- Page 1 Installation Custom Panel All Refrigerator / All Freezer FDRB5303 / FDRB5363 FDFB5303 / FDFB5363...
-
Page 2: Table Of Contents
Table of Contents Warnings & Important Information _______________________________________________________________________3 All Refrigerator/Freezer Dimensions & Specifications (30” and 36”) _________________________________________________________6 Cutout Dimensions (30”)_______________________________________________________________________8 Anti-Tip Dimensions (30”) ______________________________________________________________________9 Cutout Dimensions (36”)______________________________________________________________________10 Anti-Tip Dimensions (36”) _____________________________________________________________________11 Dimensions (Dual 30”)________________________________________________________________________12 Dimensions (Dual 30” and 36”) _________________________________________________________________13 Dimensions (Dual 36”)________________________________________________________________________14 Specifications (Dual) _________________________________________________________________________15 Cutout Dimensions (Dual 30”) _________________________________________________________________16... -
Page 3: Warnings & Important Information
IMPORTANT – Please Read and Follow • Make sure that incoming voltage is the same as unit Your safety and the safety of others is rating. An electric rating plate specifying voltage, very important. frequency, wattage, amperage, and phase is attached to We have provided many important safety the product. -
Page 4: Door Swing
• The required use of a GFI is normally related to the location of a receptacle with respect to any significant sources of water or moisture. • Viking Range, LLC will NOT warranty any problems resulting from GFI outlets which are not installed properly or do not meet the requirements below. -
Page 5: Tipping Radius
Tipping Radius 30” All Refrigerator/All Freezer 112 7/8” (286.7 cm) 30” (76.6 cm) 82 3/4” 88 1/16” (210.1 cm) (223.7 cm) 118 7/8” (302.0 cm) 36” All Refrigerator/All Freezer 36” (94.4 cm) 82 3/4” (210.1 cm) 90 3/16” (229.1 cm) -
Page 6: Dimensions & Specifications (30" And 36")
Dimensions 30” All Refrigerator/Freezer 3 – 1 9 / 3 2 ” ( 9 . 1 c m 36” All Refrigerator/Freezer 3 – 1 9 / 3 2 ” ( 9 . 1 c m i e s v a r r e ) e n t a r d... - Page 7 Specifications 30” All Refrigerator/Freezer Description FDFB/CFDFB FDRB/CFDRB Overall width 30” (76.2 cm) Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. Overall depth (from rear) To front edge of side trim: 23-3/16” (58.9 cm) To front edge of door trim: 24” (61.0 cm) Cutout width 30”...
-
Page 8: Cutout Dimensions (30")
Cutout Dimensions 30” All Refrigerator/Freezer Electric Outlet Location 6 ” ( 1 5 . 2 c m ) 9 ” ( 2 2 . 9 c m ) 9 ” ( 2 2 . 9 c m ) 8 2 - 7 / 8 ”... -
Page 9: Anti-Tip Dimensions (30")
Anti-Tip Dimensions 30” All Refrigerator/Freezer Anti-Tip Location 7 9 - 3 ” / 8 ” 1 - 1 / 2 ( 2 0 1 . 6 c m ( 3 . 8 c ) m i n t o b o t t o m a n t i - t i p b... -
Page 10: Cutout Dimensions (36")
Cutout Dimensions 36” All Refrigerator/Freezer Electric Outlet Location 6 ” ( 1 5 . 2 c m ) 9 ” ( 2 2 . 9 c m ) 9 ” ( 2 2 . 9 c m ) 8 2 - 7 / 8 ”... -
Page 11: Anti-Tip Dimensions (36")
Anti-Tip Dimensions 36” All Refrigerator/Freezer Anti-Tip Location 7 9 - 3 ” / 8 ” 1 - 1 / 2 ( 2 0 1 . 6 c m ( 3 . 8 c ) m i n t o b o t t o m a n t i - t i p b... -
Page 12: Dimensions (Dual 30")
Dimensions Dual 30” All Refrigerator/Freezer ” ( 7 3 . 7 c 3 - 1 / 2 ” ( 8 . 9 ” ( 7 6 . 2 c ” ( 7 3 . 7 c ” ( 7 6 . -
Page 13: Dimensions (Dual 30" And 36")
Dimensions Dual 30” & 36” All Refrigerator/Freezer ” ( 7 3 . 7 c 3 - 1 / 2 ” ( 8 . 9 ” ( 7 6 . 2 c ” ( 8 8 . 9 c ” ( 9 1 . -
Page 14: Dimensions (Dual 36")
Dimensions Dual 36” All Refrigerator/Freezer ” ( 8 8 . 9 c 3 - 1 / 2 ” ( 8 . 9 ” ( 9 1 . 5 c ” ( 8 8 . 9 c ” ( 9 1 . -
Page 15: Specifications (Dual)
Specifications Dual All Refrigerator/Freezer* Description (2) 30” Units (1) 36” & (1) 30” Unit (2) 36” Units Overall width 60” (152.4 cm) 66” (167.6 cm) 72” (182.9 cm) Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. Overall depth (from rear) To front edge of side trim: 23-3/16”... -
Page 16: Cutout Dimensions (Dual 30")
Cutout Dimensions Dual 30” All Refrigerator/Freezer Electric outlet location 6 ” ( 1 5 . 2 c m ) 9 ” 9 ” ( 2 2 . 9 ( 2 2 . 9 c m ) c m ) 8 2 - 7 / 8 ”... -
Page 17: Anti-Tip Dimensions (Dual 30")
Anti-Tip Dimensions Dual 30” All Refrigerator/Freezer Anti-Tip Location 7 9 - 3 / 8 ” ( 2 0 1 . 6 c m ) m i n t o b o t t o m a n t i - t i p b o a r d 8 0 - 1... -
Page 18: Cutout Dimensions (Dual 30" And 36")
Cutout Dimensions Dual 30” & 36” All Refrigerator/Freezer Electric Outlet Location 6 ” ( 1 5 . 2 c m ) 9 ” 9 ” ( 2 2 . 9 ( 2 2 . 9 c m ) c m ) 8 2 - 7 / 8 ”... -
Page 19: Anti-Tip Dimensions (Dual 30" And 36")
Anti-Tip Dimensions Dual 30” & 36” All Refrigerator/Freezer Anti-Tip Location 7 9 - 3 / 8 ” ( 2 0 1 . 6 c m ) m i n t o b o t t o m a n t i - t i p b o a r d 8 0 - 1... -
Page 20: Cutout Dimensions (Dual 36")
Cutout Dimensions Dual 36” All Refrigerator/Freezer Electric Outlet Location 6 ” ( 1 5 . 2 c m ) 9 ” 9 ” ( 2 2 . 9 ( 2 2 . 9 c m ) c m ) 8 2 - 7 / 8 ”... -
Page 21: Anti-Tip Dimensions (Dual 36")
Anti-Tip Dimensions Dual 36” All Refrigerator/Freezer Anti-Tip Location 7 9 - 3 / 8 ” ( 2 0 1 . 6 c m ) m i n t o b o t t o m a n t i - t i p b o a r d ”... -
Page 22: Overlay Dimensions (30" & 36")
Overlay Dimensions 30” Custom Panels 36” Custom Panels ” 3 / 4 - 1 / ( 1 . 9 ( 7 4 4 ” . 3 c ” 3 / 4 - 1 / ( 1 . 9 ( 8 9 4 ”... -
Page 23: Custom Grille Dimensions (30")
Custom Grille Dimensions 30” Custom Grille 1 / 2 ” ( 1 . 2 3 / 4 ” ( 1 . 9 ” 2 - 3 d i u d i u d i u ( 6 . 4 - 1 4 ”... -
Page 24: Custom Grille Dimensions (36")
Custom Grille Dimensions 36” Custom Grille 1 / 2 ” ( 1 . 2 3 / 4 ” ” ( 1 . 9 2 - 3 d i u d i u d i u ( 6 . 4 ” 4 ”... -
Page 25: Custom Grille Dimensions (Dual 30")
Custom Grille Dimensions Dual 30” Custom Grille 4 - 1 1 / 2 1 / 6 ” ( 1 . 2 ( 1 1 4 ” 3/4” 1/8” 1/2” . 2 7 3 / 4 ” (1.90 cm) ” (.32 cm) ( 1 . -
Page 26: Custom Grille Dimensions (Dual 30" And 36")
Custom Grille Dimensions Dual 30” & 36” Custom Grille 4 - 1 1 / 2 1 / 6 ” 3/4” ( 1 . 2 ( 1 1 1/8” 1/2” 4 ” . 2 7 3 / 4 ” (1.90 cm) (.32 cm) (1.27 cm) ”... -
Page 27: Custom Grille Dimensions (Dual 36")
Custom Grille Dimensions Dual 36” Custom Grille 4 - 1 1 / 2 1 / 6 ” ( 1 . 2 ( 1 1 3/4” 4 ” 1/8” 1/2” . 2 7 3 / 4 ” ( 1 . 9 ”... -
Page 28: Cabinet Information
Cabinet Information Custom panel models, (with 3/4” [1.9 cm], thick panels and custom handles locally supplied), fit flush in 25” (63.5 cm) deep (countertop depth) cabinet openings with no protrusion into room except custom handles Top View Wall 1/4” (.63 cm) space if 25”... - Page 29 Cabinet Information Custom panel models can be installed in standard 24” (61.0 cm) deep openings. However, the door faces and top ventilation grille will protrude 3/4” (1.9 cm) into the room. This is ideal for alignment with full overlay cabinet doors. Top View Flush mount cabinet doors Wall...
-
Page 30: Custom Side Panel Dimensions
Custom Side Panel Dimensions 1” Z-Bracket (2.5 cm) 1/4” (0.6 cm) 4 ” - 3 / ( 5 5 3/4” (1.9 cm) End panel 4 ” - 3 / ( 5 5 ( 2 1 - 7 / 0 . 5 8 ”... -
Page 31: Custom Panel General Information
Custom Panel General Information Custom finishing options • Panel thickness must not exceed 1” (2.5 cm) • All installations must allow for the refrigerator and on hinge side. Thicker panels will interfere with door freezer door to open a minimum of 90˚. swing and clearance. -
Page 32: Custom Door Panel Installation
Custom Door Panel Installation Remove handle side cabinet screws Remove all screws from handle side door trim. and trim with a phillips screwdriver. Remove two screws from top and bottom door trim. Remove handle side door trim. 2-1/16” 2-1/16” 1-11/16” 1-11/16”... - Page 33 Custom Door Panel Installation Slide custom wood panel to the hinge side, ensuring Reinstall handle side door trim “Z” bracket engages the door bracket. and door trim screws. Reinstall cabinet trim and screws.
-
Page 34: Custom Grille Installation
Custom Grille Installation Remove air grille center blade. Remove two 1/4” (0.6 cm) screws with a magnetic extended screwdriver at least 8” (20.3 cm) long. Pull air grille assembly forward. Remove 2 mounting brackets from the grille air assembly. Using eight screws removed from the mounting brackets, attach Insert custom air grille assembly. - Page 35 Custom Grille Installation (cont.) Install two 1/4” (0.6 cm) screws with a magnetic extended Install custom air grille center blade. screwdriver at least 8” (20.3 cm) long.
-
Page 36: General Information
General Information Area Requirements Electrical Requirements Verify the following: It is the customer’s responsibility to: • Unit can fit into residence and can be moved around • Contact a qualified electrical installer. corners and through doorways. • Assure that the electrical installation is adequate and in conformance with the National •... -
Page 37: Water Supply Requirements
• Connect a vertical or horizontal 1/2” (1.2 cm) • Viking Range, LLC is not responsible for property to 1-1/4” (3.2 cm) COLD water line near water area. damage due to improper installation or water connection. -
Page 38: Unpacking Unit
General Information • Most of the unit’s weight is at the top. Extra care is Tip Over Hazard needed when moving the unit to prevent tipping. Appliance is top heavy and tips easily when not completely installed. Keep doors closed until appliance •... -
Page 39: Installation
Installation Place unit in front of cutout. Pull the center grille louver up at an angle and pull out. Using an 8” magnetic nut driver, Remove grille assembly. remove the two 1/4” screws. Hinge Adjustment Front of unit Loosen the four hinge screws. Adjust door. Remove four side screws and remove unit top. - Page 40 Wall 2 x 4 Refrigerator Replace unit top and four side screws. Attach one 2 x 4 to wall stud (refer to dimensions page for exact location). Wall 2 x 4 Refrigerator Plug in power cord to verify operation. If needed, depending on cabinet and depth, attach second 2 x 4 to first 2 x 4.
- Page 41 Remove the two screws and pull protective tray out to Pull supply tubing forward under unit. access water valve. Note: DO NOT use plastic water lines. Flush water line by running two quarts of water Connect supply tube to water valve using into a bucket.
- Page 42 Screw Wall 2 x 4 Refrigerator Drive two screws back into place to secure tray in position Attach positive secure self-tapping bolts If the water line interferes with proper insertion of tray, it to 2 x 4 using a 22” extension. may be stored away until unit is to be moved again.
-
Page 43: Kickplate Installation
Kickplate Installation Using a phillips screwdriver, attach the Align holes on both ends of louvered panels kickplate to the unit and adjust to desired height. and insert screws. Door Stop Adjustment 120˚ 110˚ 90˚ Open refrigerator door so door stop and Remove shoulder screw and place in 90˚... -
Page 44: Final Installation
Final Installation Replace top air grille. Using an 8” magnetic nut driver, replace the two 1/4” screws. Replace the center grille louver. Open door. The display should flash. Press “ACTIVATE CONTROLS” pad and close door. Note: There is a 6 minute delay before the unit starts. -
Page 45: Performance Checklist
Performance Checklist - Verify drain pan is properly installed and there - Verify cabinet size. are no leaks on water connection. - Verify electrical supply and water supply - Install kickplate. (if applicable). - Remove internal packaging and labels and wipe - Install anti-tip device(s) and verify unit is secure. -
Page 46: Verify Operations
Verify Operations Control Panels All Refrigerator FREEZER REFRIGERATOR MAX FRZ MAX REF DOOR OPEN ACTIVATE FAST ALARM DISPLAY HIGHER LOWER CONTROLS TEMP COOL FAST COOL POWER SAB SHOW HIGH TEMP All Freezer FREEZER REFRIGERATOR MAX FRZ MAX REF DOOR OPEN ACTIVATE FAST ALARM... -
Page 47: Service & Registration
Clearly describe the problem that you are having. If you are unable to obtain the name of an authorized service agency, or if you continue to have service problems, contact Viking Range, LLC at 1-888-(845-4641), or write to: VIKING RANGE, LLC... - Page 48 Viking Range, LLC 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-(845-4641) or visit our web site at vikingrange.com F21344E EN (041523)
