Acquiring a scan

To acquire a scan click on the 'Viewfinder' button.
In the Viewfinder, once the target is locked on and highlighted green, you can capture a
scan.
This is accomplished by pressing either one or both of the trigger buttons or by clicking the
'Capture' button in the Viewfinder.
Holding the scanner and using the
trigger buttons
Once a scan has been taken it will take 15 seconds for the flashes to cool down before you
can take another scan. This is shown by the progress bar at the bottom of the Viewfinder
image.

Inspecting a scan

Good vs bad data
When reviewing a scan you may find some bad data that you wish to remove.
Rotate the scan and locate the data you wish to remove. Bad data will visibly appear
incorrect. It may appear raised, rough or overly smooth and generally will not be
comparable to the subject which was scanned.
