- Page 1 ASROCK P4S55FX+ P4S55FX User Manual http://www.manuallib.com/file/2446253 From ManualLib.com ManualLib.com collects and classifies the global product instrunction manuals to help users access anytime and anywhere, helping users make better use of products. Home: http://www.manuallib.com/ Chinese: http://www.shuomingshuku.com/ This Manual: http://www.manuallib.com/file/2446253...
-
Page 2: User Manual
User Manual Version 1.01 Published March 2004 Copyright©2004 ASRock INC. All rights reserved. This Manual: http://www.manuallib.com/file/2446253... -
Page 3: Copyright Notice
(including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock has been advised of the possibility of such damages arising from any defect or error in the manual or product. -
Page 4: Table Of Contents
4.2 Support CD Information ..........25 4.2.1 Running Support CD ..........25 4.2.2 Drivers Menu ............25 4.2.3 Utilities Menu ............25 4.2.4 ASRock “PC-DIY Live Demo” Program ....25 4.2.5 Contact Information ..........25 Appendix ............26 1. Advanced BIOS Setup Menu .......... 26 2. -
Page 5: Introduction
In case any modifications of this manual occur, the updated version will be available on ASRock website without further notice. You may find the latest memory and CPU support lists on ASRock website as well. ASRock website http://www.asrock.com 1.1 Package Contents... -
Page 6: Specifications
LAN: Speed: 802.3u (10/100 Ethernet), supports Wake-On-LAN Hardware Monitor: CPU temperature sensing Chassis temperature sensing CPU overheat shutdown to protect CPU life (ASRock U-COP)(see CAUTION 2) CPU fan tachometer Chassis fan tachometer Voltage monitoring: +12V, +5V, +3V, Vcore PCI slots: 5 slots with PCI Specification 2.2... - Page 7 ASRock I/O Plus : 1 PS/2 mouse port, 1 PS/2 keyboard port, 1 serial port: COM1, 1 parallel port: ECP/EPP support, 6 default USB 2.0 ports, 1 RJ 45 port, Audio Jack: Line In / Line Out / Microphone BIOS: AMI BIOS Supports “Plug and Play”...
-
Page 8: Motherboard Layout (P4S55Fx+)
1.3 Motherboard Layout (P4S55FX+) 21.8cm (8.6 in) Mouse PS2_USB_PWR1 CPU_FAN1 Keyboard COM1 IDE2 USB 2.0 T: USB2 B: USB3 USB 2.0 Top: T: USB0 RJ-45 B: USB1 USB 2.0 T: USB4 B: USB5 655FX AUDIO1 AUX1 JR1 JL1 1.5V_AGP1 IDE1 Audio CODEC PCI 1... -
Page 9: Motherboard Layout (P4S55Fx)
1.4 Motherboard Layout (P4S55FX) 21.8cm (8.6 in) Mouse PS2_USB_PWR1 CPU_FAN1 Keyboard COM1 IDE2 USB 2.0 T: USB2 B: USB3 USB 2.0 Top: T: USB0 RJ-45 B: USB1 USB 2.0 T: USB4 B: USB5 655FX AUDIO1 AUX1 JR1 JL1 1.5V_AGP1 IDE1 Audio CODEC PCI 1... -
Page 10: Asrock I/O Plus
1.5 ASRock I/O Plus (P4S55FX+ / P4S55FX) Parallel Port USB 2.0 Ports (USB0, USB1) RJ-45 Port USB 2.0 Ports (USB2, USB3) Line In (Light Blue) Serial Port: COM1 Line Out (Lime) PS/2 Keyboard Port (Purple) Microphone (Pink) PS/2 Mouse Port (Green) USB 2.0 Ports (USB4, USB5) -
Page 11: Installation
Chapter 2 Installation P4S55FX+ / P4S55FX is an ATX form factor (12.0-in x 8.6-in, 30.5 cm x 21.8 cm) motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Pre-installation Precautions Take note of the following precautions before you install motherboard components or change any motherboard settings. -
Page 12: Cpu Installation
2.1 CPU Installation Step 1. Unlock the socket by lifting the lever up to a 90 angle. Step 2. Position the CPU directly above the socket such that its marked corner matches the base of the socket lever. Step 3. Carefully insert the CPU into the socket until it fits in place. -
Page 13: Installation Of Memory Modules (Dimm)
2.3 Installation of Memory Modules (DIMM) P4S55FX+ / P4S55FX motherboard provides four 184-pin DDR (Double Data Rate) DIMM slots, and supports Dual Channel Memory Technology. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR DIMM pair in the slots of the same color. In other words, you have to install identical DDR DIMM pair in Dual Channel A (DDR1 and DDR3;... -
Page 14: Installing A Dimm
Installing a DIMM Please make sure to disconnect power supply before adding or removing DIMMs or the system components. Step 1. Unlock a DIMM slot by pressing the retaining clips outward. Step 2. Align a DIMM on the slot such that the notch on the DIMM matches the break on the slot. -
Page 15: Expansion Slots (Pci And Agp Slots)
PCI slots: PCI slots are used to install expansion cards that have the 32-bit PCI interface. AGP slot: The AGP slot is used to install a graphics card. The ASRock AGP slot has a special locking mechanism which can securely fasten the graphics card inserted. -
Page 16: Jumpers Setup
2.5 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on pins, the jumper is “Short”. If no jumper cap is placed on pins, the jumper is “Open”. The illustration shows a 3-pin jumper whose pin1 and pin2 are “Short”... -
Page 17: Onboard Headers And Connectors
2.6 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage of the motherboard! FDD Connector (33-pin FLOPPY1) FLOPPY1 Pin1 (see p.7 No. - Page 18 HDD power connector connector of the power supply. USB_PWR USB 2.0 Header ASRock I/O Plus provides you 6 default USB 2.0 ports on the (9-pin USB67) DUMMY rear panel. If the rear USB ports (see p.7 No.
- Page 19 Chassis Fan Connector Please connect the chassis fan cable to this connector and (3-pin CHA_FAN1) +12V match the black wire to the CHA_FAN_SPEED (see p.7 No. 16 / p.8, No. 15) ground pin. CPU Fan Connector Please connect the CPU fan cable to this connector and (3-pin CPU_FAN1) +12V...
-
Page 20: Serial Ata (Sata) Hard Disks Installation
SATA HDDs to different power wires to prevent intervention. As to Hot Swap support, please refer to the updates of later version driver that supports Hot Swap function on our website www.asrock.com NOTE What is Hot Plug Function? If the SATA HDDs are NOT set for RAID configuration, it is called “Hot... -
Page 21: Making An Sata Driver Diskette
SATA driver diskette before you start the OS installation. STEP 1: Insert the ASRock Support CD into your optical drive to boot your system. (Do NOT insert any floppy diskette into the floppy drive at this moment!) STEP 2: During POST at the beginning of system boot-up, press <F11>... -
Page 22: Bios Setup
Chapter 3 BIOS Setup 3.1 BIOS Setup Utility This section explains how to use the BIOS Setup Utility to configure your system. The Flash Memory on the motherboard stores the BIOS Setup Utility. You may run the BIOS Setup Utility when you start up the computer. Please press <F2> during the Power-On-Self-Test (POST) to enter the BIOS Setup Utility, otherwise, POST continues with its test routines. -
Page 23: Main Menu
Navigation Key(s) Function Description <F1> Displays the General Help Screen <ESC> Jumps to the Exit menu or returns to the upper menu from the current menu Moves cursor up or down between fields Selects menu to the left or right + / - Increases or decreases values <Enter>... - Page 24 TYPE To set the type of the IDE device, first, please select “IDE Devices” on Main menu and press <Enter> to get into the sub-menu. Then, select among “Primary IDE Master”, “Primary IDE Slave”, “Secondary IDE Master”, and “Secondary IDE Slave” to make configuration of its type. After making your selections on this sub-menu, press <ESC>...
-
Page 25: Advanced, Security, Power, Boot, And Exit Menus
[CD/DVD]: This is used for IDE CD/DVD drives. [ARMD]: This is used for IDE ARMD (ATAPI Removable Media Device), such as MO. Cylinders This is used to configure the number of cylinders. Refer to the drive documentation to determine the correct value. Heads This is used to configure the number of read/write heads. -
Page 26: Software Support
Media Player to play the file. 4.2.5 Contact Information If you need to contact ASRock or want to know more about ASRock, welcome to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer for further information. This Manual: http://www.manuallib.com/file/2446253... -
Page 27: Appendix
Appendix: Advanced BIOS Setup This section will introduce you the following BIOS Setup menus: “Advanced,” “Security,” “Power,” “Boot,” and “Exit.” 1. Advanced BIOS Setup Menu AMIBIOS SETUP UTILITY - VERSION 3.31a Advanced Security Main Exit Power Boot [ Setup Help ] CPU Host Frequency Auto 133MHz... -
Page 28: Chipset Configuration
Flexibility: The default value of this option is [Disabled]. It will allow better tolerance for memory compatibility when it is set to [Enabled]. Chipset Configuration: AMIBIOS SETUP UTILITY - VERSION 3.31a Advanced Chipset Configuration [ Setup Help ] <Enter> to select the Auto AGP Data Rate AGP data transfer rate. - Page 29 USB Controller: Use this to enable or disable the use of USB controller. USB 2.0 Support: Use this to enable or disable the use of USB 2.0 support. USB Device Legacy Support: Use this to enable or disable the support to emulate legacy I/O devices such as mouse, keyboard,...
-
Page 30: Resource Configuration
Resource Configuration: AMIBIOS SETUP UTILITY - VERSION 3.31a Advanced Resource Configuration [ Setup Help ] <Enter> to select PCI PCI Latency Timer (PCI Clocks) clocks. Leave on Primary Graphics Adapter default setting for the best PCI performance. F1:Help F9:Setup Defaults :Select Item +/-:Change Values Esc:Previous Menu... - Page 31 OnBoard Serial Port Use this to set addresses for the on-board serial ports or disable serial ports. Configuration options: [Auto], [Disabled], [3F8 / IRQ4 / COM1], [2F8 / IRQ3 / COM2], [3E8 / IRQ4 / COM3], [2E8 / IRQ3 / COM4]. OnBoard Infrared Port You may select [Auto] for the on-board infrared port feature, which will enable this feature if the infrared module is installed.
-
Page 32: Security Setup Menu
2. Security Setup Menu AMIBIOS SETUP UTILITY - VERSION 3.31a Security Boot Exit Main Advanced Power [ Setup Help ] Clear Supervisor Password Clear User Password <Enter> to set the supervisor password. [ Enter ] Set Supervisor Password Set User Password [ Enter ] Password Check Setup... -
Page 33: Power Setup Menu
3. Power Setup Menu AMIBIOS SETUP UTILITY - VERSION 3.31a Security Boot Exit Main Advanced Power [ Setup Help ] Disabled Suspend To RAM (S3) Repost Video on S3 Resume Disabled <Enter> to select Restore on AC / Power Loss Power Off auto-detect or disable Ring-In Power On... -
Page 34: Boot Setup Menu
4. Boot Setup Menu AMIBIOS SETUP UTILITY - VERSION 3.31a Security Boot Exit Main Advanced Power [ Setup Help ] Quick Boot Mode Enabled Boot Up Num-Lock <Enter> to enable or Boot To OS/2 disable the quick boot Boot From Network Disabled mode. -
Page 35: Exit Menu
5. Exit Menu AMIBIOS SETUP UTILITY - VERSION 3.31a Advanced Security Power Boot Exit Main [ Setup Help ] [ Enter ] Exit Saving Changes [ Enter ] Exit Discarding Changes Exits and saves the [ Enter ] Load Default Settings changes in CMOS RAM.
