Press to begin Memory Search. (See “Memory Search” in the following “Using Your ANA9310 Memory” section.) MEMO This key allows you to dial a number using just a few key presses. (You need to store some numbers in Memory Location. See the following “Using Your ANA 9310 Memory” section.)

  • Page 35: Using Your Ana 9310 Memory

    You’ll hear a confirmation beep and see the message: Note: In storing a number operation, you must press a key within 20 seconds. Otherwise, an error tone sounds and the unit returns to standby mode. The ANA 9310 then returns to standby mode.

  • Page 36: Erasing A Stored Number

    Erasing a Stored Number Press memo . Press memo . Enter the memory location number (01) to (20) you want to clear. You will hear a long beep and see:...

  • Page 37: Dialing A Stored Number

    Dialing a Stored Number Note: The following applies when the phone is in standby mode. Press TALK . Press memo . Enter the Memory Location (01 - 20). The phone automatically dials the number shown. Memory Search You can search all 20 Memory Locations to find the number you need. Once you have found the number, you can automatically dial that number by pressing the TALK key.

  • Page 38: Chain Dialing

    c. Pressing the ON/OFF MUTE key, you will move down through the Memory (20 to 1). Pressing RING/VOL you will move up through the Memory (1 to 20). Press RING/VOL or ON/OFF MUTE until you reach the desired Memory Location. Once you have the desired number, press TALK .

  • Page 39: Using Your Ana 9310 Base Unit

    The hold button (1) is used in conjunction with a desk top phone to switch from the Handset to a desk top phone. If you need to use a desk top phone which the ANA 9310 is connected to, press hold on the Handset or on the Base unit then pick up the desk top phone.

  • Page 40: Optional Headset (Exp9730/9530)

    Optional Headset (EXP9730/EXP9530) The optional Headset provides a “Hands-Free” Option for the ANA 9310. With the Headset installed, you can use the Belt Clip to carry the Handset, and conduct a conversation using the Headset. To install the optional Headset,...

  • Page 41: Using An Optional Second 2500-Type Analog Telephone

    Transferring a Call to the ANA 9310 Press hold on the Base unit and press talk on the Handset. The call is now transferred to the ANA 9310 Handset, and the Desk phone is disconnected. Transferring a Call to the Desk Telephone Press hold on the ANA 9310 Base Unit or Handset.

  • Page 42: Typical Applications

    Typical Applications You can use the ANA 9310 together with a standard PBX telephone to give you effective business communications both at your desk and away from it. Contact your PBX Administrator for more information about your System. You can have your PBX system programmed so the following sequence occurs: Your PBX telephone rings first.

  • Page 43: Optional Accessories And Replacement Parts

    Optional Accessories and Replacement Parts For the following Optional Accessories and Replacement Parts contact your PBX Administrator. EXP9704 AC Adapter for Base Unit 700 mAh Battery BT-930 Headset EXP9530 Charging Unit Wall Mount EXP9360 Telephone Cord Operating Guide OM9310 Charger EXP9385 AC Adapter AD-970 Belt Clip EXP9302...

  • Page 44: Troubleshooting

    If your ANA 9310 Cordless Telephone is not performing to your expectations, please try these simple steps. If you are still unable to resolve the problems, contact your PBX Administrator. Note: Do not attempt to service this unit yourself. All service must be done by qualified service personnel.

  • Page 45: Specifications

    Frequency Control Modulation Operating Temperature Base Unit Receive/Transmit Frequency : 902 MHz to 928 MHz Power Requirements Size Weight Handset Receive/Transmit Frequency : 902 MHz to 928 MHz Power Requirements Size Weight Battery Talk Time Standby Time Specifications shown are typical and subject to change without notice. Specifications : Phase Lock Loop : Digital...
  • Page 46 MEMO...
