- Page 1 FA938400TX –DARK TOBACCO BRENTFORD MEDIA FIREPLACE MANTEL For assistance with assembly contact: ASSEMBLY INSTRUCTION Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com...
-
Page 2: Parts List
BRENTFORD MEDIA FIREPLACE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the screw diagrams below. - Page 3 Quantity Quantity of 1 of 1 TOP PANEL MIDDLE SHELF PANEL Quantity Quantity of 1 of 1 LEFT SIDE PANEL RIGHT SIDE PANEL Quantity Quantity of 1 of 1 LEFT DIVIDED PANEL RIGHT DIVIDED PANEL Quantity Quantity of 1 of 2 BOTTOM PANEL ADJUSTABLE SHELF PANEL Quantity...
- Page 4 BRENTFORD MEDIA FIREPLACE Assembly Instructions Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated on the front page Insert cam locks (C) into predrilled holes on left divided panel (5) & right divided panel (6).
- Page 5 BRENTFORD MEDIA FIREPLACE Assembly Instructions Insert cam locks (C) into predrilled holes on pre-assembled unit in figure 2 Screw cam bolt (A) into predrilled holes on top panel (1). Attach top panel (1) to pre-assemble parts in figure 2 by inserting wood dowel (B) &...
- Page 6 BRENTFORD MEDIA FIREPLACE Assembly Instructions Attach the back panel (11) on the pre-assembled unit by screw (K) as shown. Figure 5 Well put the fireplace (M) into the unit and avoid any scratch. Figure 6...
- Page 7 BRENTFORD MEDIA FIREPLACE Assembly Instructions Assemble the wood holder (12) on bottom panel by screw (J) as shown. Figure 7 Now you can enjoy your new fireplace. Figure 8...
- Page 8 Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
- Page 9 This unit contains a permanent warning sticker located on back panel. Do not allow children under 16 years old to move the cart. Model: FA938400TX –DARK TOBACCO BRENTFORD MEDIA FIREPLACE MANTEL...
