KF12P
PA USE
L
L
KMT18
CH. 1
A.C.
12
R
KF12MT
KF12P
Powered
output
R
KF12P
Powered
output
CH. 1
CH. 2
A.C.
KF12P
KMT18
CH. 1
A.C.
Similar to the monitor use, when you
employ the KF12P combined with a
KF12MT as a stereo P.A. system you can
connect both the main Left and Right
signal from your audio source. Then you
can route one signal to the KF12MT and
the other to the powered output socket
feeding the KF12P.
CH. 1
If you need a bass reinforcement, you can
use two active KMT18 for both you P.A.
sides (L+R), feeding a different KF12P
from each 1000 W powered output
channel.
The shape of the KF12P, provided with
two different flanges for the mounting on
a pole, allows you to configure many kinds
of set up.
A.C.
KA40
CH. 2
REV. A
