SERVICE STATION MANUAL
677654 EN
MSS X10 500ie Executive

Advertisement

Table of Contents
loading

Related Manuals for PIAGGIO MSS X10 500ie Executive

Summary of Contents for PIAGGIO MSS X10 500ie Executive

  • Page 1 SERVICE STATION MANUAL 677654 EN MSS X10 500ie Executive...
  • Page 2 Not all versions/models shown in this publication are available in all countries. The availability of each model should be checked at the official PIAGGIO sales network. © Copyright 2012 - Piaggio & C. S.p.A. All rights reserved. Reproduction of this publication in whole or in part is prohibited.
  • Page 3 MSS X10 500ie Executive This service station manual has been drawn up by Piaggio & C. Spa to be used by the workshops of Piaggio dealers. It is assumed that the user of this manual for maintaining and repairing Piaggio vehicles has a basic knowledge of mechanical principles and vehicle repair technique procedures.
  • Page 5 INDEX OF TOPICS CHAR HARACTERISTICS TOOL OOLING MAIN AINTENANCE TROUBL ROUBLESHOOTING ELE SYS LECTRICAL SYSTEM ENG VE NGINE FROM VEHICLE NGINE INJEC NJECTION SUSP USPENSIONS BRAK SYS RAKING SYSTEM COOL SYS OOLING SYSTEM CHAS HASSIS PRE DE DELIVERY...
  • Page 6 INDEX OF TOPICS CHAR HARACTERISTICS...

  • Page 7: Vehicle Identification

    MSS X10 500ie Executive Characteristics Vehicle identification Identification registration numbers are made up of a prefix and a number, stamped on the chassis and on the engine. These numbers must always be quoted when ordering spare parts. We recommend checking that the chassis registration number stamped on the vehicle corresponds with that on the vehicle documentation.

  • Page 8: Vehicle Specifications

    MSS X10 500ie Executive Characteristics Dimensions and mass VEHICLE SPECIFICATIONS Specification Desc./Quantity Frame A closed double cradle in steel tubes Front suspension Hydraulic telescopic fork Ø 41 mm rear suspension Single shock absorber with electrical preloading adjustment system. Front brake Double disc Ø280 with hydraulic control actuated by the right...

  • Page 9: Tightening Torques

    MSS X10 500ie Executive Characteristics Specification Desc./Quantity Cubic capacity 493 cm³ Bore x Stroke 94 x 71 mm Compression ratio 10.5 ± 0.5: 1 Engine idle speed 1,500 ± 100 rpm Timing system Four valves, single overhead camshaft, chain-driven. Valve clearance Inlet: 0.15 mm...

  • Page 10: Front Brake

    MSS X10 500ie Executive Characteristics FRAME Name Torque in Nm Central stand bracket bolts 19,5-24,5 Side stand fixing bolt 40 to 45 Side stand sensor fixing screws 5 - 7 Throttle cable pipe grommet screw 6 - 10 FRONT BRAKE...
  • Page 11 MSS X10 500ie Executive Characteristics Name Torque in Nm Rear shock absorber - Attachment bracket 130 ÷ 140 Rear shock absorber - Suspension linkage 130 ÷ 140 Right strut screw - Rear suspension linkage 45 ÷ 50 Left strut screws - Right strut bracket 45 ÷...

  • Page 12: Transmission Cover

    MSS X10 500ie Executive Characteristics Name Torque in Nm Splash guard fixing screws 4.5 to 7 MUFFLER Name Torque in Nm Silencer heat guard fixing screw 4 to 5 Silencer screw - silencer bracket 20 ÷ 25 Lambda probe tightening on exhaust manifold...

  • Page 13: Crankcase And Crankshaft

    MSS X10 500ie Executive Characteristics CRANKCASE AND CRANKSHAFT Name Torque in Nm Countershaft fixing nut 25 ÷ 29 Engine oil filter 12 - 16 Engine oil drainage plug 24 ÷ 30 Engine-crankcase coupling screws 11 ÷ 13 Oil pump screws 5 ÷...
  • Page 14 INDEX OF TOPICS TOOL OOLING...
  • Page 15 MSS X10 500ie Executive Tooling SPECIFIC TOOLS Stores code Description 001467Y002 Driver for OD 73 mm bearing 001467Y007 Driver for OD 54-mm bearings 001467Y009 Bell for OD 42-mm bearings 001467Y010 Driver for OD 25 mm bearings 001467Y017 Driver for OD 36 mm bearings...
  • Page 16 MSS X10 500ie Executive Tooling Stores code Description 001467Y035 Bearing housing, outside ø 47 mm 001467Y006 Pliers to extract 20 mm bearings 001467Y008 Pliers to extract 17 mm ø bearings 001467Y013 Pliers to extract ø 15-mm bearings 001467Y034 Pliers to extract ø 15-mm bearings...
  • Page 17 MSS X10 500ie Executive Tooling Stores code Description 020055Y Wrench for steering tube ring nut 001330Y Tool for fitting steering seats 020004Y Punch for removing fifth wheels from headstock 020478Y Punch for driven pulley roller casing 020663Y Water pump shaft oil seal punch...
  • Page 18 MSS X10 500ie Executive Tooling Stores code Description 020074Y Support base for checking crankshaft alignment 020150Y Air heater support 020151Y Air heater 020434Y Oil pressure check fitting 020193Y Oil pressure check gauge 020431Y Valve oil seal extractor TOOL - 18...
  • Page 19 MSS X10 500ie Executive Tooling Stores code Description 020306Y Punch for assembling valve seal rings 020382Y012 bush (valve removing tool) 020329Y Mity-Vac vacuum-operated pump 020330Y Stroboscopic light to check timing 020331Y Digital multimeter 020335Y Magnetic support for dial gauge TOOL - 19...
  • Page 20 MSS X10 500ie Executive Tooling Stores code Description 020363Y 20-mm guide 020364Y 25-mm guide 020412Y 15-mm guide 020439Y 17-mm guide 020483Y 30-mm guide 020376Y Adaptor handle TOOL - 20...
  • Page 21 MSS X10 500ie Executive Tooling Stores code Description 020357Y 32x35-mm Adaptor 020358Y 37x40-mm Adaptor 020359Y 42x47-mm Adaptor 020360Y 52x55-mm Adaptor 020375Y 28 x 30 mm adaptor 020456Y Ø 24-mm adaptor 020477Y 37 mm adaptor 020604Y011 Fitting adapter 020444Y Tool for fitting/ removing the driven pulley...
  • Page 22 MSS X10 500ie Executive Tooling Stores code Description 020444Y009 wrench 46 x 55 020474Y Driving pulley lock wrench 020922Y Diagnosis Tool 020471Y Pin for countershaft timing 020468Y Piston assembly band 020470Y Pin retainers installation tool TOOL - 22...
  • Page 23 MSS X10 500ie Executive Tooling Stores code Description 020475Y Piston position checking tool 020565Y Flywheel lock calliper spanner 020467Y Flywheel extractor 020472Y Flywheel lock wrench 020476Y Stud bolt set 020479Y Countershaft lock wrench TOOL - 23...
  • Page 24 MSS X10 500ie Executive Tooling Stores code Description 020480Y Petrol pressure check kit 020512Y Piston fitting fork 020482Y Engine support 020527Y Engine support base 020648Y Single battery charger TOOL - 24...
  • Page 25 INDEX OF TOPICS MAIN AINTENANCE...

  • Page 26: Maintenance Chart

    MSS X10 500ie Executive Maintenance RESET SERVICE WARNING LIGHT At vehicle ignition, immediately after the ignition check, if there are less than 300 km (187.5 miles) to the next scheduled service, the corresponding icon flashes for 5 seconds. Once the service mile- age has been reached, the icon remains steadily on until it is reset.

  • Page 27: Checking The Spark Advance

    MSS X10 500ie Executive Maintenance Checking the spark advance The ignition advance is determined electronically on the basis of parameters known by the control unit. For this reason it is not possible to interpret the reference values based on the engine rpm.

  • Page 28: Spark Plug

    MSS X10 500ie Executive Maintenance - Connect the diagnostic tester. - Start the engine. - Select the «Parameters» function in this menu. - Set the stroboscopic light control to the traditional four-stroke engine position (1 spark, 2 revs). - Check that the real values of rpm and ignition advance match those measured using the diag- nostic tester.
  • Page 29 MSS X10 500ie Executive Maintenance SPARK PLUGS MUST BE REMOVED WHEN THE ENGINE IS COLD. SPARK PLUGS MAINTENANCE OPERATIONS ARE DESCRIBED IN THE SCHEDULED MAINTENANCE TABLE. USING NON-CONFORMING ELECTRONIC CEN- TRAL UNITS AND ELECTRONIC IGNITIONS OR SPARK PLUGS OTHER THAN THOSE PRESCRIBED MAY SERI- OUSLY DAMAGE THE ENGINE.
  • Page 30 MSS X10 500ie Executive Maintenance Replacement - Remove the oil filler plug «A». - Unscrew the oil drainage cap «B» and drain out all the oil. - Screw in the drainage cap again and fill the hub with the prescribed oil.

  • Page 31: Engine Oil

    MSS X10 500ie Executive Maintenance AGIP FILTER OIL OIL FOR AIR FILTER SPUNGE Mineral oil with specific additives for increased ad- hesiveness Engine oil In four stroke engines, the engine oil is used to lubricate the timing elements, the bench bearings and the thermal group.
  • Page 32 MSS X10 500ie Executive Maintenance Make sure the pre-filter and drainage plug O-rings are in good conditions. Lubricate them and refit the mesh filter and the oil drainage plug, screwing them up to the prescribed torque. Refit the new cartridge filter being careful to lubri- cate the O-ring before fitting it.

  • Page 33: Engine Oil Filter

    MSS X10 500ie Executive Maintenance If the check is carried out after the vehicle has been used, and therefore with a hot engine, the level will be lower; in order to carry out a correct check, wait at least 10 minutes after the engine has been stopped so as to get the correct level.

  • Page 34: Checking The Ignition Timing

    MSS X10 500ie Executive Maintenance Checking the ignition timing - Remove the plastic cap on the flywheel cover -Turn the flywheel until the reference mark «T» on the rotor matches the reference mark on the fly- wheel cover as shown in the figure (TDC). Make...
  • Page 35 MSS X10 500ie Executive Maintenance Anti-evaporation system The breather of vapours from the fuel tank is cre- ated by means of a valve. The black-coloured part of such a valve must be connected to the pipe coming from the tank.
  • Page 36 INDEX OF TOPICS TROUBL ROUBLESHOOTING...
  • Page 37 MSS X10 500ie Executive Troubleshooting Noisy suspension NOISY SUSPENSION Possible Cause Operation Faults in the suspension system If the front suspension is noisy, check: the efficiency of the front shock absorber; the condition of the ball bearings and relevant lock-nuts, the limit switch rubber buffers; and the movement bushings.
  • Page 38 INDEX OF TOPICS ELE SYS LECTRICAL SYSTEM...
  • Page 39 MSS X10 500ie Executive Electrical system 1. 12v-10Ah battery 2. Starter motor 3. Starter relay contact 4. Starter relay coil 5. Regulator 6. Flywheel 7. Chassis ground 8. Chassis engine-ground 9. Ignition switch 10. Fuse No. 1 - 15A 11. Fuse No. 2 - 10A 12.
  • Page 40 MSS X10 500ie Executive Electrical system 20. Preinstallation for satellite navigation system 21. Fuel tank flap actuator 22. Fuel tank flap button 23. Saddle actuator 24. Saddle button 25. LV socket 26. Helmet compartment light switch 27. 12v-5w light unit bulb 28.
  • Page 41 MSS X10 500ie Executive Electrical system 58. Fuel pump 59. Diagnostics socket 60. Left front daylight running light 61. Right front daylight running light 62. Left rear tail light bulb 63. Right rear tail light bulb 64. Left side control lighting 65.
  • Page 42 MSS X10 500ie Executive Electrical system Components arrangement ELE SYS - 42...
  • Page 43 MSS X10 500ie Executive Electrical system 1. Pulsante apertura sella e connettore 2. Pulsante luci di emergenza e connettore 3. Pulsante apertura sportello carburante e connettore 4. Pulsante ASR e connettore - per accedervi rimuovere la modanatura dei pul- santi.
  • Page 44 MSS X10 500ie Executive Electrical system 5. Dispositivo manopola lato destro e connet- tore 6. Dispositivo manopola lato sinistro e connet- tore - per accedervi rimuovere il gruppo ottico anteri- ore. 7. Dispositivo presa USB e connettore - per accedervi rimuovere il gruppo ottico anteri- ore.
  • Page 45 MSS X10 500ie Executive Electrical system 8. Gruppo strumenti e connettore 9. Commutatore a chiave e connettore - per accedervi rimuovere il gruppo cupolino-par- abrezza. 10. Predisposizione accessori (predisposi- zione antifurto e Blue Dash) - per accedervi rimuovere il gruppo cupolino-par- abrezza.
  • Page 46 MSS X10 500ie Executive Electrical system 12. Briglia connessione proiettore 13. Dispositivo comando lampeggiatori - per accedervi rimuovere il gruppo ottico anteri- ore. 14. Pulsanti stop e connettori - per accedervi rimuovere il gruppo ottico anteri- ore. 15. Proiettore anabbagliante sinistro e connet- tore 16.
  • Page 47 MSS X10 500ie Executive Electrical system 17. Predisposizione navigatore GPS - per accedervi rimuovere la modanatura dei pul- santi e la modanatura laterale sinistra. 18. Proiettore abbagliante e luce di posizione Anteriore a LED e connettore - per accedervi rimuovere il gruppo cupolino-par- abrezza.
  • Page 48 MSS X10 500ie Executive Electrical system 19. Proiettore anabbagliante destro e connet- tore 20. Indicatore di direzione anteriore destro e connettore - per accedervi rimuovere il gruppo ottico anteri- ore. 21. Sensore temperatura aria esterna e con- nettore - per accedervi rimuovere il gruppo ottico anteri- ore.
  • Page 49 MSS X10 500ie Executive Electrical system 22. Presa B.T. e connettore - per accedervi rimuovere il gruppo ottico anteri- ore. 23. Antenna immobilizer - per accedervi rimuovere la copertura centrale ed il vano porta oggetti. 24. Pulsante cavalletto laterale e connettore - per accedervi rimuovere la copertura inferiore ed il portello carburante.
  • Page 50 MSS X10 500ie Executive Electrical system 25. Elettroventola radiatore e connettore - per accedervi rimuovere la copertura inferiore ed il portello carburante. 26. Connettore indicatore livello carburante su cruscotto - per accedervi rimuovere la copertura inferiore ed il portello carburante.
  • Page 51 MSS X10 500ie Executive Electrical system 27. Pompa carburante e connettore - per accedervi rimuovere il vano porta casco. 28. Pulsante illuminazione vano casco e con- nettore - per accedervi rimuovere il vano porta casco. 29. Attuatore apertura sella - per accedervi rimuovere il semi codone sinistro.
  • Page 52 MSS X10 500ie Executive Electrical system 30. Sensore anti-ribaltamento - per accedervi rimuovere la pedana appoggiapie- di e la fiancata laterale destra. 31. Attuatore apertura portello carburante - per accedervi rimuovere la pedana appoggiapie- di e la fiancata laterale destra.
  • Page 53 MSS X10 500ie Executive Electrical system 35. Sensore pressione olio 36. Centralina iniezione 37. Iniettore 38. Sensore temperatura motore - per accedervi rimuovere il portello vano porta casco. 39. Sonda lambda e connettore - per accedervi rimuovere il vano porta casco.
  • Page 54 MSS X10 500ie Executive Electrical system 40. Sensore velocità posteriore e connettore - per accedervi rimuovere il vano porta casco. 41. Bobina A.T. 42. Cavi bobina A.T. - per accedervi rimuovere la pedana poggiapiedi e la fiancata sinistra. 43. Cappucci candele di accensione - per accedervi rimuovere il portello ispezione can- dela.
  • Page 55 MSS X10 500ie Executive Electrical system 44. Motorino di avviamento - per accedervi rimuovere il vano porta casco. 45. Presa di diagnosi 46. Negativo batteria 47. Positivo batteria 48. Teleruttore avviamento - per accedervi rimuovere il coperchio vano batte- ria.
  • Page 56 MSS X10 500ie Executive Electrical system 51. Luce illuminazione targa e connettore - per accedervi rimuovere il supporto targa. 52. Indicatore di direzione posteriore destro e connettore 53. Fanale posteriore destro e connettore - per accedervi rimuovere la fiancata ed il gruppo ottico posteriore destro.
  • Page 57 MSS X10 500ie Executive Electrical system 54. Indicatore di direzione posteriore sinistro e connettore 55. Fanale posteriore sinistro e connettore - per accedervi rimuovere la fiancata ed il gruppo ottico posteriore sinistro. 56. Centralina ABS - per accedervi rimuovere il gruppo cupolino-par- abrezza.
  • Page 58 MSS X10 500ie Executive Electrical system 57. Sensore velocità anteriore e connettore - per accedervi rimuovere il gruppo ottico anteri- ore. 58. Attuatore regolazione precarico ammortiz- zatore posteriore e connettore - per accedervi rimuovere la pedana poggiapiedi sinistra e la fiancata sinistra.
  • Page 59 MSS X10 500ie Executive Electrical system 59. Pulsante aumento precarico ammortizza- tore e connettore 60. Pulsante diminuzione precarico ammortiz- zatore e connettore - per accedervi rimuovere il cruscotto. 61. Centralina regolazione precarico ammor- tizzatore posteriore - per accedervi rimuovere lo scudo anteriore.
  • Page 60 MSS X10 500ie Executive Electrical system Located on the frame on the right side of the vehicle - remove the semi-tail fairing and the right rear light unit to reach it. Located on the engine under the support bracket of the cabling.
  • Page 61 MSS X10 500ie Executive Electrical system 7. Fall sensor and fuel door actuator. 8. Voltage regulator. 9. Electric fan connector. 10. Alternator connector. 11. Pick-up connector and oil pressure sensor. 12. Main cable harness. 13. Side stand sensor connector. 14. Saddle opening actuator.
  • Page 62 MSS X10 500ie Executive Electrical system Ignition List of components 1 Battery 12V-10Ah 7 Frame ground node 9 Ignition switch 12 Fuse No. 3 16 Fuse No. 7 18 Fuse No. 9 40 CDI injection control unit 41 Rear ground node...
  • Page 63 MSS X10 500ie Executive Electrical system Battery recharge and starting List of components 1 Battery 12V-10Ah 2 Starter motor 3 Starter relay contact 4 Starter relay coil 5 Voltage regulator 6 Flywheel 7 Frame ground node 8 Frame-engine ground node 9 Ignition switch 12 Fuse No.
  • Page 64 MSS X10 500ie Executive Electrical system 43 Rear ground regulator 53 Engine stop button 54 Side stand switch 69 Stop switch 70 Engine starter button 71 Left stop light 72 Right stop light 84 CDI injection control unit ground node...
  • Page 65 MSS X10 500ie Executive Electrical system 31 Instrument panel 36 Fuel level transmitter 37 Engine water temperature sensor for instrument 40 CDI injection control unit 41 Front ground node 42 Rear ground node 43 Rear ground regulator 44 Instrument panel ground node...
  • Page 66 MSS X10 500ie Executive Electrical system 18 Fuse No. 9 -30A 31 Instrument panel 40 CDI injection control unit 41 Front ground node 42 Rear ground node 43 Rear ground regulator 59 Diagnostics socket 77 Fuse No. 10 -40A 84 CDI injection control unit ground node...
  • Page 67 MSS X10 500ie Executive Electrical system 10 Fuse No. 1 -15A 12 Fuse No. 3 -10A 13 Fuse No. 4 -7,5A 14 Fuse No. 5 -7,5A 16 Fuse No. 7 -5A 18 Fuse No. 9 -30A 19 USB socket 20 Satellite navigator socket...
  • Page 68 MSS X10 500ie Executive Electrical system List of components 1 Battery 12V-10Ah 7 Frame ground node 9 Ignition switch 10 Fuse No. 1 -15A 12 Fuse No. 3 -10A 14 Fuse No. 5 -7,5A 27 Light unit 31 Instrument panel...
  • Page 69 MSS X10 500ie Executive Electrical system 74 Headlight 76 Blue dash device 77 Fuse No. 10 -40A 84 CDI injection control unit ground node 88 ABS Control unit 91 Resistance 120ohm termination of CAN line SHOCK ABSORBER ADJUSTMENT DEVICE List of components...
  • Page 70 MSS X10 500ie Executive Electrical system 59 Diagnostics socket 78 Shock absorber adjustment device 79 Shock absorber adjustment button "UP" 80 Shock absorber adjustment button "DOWN" 81 Encoder for shock absorber electric device 82 Shock absorber actuator 83 Shock absorber adjustment device ground node...
  • Page 71 MSS X10 500ie Executive Electrical system 18 Fuse No. 9 -30A 28 Turn indicator command 29 Emergency light bulb button 30 Turn indicator device 31 Instrument panel 32 Left front turn indicator 33 Right front turn indicator 34 Left rear turn indicator...
  • Page 72 MSS X10 500ie Executive Electrical system Switches check To check buttons and switches, check that, according to their position, the continuity of contacts is correct as indicated in the following charts. Ar: Orange Az: Sky Blue Bi: White Bl: Blue Gi: Yellow Gr: Grey Ma: Brown Ne: Black Ro: Pink Rs:...
  • Page 73 MSS X10 500ie Executive Electrical system TURN INDICATOR SWITCH HORN BUTTON HELMET COMPARTMENT LIGHT SWITCH SADDLE OPENING SWITCH ELE SYS - 73...
  • Page 74 MSS X10 500ie Executive Electrical system MODE BUTTON STAND BUTTON FUEL TANK FLAP BUTTON STOP BUTTONS ELE SYS - 74...
  • Page 75 MSS X10 500ie Executive Electrical system ASR BUTTON Voltage regulator check Con batteria perfettamente carica, misurare la ten- sione presente ai poli della batteria con motore a regime elevato. La tensione non deve superare 15 Volt. Rilevando tensioni superiori, procedere con la sostituzione del regolatore.
  • Page 76 MSS X10 500ie Executive Electrical system Turn signals system check 1. Battery 2. Fuse No. 9 3. ignition switch contacts 4. Fuse No. 5 5. Turn indicators control device 6. Turn indicator control 7. LH indicators 8. RH indicators 9. Turn indicator warning light bulb 10.
  • Page 77 MSS X10 500ie Executive Electrical system 7) Check that the Pink and White-Blue cables connecting the bulbs and the turn indicator device are not interrupted. 8) Check the bulbs ground connection. level indicators WARNING ALL CONTINUITY TESTS MUST BE CARRIED OUT WITH THE CORRESPONDING CONNECTORS DISCONNECTED.
  • Page 78 MSS X10 500ie Executive Electrical system Specification Desc./Quantity Quantity: 1 Power: 12V - 5W Helmet compartment light bulb Type: Cylindrical C5W Quantity: 1 Power: 12V - 5W Instrument panel lighting bulb Type: LED Quantity: 10 Power: - Lighting bulb switches...
  • Page 79 MSS X10 500ie Executive Electrical system Once the main fuse box «A» is removed, unscrew the screw «F» and remove the cover«E» of the secondary fuse box. SECONDARY FUSES SECONDARY FUSES Specification Desc./Quantity Fuse No. 1 Capacity: 15 A Protected circuits: Powered by battery LV socket, helmet compartment bulb, turn indicators control device, instrument panel, antitheft-device pre-installation.
  • Page 80 MSS X10 500ie Executive Electrical system MAIN FUSES Working on the side fins«D», remove the cov- er«C» to access the main fuse «9». On the other side of the battery compartment, the main fuse is located instead «10». The spare fuse «11» is positioned in the same box, but on the side.
  • Page 81 MSS X10 500ie Executive Electrical system Specification Desc./Quantity Fuse No. 10 Capacity: 40A Protected circuits:ABS control unit. Fuse No. 11 Capacity: 30 A Protected circuits:Reserve. Dashboard A - Fuel gauge B - Speedometer C - Fuel reserve warning light D - Insufficient oil pressure warning light...
  • Page 82 MSS X10 500ie Executive Electrical system S - ODO/TRIP Button Actuators master box 1. Shock absorber preloading control unit 2. UP button 3. DOWN button 4. Digital instrument panel 5. Actuator 6. Encoder 7. Ignition switch 8. Battery 9. K Line...

  • Page 83: Battery Installation

    MSS X10 500ie Executive Electrical system In case of failure with the key set to the «ON» position of the «UP» and «DOWN» buttons, and if the icon on the digital display flashes, it is necessary to reset the adjustment system.
  • Page 84 MSS X10 500ie Executive Electrical system 3) Procedure for filling the battery with acid. Position the electrolyte container upside down with the six areas sealed in line with the six battery filler holes. Push the container down with enough force to break the seals.
  • Page 85 MSS X10 500ie Executive Electrical system 12.8 - 13.15 V Bring the battery to full charge, us- ing the 020648Y battery charger: a - select the type of battery with the red switch on the left of the panel battery charger panel...
  • Page 86 MSS X10 500ie Executive Electrical system g - The activation cycle of the new battery lasts for 30 minutes after the ignition of the recharge LED has taken place h - Disconnect the clamps from the battery and check the voltage, if voltages are detected of less than 12.8 V, proceed with a new recharge of the...
  • Page 87 MSS X10 500ie Executive Electrical system 14. Oil pressure warning light (White-Purple) 15. Engine check warning light (Brown-White) 16. ABS Warning Light (Orange) 17. ASR Warning Light (Brown-Sky blue) 18. Parking brake warning light (Black) 19. Engine unable to start warning light (Blue) 20.
  • Page 88 MSS X10 500ie Executive Electrical system ELECTRIC FAN CONNECTOR 1. Ground lead (Black) 2. Power via electric fan relay (Red-Green) PICKUP CONNECTOR 1. Engine speed sensor positive signal (Red) 2. Engine speed sensor negative signal (Brown) 3. Oil pressure sensor signal (White-Purple) REGULATOR CONNECTOR 1.
  • Page 89 MSS X10 500ie Executive Electrical system 13. Pick-up sensor positive (Red) 14. Petrol injector command (Purple) 15. Pick-up sensor negative (Brown) 16. Serial line K (Orange-Black) 17. Immobilizer (Yellow) 18. Side stand signal (Orange) 19. Headlight consent (White-Black) 20. Injection load solenoid (Black-Purple) 21.
  • Page 90 MSS X10 500ie Executive Electrical system FUEL LEVEL TRANSMITTER CONNECTOR 1. Fuel level indicator (White-Green) 2. Ground lead (Black) 3. Not connected COOLANT TEMPERATURE SENSOR CON- NECTOR 1. Electronic injection control unit (Sky blue - Green) 2. Instrument panel (Yellow-Pink) 3.
  • Page 91 MSS X10 500ie Executive Electrical system ABS CONTROL UNIT CONNECTOR 1. Battery-powered (Red) 2. Negative from rear speed sensor (Brown-Black) 3. Positive from rear speed sensor (Brown-Red) 4. Ground lead (Black) 5. Not connected 6. Not connected 7. Not connected 8.
  • Page 92 MSS X10 500ie Executive Electrical system 6. Signal from UP control button (Yellow-Red) 7. Positive for shock absorber actuator (Brown- Red) 8. Negative for shock absorber actuator (Brown- Black) 9. Ground lead (Black) 10. Ground lead (Black) 11. Signal from DOWN control button (Yellow- Black) 12.
  • Page 93 MSS X10 500ie Executive Electrical system STARTER MOTOR POSITIVE CONNECTOR (Red) STARTER MOTOR CONNECTOR NEGATIVE (Black) FRAME-ENGINE GROUND CONNECTOR (Black) FRAME GROUND CONNECTOR (Black) ELE SYS - 93...
  • Page 94 MSS X10 500ie Executive Electrical system ASR BUTTON CONNECTOR 1. Ground (Grey-Black) 2.signal for CDI injection control unit (Sky blue- White) SADDLE BUTTON CONNECTOR 1. Ground lead (Black) 2.Actuator control (Blue-Black) FUEL TANK FLAP BUTTON CONNECTOR 1. Ground lead (Black) 2.Actuator control (Blue-Black)
  • Page 95 MSS X10 500ie Executive Electrical system SHOCK ABSORBER CONTROL BUTTON CON- NECTOR (DOWN) 1. Ground lead (Black-Green) 2.Signal for shock absorber adjustment device (Yellow-Black) EMERGENCY LIGHT BUTTON CONNECTOR 1. Signal for turn indicator control device (Red- Yellow) 2. Live power supply (White) SADDLE ACTUATOR CONNECTOR 1.
  • Page 96 MSS X10 500ie Executive Electrical system HORN CONNECTOR 1. Ground lead (Black) 2. Button control (Grey-Black) LV SOCKET CONNECTOR 1. Not connected 2. Battery-powered (Red-Blue) 3. Ground lead (Black) USB SOCKET CONNECTOR 1. Ground lead (Black) 2. Live (White) SATELLITE NAVIGATOR SOCKET CONNEC- 1.
  • Page 97 MSS X10 500ie Executive Electrical system FRONT TONE WHEEL SENSOR CONNECTOR 1. Negative signal for ABS control unit (Sky blue- black) 2. Positive signal for ABS control unit (Sky blue - Red) REAR TONE WHEEL SENSOR CONNECTOR 1. Negative signal for ABS control unit (Brown- black) 2.
  • Page 98 MSS X10 500ie Executive Electrical system AMBIENT TEMPERATURE SENSOR CONNEC- 1. Ground lead (Black) 2. Signal for instrument (Yellow-Blue) HEADLIGHT CONNECTOR 1. Low light command (Purple) 2. Ground lead (Black) 3. Daylight running light (Yellow-Black) 4. Low beam control (Brown) LAMBDA PROBE CONNECTOR 1.
  • Page 99 MSS X10 500ie Executive Electrical system 4 Live positive from fuse F8 (3A) for daylight run- ning light - License plate light - control lighting - instrument panel lighting (Yellow-Black) 5. Live positive from battery for power supply of fuses F5-F6-F7-F8 (Orange) 6.
  • Page 100 MSS X10 500ie Executive Electrical system RELAY BOX TERMINAL BLOCK 85. Negative from injection control unit (Black-Pur- ple) 86. Live positive from fuse F7 (5A) (Orange-Blue) 87. Positive for Injection loads (Black-Green) 87a. Not connected 30. Positive from F3 fuse (10A) (Red-White) 85.
  • Page 101 MSS X10 500ie Executive Electrical system RIGHT CONTROL DEVICE CONNECTOR 1. Engine stop control (orange) 2. Consent from engine stand button (Brown-Red) 3. Ground lead (Black-Green) 4. MODE button signal (Grey) 5. Ground lead (Black) 6. Control panel lighting (Yellow-Black) 7.
  • Page 102 MSS X10 500ie Executive Electrical system ABS FUSE-BOX CONNECTOR 1. ABS control unit positive (Red) 2. Battery positive (Red) DIAGNOSTICS CONNECTOR 1. Not connected 2. Ground lead (Black) 3. Serial line K (Orange-Black) IGNITION SWITCH CONNECTOR 1. Positive for fuses F5-F6-F7-F8 (Orange) 2.
  • Page 103 MSS X10 500ie Executive Electrical system TURN INDICATORS DEVICE CONNECTOR 1. Command from emergency lights button (Red- Grey) 2. Command from left side indicator light switch (Pink-Black) 3. Command from right side indicator light switch (Sky blue-Black) 4. Left side taillight command (Pink) 5.
  • Page 104 MSS X10 500ie Executive Electrical system LICENSE PLATE LIGHT LAMP CONNECTOR 1.Battery positive from fuse F8 (3A) (Yellow-Black) 2. Ground lead (Black) RIGHT TAILLIGHT CONNECTOR 1. Daylight running light command (Yellow-Black) 2. Ground lead (Black) 3. Stop lights command (White-Black) LEFT TAILLIGHT CONNECTOR 1.
  • Page 105 MSS X10 500ie Executive Electrical system REAR LEFT TURN INDICATOR 1. Ground lead (Black) 2. Turn lights device command (Pink) FRONT RIGHT TURN INDICATOR 1. Ground lead (Black) 2. Command from turn lights device (White-Blue) REAR RIGHT TURN INDICATOR 1. Ground lead (Black) 2.
  • Page 106 MSS X10 500ie Executive Electrical system 1. Sostituire la centralina regolazione ammortizzatore. 2. Sostituire ammortizzatore completo di sistema regolazione precarico. CODICE ERRORE: C1001 - Motore elettrico Causa errore: Battuta meccanica inaspettata Procedure di controllo: 1. Effettuare procedura azzeramento sistema di regolazione precarico ammortizzatore.
  • Page 107 MSS X10 500ie Executive Electrical system 5. Verificare che non sia presente continuita tra i pin del pulsante UP quando non premuto e che sia presente continuità se premuto. 6. Verificare che non sia presente continuita tra i pin del pulsante DOWN quando non premuto e che sia presente continuità...
  • Page 108 MSS X10 500ie Executive Electrical system 2. Verificare che tra i pin 3 e pin 5 connettore dispositivo regolatore ammortizzatore sia presente una tensione di 12 V. Soluzioni (se procedura di controllo da esito negativo): 1. Ripristinare i contatti. 2. Sostituire centralina regolazione ammortizzatore.
  • Page 109 INDEX OF TOPICS ENG VE NGINE FROM VEHICLE...
  • Page 110 MSS X10 500ie Executive Engine from vehicle Exhaust assy. Removal SMONTAGGIO MARMITTA COMPLETA: - Rimuovere preventivamente il vano sottosella e scollegare il connettore della sonda lambda. - Svitare le viti di fissaggio e rimuovere la prote- zione della paratia paracalore dal silenziatore.
  • Page 111 MSS X10 500ie Executive Engine from vehicle - Allentare il dado e svitare la vite disimpegnando la fascia di sostegno del silenziatore al collettore. - Svitare la vite di fissaggio del silenziatore alla staffa di supporto del silenziatore e sfilarlo dal col- lettore prestando attenzione a non farlo cadere.
  • Page 112 MSS X10 500ie Executive Engine from vehicle MONTAGGIO MARMITTA COMPLETA: Per il montaggio procedere nell'ordine inverso allo smontaggio. Prestare attenzione alle coppie di serraggio. N.B. ALWAYS REPLACE THE GRAPHITE BUSHING BETWEEN THE MANIFOLD AND THE SILENCER. MUFFLER Name Torque in Nm...
  • Page 113 MSS X10 500ie Executive Engine from vehicle 6. Fascia sostegno marmitta Removal of the engine from the vehicle SMONTAGGIO MOTORE DAL VEICOLO: Rimuovere preventivamente: - il vano portacasco - le fiancate laterali - la marmitta completa - i puntoni della sospensione posteriore...
  • Page 114 MSS X10 500ie Executive Engine from vehicle - Scollegare il connettore della centralina. - Svitare la vite di fissaggio della massa al motore. - Scollegare la tubazione carburante dall'iniettore premendo sul fermo di sicurezza verde. - Scollegare i cavi dell'acceleratore «A» allentando i dadi di registrazione «B».
  • Page 115 MSS X10 500ie Executive Engine from vehicle - Scollegare il cavo di alimentazione del motorino di avviamento. - Scollegare i connettori del pick-up e del genera- tore. - Rimuovendo le viti dal lato destro del parafango posteriore, rimuovere il cavo del sensore press- ione olio dal passacavo.
  • Page 116 MSS X10 500ie Executive Engine from vehicle - Disimpegnare la fascetta di fissaggio e rimuovere la tubazione radiatore-pompa acqua del circuito di raffreddamento. - Disimpegnare la tubazione del liquido refriger- ante dalla valvola by-pass. - Svitare il dado dell'asse di fissaggio braccio os- cillante lato motore.
  • Page 117 INDEX OF TOPICS NGINE...

  • Page 118: Removing The Driven Pulley

    MSS X10 500ie Executive Engine Removing the driven pulley - Remove the clutch bell. - Remove the stationary driving half-pulley. - Remove the driven pulley assembly with the belt. CAUTION SIMULTANEOUSLY WHEN CHANGING THE BELT, CARRY OUT THE CLEANING THE REAR TRANSMISSION BY MEANS OF BLOWING AND REMOVAL OF ANY DEPOSITS FROM THE FRIC- TION SEALS OF THE CLUTCH BY MEANS OF LIGHT SANDING.
  • Page 119 MSS X10 500ie Executive Engine - Measure the pulley sliding bushing outside di- ameter shown in the figure. Characteristic Diametro minimo ammesso: Ø 29,959 mm Diametro massimo: Ø 29,98 mm Verificare che i rulli non siano danneggiati od usurati. Characteristic Diametro minimo ammesso: Ø...
  • Page 120 MSS X10 500ie Executive Engine Refitting the driving pulley Installing the roller container - Install the spacer with the internal chamfer facing towards the inside. - Position the rollers on the half-pulley as shown in the figure. - The closed side must rest on the inside thrust face of the roller container.
  • Page 121 MSS X10 500ie Executive Engine Installing the fixed driving half-pulley - Insert the spacer. - Install the fixed driving half-pulley and check that it is in contact with the spacer and with the guide bushing of the movable driving pulley.
  • Page 122 MSS X10 500ie Executive Engine - Turn the central pulley nut to horizontally align the holes and install the special tool. N.B. CHECK THAT THE STOP WRENCH TOOL IS EASILY IN- SERTED INTO THE PULLEY AND IN THE ENGINE CRANK- CASE.
  • Page 123 MSS X10 500ie Executive Engine 2 - Verificare il corretto collegamento dei terminali negativi (negativo batteria e negativo motorino di avviamento) fra di loro ed al telaio. SI punto 4 NO punto 5 3 - Recharge and if necessary replace the battery.
  • Page 124 MSS X10 500ie Executive Engine 7- Low trailing speed High electrical absorption Carry out a test of the engine rotation (example: possible melting of the bushes) and if no anomalies are found, replace the starter motor. 8- Low trailing speed...
  • Page 125 MSS X10 500ie Executive Engine The starter control (energised remote control) is slaved to enabling signals by the side stand and the emergency OFF/RUN switch, which does not allow starting given dangerous conditions. The starter control circuit is not controlled by the immobilizer system, therefore before insisting on the starter system, check the consensus of the immobilizer.
  • Page 126 INDEX OF TOPICS INJEC NJECTION...
  • Page 127 MSS X10 500ie Executive Injection Terminals setup CDI INJECTION CONTROL UNIT CONNECTOR 1. Injection warning light (Brown-White) 2. Rpm indicator (Green) 3. CAN L Line (Pink-White) 4. Lambda probe negative (Light blue-Black) 5. Live (Orange-Blue) 6. Battery power (Red-White) 7. Immobilizer aerial (Orange-White) 8.
  • Page 128 MSS X10 500ie Executive Injection EMS circuit diagram Elenco componenti 1 Batteria 12V-10Ah 2 Motorino di avviamento 3 Contatto teleruttore di avviamento 4 Bobina teleruttore di avviamento 5 Regolatore di tensione 6 Volano 7 Nodo massa telaio 8 Nodo massa telaio-motore 9 Commutatore a chiave 12 Fusibile N.3-10A...
  • Page 129 MSS X10 500ie Executive Injection 59 Presa diagnostica 69 Pulsante stop 70 Pulsante avviamento motore 84 Nodo di massa centralina iniezione CDI 91 Resistenza 120ohm terminazione linea CAN Removing the butterfly valve Rimuovere preventivamente: - la fiancata laterale sinistra - la cassa filtro aria - il portello di ispezione corpo farfallato.
  • Page 130 MSS X10 500ie Executive Injection Rimuovere la fascetta di fissaggio del manicotto filtro aria al corpo farfallato. Liberare i cavi di trasmissione dal comando gas «A» allentando i dadi di registro «B». Rimuovere il corpo farfallato completo di centrali- Pump supply circuit...
  • Page 131 MSS X10 500ie Executive Injection Specification Desc./Quantity Ignition switch contacts Fuse No. 7 Injection load solenoid Fuel pump HV coil Fuel injector Injection ECU Electric fan solenoid When switched to «ON», the fuel pump starts to rotate for 2 seconds and then stops. When the engine starts, in the presence of rpm timing signal the pump is continuously supplied.
  • Page 132 MSS X10 500ie Executive Injection Inspecting the injector circuit CARICHI INIEZIONE Specification Desc./Quantity Battery 12V - 12 Ah Fusibile N° 3 10 A Fuse No. 9 Ignition switch contacts Fuse No. 7 Injection load solenoid Fuel pump HV coil Fuel injector...
  • Page 133 MSS X10 500ie Executive Injection Inspecting the injector hydraulics Lift the saddle and remove the engine compartment access cover. Remove the injector, by unscrewing the screw in- dicated in figure. Install the appropriate tool for checking fuel pres- sure and position the manifold over a container graduated by at least 100 cm³.
  • Page 134 MSS X10 500ie Executive Injection Tachometer Scollegare il connettore pompa carburante. Avviare il motore ed attendere il suo arresto. Con cablaggio collegato a centralina ed impianto eseguire un tentativo di avviamento e verificare che la tensione tra i pin 13 e 15 sia di circa 2,8 V ~ - Verificare la continuità...
  • Page 135 MSS X10 500ie Executive Injection 020331Y Digital multimeter HT coil CARICHI INIEZIONE Specification Desc./Quantity Battery 12V - 12 Ah Fusibile N° 3 10 A Fuse No. 9 Ignition switch contacts Fuse No. 7 Injection load solenoid Fuel pump HV coil...
  • Page 136 MSS X10 500ie Executive Injection Specific tooling 020331Y Digital multimeter Check function of fuses No. 3 and 7 for the ECU and injection load solenoid. Coolant temperature sensor INJEC - 136...
  • Page 137 MSS X10 500ie Executive Injection TEMPERATURE SENSOR Specification Desc./Quantity Instrument panel Injection ECU Water temperature sensor Con connettore lato centralina scollegato e connettore sensore temperatura liquido di raffreddamento collegato, verificare che i valori resistivi, tra il pin 9 e massa, corrispondano alla temperatura del motore.
  • Page 138 MSS X10 500ie Executive Injection i.e. there is oxygen or there is not. The sensor is positioned on the exhaust manifold before the catalytic converter in an area where the gas temperature is always high. The temperature at which the sensor works is at least 350°C at 600°C and it has a reaction time of just 50 milliseconds.
  • Page 139 INDEX OF TOPICS SUSP USPENSIONS...
  • Page 140 MSS X10 500ie Executive Suspensions Refitting the front wheel Eseguire le operazioni in senso inverso allo smon- taggio rispettando la coppia prescritta CAUTION PER UN PRIMO LOTTO DI VEICOLI, SARÀ PRESENTE UNA RONDELLA Ø26 mm SOTTO IL DADO DI FISSAGGIO RUO- TA.
  • Page 141 MSS X10 500ie Executive Suspensions - Fit the oil seal retaining circlip. - Grease and fit a new dust gaiter. - Fill the fork leg with the recommended product. Recommended products AGIP FORK 10 W Oil for fork. Characteristic Oil quantity per stem 155 cm³...
  • Page 142 MSS X10 500ie Executive Suspensions - Bleed the hydraulic rod by actuating the stem re- peatedly. - Fit the spring into the stem. CAUTION FIT THE SPRING WITH THE SMALLER PITCH TO THE UP- PER PART OF THE STEM. - Fit the fork leg together with the stem on the fork supporting clamp until it stops.
  • Page 143 MSS X10 500ie Executive Suspensions PAY PARTICULAR ATTENTION TO THE FIT- TING OF THE SPEED SENSOR; PROCEED AS FOLLOWS: - install the speed sensor with its washer. - Measure the height «X» with the aid of a feeler gauge and check that its value is correct.
  • Page 144 MSS X10 500ie Executive Suspensions - Fit the steering bearing upper seat. - Fit the cover plate. - Insert the lower tightening ring nut, screw until it stops and, with the specific tool, tighten to the pre- scribed torque. Specific tooling...
  • Page 145 MSS X10 500ie Executive Suspensions - Fit the spacer between the two ring nuts on the steering tube in the position indicated. - Insert the upper tightening ring nut, screw until it stops and, with the specific tool, tighten to the in- dicated torque.
  • Page 146 MSS X10 500ie Executive Suspensions - Fit the front wheel. Rear LEGENDA: 1. Bussola filettata 2. Distanziale 3. Distanziale 4. Leveraggio sospensione posteriore completo 5. Assieme puntone sinistro 6. Staffa fissaggio puntone sinistro 7. Staffa supporto puntone destro 8. Staffa attacco ammortizzatore 9.
  • Page 147 MSS X10 500ie Executive Suspensions 10. Assieme puntone destro Removing the rear wheel - Rimuovere il supporto marmitta. - Rimuovere il distanziale. - Rimuovere la ruota posteriore. See also Removal Refitting the rear wheel Eseguire le operazioni in senso inverso allo smontaggio rispettando la coppia prescritta.
  • Page 148 MSS X10 500ie Executive Suspensions Swing-arm LEGENDA: 1. Distanziale 2. Distanziale 3. Piastra supporto silent-block sinistra con p.i. 4. Silent block 5. Tirante completo 6. Braccio oscillante completo lato telaio 7. Piastra supporto silent-block destra con p.i. 8. Braccio oscillante completo lato motore...
  • Page 149 MSS X10 500ie Executive Suspensions - Rimuovere il dado del perno lato motore ed es- trarre il perno. - Rimuovere i dadi di fissaggio delle staffe di sup- porto silentblock al telaio. - Rimuovere il dado del perno di collegamento del braccio oscillante lato telaio alle staffe di supporto silentblock e al telaio e sfilare il perno.
  • Page 150 MSS X10 500ie Executive Suspensions - Rimuovere il perno di collegamento del braccio oscillante lato telaio al tirante. Overhaul - Contollare che i silentblock del tirante non risul- tino usurati o deformati, in tal caso procedere con la sostituzione. - Utilizzando la specifica pinza rimuovere l'anello...
  • Page 151 MSS X10 500ie Executive Suspensions - Mediante manico, adattatore e guida inserire il cuscinetto nella propria sede. -Inserire il distanziale e bloccarlo con l'anello elas- tico. Specific tooling 020359Y 42x47-mm Adaptor 020363Y 20-mm guide 020376Y Adaptor handle 002465Y Pliers for circlips - Rimuovere il distanziale sul lato sinistro dell'at- tacco del braccio oscillante sul motore dall'interno.
  • Page 152 MSS X10 500ie Executive Suspensions - Controllare che i silentblock non risultino usurati i deformati, in tal caso procedere con la sostitu- zione. - Controllare che le bussole in materiale plastico del braccio oscillante lato motore e lato telaio non siano usurate o deformate.
  • Page 153 MSS X10 500ie Executive Suspensions - Mediante manico e guida inserire le rulliere nelle proprie sedi. CAUTION LE RULLIERE DEVONO ESSERE INSERITE CON LA FAC- CIA CON LE SCRITTE RIVOLTA VERSO L'ESTERNO DEL BRACCIO OSCILLANTE. Specific tooling 020412Y 15-mm guide...
  • Page 154 MSS X10 500ie Executive Suspensions TL 9150 066, symbol NATO G 460 Refitting - Posizionare la staffa di supporto silent block al telaio con installata la bussola di centraggio avvi- tando senza serrare. - Posizionare il braccio oscillante inserendo l'asse lato telaio.
  • Page 155 MSS X10 500ie Executive Suspensions SEQUENZA DI SERRAGGIO BRACCIO OSCILLANTE E PUNTONI: 1. Posizionare la staffa supporto silent-block, con pre-inserito il part. «D», avvitando senza serrare il part. «A». 2. Posizionare il braccio oscillante inserendo il part. «E». 3. Serrare a coppia i puntoni destro e sinistro lato motore e lato leveraggio.
  • Page 156 MSS X10 500ie Executive Suspensions Removal SMONTAGGIO AMMORTIZZATORE POSTERI- ORE COMPLETO DI DIPOSITIVO ELETTRICO - Rimuovere la fiancata laterale destra. - Rimuovere il vano portacasco. - Rimuovere la pedana poggiapiedi destra. - Rimuovere lo scudo anteriore. CAUTION SOSTENERE ADEGUATAMENTE LA PARTE POSTERI- ORE DEL VEICOLO.
  • Page 157 MSS X10 500ie Executive Suspensions - Estrarre la vite prestando attenzione all'abbas- samento della parte posteriore del veicolo. - Allentare preventivamente il dado di fissaggio anteriore dell'ammortizzatore sulla staffa di attac- - Svitare i dadi di fissaggio della staffa di attacco ammortizzatore al telaio.
  • Page 158 MSS X10 500ie Executive Suspensions - Staccare la connessione dal dispositivo elettrico. - Svitare le viti di fissaggio delle fascette al dispo- sitivo elettrico. - Rimuovere il dispositivo elettrico completo di fascette e tubazione. - Liberare la tubazione dalle fascette di ritegno al telaio.
  • Page 159 MSS X10 500ie Executive Suspensions - Rimuovere la staffa della pedana poggiapiedi svitando le viti indicate. - Estrarre la sospensione completa di ammortiz- zatore, tubazione e dispositivo elettrico. - Al banco da lavoro rimuovere il dado di fissaggio dell'ammortizzatore alla staffa.
  • Page 160 MSS X10 500ie Executive Suspensions CAUTION NON SMONTARE I RACCORDI DELLA TUBAZIONE ONDE EVITARE IL NON FUNZIONAMENTO DELL'AMMORTIZZA- TORE. LO SPURGO DELL'AMMORTIZZATORE POSTERI- ORE E DI TUTTO IL SISTEMA DI REGOLAZIONE ELET- TRONICA DEL PRECARICO È STATO ESEGUITO IN ATMOSFERA PROTETTA.
  • Page 161 MSS X10 500ie Executive Suspensions - Rimuovere le viti di fissaggio della staffa supporto puntone destro alla staffa supporto marmitta e sfi- lare la staffa supporto puntone destro dalla staffa supporto marmitta. - Rimuovere la vite di fissaggio dell'ammortizza- tore posteriore al leveraggio.
  • Page 162 MSS X10 500ie Executive Suspensions - Rimuovere la bussola di centraggio del leverag- gio svitando le ghiere di regolazione. - Rimuovere il leveraggio completo di puntoni face- ndo attenzione al distanziale nel lato sinistro del telaio. See also Side fairings...
  • Page 163 MSS X10 500ie Executive Suspensions - Rimuovere l'anello elastico con l'apposita pinza. Specific tooling 002465Y Pliers for circlips - Con l'ausilio dell'apposito estrattore e della rela- tiva campana rimuovere i cuscinetti a sfere. Specific tooling 001467Y009 Bell for OD 42-mm bearings...
  • Page 164 MSS X10 500ie Executive Suspensions - Mediante pistola termica riscaldare la sede dei cuscinetti a sfera. - Utilizzando l'attrezzo specifico inserire i cusci- netti, uno alla volta, nella propria sede. - Con l'apposita pinza rimontare l'anello elastico di bloccaggio dei cuscinetti.
  • Page 165 MSS X10 500ie Executive Suspensions - Serrare il dado tenendo fermo l'asse del perno. - Riavvitare i puntoni al leveraggio. - Riavvitare le staffe dei puntoni al carter e al supporto marmitta. - Riavvitare l'ammortizzatore al leveraggio. SEQUENZA DI SERRAGGIO LEVERAGGIO SOSPENSIONE POSTERIORE: 1.
  • Page 166 MSS X10 500ie Executive Suspensions 7. Serrare il dado «C» tenendo fermo l'asse «H». LEVERAGGIO SOSPENSIONE POSTERIORE Name Torque in Nm Rear shock absorber - Suspension linkage 130 ÷ 140 Right strut screw - Rear suspension linkage 45 ÷ 50 Left strut screws - Right strut bracket 45 ÷...
  • Page 167 MSS X10 500ie Executive Suspensions - Avvitare la vite di fissaggio posteriore dell'ammortizzatore - Fissare la tubazione al telaio con fascette di ritegno, assicurandosi di posizionarla correttamente come in figura. - Avvitare la staffa della pedana poggiapiedi. AMMORTIZZATORE POSTERIORE Name...
  • Page 168 MSS X10 500ie Executive Suspensions Exhaust bracket LEGENDA: 1. Staffa supporto marmitta (Braccio sospensione) 2. Anello seeger 3. Cuscinetto a sfere Removal - Rimuovere il silenziatore. - Posizionare il mezzo sul cavalletto centrale. SUSP - 168...
  • Page 169 MSS X10 500ie Executive Suspensions - Rimuovere la coppiglia e la copertura del dado. - Con cavalletto laterale abbassato rimuovere il dado di fissaggio della ruota posteriore e il relativo distanziale. - Rimuovere il freno posteriore e il freno di stazio- namento svitando le viti indicate.
  • Page 170 MSS X10 500ie Executive Suspensions - Rimuovere le viti della staffa del leveraggio della sospensione posteriore e disaccoppiare la staffa dal supporto della marmitta. - Rimuovere le viti di fissaggio del parafango pos- teriore alla staffa supporto marmitta. - Rimuovere i dadi di fissaggio del supporto mar- mitta al carter disimpegnandolo dal parafango posteriore.
  • Page 171 MSS X10 500ie Executive Suspensions Overhaul - Mediante le apposite pinze rimuovere l'anello elastico. Specific tooling 002465Y Pliers for circlips - Poggiare il supporto marmitta su supporti di legno per poter lavorare in piano con la parte interna riv- olta verso l'alto.
  • Page 172 MSS X10 500ie Executive Suspensions Refitting Eseguire le operazioni in senso inverso allo smon- taggio rispettando le coppie prescritte. - Installare il sensore ruota fonica con la relativa rondella. - Rilevare la quota «K» mediante l'ausilio di uno spessimetro e verificarne il corretto valore: K= (1,05÷1.85) mm...

  • Page 173: Side Stand

    MSS X10 500ie Executive Suspensions CAUTION SUPPORT THE VEHICLE ADEQUATELY. - Svitare i dadi di fissaggio della staffa supporto del cavalletto centrale al telaio. - Rimuovere il cavalletto centrale completo di staf- fa supporto. - Al banco, sganciare la molla, svitare i relativi bulloni di fissaggio e separare il cavalletto centrale alla staffa di supporto.
  • Page 174 MSS X10 500ie Executive Suspensions CAUTION LOWERING THE SIDE STAND SIMULTANEOUSLY MOVES THE PARKING BRAKE. BEFORE LEAVING BE SURE TO HAVE STORED IT. Locking torques (N*m) Side stand fixing bolt 40 to 45 See also Parking brake SUSP - 174...
  • Page 175 INDEX OF TOPICS BRAK SYS RAKING SYSTEM...
  • Page 176 MSS X10 500ie Executive Braking system Removal - Rimuovere il silenziatore. - Rimuovere i due fissaggi pinza freno posteriore al supporto come indicato in foto. N.B. IF IT IS NECESSARY TO REPLACE OR SERVICE THE BRAKE CALLIPER, BEFORE REMOVING THE FITTINGS...
  • Page 177 MSS X10 500ie Executive Braking system Refitting - Per il montaggio della pinza ripetere in senso in- verso le operazioni precedentemente descritte. Locking torques (N*m) Screw tightening calliper to support 20 ÷ 25 If the calliper is replaced: CAUTION ALWAYS USE NEW COPPER WASHERS.
  • Page 178 MSS X10 500ie Executive Braking system Refitting Per il montaggio operare come descritto di segui- - Inserire le due pastiglie all'interno della pinza. - Avendo cura di posizionare correttamente la mol- la di ritegno, avvitare il perno di bloccaggio pasti- glie alla giusta coppia di bloccaggio applicando il prodotto consigliato.
  • Page 179 MSS X10 500ie Executive Braking system See also Removal Refitting To fit, proceed as follows: - Insert the two pads in the callipers. - Screw the two pad lock pins to the correct torque, and apply the recommended product. - Fit the calliper on its support, tightening the two screws to the prescribed torque.
  • Page 180 MSS X10 500ie Executive Braking system Rear - combined - Remove the rubber cap from the bleed screw. - Insert a rubber pipe in the bleed screw to permit the brake fluid to be recovered. - With the brake lever, load the system and bring it up to the required pressure.
  • Page 181 MSS X10 500ie Executive Braking system - Ripristinare il livello liquido freni in vaschetta. In caso di necessità è possibile eseguire lo spurgo anche mediante pompa a depressione specifica THE BLEEDING OPERATIONS OF THE BRAKING SYSTEM, EVEN FOR THE VERSION EQUIPPED WITH ABS SYSTEM, DO NOT ALLOW THE USE OF DIAGNOSTIC TESTER, AND ARE THERE- FORE EQUAL TO THOSE DESCRIBED FOR THE STANDARD BRAKE SYSTEM.

  • Page 182: Brake Pipes

    MSS X10 500ie Executive Braking system Ad operazione conclusa serrare la vite di spurgo olio alla coppia prescritta. N.B. WHILE REFITTING, REPLACE THE COPPER GASKETS ON THEIR FITTINGS. WARNING BRAKE FLUID IS HYGROSCOPIC; THAT IS, IT ABSORBS MOISTURE FROM THE SURROUND- ING AIR.
  • Page 183 MSS X10 500ie Executive Braking system - Release the pipes from the spring. - Disconnect the front left brake caliper line from the ABS unit. The first section of the line is now free. - Disconnect the right hand brake master line from the ABS unit.
  • Page 184 MSS X10 500ie Executive Braking system INTEGRAL REAR BRAKE PIPES REMOVAL - Remove all the plastics of the bodywork, includ- ing the handlebar. - Disconnect the brake pipes from the rear calliper and drain the system collecting the fluid. - Disconnect the brake pipes from the right front calliper and drain the system collecting the fluid.
  • Page 185 MSS X10 500ie Executive Braking system - Release the pipes from the springs. - Rimuovere le fascette di fisaggio della tubazione al telaio. - Release the pipes from the spring. - Disconnect the rear hand brake caliper line from the ABS unit.
  • Page 186 MSS X10 500ie Executive Braking system - Remove the metal clamp placed inside the front wheel housing. - Disconnect the pipes from the distribution valve. - Disconnect the front right brake caliper line from the ABS unit. The second section of the line is now free.

  • Page 187: Parking Brake

    MSS X10 500ie Executive Braking system - Release the pipes from the collar. - Disconnect the pipes from the left brake pump. INSTALLAZIONE TUBAZIONI FRENO - Per il montaggio eseguire le operazioni di smontaggio in senso inverso. THE CONTROL UNIT, SUPPLIED AS A SPARE, IS SEALED AND COMES WITH BRAKE FLUID.
  • Page 188 MSS X10 500ie Executive Braking system LEGENDA: 1. Cavalletto laterale 2. Trasmissione comando freno di stazionamento 3. Pinza freno di stazionamento 4. Coppia pasticche freno PARKING BRAKE CALLIPER REMOVAL - Undo the two screws indicated and remove the calliper from the silencer support bracket.
  • Page 189 MSS X10 500ie Executive Braking system - Unscrew the two screws indicated to remove the protection, then loosen the indicated nut to remove the transmission. - Per il rimontaggio eseguire le operazioni in senso inverso. Dopo aver effettuato la registrazione serrare il dado indicato alla coppia prescritta.
  • Page 190 INDEX OF TOPICS COOL SYS OOLING SYSTEM...

  • Page 191: Circuit Diagram

    MSS X10 500ie Executive Cooling system Circuit diagram 1. Vaso di espansione 2. Tubo ritorno vaso espansione 3. Tubo mandata vaso espansione 4. Radiatore 5. Elettroventola 6. Tubazione collegamento termostato-radiatore 7. Tubazione collegamento radiatore-pompa acqua 8. Termostato 9. Tubazione collegamento testa-termostato 10.
  • Page 192 MSS X10 500ie Executive Cooling system Specification Desc./Quantity Starts opening 90 ± 2°C ELECTRIC VENTILATION Specification Desc./Quantity Electric ventilation starts at 100° C Electric ventilation stops at 90° C WATER PUMP Specification Desc./Quantity Type Centrifugal Control Coaxial to crankshaft RADIATOR Specification Desc./Quantity...

  • Page 193: Coolant Replacement

    MSS X10 500ie Executive Cooling system Coolant replacement Rimuovere preventivamente: - il gruppo ottico anteriore - le fiancate laterali destre e sinistre - la copertura inferiore - la pedana poggiapiedi destra. SVUOTAMENTO IMPIANTO DI RAFFREDDA- MENTO Allentare la fascetta e dopo aver sfilato il tubo di mandata alla pompa acqua, lasciar defluire il liq- uido in un contenitore di capacità...
  • Page 194 MSS X10 500ie Executive Cooling system System bleed Sollevare la sella e svitare le viti di fissaggio del portello di accesso corpo farfallato. Assicurarsi che il livello del liquido di raffredda- mento sia compreso tra i riferimenti di «MIN» e «MAX»...

  • Page 195: Water Pump

    MSS X10 500ie Executive Cooling system Serrare la valvola di spurgo rispettando la coppia prescritta. Ripristinare il livello del liquido di raf- freddamento all'interno del vaso di espansione. Locking torques (N*m) Bleed screw Water pump Water pump Rilevando rumosità o perdite di liquido dal tubo di drenaggio della pompa acqua, è...
  • Page 196 MSS X10 500ie Executive Cooling system - Verificare che il coperchio pompa acqua non pre- senti deformazioni o crettature. - Verificare le buone condizioni dell'O-Ring di ten- uta. - In caso contrario sostituire il componente. - Adequately fit a new O-ring, be careful to lubricate it with petroleum jelly grease.
  • Page 197 MSS X10 500ie Executive Cooling system Check 1) Visually inspect that the thermostat is not dam- aged. 2) Fill a metal container with approx. 1 litre of wa- ter. Immerse the thermostat, and keep it in the centre of the container.
  • Page 198 MSS X10 500ie Executive Cooling system Cooling system fluid 1.75 l COOL SYS - 198...
  • Page 199 INDEX OF TOPICS CHAS HASSIS...
  • Page 200 MSS X10 500ie Executive Chassis Rear handlebar cover - To remove the dashboard, first remove the han- dlebar cover. - Then undo the central screw. - Operating from both sides, unscrew the two screws inside the glove-box of the dashboard.
  • Page 201 MSS X10 500ie Executive Chassis - Unscrew and remove the two side screws. - Unscrew and remove the two central screws. - Remove the central cover. - Remove the expansion tank cap by unscrewing it and temporarily close it with a clean cloth so that no dust or other impurities get into the coolant.
  • Page 202 MSS X10 500ie Executive Chassis - Remove the internal cover of the dashboard glove-box. - Working inside the left compartment, disconnect the USB socket connector. - Disconnect the instrument panel connector. - Remove the dashboard. - Remove the cloth and insert the cap in the ex- pansion tank.
  • Page 203 MSS X10 500ie Executive Chassis - Remove the side moulding by sliding it off the fittings. See also Front handlebar cover Taillight assy. First remove the rear centre cover and the side fairing on the affected side. - Operating on the inside and rear of the fairing,...
  • Page 204 MSS X10 500ie Executive Chassis Svitare e togliere le due viti, superiore ed inferiore, e rimuovere la copertura della pedana passeg- gero. Svitare la vite di fissaggio della pedana poggia- piedi passeggero. Rimuovere la pedana poggiapiedi passeggero, prestando attenzione alle linguette di incastro.
  • Page 205 MSS X10 500ie Executive Chassis Svitare le viti di fissaggio della parte posteriore della pedana. Svitare le viti di fissaggio della parte anteriore della pedana. Estrarre la pedana poggiapiedi. CHAS - 205...
  • Page 206 MSS X10 500ie Executive Chassis - Remove the lower cover of the footrest, being careful not to damage it. Locking torques (N*m) Footrests central fixing screws Footr- 4.5 to 7 ests rear fixing screws Passenger foot- 4.5 to 7 rest fixing screws Passenger footrest 4.5 to 7...
  • Page 207 MSS X10 500ie Executive Chassis - Remove the side paying close attention and pull- ing it out from the five side retainers and from the front one. The operations for the removal of the side are de- scribed for one but apply to both.
  • Page 208 MSS X10 500ie Executive Chassis - Remove the central moulding, pulling it outwards. - Undo the rear fixing screws of the side frame. - Remove the side frame. - Repeat the operations also for the other side of the vehicle.
  • Page 209 MSS X10 500ie Executive Chassis - Remove the central rear protection. - Remove the rear lower cover. - Undo the fixing screws of the central fairing. - Using a screwdriver deviate the central fairing, detaching the clips and loosen the screw below the side fairing.
  • Page 210 MSS X10 500ie Executive Chassis - Undo the rear fixing screw of the side fairing. - Undo the screw fixing the side fairing to the foot- rest. - Undo the screw fixing the rear light unit to the battery compartment.
  • Page 211 MSS X10 500ie Executive Chassis - Disconnect the electrical connectors of the rear light unit. Remove the side fairing complete with taillight. - Repeat the operations also for the other side of the vehicle. CAUTION PAY ATTENTION TO THE PRESENCE OF THE PLATES.
  • Page 212 MSS X10 500ie Executive Chassis - Disconnect the license plate light connector and remove the license plate support. Locking torques (N*m) Splash guard fixing screws 4.5 to 7 See also Side fairings Air filter To remove the filter box it is first necessary to re- move the left side panel.

  • Page 213: Rear Mudguard

    MSS X10 500ie Executive Chassis Rear mudguard - Working on the left side of the vehicle, undo and remove the two screws fixing the filter box and the rear mudguard. - Undo and remove the two fixing screws on the...
  • Page 214 MSS X10 500ie Executive Chassis - Working from both sides, unscrew and remove the upper fixing screws. - Remove the main fuse cover. - Undoing the screw, disconnect the positive from the cable. - Release the cabling from the helmet compart- ment, moving the cables from below, through the opening.
  • Page 215 MSS X10 500ie Executive Chassis - Undo and remove the two screws from inside the helmet compartment and release the saddle lock. - Disconnect the two connectors of the helmet compartment light bulb switch. - Remove the Seeger ring and, retrieving the washer, remove the saddle lifting piston from the linkage.
  • Page 216 MSS X10 500ie Executive Chassis - Remove the helmet compartment paying atten- tion to the saddle linkage. - Unscrew the clamp if necessary. Locking torques (N*m) Helmet compartment fixing screws 4.5 to 7 See also Seat Side fairings Rear central cover...
  • Page 217 MSS X10 500ie Executive Chassis ASTM D 3306 - ASTM D 4656 - ASTM D 4985 - CUNA NC 956-16 Characteristic Cooling system fluid 1.75 l RADIATOR REMOVAL - Undo the central screw and pull the wheel hous- ing. - Unscrew and remove the two fixing screws and collect their washers.
  • Page 218 MSS X10 500ie Executive Chassis - Remove the fan cover by unscrewing and re- moving the two fixing screws. - working from the right side, unhook the two clamps. - working from the left side, unhook the two clamps. - Remove the clamp and release the electric fan connector.
  • Page 219 MSS X10 500ie Executive Chassis - If it is necessary to remove the electric fan un- screw and remove the fixing screw. See also Headlight assy. Side fairings Footrest Handles and top side fairings REMOVAL OF SIDE HANDLES The following operations only refer to one handle, but they apply to both.
  • Page 220 MSS X10 500ie Executive Chassis - Pull upward on the handle cover, making sure of the presence of the clips on the relative pins. - Undo the fixing screws of the handle, retrieving the washers. - Remove the handle. REFITTING OF REAR HANDLES...
  • Page 221 MSS X10 500ie Executive Chassis Battery - Undo the fixing screws of the rear frame. - Remove the rear frame complete with battery door. - Remove the battery after disconnecting its clamps. CHAS - 221...
  • Page 222 INDEX OF TOPICS PRE DE DELIVERY...

  • Page 223: Electrical System

    MSS X10 500ie Executive Pre-delivery Tightening torques inspection - Lower fixing of the rear shock absorber struts to the brackets - Fixing of the shock absorber strut left bracket to the crankcase - Fixing of the right strut shock absorber to the exhaust support bracket...
  • Page 224 MSS X10 500ie Executive Pre-delivery WARNING BATTERY ELECTROLYTE IS TOXIC AND IT MAY CAUSE SERIOUS BURNS. IT CONTAINS SUL- PHURIC ACID. AVOID CONTACT WITH YOUR EYES, SKIN AND CLOTHING. IN CASE OF CONTACT WITH YOUR EYES OR SKIN, RINSE WITH ABUNDANT WATER FOR ABOUT 15 MINUTES AND SEEK IMMEDIATE MEDICAL ATTENTION.
  • Page 225 ABS: 65 Air filter: 30, 212 Battery: 63, 83, 221 Brake: 174, 182, 187 Bulbs: Coolant: 136, 193 Electric: Engine oil: 31 Fuses: 78 Headlight: 219 Identification: 7 Maintenance: 26 Oil filter: 33 Recommended products: Spark plug: 28, 71 Stand: 173 Start-up: Suspension: 37 Switch:...
  • Page 226 Vehicle: 7, 110, 113...
