- Page 1 H25R5A/W H50R5A/W F255A/W F505A/W C25R5A/W C50R5A/W 801 Church Lane • P.O. Box D, Easton, PA 18044 Toll-free (800) 523-9361 • (888) 2-FOLLETT 206649 (610) 252-7301 • FAX (610) 250-0696 • www.follettice.com Cool Ideas For Ice Management ® ® 10/00 ®...
- Page 2 ICDI220...
-
Page 3: Attention Installer
After uncrating and removing all packing material, inspect the equipment for concealed shipping damage. If damage is found, notify your shipper immediately and contact Follett Corporation for help in filing a claim, if necessary. Caution: Do NOT tilt any freestanding model or icemaker unit further than 30° off vertical during uncrating or installation. -
Page 4: Ambient Specifications
ICDI220 Ambient specifications Air Temp 100° F/38°C Max. 50°F/10°C Min. (Best performance below 80˚F/27˚C) Water Temp 90°F/32°C Max. 40°F/4°C Min. (Best performance below 70˚F/21˚C) Water Pressure 70 P.S.I. Max. 10 P.S.I. Min. Plumbing C25/50 with H25/50 with C25/50 with H25/50 with F25/50 remote icemaker remote icemaker integral icemaker integral icemaker Dispenser drain... -
Page 5: Installation Procedures
ICDI220 Installation procedures Before you begin • All dispensers must be installed level in both directions to ensure proper operation. • Required service and ventilation clearances: • Models with integral icemakers (in top of cabinet) — 6" (15.2 cm) on right side of dispenser and at top. •... -
Page 6: Installing Countertop Dispensers Without Legs
ICDI220 Counter cut-outs 9" x 14" 229 mm x 356 mm 9" x 14" cutout 229 mm x 356 mm .5" (13 mm) to . 375" cutout 10 mm cutout .5" (13 mm) to 1.5626" cutout 40 mm 10.5" 267 mm 10.5"... -
Page 7: Installing Countertop Dispensers With Legs Accessory
ICDI220 Installing countertop dispensers with legs accessory Only models with remote icemakers can be installed on legs. Legs cannot be used with models equipped with integral icemakers (icemaker in top of cabinet). 1. For units where utilities will exit through back of dispenser, loosen rear-most clamp connecting PVC drain line to flexible tubing, rotate line 180˚... - Page 8 ICDI220 Installing 25 and 50 Series wallhung dispensers 1. For all 25 and 50 Series wallhung dispensers, install supplied wall bracket with six (6) 3/8" dia. fasteners as shown in diagrams below. (Note that three holes are available at each fastening site to allow capture Support angle and hook detail of studs/support within wall.)
-
Page 9: Installing Remote Icemaker
ICDI220 H25T5A/W mounting dimensions H50T5A/W mounting dimensions 20.625" 20.625" 524 mm 524 mm 1.0625" 1.0625" 27 mm 27 mm filler strip filler strip wall stud wall stud 16" 16" 3/8" (10 mm) 3/8" (10 mm) 406 mm 406 mm 2.3125" 2.3125"... - Page 10 ICDI220 7. Place free end of tube in cup of hot water to soften, slip supplied hose clamp onto tube and push tube onto exit port of evaporator. DO NOT TWIST HOSE WHEN SECURING TO EVAPORATOR. 8. Fasten tube on port with hose clamp, being sure that clamp is positioned on evaporator side of flange. 9.
- Page 11 ICDI220...
- Page 12 ICDI220 801 Church Lane • P.O. Box D, Easton, PA 18044 Toll-free (800) 523-9361 • (888) 2-FOLLETT 206649 (610) 252-7301 • FAX (610) 250-0696 • www.follettice.com Cool Ideas For Ice Management ® ® 10/00 ®...
