- Page 1 Instruction Manual Bedienungsanleitung Manuel d’utilisation Manuale di Istruzioni...
- Page 2 NOTICE All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-to-date product literature, visit horizonhobby.com and click on the support tab for this product. Meaning of Special Language The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product: NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND a little or no possibility of injury.
-
Page 3: Table Of Contents
5.27 in (134mm) 19.4 oz (550 g) Height Flying Weight Box Contents: ™ • Conspiracy BNF Quadcopter - 2- and 3-blade Propellers - Prop Nut Wrench - Video transmitter antenna - Hook and Loop Strap Needed to Complete: • DSM2 ® /DSMX ®... -
Page 4: First Flight Preparation
First Flight Preparation Flying Checklist ❏ Always turn the transmitter on fi rst • Remove and inspect contents ❏ Plug the fl ight battery into the lead from the ESC • Begin charging the fl ight battery ❏ Allow the ESC to initialize and arm properly •... -
Page 5: Assembly
Powering on without the antenna will damage the transmitter. Install the Propellers The quadcopter comes with both 2 and 3-blade propellers. Install either the 2-blade OR the 3-blade propellers. Do not combine the different propellers. -
Page 6: Transmitter Setup
Transmitter Setup DX6, DX7 (Gen 2), DX8 (Gen 2), DX9, DX18, DX20 SETUP LIST FUNCTION LIST Model Type Servo Setup Airplane Chan Travel Reverse Chan Travel Reverse 150/150 Normal 148/148 Reverse F-Mode Setup 148/148 Reverse 100/100 Normal Switch 1 Inhibit 148/148 Normal AUX1... -
Page 7: Transmitter And Receiver Binding
Transmitter and Receiver Binding To bind or re-bind your quadcopter to your chosen transmitter, follow the directions below. Binding Procedure 1. Select the correct model in your transmitter. 2. Power off your transmitter. 3. Lower the throttle fully. 4. With the transmitter off, power on the quadcopter. The receiver will attempt to connect to the last transmitter it was bound to. -
Page 8: Using The Video Transmitter
Elevator Left Side View Left Side View Elevator down Elevator up Forward Backward Aileron Rear View Rear View Aileron right Aileron left Left Right Using the Video Transmitter NOTICE: Never power on the video transmitter without the antenna installed. Powering on without the antenna will damage the video transmitter. -
Page 9: Adjusting The Fpv Camera Angle
Adjusting the FPV Camera Angle To adjust the FPV camera angle: 1. Loosen the FPV camera angle adjustment screw on both sides of the quadcopter. DO NOT remove the screws. 2. Rotate the camera up or down to the desired angle. 3. -
Page 10: Preparing The Conspiracy Quadcopter For Flight
Preparing the Conspiracy Quadcopter for Flight 1. Before each fl ight, ALWAYS power on the transmitter before connecting the fl ight battery to the quadcopter. After each fl ight, disconnect the fl ight battery from the quadcopter before powering off the transmitter. NOTICE: Connecting the fl... -
Page 11: Troubleshooting Guide
Troubleshooting Guide Problem Possible Cause Solution Quadcopter not initialized on a level Disconnect the fl ight battery, center the control Quadcopter control response is surface trim and re-initialize the quadcopter inconsistent or requires extra Adjust battery position so quadcopter trim to neutralize movement Battery not correctly placed balances in the center of the frame Motor arm switch is in the OFF position... -
Page 12: Parts Explosion
Parts Explosion Parts Listings Part # Description Part # Description 1 BLHA1002 5x4 FPV Race Prop, 2Blade, Green 11 BLH02005 Hardware Kit 2 BLHA1003 5x4 FPV Race Prop, 3Blade, Green 12 BLH02006 M5 LockNut 3 BLHA1006 20A ESC BLHeli Opto Quad Pack FC32 Flight Controller 13 SPMFC3206 Rev 6 w/SPM RX Connector... -
Page 13: Limited Warranty
Limited Warranty What this Warranty Covers or Horizon directly. This will enable Horizon to better answer your questions and service you in the event that you may need any Horizon Hobby, LLC, (Horizon) warrants to the original purchaser assistance. For questions or assistance, please visit our website that the product purchased (the “Product”) will be free from at www.horizonhobby.com, submit a Product Support Inquiry, or defects in materials and workmanship at the date of purchase. -
Page 14: Warranty And Service Contact Information
Warranty and Service Contact Information Country of Horizon Hobby Contact Information Address Purchase Horizon Service Center servicecenter.horizonhobby.com/ (Repairs and Repair Requests) RequestForm/ productsupport@horizonhobby.com Horizon Product Support United States 4105 Fieldstone Rd (Product Technical Assistance) of America Champaign, Illinois, 61822 USA 877-504-0233 websales@horizonhobby.com Sales... - Page 15 ©2016 Horizon Hobby, LLC. Blade,Conspiracy, SAFE, the SAFE logo, DSM, DSM2, DSMX, the BNF logo, ModelMatch, EC3 and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC. The Spektrum trademark is used with permission of Bachmann Industries, Inc.
