Fritz! Box 7570 Installation, Configuration & Operation

Vdsl
Hide thumbs
Table of Contents

Advertisement

Quick Links

Installation,
configuration
and operation
FRITZ!Box
Fon WLAN 7570 vDSL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRITZ!Box 7570 and is the answer not in the manual?

Questions and answers

Related Manuals for Fritz! FRITZ!Box 7570

Summary of Contents for Fritz! FRITZ!Box 7570

  • Page 1 FRITZ!Box Fon WLAN 7570 vDSL Installation, configuration and operation...

  • Page 2: Legal Notice

    Legal Notice Legal Notice FRITZ!Box Fon WLAN 7570 vDSL This documentation and the software it describes are protected by copyright. AVM grants the non- exclusive right to use the software, which is supplied exclusively in object code format. The licensee may create only one copy of the software, which may be used exclusively for backup use.

  • Page 3: Table Of Contents

    Security and Handling ......7 FRITZ!Box Fon WLAN 7570 vDSL ..... . 9 Package Contents.
  • Page 4 FRITZ!DSL Diagnosis........
  • Page 5 Disconnecting the FRITZ!Box from the Computer ....111 12.2 Removing the FRITZ!DSL Software......111 12.3 Removing the Printer Port .
  • Page 6 Index ......... 163 FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 7: Connecting And Operation7

    You can either place FRITZ!Box on a horizontal surface or Handling mount it on a wall. Please note the following: Place or hang the FRITZ!Box in a dry location that is free of dust and protected from direct sunlight. Do not place FRITZ!Box on excessively heat-sensitive surfaces, as the base of the device can heat up during normal operation.
  • Page 8 Security and Handling For detailed information about the symbols, numerals and function keys used in the manual, see the section “Direc- tions for Operation” from page 115. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 9: Fritz!Box Fon Wlan 7570 Vdsl

    FRITZ!Box Fon WLAN 7570 vDSL An Overview The FRITZ!Box Fon WLAN 7570 vDSL is a Private Branch Exchange (PBX) for making telephone calls via the Internet and the fixed-line network. The FRITZ!Box connects your computers directly with your DSL line. Each connected computer can establish an Internet connection over the FRITZ!Box.
  • Page 10 The FRITZ!Box is equipped with an integrated firewall. Firewall When the FRITZ!Box Fon WLAN 7570 vDSL is operated as a router, this firewall protects your network from attacks from the Internet. The FRITZ!Box is equipped with a USB host controller to...

  • Page 11: Package Contents

    Linux operating system or Ap- Supported ple computers with the Mac OS X operating system. Package Contents The following is included in the FRITZ!Box Fon WLAN 7570 vDSL package: FRITZ!Box Fon WLAN 7570 vDSL one power supply unit with a cable for connection to...

  • Page 12: Operation Requirements

    Operation Requirements Operation Requirements In order to operate the FRITZ!Box, you must have the fol- lowing: a Web browser that supports Java script (for instance, Internet Explorer version 6.0 or higher, or Firefox version 1.5 or higher) DSL line 1TR112 (compatible with U-R2), ITU G.992.1, ITU G.992.3, ITU G.992.5, or a VDSL line...

  • Page 13: Connecting

    Using the Installation Help on the CD On computers with Windows operating systems you can use the Installation Help on the FRITZ!Box CD. The Installa- tion Help presents instructions on the screen, guiding you through the steps required to launch operation of the FRITZ!Box.
  • Page 14 FRITZ!Box user interface. Launching Operation without the Installation Help CD If you do not want to use the Installation Help on the FRITZ!Box CD, then work through the instructions below in the recommended order: Placement of FRITZ!Box; see the section “Security and Handling”...

  • Page 15: Mounting On A Wall

    Mounting on a Wall Mount the wall holder included in the package on the wall. Mounting the wall holder for the FRITZ!Box Place the FRITZ!Box on the wall holder and slide it into posi- tion. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 16: Connecting To Electrical Power

    Connecting to Electrical Power Attaching the FRITZ!Box to the wall holder Connecting to Electrical Power Connecting to the power supply Set aside the power supply unit out of the FRITZ!Box package. Connecting FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 17: Connecting The Computer(S)

    The green “Power/DSL” LED will begin flashing after a few seconds. Connecting the Computer(s) If you would like to surf the web using the FRITZ!Box or to open the FRITZ!Box user interface, then you must connect a computer with the FRITZ!Box.

  • Page 18: Connecting Computer(S) To The Lan Port

    Connecting Computer(s) to the LAN Port If you want to connect a computer to one of the four LAN ports on the FRITZ!Box, make sure that your computer is equipped with a network adapter. A LAN port is usually des- ignated by the icon at left or labeled “LAN”.
  • Page 19 Connecting a Network Hub or Switch You can connect a network hub or switch to one of the LAN ports on the FRITZ!Box if you would like to connect multiple computers to the FRITZ!Box via LAN. Connecting FRITZ!Box to a network hub...

  • Page 20: Connecting Computer(S) Wirelessly Via Wlan

    For more information on WLAN, see the section “More about WLAN” from page 125. Connecting the FRITZ!WLAN USB Stick If you are using a FRITZ!WLAN USB Stick N or a Connect FRITZ!WLAN USB Stick by AVM as a WLAN adapter, you can...
  • Page 21 Using WLAN adapters from Other Manufacturers Now insert the FRITZ!WLAN USB Stick N in the USB port of the computer. The security settings saved on the FRITZ!WLAN USB Stick N are applied to the computer. Now the FRITZ!Box and FRITZ!WLAN USB Stick N are connected with each other...
  • Page 22 If your WLAN adapter does not support WPA, you must con- WPA Not Supported vert the encryption in the FRITZ!Box to WEP. For this you must change the WLAN settings in the FRITZ!Box. To do so, proceed as follows: Connect the FRITZ!Box and the computer using the network cable (yellow) (see the section “Connecting...

  • Page 23: Connecting To The Dsl/Vdsl Line

    Connecting to the DSL/VDSL Line Close the user interface and clear the connection be- tween the FRITZ!Box and the computer. Remove the network cable (yellow). Configure your WLAN adapter with the security set- tings entered in the FRITZ!Box. The WLAN connection between your WLAN adapter and the FRITZ!Box will be established.

  • Page 24: Connecting To The Isdn Line

    DSL/VDSL splitter. The green “Power” LED stops flashing after a short time and remains lit to signalize that FRITZ!Box is ready for Internet connections over DSL or VDSL. Connecting to the ISDN Line Your telephone line is either an analog line or an ISDN line.

  • Page 25: Connecting With The Analog Telephone Line

    RJ45/RJ11 adapter included in the package and then insert the adapter into the socket of the ISDN NT. Now the FRITZ!Box and the ISDN line are connected. Connecting with the Analog Telephone Line Your telephone line is either an analog line or an ISDN line.

  • Page 26: Connecting Telephone, Fax, Or Answering Machine

    You can connect two analog terminal devices like tele- phones, fax machine or answering machine to the FRITZ!Box. Insert the TAE plug of your analog device in one of the TAE sockets “FON 1” or “FON 2” located on the back panel of the FRITZ!Box.

  • Page 27: Connecting Isdn Telephones

    Connecting ISDN Telephones Analog devices with an RJ11 plug are connected to the RJ11 sockets “FON 1” or “FON 2” located on the back panel of the FRITZ!Box using the TAE/RJ11 adapter included in the package. 3.11 Connecting ISDN Telephones...

  • Page 28: Connecting Isdn Pbxs

    Connecting ISDN PBXs 3.12 Connecting ISDN PBXs If you have an ISDN PBX, you can connect this PBX to the FRITZ!Box. With the telephones connected to the PBX you can make calls both via the Internet and via the fixed-line network.

  • Page 29: Opening The User Interface

    Opening the User Interface Opening the User Interface fritz.box The FRITZ!Box has a user interface that can be used in a web browser. The user interface presents information about the FRITZ!Box product, ports and connections. This is also where you configure settings for operation of the FRITZ!Box.

  • Page 30: Internet Connections

    Internet Connections Setting Up the Internet Connection In order to allow Internet access with the FRITZ!Box, you must first config- ure the Internet connection in the FRITZ!Box user interface. The FRITZ!Box can be operated directly at the DSL or VDSL line. Alterna- tively, it can be connected to a cable modem, a DSL or VDSL modem, or a DSL router, or integrated into an existing network.
  • Page 31 Configuring the Internet Connection Manually As a final step, click “Apply”. If the FRITZ!Box is connected to a cable modem, a DSL or VDSL modem or a router, or integrated into an existing net- work, you must also configure your Internet connection as described above.

  • Page 32: The Dect Function

    Every cordless phone that supports the DECT-GAP standard (also known as a DECT tele- phone) can be registered at the FRITZ!Box. A total of up to five cordless phones can be registered.

  • Page 33: Making An Internal Call To A Cordless Phone

    Entry 3 ss613 Entry 4 ss614 Entry 5 Logging a Cordless Phone off of the FRITZ!Box Start a web browser. Open the FRITZ!Box user interface by entering fritz.box in the address field. In the “Start Menu” area, select the “Telephony Equip- ment”...

  • Page 34: Switching The Dect Function On And Off

    The DECT function is switched on when the first cord- less phone is registered. Switching off the DECT function When the last cordless phone is logged off in the FRITZ!Box user interface, the DECT function is switched off automatically. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 35: Telephone Connections

    Telephone Connections Telephone Connections Configuring FRITZ!Box for Telephony Using the FRITZ!Box you can make telephone calls via the Internet and the fixed-line network. Once you have connected the FRITZ!Box as described in the chapter “Connecting” from page 13, you can configure the FRITZ!Box for making telephone calls.

  • Page 36: Configuring Telephony Equipment

    The Internet numbers can be from one or from multiple dif- ferent Internet telephony providers. Fixed-line Number With the FRITZ!Box you can make calls both via the analog fixed-line network and via the ISDN fixed-line network: In order to make calls via the analog fixed-line network with the FRITZ!Box, enter your telephone numbers in the FRITZ!Box.
  • Page 37 If you have connected an analog answering machine (to “FON 1” or “FON 2”, for instance), configure it as an answering machine. The FRITZ!Box is also equipped with integrated an- swering machines, which can be enabled and config- ured in the “Settings / Advanced Settings / Telephony / Answering Machines”...

  • Page 38: Functions And Settings For Telephony

    ISDN PBX The Wizard explains step by step how to prepare the ISDN telephone system for operation at the FRITZ!Box. Functions and Settings for Telephony More functions and settings options for telephony are available in the “Settings / Advanced Settings / Telephony”...
  • Page 39 Telephone Book Telephone Book A Telephone Book is at your disposal in the FRITZ!Box. If an AVM handset is registered at the FRITZ!Box, the Tele- phone Book can be transferred to the handset. Call Diversion With this function you can divert incoming calls to another number.
  • Page 40 Answering Machines The FRITZ!Box is equipped with several integrated answer- ing machines, each of which can be enabled and config- ured individually. By enabling the setting “Send messages by e-mail” you can have recorded messages sent to you by e-mail.

  • Page 41: The Answering Machine Menu

    Select a greeting during monitoring Record greeting > End with 1 Listen to “Recording and Selection” menu again Back to Main menu Listen to “Record greetings” menu again Back to main menu Listen to main menu again FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 42: Usb Devices

    USB Devices USB Devices at the FRITZ!BoxUSB The FRITZ!Box is equipped with a USB port (also known as a USB host controller). Various USB devices can be connected to the host controller: an AVM FRITZ!WLAN USB Stick N or an AVM FRITZ!WLAN USB Stick...

  • Page 43: Accessing Usb Devices

    Accessing USB Devices Accessing USB Devices As soon as a USB device is connected to the FRITZ!Box, all Network Access of its functions are available in the entire network: The files in the USB mass storage can be accessed from the network via FTP (File Transfer Protocol), or you can make the USB mass storage device available as a network storage device.
  • Page 44 Select the “Advanced Settings” menu in the “Set- tings” area. Enable the expert mode option of the FRITZ!Box in the “System / Expert Mode” menu. Confirm by clicking “Apply”. Open the “USB Devices / Device Overview” menu.
  • Page 45 Select the “Advanced Settings” menu in the “Set- tings” area. Enable the expert mode option of the FRITZ!Box in the “System / Expert Mode” menu. Confirm by clicking “Apply”. Open the “USB Devices / USB Remote Connection”...

  • Page 46: Usb Mass Storage Devices

    The access rights and password are are not enabled if the USB remote connection is enabled for all USB mass stor- age devices. On the FRITZ!Box user interface you can configure access Access Rights and Passwort rights and password protection for the USB storage de- Protection vices.
  • Page 47 (streaming). The hard drive with the music collection is simply connected to the USB port of the FRITZ!Box and a suitable playback de- vice is integrated into the local network. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 48: Usb Printers

    With UPnP AV this technology has been expanded to audio and video contents. The FRITZ!Musikbox makes files available in the MP3, WMA or WAV format. USB Printers You can connect a USB printer to the USB port and either enable the USB remote connection, or use the USB printer as a network printer.
  • Page 49 For computers with Linux: The printer must be supported by CUPS (Common UNIX Printing System) software and be detected cor- rectly at the USB port of the FRITZ!Box. For Apple computers: The only printers that can be used are the ones whose drivers can be selected in the “Printer”...
  • Page 50 Configuring the Printer Port in the Windows Operating Systems Configuring the Printer Port in the Windows Operating Systems If the “FRITZ!Box” entry is already listed in the “Programs” group of the start menu of the computer, this means that the printer port is already configured on this computer.
  • Page 51 Click “Next”. In the “Select a Printer Port” window, select the option “Use the following port” and select “AVM: (FRITZ!Box USB Printer Port)” from the list field. Click “Next”. Select the manufacturer for the USB printer connected to the FRITZ!Box from the “Manufacturers”...
  • Page 52 Setting Up Printers in SUSE Linux Systems A USB printer can be connected to the USB port of the FRITZ!Box for use as a network printer. The printer is then available to all computers connected with the FRITZ!Box. Install the printer as “root” or “superuser”.
  • Page 53 Setting Up USB Printers on Apple Computers A USB printer can be connected to the USB port of the FRITZ!Box for use as a network printer. The printer is then available to all computers connected with the FRITZ!Box. Under “Go / Utilities”, open the “Printer Setup Utility”.

  • Page 54: Fritz!Wlan Usb Stick N And Fritz!Wlan Usb Stick

    Printers.php3 FRITZ!WLAN USB Stick N and FRITZ!WLAN USB Stick The FRITZ!WLAN USB Stick N and the FRITZ!WLAN USB Stick are WLAN adapters manufactured by AVM for connection to a computer. Using a WLAN adapter you can connect the computer wirelessly with the FRITZ!Box.

  • Page 55: Usb Hub

    After the security settings have been transmitted auto- matically, you can insert the FRITZ!WLAN USB Stick in a computer. Now the FRITZ!WLAN USB Stick is ready to establish a con- nection to the FRITZ!Box. No further settings are necessary. USB Hub A USB hub can be connected to the USB host controller.

  • Page 56: Tips For Using Usb Devices

    Tips for Using USB Devices Tips for Using USB Devices When using USB devices at the USB port of the FRITZ!Box, USB Devices please keep in mind the following; If more than one USB device without its own power supply is connected to the FRITZ!Box, note that, in ac- cordance with the USB specification, the total current consumption may not exceed a value of 500 mA.

  • Page 57: Fritz!Dsl: The Software Suite

    FRITZ!DSL: The Software Suite Using DSL with the FRITZ!Box The FRITZ!DSL software includes a number of programs designed for use with DSL, all of which are introduced briefly in this chapter. Once you have installed FRITZ!DSL, the “Start Center” icon appears on your desktop.

  • Page 58: Installing Fritz!Dsl

    The FRITZ!DSL welcome screen appears. Confirm with “Continue”. Specify the folder in which you want to install FRITZ!DSL on your computer. Confirm with “Continue”. Next, specify the program group for FRITZ!DSL in the Start menu. Confirm with “Continue”. Confirm with “Finish”. Installation has been concluded.

  • Page 59: Fritz!Dsl Protect

    FRITZ!DSL Protect protects your computer from unwanted Internet connections, supplementing the firewall functions of your FRITZ!Box. With FRITZ!DSL Protect you can check all Internet connections that are established or accepted by lo- cal programs on your computer. You can permit or prohibit...

  • Page 60: Fritz!Dsl Diagnosis

    DSL diagnostics function makes it possible to monitor the FRITZ!Box connection and installation. WebWatch Click the “Web Test” button in the FRITZ!DSL Start Center to start the FRITZ!DSL WebWatch program. WebWatch tests the quality of your Internet connection, and displays the re- sults of these test graphically.

  • Page 61: Configuration And Operation At The Telephone

    Configuration and Operation at the Telephone Configuration and Operation at the Telephone FRITZ!Box Keypad Sequences Many of the FRITZ!Box functions and features can be config- ured and used over a telephone connected to a FRITZ!Box extension. Only tone-dialing (dual-tone multifrequency = DTMF) telephones can be used in configuration and opera- tion.
  • Page 62 Hang up the handset. Restoring Factory Settings The FRITZ!Box can be reset to its condition upon delivery by restoring factory settings. All settings you made in the FRITZ!Box—including the con- figured Internet connection—are deleted when the factory settings are restored.
  • Page 63 Do Not Disturb You can enable the Do Not Disturb function for any tele- phone connected to FRITZ!Box in the user interface. When Do Not Disturb is enabled, the telephone will not ring. In configuring this function you can choose between enabling...
  • Page 64 Do Not Disturb for extension <Ext.> Alarm The FRITZ!Box includes an alarm function. The alarm can be configured individually for each connected telephone. First enter on the telephone the time at which you would like to be awakened and save this entry. Then enable the alarm function.
  • Page 65 Internet numbers. In addition to call forwarding, there is also call diversion via the FRITZ!Box. Use this kind of call diversion to divert calls to internal and external lines. See the section “Call Diver- sion” on page 71 for more information.
  • Page 66 Wait for the acknowledgement tone. Hang up the handset. Disable Call Forwarding Immediately for Any MSN Pick up the handset. s21ss<MSN>r Dial the sequence shown at left. Wait for the acknowledgement tone. Hang up the handset. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 67 Wait for the acknowledgement tone. Hang up the handset. Call Forwarding When Busy for Any MSN Pick up the handset. s67s<DNo> Dial the sequence shown at left. s<MSN>r Wait for the acknowledgement tone. Hang up the handset. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 68 Wait for the acknowledgement tone. Hang up the handset. Disable Call Forwarding When Busy for All MSNs Pick up the handset. s67ssr Dial the sequence shown at left. Wait for the acknowledgement tone. Hang up the handset. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 69 ID (the first number assigned to an extension), for any number (for in- stance, a telephone at the other FRITZ!Box extension), or for all numbers. All settings can be disabled at any time. Call Forwarding Delayed for Your Outgoing Caller ID Pick up the handset.
  • Page 70 Wait for the acknowledgement tone. Hang up the handset. Disable Call Forwarding Delayed for All MSNs Pick up the handset. s61ssr Dial the sequence shown at left. Wait for the acknowledgement tone. Hang up the handset. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 71 Incoming calls to the FRITZ!Box telephones can be diverted to a different extension or to an external number. In con- trast to call diversion over FRITZ!Box, there is also call for- warding (call diversion via the central exchange). How to use call forwarding by phone is described in the section “Call Diversion on the ISDN Line”...
  • Page 72 Call Diversion After the Third Ring or When Busy Pick up the handset. r44<Ext.>s Dial the sequence shown at left. <DNo>/<Ext.>s r91ss Save your settings if desired by di- aling the sequence shown at left. Hang up the handset. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 73 Hang up the handset. Disable Call Diversion Pick up the handset. r40<Ext.>ss Dial the sequence shown at left. r91ss Save your settings if desired by di- aling the sequence shown at left. Hang up the handset. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 74 Hang up the handset. Disable Call Waiting Pick up the handset. r2 <Ext.> s1s Dial the sequence shown at left. r91ss Save your settings if desired by dialing the sequence shown at left. Hang up the handset. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 75 Hang up the handset. CLIR on a Case-by-Case Basis Pick up the handset. s31r Dial the sequence shown at left. Now you hear the external dial tone. Dial the number you want to call. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 76 The caller’s display will continue to show the number that was actually dialed. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 77 Pick up the handset. r53<Ext.>s0s Dial the sequence shown at left to enable transmission of the connected line’s num- ber. r91ss Save your settings if desired by dialing the sequence shown at left. Hang up the handset. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 78 This makes sense at any extension which is used to make many internal calls, for instance, between the exten- sions of the FRITZ!Box. When automatic outside dialing is disabled, for an external call the 0 must be dialed before the telephone number.

  • Page 79: Operation At The Telephone

    Hang up the handset. 10.2 Operation at the Telephone This section describes how you can use the FRITZ!Box fea- tures via your telephone keypad. Shortening the Dialing Procedure The FRITZ!Box automatically recognizes when a number has been entered, but not until a few seconds after the final digits are entered.
  • Page 80 “List of Internet Numbers”. Making Internal Calls All calls conducted between telephones connected to the FRITZ!Box, be they analog or ISDN/DECT phones, are inter- nal telephone calls. These calls are free of charge. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 81 (for instance, 51). 5<MSN> If you would like to call an ISDN terminal de- vice that does not have an internal phone number, dial 5, followed by the MSN that was saved in the ISDN terminal device. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 82 Pick up a Call Pick up the handset. Dial the sequence shown at left. The call is now connected to your extension and you can talk to the caller. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 83 20 seconds, as it would for an external call. When you pick up your handset, the number of desired party will be dialed automatically. “Call Back on Busy” can be used for both external and in- ternal connections. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 84 “Call Back on No Response” can be used both for external and internal connections. This command can be activated five times for each line. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 85 Callback requests can also be deleted manually, with the oldest callback request being deleted first. Delete Callback Requests Manually Pick up the handset. r37r Dial the sequence shown at left. Hang up the handset. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 86 In this case the phone rings as soon Call as you hang up. Pick up the handset again to re- turn to the last call that was on hold. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 87 Three-Party Conference Call Three-Party Conference Call FRITZ!Box allows you to hold telephone conferences with two other people at once. Two external and one internal party, or two internal and one external party can conduct a conference call with each other.
  • Page 88 Caller 2. In this case, your phone rings as soon as you hang up. Pick up the handset to return to Caller 1 again. Hang up the handset to end the connection. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 89: Transferring Calls

    Transferring Calls Transferring Calls The “Call Transfer” function allows you to transfer a connec- tion from one of FRITZ!Box's extension to another. Transfer Calls Call 1 You are talking to Caller 1. Press the Hold button. Caller 1 is now on hold.
  • Page 90 Dial the sequence shown at left. The connection on hold and the active connection are connected with each other. The external parties continue the call while you clear the connection. Hang up the handset. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 91 With this type of external transfer, both parties are con- nected to each other over your PBX. This means that both B channels on your ISDN line remain busy with this con- nection as long as the parties are connected to each other. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 92 ISDN terminal de- vice (such as an ISDN telephone) that is connected to your BRI line along with the FRITZ!Box. You will hear an acknowledgement tone to indicate that the call has been successfully suspended. If you hear the fail- ure tone, this may indicate that you made a mistake, or that the “Suspend/Resume”...
  • Page 93 Wait for the acknowledgement tone. The baby monitoring phone function is now enabled. Do not hang up the handset! Dial the number of the extension to listen in at an extension with room monitoring activated. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 94 Enter a Keypad Sequence on an Extension without Automatic Outside Dialing Pick up the handset. 0sr<Seq> Dial the sequence shown at left. <Seq> stands for the keypad sequence you received from your tele- phone carrier. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 95: Troubleshooting

    Help for Errors This chapter provides concrete assistance if you are not able to open the user interface of your FRITZ!Box, if you are having problems with the WLAN connection, or if you want to change the IP settings on your com- puter.
  • Page 96 Checking the Cable Connections Checking the Cable Connections The user interface of the FRITZ!Box does not appear in the window of your web browser. Possible Cause The cable connections are not secure. Remedy Make sure that all cable connections are plugged in securely.
  • Page 97 Remedy Set the network adapter used to DHCP so that the IP ad- dress can be obtained via the DHCP server of the FRITZ!Box. Adjust the settings to those described in the section “IP Settings” from page 106. Disabling Dial-Up Connections The user interface is not opened;...
  • Page 98 The proxy settings of the web browser prevent the user in- terface from being opened. Remedy Enter the DNS name and the IP address of the FRITZ!Box as an exception in the proxy settings of the web browser. Select the “Connections” settings page under “Tools / Internet Options...”.
  • Page 99 In the next window, click the “Advanced...” button and enter in the “Add this Web site to the zone:” field: fritz.box Disable the option “Require server verification (https:) for all sites in this zone”. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 100 DSL/VDSL cable and connecting to the Internet. Opening the User Interface of the FRITZ!Box The FRITZ!Box is equipped with a fixed IP address that can- not be changed. FRITZ!Box always can be reached at this IP address. This fixed IP address is: Fixed IP Address 169.254.1.1...

  • Page 101: The Wlan Adapter Cannot Find Fritz!Box

    11.2 The WLAN Adapter Cannot Find FRITZ!Box If the radio network “FRITZ!Box Fon WLAN 7570 vDSL” is not found by the WLAN adapter of a computer, work through the following steps to find the source of the error and re- solve it.
  • Page 102 The wireless network of the FRITZ!Box is not found by the WLAN adapter. Possible Cause WLAN is not enabled in the FRITZ!Box. If the “WLAN” LED on the FRITZ!Box is not lit up or is flashing, this means that WLAN is not enabled.

  • Page 103: Wlan Connection Is Not Established

    11.3 WLAN Connection Is Not Established Comparing the Security Settings for WLAN Make sure that the WLAN security settings registered in the FRITZ!Box agree with the security settings of the WLAN adapter. Here is how to view the WLAN security settings of the FRITZ!Box and print them out.
  • Page 104 Testing the WLAN Connection Without Security Settings Disable the WLAN security settings to test whether a WLAN connection between the FRITZ!Box and the WLAN adapter is possible at all. Connect the FRITZ!Box to a computer using a network cable. Proceed as described in the section “Connect- ing Computer(s) to the LAN Port”...
  • Page 105 Ruling Out Interference Caused by Other Wireless Networks If there are other devices in the immediate vicinity of your FRITZ!Box that use the 2.4-GHz band, simultaneous use of frequencies can result in mutual interference (for example, fluctuations or interrupted connections). Disruptions can also be caused by other WLAN access points, or by Blue- tooth devices, garage door openers or wireless AV bridges.

  • Page 106: Ip Settings

    See the relevant section for your operating system. If FRITZ!Box is operated in a network, no other DHCP server may be activated in this network. If you need to operate a DHCP server, please disable the DHCP feature in the “Ad- vanced System Settings”.
  • Page 107 Click the “Properties” button. Select “Internet Protocol (TCP/IP)” in the list of items used in this network connection and click “Proper- ties”. Enable the options “Obtain an IP address automatical- ly” and “Obtain DNS server address automatically”. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 108: Windows 2000

    Select “Start / Settings / Control Panel / Network and Dial-up Connections”. Double-click to select the LAN connection with the net- work adapter bound to FRITZ!Box. Click the “Properties” button. Double-click to select “Internet Protocol (TCP/IP)” in the list of network components.
  • Page 109 In the “Network” window, select the “Built-in Ether- net” entry from the “Show:” drop-down menu. Switch to the “TCP/IP” settings page and select the “Using DHCP:” option from the “Configure IPv4” drop- down menu. Click “Apply Now”. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 110 The computer now receives an IP address from the FRITZ!Box. Obtaining an IP Address Automatically in Linux For comprehensive information and tips on the topic of net- work configuration in Linux, see, for example: http://www.tldp.org/HOWTO/NET3-4-HOWTO-5.html FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 111: Uninstallation

    If the computer is connected to one of the LAN ports on the LAN Port FRITZ!Box, simply remove the network cable. If the computer is connected to the FRITZ!Box via a network hub or switch, remove the network cable between the com- puter and the network hub or switch.

  • Page 112: Removing The Printer Port

    Open “start / Control Panel / Add or Remove Pro- grams”. Make sure that the “Change or Remove Pro- grams” button is selected in the column at left. Select the “AVM FRITZ!DSL” entry from the list of “Cur- rently installed programs”. Click the “Change/Remove” button.

  • Page 113: Removing The Program Group

    Open “start / Control Panel / Add or Remove Pro- grams”. Make sure that the “Change or Remove Pro- grams” button is selected in the left-hand column. Select the “AVM FRITZ!Box Printer Port” entry from the list of “Currently installed programs”. Click the “Change/Remove” button.
  • Page 114 Open “start / Control Panel / Add or Remove Pro- grams”. Make sure that the “Change or Remove Pro- grams” button is selected in the left-hand column. Select the “AVM FRITZ!Box Documentation” entry from the list of “Currently installed programs”. Click the “Change/Remove” button.

  • Page 115: Directions For Operation

    Directions for Operation Symbols, Keys and LEDs The following sections present important information and tips for opera- tion of the FRITZ!Box Fon WLAN 7570 vDSL. 13.1 Symbols and Highlighting This symbol indicates useful hints to assist you in working with the FRITZ!Box.

  • Page 116: The Telephone Keypad

    In the place of the abbreviation <DNo>, enter the complete number of the external line. <DNo./Ext.> Enter the external telephone number (desti- nation number) or extension number (Ext.) to which your calls are to be diverted. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 117: Leds

    LEDs 13.4 LEDs Twelve LEDs are built into the top of the FRITZ!Box Fon WLAN 7570 vDSL, which flash or light up to display various connection statuses. Status Meaning INFO a telephone connection between two Internet telephony subscribers is active; the call is free of charge (this function...

  • Page 118: Handset And Ring Patterns

    Internal dial tone External dial tone Positive confirmation Neg. acknowledgment Call waiting Calls External call Internal call Call back Internet telephony Registration error Fixed-line substitute Handset and ring patterns on FRITZ!Box Fon WLAN 7570 vDSL FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 119: Product Details And Useful Information119

    PRODUCT DETAILS AND USEFUL INFORMATION Product Details FRITZ!Box Fon WLAN 7570 vDSL This chapter provides you with product details on FRITZ!Box Fon WLAN 7570 vDSL. You receive information on the cables and buttons, technical data and further details. Cables and Buttons...

  • Page 120: Wlan Button

    AVM recommends using a network cable no more than 100 meters long. WLAN Button The FRITZ!Box is equipped with a WLAN button on the rear panel of the housing. The WLAN button can be used to activate and deactivate WLAN.

  • Page 121: Technical Specifications

    IEEE 802.11a – 54 Mbit/s – IEEE 802.11b – 11 Mbit/s – IEEE 802.11g – 54 Mbit/s – IEEE 802.11n draft 2.0 – 300 Mbit/s Router Function DSL/VDSL router DHCP server Firewall with IP masquerading/NAT FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 122: Physical Specifications

    Physical Specifications Dimensions (WxDxH): approx. 210 x 155 x 25 mm Supply voltage: 230 V / 50 Hz Maximum power consumption: 16 W Average power consumption: 6 W Firmware can be updated Conform to CE standards FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 123: Declaration Of Ce Conformity

    The manufac- AVM GmbH turer Alt-Moabit 95 D-10559 Berlin herewith declares that the product FRITZ!Box Fon WLAN 7570 vDSL Type: ADSL/VDSL WLAN Router complies with the following directives: 1999/5/EC R&TTE Directive: Radio Equipment and Telecommunica- tions Terminal Equipment 2004/108/EEC EMC Directive: Electromagnetic Compatibility...

  • Page 124: Disposal

    Electronic Equipment Act (ElektroG), the FRITZ!Box Fon WLAN 7570 vDSL, as well as all devices and electronic com- ponents contained in the FRITZ!Box Fon WLAN 7570 vDSL package may not be disposed with household waste. Please bring these to your local collection points for dispos-...

  • Page 125: More About Wlan

    Data throughput IEEE 802.11a, IEEE 802.11b, IEEE 802.11g and IEEE 802.11n. WLAN adapters based on one or more of the standards list- ed can be used for WLAN connections with the FRITZ!Box. The standards are intended for different frequency bands. Standard...
  • Page 126 With a maximum throughput rate of 11 Mbit/s, this is the IEEE 802.11b oldest standard for radio networks. Older WLAN adapters of the first generation can communicate with the FRITZ!Box using 802.11b. However, if the WLAN adapter supports newer standards such as 802.11g, the latest standard should be used.

  • Page 127: Security

    CCM (Counter with CBC-MAC Protocol) de- fines how the AES procedure is applied to WLAN packets. FRITZ!Box supports the AES encryption procedure as part of the WPA2 mechanism, and the TKIP encryption procedure as part of the WPA mechanism. This means that the FRITZ!Box can be used in combination with any WLAN adapters that also support WPA2 with AES or WPA with TKIP.
  • Page 128 20 characters long. Use numerals, letters and special characters and combine capitals and lower-case letters. In the FRITZ!Box a method combining WPA + WPA2 encryp- Default Setting tion with the TKIP/AES-CCMP encryption method is precon- figured. This setting allows you to use WLAN adapters that support WPA (TKIP) or WPA2 (AES-CCMP) or both methods.
  • Page 129 Encryption If your WLAN adapter supports an encryption method that Recommendation is more secure than the one preconfigured in the FRITZ!Box, you should select the more secure encryption method in your FRITZ!Box. To configure the best security settings possible with...

  • Page 130: Frequency Ranges

    Additional tips on interference in the WLAN radio network are presented in the section “Ruling Out Interference Caused by Other Wireless Networks” from page 105. The FRITZ!Box can operate in the 5-GHz frequency band as 5-GHz Frequency Band an alternative. This frequency range is used much less of- ten than the most common 2.4-GHz frequency range.
  • Page 131 IEEE 802.11a or IEEE 8002.11n standard. The FRITZ!Box works in the WLAN network either in the 2.4- 2.4 GHz or 5 GHz GHz range or in the 5-GHz range, but not parallel in both fre- quency ranges at the same time.
  • Page 132 Allocation of the WLAN channels in the 5-GHz range: Channel Frequency (GHz) Channel Frequency (GHz) 5.180 5.540 5.200 5.560 5.220 5.580 5.240 5.600 5.260 5.620 5.280 5.640 5.300 5.660 5.320 5.680 5.500 5.700 (20 MHz band- width only) 5.520 FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 133: More About Network Settings

    More about Network Settings FRITZ!Box and Networks The FRITZ!Box is delivered with preconfigured network settings. Accord- ing to these settings, all computers connected with the FRITZ!Box are lo- cated in the same subnetwork. You can change any of these preconfigured settings, but should only do so if you are well versed in networking tech- nology.

  • Page 134: Ip Address

    192.168.178.253 You can change the preset IP address. When Does It Make Sense to Change the IP Address? You should change the IP address of the FRITZ!Box if the fol- Circumstances lowing apply to your network: You have an existing local IP network, one subnet with several computers.
  • Page 135 The subnet mask must correspond with that of the connected subnet. When the DHCP server of the FRITZ!Box is enabled, the addresses 20 through 200 in the fourth group of nu- merals of the IP address are reserved for the DHCP server.

  • Page 136: Dhcp Server

    DHCP server is enabled by default in the factory settings. Every time the operating system on a computer connected with FRITZ!Box is started, it is assigned an IP address by the DHCP server. Only one DHCP server may be active within any network.
  • Page 137 You can switch off the DHCP server. To make sure that all computers remain in the same subnet as the FRITZ!Box even when the DHCP server is disabled, you must enter the IP addresses manually in the comput- er’s network settings. First disable the option “Obtain an IP address automatically”...

  • Page 138: Subnetwork

    Changing the DHCP Server Settings In the case of the preset IP address of the FRITZ!Box, the fol- lowing IP addresses are available for assignment to the computers: 192.168.178.2 - 192.168.178.253 Each IP address can be assigned only once. Changing the DHCP Server Settings Proceed as follows to open the DHCP server settings: Start a web browser on your computer.
  • Page 139 Disabling “All computers are located in the same IP network” The DHCP server of the FRITZ!Box assigns all of the comput- ers connected with the FRITZ!Box an IP address from the ad- dress pool of the DHCP server. Address pool of the DHCP server 192.168.178.20 - 200...
  • Page 140 “Apply”. Open the “System / Network Settings” menu. Click the “IP Addresses” button. The “IP Settings” page is opened. Here you can change the setting “All computers are located in the same IP network”. FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 141: More About Internet Telephony

    Telephony Scenarios If you have configured both a fixed-line number and an In- ternet number in FRITZ!Box, you can make calls in all direc- tions: from the fixed-line network into the fixed-line network from the Internet into the fixed-line network from the Internet into the Internet and receive calls from all directions as well.

  • Page 142: Bandwidth Management

    This function ensures that the speech quality dur- ing telephone calls over the Internet is not reduced by surf- ing activity. To do this, the FRITZ!Box adjusts all uploads and downloads to the currently available bandwidth. Be- cause the FRITZ!Box also places a higher priority on Internet telephony connections over Internet data connections, un- welcome interference is largely avoided.

  • Page 143: Customer Service Guide

    The Readme file is included on the FRITZ!Box CD. The manual of the FRITZ!Box Fon WLAN 7570 vDSL is includ- Manual ed in PDF format in the “Info” folder on the FRITZ!Box CD. You can install the Adobe Acrobat reader to view PDF docu- ments from the “Info”...

  • Page 144: Information In The Internet

    The FAQs can be viewed at the following address: www.avm.de/en/service/FAQs Updates and Software AVM provides firmware updates and various software for the FRITZ!Box Fon WLAN 7570 vDSL for free downloading over the Internet. Use the “Firmware Update” Wizard on the FRITZ!Box user Firmware interface to perform an update of your firmware.

  • Page 145: Support From The Avm Service Team

    Support from the AVM Service Team Support from the AVM Service Team Should problems with your FRITZ!Box arise, we recommend taking the following steps: If you have questions about starting operation of your FRITZ!Box, please consult the chapter “Connecting” from page 13.
  • Page 146 Which operating system are you using (e.g., Windows Vista or Windows XP)? How is the FRITZ!Box connected to your computer, with a network cable or via WLAN? At what step of the installation or in which application...

  • Page 147: Glossary

    24 Mbit/s. ADSL2+ is completely downward compatible, meaning that terminal equipment compliant with ADSL and ADSL2 can al- so be operated on ADSL2+ lines, although the devices can- not exploit the advantages of ADSL2+. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 148 IP addresses of the DNS serv- er to be used and of the default gateway. In assigning the IP addresses the DHCP server selects from a prescribed pool of IP addresses. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 149 IP addresses. This means that even pri- vate users have an economical way of placing their own In- ternet offers on their computer at home. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 150 Some firewalls also integrate additional concepts like IP masquerading and NAT to decouple data traffic by distin- guishing strictly between the internal and external network. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 151 If a computer wants to transfer data packets to a computer in another network, it must first transmit the packet to the gateway. To do this, the computer must know the address of the gateway. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 152 000 and 255. Every IP address contains two components: the network ad- dress and the host address. These two components can be read out of an IP address only if the subnet mask is also specified. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 153 Addressing is one of the main functions of the Internet Pro- tocol (IP). Internet addresses can be written in decimal, oc- tal or hexadecimal notation. The FRITZ!Box uses “dotted- decimal” notation: The four bytes of an address are repre- sented by decimal numbers separated by dots. The total volume of Internet addresses, the address space, is sepa- rated into classes (A, B, C, D, and E).
  • Page 154 If a computer from the local network offers server services, for instance, the configuration of a router using NAT or IP masquerading must forward the port used by the server FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 155 A local IP network can consist of one subnetwork or be di- vided into multiple subnetworks. The division into subnet- works is performed when the local IP network is configured. The subnetworks of a local IP network are also IP networks. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 156 Subnet mask: 255.255.0.0 The assignment of the first two groups of numerals in the subnet mask indicates that the first two groups of numerals in the IP ad- dress define the network. The following addresses result: FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 157 For this an Auto Configuration Client (ACC) must be in- tegrated in the device. The specifications for automatic configuration of the ADSL terminal device are stored on the Auto Configuration Server by the given Internet Service Pro- FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 158 Through traffic shaping these delays are avoided by provid- ing the dispatch of confirmation packets with bandwidth suitable for the given download activities. All of the packets to be sent are also assigned a priority suitable for their packet types. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 159 Today voice connections via the Internet, even to fixed-line and mobile networks, can be conducted conveniently using VoIP telephone systems that allow al- FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 160 Internet in private or public institutions. Many airports, hotels and cafes, for instance, make WLAN hotspots avail- able to their customers, either free or subject to a charge. Ultimately this has maneuvered WLAN into serious compe- tition with mobile UMTS technology. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 161 Bluetooth is the more useful solution, however, as Bluetooth uses consider- ably less power than wireless LAN. What is more, Bluetooth technology is more flexible and thus offers a greater band- width of potential applications. FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 162 Glossary FRITZ!Box Fon WLAN 7570 vDSL...

  • Page 163: Index

    LAN......18 multiple computers ... . 19 network hub/switch ... 19 FRITZ!Box Fon WLAN 7570 vDSL...
  • Page 164 ..... . .2 FRITZ!DSL ..... . . 57 logging off a cordless phone .
  • Page 165 ....127 standards....127 using FRITZ!WLAN USB Stick..20 WLAN connection other manufacturers .
