The Viewfinder will then display a live view from the scanner.
The Viewfinder
Target tracking in the Viewfinder
The target is required to take a scan. The Viewfinder has a tracking capability and displays
to you, via a ring around the target, the distance that you are away from the subject.
There are various methods of feedback in the viewfinder to correctly position the SCANIFY,
the target highlight color and the changing status icon on the side of the viewfinder.
Red – Too far away from
the target (> 45cm/17.7")
Green – Perfect distance
from the target
(35cm/13.7" –
45cm/17.7")
Turns on the scanners guide
lights for use in low light
Rotates the camera view
Preview window
Scan position and status
Flash recharge
White – Too close to the
target (< 35cm/13.7")
18
