13.2 Appliance technical settings and
parameter list
The access to the boilers technical data allows you to adjust the
boiler to the exact system requirements.
Note: the heating power decrease has no effect on the domestic
hot water power.
13.2.1 Installation settings
• Press for more than 7 seconds on the button
access the configuration menu. The screen displays "0".
• Press 4 times on the button under the symbol
The screen displays "96". This is the installer's password.
• Press on to validate. The screen displays the
parameter "00" and its value "XX".
• Press on button or under the symbol
parameter to modify.
• Press on button or under the symbol
value of the parameter.
• Do likewise for each parameter that needs to be modified.
• Press for more than 3 seconds on the button
the configuration menu.
Code Parameter
d.00 Maximum heating power
d.01 Pump over-run time - heating
Blocking time for burner in heating
d.02
mode (anti-cycle time)
The following menu is displayed if a domestic hot water tank is connected to the appliance.
d.03 Temperature of the DHW outlet
d.04 Temperature of water in the tank
d.18 Pump function
d.19 Speed of the pump
Maximum temperature setting for
d.20
domestic hot water
The following 2 menus are displayed if an option card (not supplied) is installed on the appliance.
d.27 Function relay 1
d.28 Function relay 2
0020112600_02 - 10/12 - Glow-worm
to
.
to access the
to modify the
to exit
Unit Description
Choose a value:
12sxi ► 4 to 12 kW
kW
18sxi ► 5 to 18 kW
30sxi ► 8 to 30 kW
min. Choose a value between 2 and 60.
To prevent the burner frequently switching on and off,
the reactivation of the burner is electronically blocked for a period
that is determined each time the burner stops. The burner blocking
time can be adapted to the usage conditions for the heating
min.
installation and depends on the temperature that is set for heating:
- at 80°C, the period is fixed (2 minutes)
- at 10°C, the period is adjustable: choose a value between 2 and
60 minutes.
°C Display the temperature of the DHW outlet.
°C Display tank water temperature.
Mode:
0 = With the burner
-
1 = Continuous with ambient temperature
2 = Continuous
Functioning mode:
0 = Automatic: maximum speed when the burner is switched on
- 1 = Minimum speed
2 = Automatic: automatic speed when the burner is switched on
3 = Maximum speed
The recommended maximum temperature setting for domestic hot
°C
water is 60°C. Choose a value suitable for your needs.
- Reserved for future use
- Reserved for future use
INSTALLATION
factory Modifiable
setting parameter
12
yes
18
30
5 yes
20 yes
- no
- no
1 yes
2 yes
60 yes
1 yes
2 yes
