Palm Rest
Dell™ Inspiron™ 910 Service Manual
Removing the Palm Rest
Replacing the Palm Rest
Removing the Palm Rest
CAUTION: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal surface (such
as the back panel) on the computer.
1. Follow the instructions in Before You
2. Remove the module cover (see
3. Remove the keyboard (see
4. Turn the computer over and remove the left and right rubber bumpers.
5. Remove the nine screws from the computer base.
1 left rubber bumper
3 right rubber bumper
6. Turn the computer over and remove the seven screws from the top of the palm rest.
7. Disconnect the Bluetooth card cable, touch pad cable, and the power button cable from the respective system board connectors.
Begin.
Removing the Module Cover).
Removing the Keyboard).
2 screw (9)
