3" Air cut-off tool
With 5" extension
set up And operAting instructions
Visit our website at: http://www.harborfreight.com
read this material before using this product.
failure to do so can result in serious injury.
sAVe this MAnuAl.
©
Copyright
2010 by Harbor Freight Tools
contained herein may be reproduced in any shape or form without the express written consent of Harbor
Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing improvements,
actual product may differ slightly from the product described herein.
for technical questions or replacement parts, please call 1-800-444-3353.
Model
67996
®
. All rights reserved. No portion of this manual or any artwork
Advertisement
Table of Contents
Related Manuals for Central Pneumatic 67996
Summary of Contents for Central Pneumatic 67996
-
Page 1: Set Up And Operating Instructions
3” Air cut-off tool With 5” extension Model 67996 set up And operAting instructions Visit our website at: http://www.harborfreight.com read this material before using this product. failure to do so can result in serious injury. sAVe this MAnuAl. © ®... -
Page 2: Important Safety Information
Always wear injury. eye protection. Safety equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used SKU 67996 for technical questions, please call 1-800-444-3353. Page 2... - Page 3 The correct air tool will do the job better as a cut-off tool. read all safety warnings, instructions, illustrations SKU 67996 for technical questions, please call 1-800-444-3353. Page 3...
- Page 4 The spinning accessory may grab accessory such as abrasive wheels the surface and pull the air tool out of for chips and cracks, backing pad your control. for cracks, tear or excess wear, wire SKU 67996 for technical questions, please call 1-800-444-3353. Page 4...
-
Page 5: Kickback And Related Warnings
Your risk from these exposures varies, you to resist kickback forces. Always depending on how often you do this type use auxiliary handle, if provided, for of work. To reduce your exposure to SKU 67996 for technical questions, please call 1-800-444-3353. Page 5... - Page 6 The guard helps to protect possible kickback may propel the operator from broken wheel fragments spinning wheel and the air tool directly at and accidental contact with wheel. you. SKU 67996 for technical questions, please call 1-800-444-3353. Page 6...
-
Page 7: Vibration Safety
Pregnant SKU 67996 for technical questions, please call 1-800-444-3353. Page 7... -
Page 8: Specifications
A 1/4”-18 NPT Remove this plug before set up. Male Quick Connector (not included) is required. Then connect the Quick SKU 67996 for technical questions, please call 1-800-444-3353. Page 8... -
Page 9: Operating Instructions
If tool will not be used at this time, turn off and detach air supply, safely discharge any residual air pressure, and release throttle to prevent accidental operation. SKU 67996 for technical questions, please call 1-800-444-3353. Page 9... -
Page 10: General Operating Instructions
Cut-Off Tool Wheel Guard (38) Spindle Male (35) Trigger (4) Quick Connector Cutting Wheel (39) (not included) Safety Lock Washer (40) Screw (41) Inlet (2) figure 1 SKU 67996 for technical questions, please call 1-800-444-3353. Page 10... - Page 11 Clean external surfaces of the tool with clean, dry cloth. Then store the tool indoors out of children’s reach. SKU 67996 for technical questions, please call 1-800-444-3353. Page 11...
-
Page 12: User Maintenance Instructions
These procedures are in addition to the regular checks and maintenance explained as part of the regular operation of the air-operated tool. daily - Air supply Maintenance: Every day, perform maintenance on SKU 67996 for technical questions, please call 1-800-444-3353. Page 12... -
Page 13: Troubleshooting
Damaged valve or housing. Replace damaged components. Dirty, worn or damaged valve. Clean or replace valve assembly. follow all safety precautions whenever diagnosing or servicing the tool. disconnect air supply before service. SKU 67996 for technical questions, please call 1-800-444-3353. Page 13... -
Page 14: Please Read The Following Carefully
If product has no serial number, record month and year of purchase instead. note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. SKU 67996 for technical questions, please call 1-800-444-3353. Page 14... -
Page 15: Assembly Diagram
AsseMBlY diAgrAM SKU 67996 for technical questions, please call 1-800-444-3353. Page 15... -
Page 16: Limited 90-Day Warranty
This warranty gives you specific legal rights and you may also have other rights which vary from state to state. 3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • (800) 444-3353 SKU 67996 for technical questions, please call 1-800-444-3353. Page 16...
