ECOWATER
S Y S T E M S
INSTALLATION USING ECOWATER BYPASS VALVE
Filtered
Water OUT
120V,
60 Hz
Outlet
Drain
Fitting
Valve
Drain
Hose
Valve
Drain
Hose
Unfiltered
Water IN
Unfiltered Water
to Outside Faucets
1" Sweat Adaptor (2)
not included
1" Copper Tube (2)*
O-Ring Seal (2)*
#7214383
Bypass
* Included with filter - Pipe and
Valve
fittings supplied by installer.
Clip (2)*
Valve
INLET
FIG. 5
Pull out for
To adapt a copper tube to the filter, buy a compression fitting (garden hose thread to
filtered water
5/8" I.D. minimum tube and necessary tubing from your local hardware store.
"Service"
Push in for
Bypass
To standpipe, sump, laundry
tub or other suitable drain.
1-1/2"
Air Gap
FLOOR
DRAIN

Typical Installation Illustrations

Use if water supply flows from the left.
Include single or 3-valve bypass.
UNFILTERED
WATER
FROM FILTER
OUTLET
INSTALLATION USING 3-VALVE BYPASS
For filtered water SERVICE:
-Open the inlet and outlet
valves
For unfiltered BYPASS:
-Close the inlet and outlet
valves
-Open the bypass valve
CONNECTING A RIGID VALVE DRAIN TUBE
Clip
Drain Fitting
1-1/2""
SUMP
Air Gap
LAUNDRY
TUB
1-1/2" Air Gap
6
CROSS-OVER
FILTERED
WATER
TO FILTER
INLET
BYPASS
Valve
OUTLET
INLET
Valve
Valve
1" Sweat
Adaptor (2)
not included
Clip (2)*
1" Copper Tube (2)*
O-Ring Seal (2)*
Valve
INLET
Adaptor, garden hose
thread to compression
5/8" I.D.
(minimum)
copper tube
1-1/2"
Air Gap
STAND
PIPE
FIG. 6
FIG. 7
