GAS VALVE
(DUNGS)
IMPORTANT NOTES
THESE INSTRUCTIONS SUPERCEDE
THE GAS VALVE SETTING PROCEDURE CONTAINED
WITHIN THE ORIGINAL APPLIANCE LITERATURE.
If the burner door is removed during the gas valve
replacement a new door seal must be fitted.
Burner Door Seal kit - Part No. 801635
MODEL
MODEL
24 & 30 ultracom cx
12 – 30 hxi
24 & 30 ultracom cxi
12 – 30 ultracom hxi
18 & 30 ultracom sxi
18 & 30 sxi
24 & 30cxi
KIT Pt. No 2000802442
KIT Pt. No. 2000802664
6mm white scroll
6mm white scroll incl.
incl. Brass liner
Brass Flange adaptor, 4
and grommet
off screws, 2 "O" rings
MODEL
MODEL
38 hxi
38 cxi
38 ultracom hxi
38 ultracom cxi
BG330
Xtramax HE
KIT Pt. No. 0020018823
KIT Pt. No 2000802452
12mm grey scroll incl.
12mm grey scroll
Brass Flange adaptor,
incl. Brass liner
4 off screws, 2 "O" rings
and grommet
Technical Helpline: 01773 828300
