- Page 1 71-6881-250 09/09 Lionel Lionel Barrel Shed Owner’s Barrel Shed Owner’s Manual Manual...
- Page 2 SC-2 wiring and operation Accessory Switch Controller wiring and operation Replacing the lamp Chimney installation Limited Warranty/Lionel Service The following Lionel marks may be used throughout this instruction manual and are protected under law. All rights reserved. Lionel , TrainMaster , Odyssey...
- Page 3 12-18 volts (AC). As illustrated in Figure 1, you may connect the accessory to a separate power supply or to a Lionel Lock-On (available separately, 6-62900) connected to your track. You will need the ends of the wires to be stripped back 1/4”...
- Page 4 Wiring and operating your accessory with TrainMaster Command Control ou may choose to wire your accessory with an SC-2 Switch and Accessory Controller (available separately, 6-22980) or the Accessory Switch Controller (available separately, 6-14182) for operation in the TrainMaster Command Control environment. Refer to these manuals for additional information.
- Page 5 Accessory Switch Controller wiring and operation hree wires are needed to connect your accessory to the Accessory Switch Controller (ASC) and a separate accessory transformer. Refer to Figure 3. 1. Attach one wire to the transformer Power/A terminal and connect it to the COMM terminal on the ASC.
- Page 6 Replacing the lamp he accessory is illuminated by one lamp, Lionel part no. 600-2313-300, located inside the building. During the course of normal operations, this lamp may require replacement. New lamps are available from your authorized Lionel service center or from Lionel Service.
- Page 7 Installing the chimney he chimney is packed separately in the box and is easy to install. Locate the hole in the roof and place the pin on the base of the chimney into the hole. Figure 5. Chimney installation...
- Page 8 (or copy) from an Authorized Lionel Retailer*, will at the discretion of Lionel LLC, be repaired or replaced, without charge for parts or labor. In the event the defective product cannot be repaired, and a suitable replacement is not available, Lionel will offer to replace the product with a comparable model (determined by Lionel LLC), if available.
