STATUS/DC/SHUNT A
max removed
kWatts
DOWN
STATUS/DC/SHUNT A
max charged
amps
DOWN UP RESET
STATUS/DC/SHUNT A
max charged
kWatts
DOWN UP
CONTINUING TO PRESS THE<DOWN> SOFT KEY LEADS TO max removed amps, max removed
kWatts, max charged amps, and max charged kWatts for SHUNT B and SHUNT C
STATUS/DC/SHUNT
end of shunt
status menu
STATUS/DC
METER SHUNT BATT TOP
STATUS/DC/BATT
total days
DOWN
21
0.010
UP RESET TOP
39.8
TOP
0.510
RESET TOP
UP TOP STATUS
STATS
at 100%
0.5
UP RESET
Displaying the kilowatts removed provides the user
with more precise energy usage information. This
fi gure can be returned to 0 by pressing the <RESET>
soft key. Press the <DOWN> soft key to view the max
charged screen.
SHUNT A shows a maximum of 39.8 amps charged.
Pressing the <RESET> soft key returns this value to
0. Press the <DOWN> soft key to continue in the
STATUS menu.
SHUNT A shows 0.510 kilowatts as the maximum
charged. Pressing the <RESET> soft key returns
this value to 0. Press the <DOWN> soft key to view
SHUNT B and SHUNT C values. Proceed through the
same steps as in SHUNT A. When fi nished with SHUNT
C, the end of shunt status menu screen appears
Press the <STATUS> soft key.
Press the <BATT> soft key to view the FlexNet DC
battery readings
STATUS/DC/BATT displays the number of days the
battery has been at 100% SOC. Press the <RESET>
soft key to restart the timer. Press the <DOWN> soft
key to view the next battery status screen.
