- Page 1 XPS 13 2-in-1 (9310 2n1) Setup and Specifications Regulatory Model: P103G Regulatory Type: P103G002 September 2020 Rev. A00...
- Page 2 A WARNING indicates a potential for property damage, personal injury, or death. © 2020 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners.
-
Page 3: Table Of Contents
Contents Chapter 1: Set up your XPS 13 2-in-1 (9310 2n1)................4 Chapter 2: Views of XPS 13 2-in-1 (9310 2n1)................6 Front....................................... 6 Left......................................6 Right......................................7 Base......................................7 Display....................................8 Bottom....................................9 Modes.....................................9 Chapter 3: Specifications of XPS 13 2-in-1 (9310 2n1)..............11 Dimensions and weight..............................11... -
Page 4: Chapter 1: Set Up Your Xps 13 2-In-1 (9310 2N1)
SLN151748 at www.dell.com/support. For Windows: Follow the on-screen instructions to complete the setup. When setting up, Dell recommends that you: ● Connect to a network for Windows updates. NOTE: If connecting to a secured wireless network, enter the password for the wireless network access when prompted. - Page 5 Table 1. Locate Dell apps Resources Description My Dell Centralized location for key Dell applications, help articles, and other important information about your computer. It also notifies you about the warranty status, recommended accessories, and software updates if available. SupportAssist Pro-actively checks the health of your computer’s hardware and software.
-
Page 6: Chapter 2: Views Of Xps 13 2-In-1 (9310 2N1)
Views of XPS 13 2-in-1 (9310 2n1) Front 1. Power and battery-status light Indicates the power state and battery state of the computer. Solid white—Power adapter is connected and the battery is charging. Solid amber—Battery charge is low or critical. -
Page 7: Right
Press to left-click. 3. Right-click area Press to right-click. 4. Power button with fingerprint reader Press to turn on the computer if it is turned off, in sleep state, or in hibernate state. Views of XPS 13 2-in-1 (9310 2n1) -
Page 8: Display
10 seconds to force shut-down the computer. Place your finger on the power button to log-in with the fingerprint reader. NOTE: You can customize power-button behavior in Windows. For more information, see Me and My Dell at www.dell.com/support/manuals. Display 1. -
Page 9: Bottom
1. Left speaker Provides audio output. 2. Service Tag label The Service Tag is a unique alphanumeric identifier that enables Dell service technicians to identify the hardware components in your computer and access warranty information. 3. Right speaker Provides audio output. - Page 10 Tablet Stand Tent Views of XPS 13 2-in-1 (9310 2n1)
-
Page 11: Chapter 3: Specifications Of Xps 13 2-In-1 (9310 2N1)
Specifications of XPS 13 2-in-1 (9310 2n1) Dimensions and weight The following table lists the height, width, depth, and weight of your XPS 13 2-in-1 (9310 2n1). Table 2. Dimensions and weight Description Values Height: 14.35 mm (0.56 in.) Width 297 mm (11.69 in.) -
Page 12: Operating System
Your XPS 13 2-in-1 (9310 2n1) supports the following operating systems: ● Windows 10 Home (64-bit) ● Windows 10 Professional (64-bit) Memory The following table lists the memory specifications of your XPS 13 2-in-1 (9310 2n1). Table 5. Memory specifications Description Values... -
Page 13: Internal Slots
Communications Wireless module The following table lists the Wireless Local Area Network (WLAN) modules that are supported on your XPS 13 2-in-1 (9310 2n1) NOTE: The wireless module is integrated on the system board. Table 8. Wireless module specifications... -
Page 14: Audio
Your XPS 13 2-in-1 (9310 2n1) supports one of the following storage configurations: ● One 1620 onboard solid-state drive The primary drive of your XPS 13 2-in-1 (9310 2n1) varies with the storage configuration. For computers: ● with a M.2 drive, the M.2 drive is the primary drive Table 10. -
Page 15: Keyboard
The maximum capacity supported by the media-card reader varies depending on the standard of the media card installed in your computer. Keyboard The following table lists the keyboard specifications of your XPS 13 2-in-1 (9310 2n1). Table 12. Keyboard specifications Description... -
Page 16: Touchpad
For more information about touchpad gestures for Windows 10, see the Microsoft knowledge base article 4027871 support.microsoft.com. Power adapter The following table lists the power adapter specifications of your XPS 13 2-in-1 (9310 2n1). Table 15. Power adapter specifications Description Values... -
Page 17: Battery
Operating 0°C to 40°C (32°F to 104°F) Storage -40°C to 70°C (-40°F to 158°F) Battery The following table lists the battery specifications of your XPS 13 2-in-1 (9310 2n1). Table 16. Battery specifications Description Values Battery type 51 Wh, 4-cell "smart" lithium-ion Battery voltage 7.60 VDC... -
Page 18: Display
Display The following table lists the display specifications of your XPS 13 2-in-1 (9310 2n1). Table 17. Display specifications Description Option one Option two Display type Full High Definition Ultra High Definition Display-panel technology Wide Viewing Angle (WVA) Wide Viewing Angle (WVA) -
Page 19: Gpu-Integrated
Fingerprint-reader sensor resolution 500 dpi Fingerprint-reader sensor pixel size 64 x 80 GPU—Integrated The following table lists the specifications of the integrated Graphics Processing Unit (GPU) supported by your XPS 13 2-in-1 (9310 2n1). Table 19. GPU—Integrated Controller Memory size... -
Page 20: Chapter 4: Dell Low Blue Light Display
Dell low blue light display optimizes eye comfort with a flicker-free screen. The low blue light feature is designed to reduce the amount of blue light that is emitted from the monitor to optimize eye comfort. -
Page 21: Chapter 5: Keyboard Shortcuts Of Xps 13 2-In-1 (9310 2N1)
You can also define the primary behavior of the function keys (F1-F12) by changing Function Key Behavior in BIOS setup program. Table 21. List of keyboard shortcuts Function key Redefined key (for multimedia control) Behavior Mute audio Decrease volume Increase volume Play/Pause Toggle keyboard backlight Decrease brightness Increase brightness Keyboard shortcuts of XPS 13 2-in-1 (9310 2n1) - Page 22 The fn key is also used with selected keys on the keyboard to invoke other secondary functions. Table 22. List of keyboard shortcuts Function key Behavior Pause/Break Toggle scroll lock System request Open application menu Toggle fn-key lock Keyboard shortcuts of XPS 13 2-in-1 (9310 2n1)
-
Page 23: Chapter 6: Getting Help And Contacting Dell
Getting help and contacting Dell Self-help resources You can get information and help on Dell products and services using these self-help resources: Table 23. Self-help resources Self-help resources Resource location Information about Dell products and services www.dell.com My Dell app...
