Appendix : Technical specification

Intellian i4/i4P

General
Approvals
CE – conforms to EU Directive 89/336/EEC
FCC – verified to CFR47:Part 15
Dimensions
Satellite antenna unit 50cm(19.7") x 54cm(21.2")
Antenna dish diameter 45cm(17.7")
Antenna control unit 17.8cm(7")x21.6cm(8.5")x5.38cm(2.1")
Weight
Satellite antenna unit 11.6kg (21.5 lbs)
Antenna control unit 1.2kg (2.6 lbs)
Environmental
Operating temperature range -15°C to + 55°C
Storage temperature range
-25°C to + 70°C
Humidity limit
95% R.H
Operating voltage 10.8 ~ 15.6 V DC
Power consumption Typ. 30W, Max. 50W
Antenna system performance
Frequency Ku-band(10.7 to 12.75 GHz)
Minimum EIRP 49dBW
Azimuth range 680°
Elevation range 0° ~ +90°
Roll ±25°
Ship's motion
Pitch ±15°
Roll and pitch response rate 50° / second
Turn rate 50° / second
69 70 i3/i4/i4P Satellite Antenna System – Install and User manual

Intellian i3

General
Approvals
CE – conforms to EU Directive 89/336/EEC
FCC – verified to CFR47:Part 15
Dimensions
Satellite antenna unit 43cm (17") x 44cm(17.3")
Antenna dish diameter 37cm(14.6")
Antenna control unit 17.8cm(7")x21.68cm(8.5")x5.38cm(2.1")
Weight
Satellite antenna unit 9kg (19.8 lbs)
Antenna control unit 1.2kg (2.6 lbs)
Environmental
Operating temperature range -15°C to + 55°C
Storage temperature range
-25°C to + 70°C
Humidity limit
95% R.H
Operating voltage 10.8 ~ 15.6 V DC
Power consumption Typ. 30W, Max. 50W
Antenna system performance
Frequency Ku-band(10.7 to 12.75 GHz)
Minimum EIRP 50dBW
Azimuth range 680°
Elevation range +10° ~ +80°
Roll ±25°
Ship's motion
Pitch ±15°
Roll and pitch response rate 60° / second
Turn rate 60° / second
