INSTALLATION
Code Parameter
d.34 Speed of fan
d.40 Heating flow temperature
d.41 Heating return temperature
The following 2 menus are displayed if an outdoor sensor (not supplied) is installed on the appliance.
d.43 Heating curve
d.47 Exterior temperature
Time remaining before the end of the
d.67
anti-cycle in heating mode.
Maximum temperature setting for
d.71
heating outlet
d.90 Detection of eBUS controller
13.2.2 After Sales Service settings
• Press for more than 7 seconds on the button
access the configuration menu. The screen displays "0".
• Press on button or under the symbol
After Sales Service password.
• Press on to validate. The screen displays the
parameter "00" and its value "XX".
• Press on button or under the symbol
parameter to modify.
• Press on button or under the symbol
value of the parameter.
• Repeat the process for each parameter modified.
• Press for more than 3 seconds on the button
the configuration menu.
Code Parameter
d.08 Current state of the 230V room thermostat
d.09 Flow temperature set point from external eBus control
d.10 Pump status
d.16 Current state of the 24V room thermostat
d.17 Flow or Return temperature control
d.21 DHW status
d.22 DHW mode (eBus and direct connection to board)
d.23 Central heating mode
d.25 DHW mode
d.33 Speed setpoint of fan
d.44 Digitalized ionisation voltage
- 28 -
Unit Description
Fan speed is displayed between 0 and 99.
rpm
Multiply the displayed value by 100.
°C Display the heating flow temperature.
°C Display the heating return temperature.
See the instructions for the external sensor connected to the
K
appliance.
°C Display the temperature measured by the external sensor.
min. Display the time remaining before the end of the anti cycle.
°C Select a value between 50°C and 80°C.
0 = Not detected
-
1 = Detected
to
and enter the
to access the
to modify the
to exit
Unit Description
230V room thermostat :
- 0 = open (no heating),
1 = closed (heating mode).
°C External eBus set value.
0 = off
-
1 = on
0 = open (no heating),
°C
1 = closed (heating mode)
Temperature regulation on flow (radiator) or return
°C
(under-floor heating) temperature sensor.
0 = DHW function disabled
-
1 = DHW activated
0 = off
-
1 = on
0 = CH not available (summer mode)
-
1 = CH available (winter mode)
DHW loading enabled or disabled by Appliance
-
Interface or Ebus or external controls.
Fan speed is displayed between 0 and 99.
rpm
Multiply the displayed value by 100.
V Display the digitalized ionisation voltage
factory Modifiable
setting parameter
- no
- no
- no
1.2 yes
- no
- no
75 yes
- no
factory Modifiable
setting parameter
- no
- no
- no
- no
0 yes
- no
- no
- no
- no
- no
- no
