- Page 1 054-8161-0 CompaCt ReCipRoCating Saw INSTRUCTION IMPORTANT: Read and understand this instruction manual thoroughly before MANUAL using the product.
-
Page 2: Table Of Contents
headline bars TAbLe Of CONTeNTS Technical Specifications Safety Guidelines 5–8 Key Parts Diagram Important Information continuation tabs Assembly Instructions 11–12 Operating Instructions 13–16 Maintenance Troubleshooting notes Part list 19–20 Warranty 21–22 warnings NOTe: If any parts are missing or damaged, or if you have any questions, please call our toll-free helpline at 1-800-689-9928 SAVe THeSe INSTRUCTIONS • This manual contains important safety and operating... -
Page 3: Technical Specifications
054-8161-0 | contact us 1.800.689.9928 RULeS fOR SAfe OPeRATION TeCHNICAL SPeCIfICATIONS WARNING! Rated voltage 120V~, 60Hz Rated power input Safety symbols in this Instruction Manual are used to flag possible dangers. The safety symbols and their explanations require your full understanding. The safety warnings do not, by themselves, Variable speed 0–2700 SPM... - Page 4 054-8161-0 | contact us 1.800.689.9928 eLeCTRICAL SAfeTy • Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety • Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter measures reduce the risk of starting the power tool accidentally. plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of • Store idle power tools out of the reach of children and do not allow persons unfamiliar with the...
-
Page 5: Key Parts Diagram
054-8161-0 | contact us 1.800.689.9928 SAfeTy INSTRUCTIONS fOR ReCIPROCATINg SAw PACKAge CONTeNTS • Hold the power tool by insulated gripping surfaces when performing an operation where the Compact reciprocating saw, general-cutting blade, hex key and instruction manual cutting accessory may contact hidden wiring or its own cord. If a cutting accessory contacts a “live” Key PARTS dIAgRAM wire, it may cause the exposed metal parts of the power tool to become“live”... -
Page 6: Important Information
054-8161-0 | contact us 1.800.689.9928 IMPORTANT INfORMATION ASSeMbLy ANd AdJUSTMeNT INSTRUCTIONS Before attempting to use this reciprocating saw, familiarize yourself with all of its operating features and safety INSTALLINg ANd ReMOVINg THe requirements. fig 1 bLAdeS (fig 1) 1. -
Page 7: Operating Instructions
054-8161-0 | contact us 1.800.689.9928 PIVOT SHOe OPeRATINg INSTRUCTIONS SLIdINg THe SHOe IN OR OUT (fig 2a) TURNINg THe SAw ON ANd Off ANd fig 2a fig 3 CONTROLLINg THe SPeed (fig 3) For maximum control and longer blade life, the base... -
Page 8: General Cutting
054-8161-0 | contact us 1.800.689.9928 geNeRAL CUTTINg PLUNge CUTTINg (fig 4) fig 4 Your reciprocating saw is ideal for plunge cutting directly 1. Unplug the reciprocating saw from the power supply. into surfaces that cannot be cut from an edge, such as 2. -
Page 9: Maintenance
054-8161-0 | contact us 1.800.689.9928 MeTAL CUTTINg MAINTeNANCe The saw can be used to cut metals, such as sheet steel, pipe, steel rods, aluminum, brass, and copper. Be Before each use, inspect the reciprocating saw, on/off switch and cord for damage. Check for damaged, careful not to twist or bend the saw blade. -
Page 10: Troubleshooting
054-8161-0 | contact us 1.800.689.9928 TROUbLe SHOOTINg exPLOded VIew Problem Possible Causes Solution The tool is not connected to a The motor does not start Connect the tool to a power source power source Blade cannot be removed... - Page 11 5670169000 2750873000 Rotor 3660296000 Torsion Spring 5700004000 Ball Bearing This Mastercraft product is guaranteed for a period of 3 years from the date of original retail purchase 3123316000 Cover 5650038000 Plain Washer against defects in workmanship and materials, except for the following components: 5660032000 Circlips For Shaft...
-
Page 12: Warranty
054-8161-0 | contact us 1.800.689.9928 additional Limitations This warranty applies only to the original purchaser and may not be transferred. Neither the retailer nor the manufacturer shall be liable for any other expense, loss or damage, including, without limitation, any indirect, incidental, consequential or exemplary damages arising in connection with the sale, use or inability to use this product.
