USING THE GRATING/SLICING DISCS

We recommend that you use the discs in the Midi bowl.
1
Slide the extension over the motor shaft.
3
Place the chosen disc with the relevant
reference facing upwards.
For non-reversible discs, make sure you
place the disc the right way up.
For all XL Food Processors discs are non-reversible.
12
2
Slicing/grating disc : each side is engraved
with a reference code, e.g. R/G4 = 4-mm
grater, E/S 2 = 2-mm slicer.
4
Slide the disc onto the extension. Turn it so
that it slots on properly. This is a two-stage
process.
W A R N I N G
• Always handle the discs with care, as
the blades are extremely sharp.
• Never insert your fingers or a foreign
object into the feed tube. Always use
the pusher designed for that purpose.
