Viking Range BRTGK72SS Installation Instructions Manual

Built-in bottom mount refrigerator/ freezer

Advertisement

Quick Links

INSTALLATION
INSTRUCTIONS
BUILT-IN BOTTOM MOUNT REFRIGERATOR/FREEZER
BRTGK72SS/PBRTGK72SS GRILLE KITS
(FOR PROFESSIONAL SERIES ONLY)
IMPORTANT - PLEASE READ AND FOLLOW
Make sure that incoming voltage is the same as unit rating. An electric rating plate specifying voltage, frequency, wattage,
amperage, and phase is attached to the product.
Please refer to Installation Instructions provided with bottom mount refrigerator/freezer for additional information.
To reduce the risk of fire, electric shock, or injury to persons, installation work and electrical wiring must be done by qualified
people in accordance with all applicable codes and standards, including fire-rated construction.
The installer should leave these instructions with the consumer who should retain for local inspector's use and for future
reference.

GENERAL INFORMATION

Your safety and the safety of others
is very important.
We have provided many important safety
messages in this manual and on your
appliance. Always read and obey all
safety messages.
This is the safety alert symbol. This
symbol alerts you to hazards that
can kill or hurt you and others.
All safety messages will be
preceded by the safety alert symbol and
the word "DANGER" or "WARNING".
These words mean:
You will be killed or seriously injure e d if you
don't follow instructions.
You can be killed or seriously injured if
you don't follow instr r uctions.
All safety messages will identify the
hazard, tell you how to reduce the chance
if injury, and tell you what can happen if
the instructions are not followed.
Most of the refrigerator's weight is at the top. Extra care is needed when moving the
refrigerator to prevent tipping.
Keep cardboard shipping piece or plywood under refrigerator until it is installe e d in
the operating position.
It is your responsibility to :
-comply with installation specifications and dimensions
-properly install refrigerator
-remove any moldings or decorative panels that prevent the refrigerator from
being serviced
-make sure that you have these materials, (not provided with the unit), which
are necessary for proper installation:
2 - 1/4" (6 mm) copper tubing with shutoff valve
2 - 1/4" (6mm) compression fitting
#8 x 3" (7.6 cm) wood screws (Longer screws may be required.)
BRTGK72SS - Qty 12
PBRTGK72SS - Qty 12
2 - saddle valves (do not use self-piercing valves).
-assure that floor will support refrigerator, door panels and contents,
(approximately 1200 lbs. [540 kg.])
-provide a properly grounded electrical outlet
-assure that location will permit appliance doors to open 90
VIKING RANGE CORPORATION
111 Front Street
Greenwood, Mississippi 38930 USA
(662) 455-1200
TIP OVER HAZARD
Refrigerator is top heavy and tips easily when
not completely installed.
Keep doors closed until refrigerator is
completely installed and secured with lag bolts
to rear wall. Use two or more people to move
and install refrigerator. Failure to do so can
result in death or serious in n jury
o
minimum

Advertisement

loading

Summary of Contents for Viking Range BRTGK72SS

  • Page 1: General Information

    2 - 1/4” (6mm) compression fitting #8 x 3” (7.6 cm) wood screws (Longer screws may be required.) All safety messages will identify the BRTGK72SS - Qty 12 hazard, tell you how to reduce the chance PBRTGK72SS - Qty 12 if injury, and tell you what can happen if 2 - saddle valves (do not use self-piercing valves).
  • Page 2 BASIC SPECIFICATIONS AND DIMENSIONS VCBB363-DUAL INSTALLATION DESCRIPTION BRTGK72SS PBRTGK72SS Overall Width 72” (182.9 cm) Overall Height from Bottom Min. 82 3/4” (210.2 cm) Max. 84 1/16” (213.5 cm) Overall Depth from Rear To rear edge of side trim 22 3/16” (56.4 cm) To front of top grille 24 11/16”...
  • Page 3: Cabinet Opening Dimensions

    SITE PREPARATIONS AND CONSIDERATIONS BRTGK72SS PROFESSIONAL 36” W. BOTTOM MOUNT DUAL INSTALLATION, CABINET OPENING DIMENSIONS 39 3/16” (99.5 cm) FOUR (2 per unit) 1” (2.5 cm) TYP 35 13/16” (91.5 cm) ELECTRICAL RECEPTACLE LOCATIONS (SHADED AREAS) 82 7/8” (210.5 cm) Min.
  • Page 4 SITE PREPARATIONS AND CONSIDERATIONS PBRTGK72SS PROFESSIONAL 36” W. BOTTOM MOUNT DUAL INSTALLATION, CABINET OPENING DIMENSIONS (2 per unit) 2” x 4” mounting boards (1-1/2” [3.8 cm] x 3-1/2” [8.9 cm]) NOTE: If unit is installed d deeper than 24” (61.0 cm), then shim behind anit-tip bracket Electrical outlet thickness by the same amount.
  • Page 5 GRILLE ASSEMBLY/INSTALLATION BRTGK72SS PROFESSIONAL MODEL (FOR PBRTGK72SS INSTALLATION - SKIP TO PAGE 9) Before moving the refrigerators in place, confirm the finished dimensions, electrical, and plumbing locations, minimum door clearances, and door panel installations are accurate. (See Installation Instructions provided with refrigerators).
  • Page 6 3. Verify operation by plugging in Power power cord. Power switch will Switch be shipped in the ON position and showroom switch will be in the ON position. (If showroom switch is switched to the “OFF” position, showroom mode is engaged and power is shut off to the compressor.
  • Page 7 5. Remove cabinet side trim that is mounted on the right hand side of the unit that is to be installed on the left side of the installation. Replace this side trim with the connection “J” shaped side trim and shim included in the full length grille kit.
  • Page 8 8. Assemble air ducts to 72” grille using the supplied 15 screws removed in step 2c. 9. Remove 72” center grille blade by lifting up and pulling forward. 10. Insert air ducts and 72” grille into refrigerators. Screw air ducts into units with four screws per unit. GRILLE ASSEMBLY BLACK AIR DUCTS REAR VIEW OF...
  • Page 9 GRILLE ASSEMBLY/INSTALLATION PBRTGK72SS PROFESSIONAL MODEL Before moving the refrigerators in place, confirm the finished dimensions, electrical, and plumbing locations, minimum door clearances, and door panel installations are accurate. (See Installation Instructions provided with refrigerators). 1. Position refrigerators in front of cutout. 2.
  • Page 10 4. Remove cabinet side trim that is mounted on the left hand side of the unit that is to be installed on the right side of the installation. Replace this side trim with the “Z” shaped side trim and shim included in the full length grille kit.
  • Page 11 8. Assemble grille brackets to 72” grille using the 16 screws removed in step 2c. 9. Remove 72” center grille blade by lifting up and pulling forward. 10. Insert 72” grille into refrigerators. Screw 72” grille assembly into units with (4) screws removed in step 2b.
  • Page 12 Viking Range Corporation 111 Front Street • Greenwood, Mississippi 38930 USA • (662) 455-1200 Specifications subject to change without notice http://www.vikingrange.com F20083B (PS0306VR)
