T
Z
™ option
URBO
ONE
Blasts into every corner to eliminate the
need for soaking and scrubbing of dirty,
baked-on dishes. For your toughest
items, use the T
Z
URBO
ONE
the Pots Pans cycle. See loading
information.
Hi Temp
Raises the main wash temperature to
improve cleaning. When used with the
Normal Wash cycle this will provide a
little extra tough cleaning capability, but
not as much as the Pots Pans cycle.
Sani Rinse
This high temperature option sanitizes
your dishes and glassware in accordance
with National Sanitation Foundation
(NSF)/ANSI Standard 184 for Residential
Dishwashers. Certified residential
dishwashers are not intended for
licensed food establishments. The green
sanitized light indicates that the Sani
Rinse option was successfully
completed.
Heated Dry
Turns the heat element on after the wash
cycle is completed. Use rinse aid with or
without the Heated Dry option for best
drying results. Plastic items are less likely
to deform when loaded in the top dish
rack.
The maximum additional water used for any combination of options is 2.1 gal. (7.9 L).
Delay Hours
Use this option to run your dishwasher during off-peak hours. Local utility providers recommend using energy during off-peak hours
when possible. Be sure to close the door and press START/RESUME after adding items.
To delay the start
1. Select a wash cycle and options.
2. Press the delay button to choose the number of hours to be delayed.
3. Close the door and press START/RESUME. The dishwasher starts in the selected number of hours.
NOTE: Anytime the door is opened (such as, to add a dish), the START/RESUME button must be pressed again to resume the delay
countdown.
Control Lock Option
Use the Control Lock option to avoid unintended use of the dishwasher between cycles. When LOCK ON is lit, all buttons are
disabled. The dishwasher door can still be opened/closed while the controls are locked.
To turn on the Lock
Press and hold HEATED DRY for 4 seconds. LOCK ON will light up. If you press any pad while your dishwasher is locked, the light
flashes 4 times.
NOTE: The dishwasher cannot run if the control is locked.
To turn off the Lock
Press and hold HEATED DRY for 4 seconds. The light turns off.
Can be
selected with
SmartWash
Pots Pans
™ option with
Normal Wash
SmartWash
Pots Pans
Normal Wash
SmartWash
Pots Pans
Normal Wash
Available with
any cycle
except
Quick Rinse
What it does
Directs all of the
cleaning power of the
H E
®
dishwasher to the
TURBOZONE™ area
during certain times in
the wash cycle.
H E
®
Raises the main wash
temperature from 105°F
(41°C) to 120°F (49°C).
Increases the main wash
temperature from 105°F
H E
®
(41°C) to 120°F (49°C)
and the final rinse from
140°F (60°C) to 155°F
(68°C).
Turns the heat element
on at the end of the
wash cycle.
Added time to cycle
Typical
Max
25
40
22
37
33
57
26
32
Added
Water
Gallons
(Liters)
0 - 2.1
(0 - 7.9)
0 - 2.1
(0 - 7.9)
0 - 2.1
(0 - 7.9)
0
17
