Summary of Contents for MasterCraft 054-8363-0
- Page 1 054-8363-0 Corded CirCular Saw INSTRUCTION IMPORTANT: Read and understand this instruction manual thoroughly before MANUAL using the product.
-
Page 2: Table Of Contents
headline bars TAbLe Of CONTeNTS Technical Specifications Safety Guidelines 5–10 Key Parts Diagram 11–12 Important Information 13–15 continuation tabs Assembly Instructions 16–19 Operating Instructions 20–24 Maintenance Troubleshooting notes Part List 27–29 Warranty 30–31 warnings NOTe: If any parts are missing or damaged, or if you have any questions, please call our toll-free helpline at 1-800-689-9928 SAVe THeSe INSTRUCTIONS • This manual contains important safety and operating... -
Page 3: Technical Specifications
054-8363-0 | contact us 1.800.689.9928 RULeS fOR SAfe OPeRATION TeCHNICAL SPeCIfICATIONS WARNING! Rated power input 14.0A Rated Voltage 120V~, 60Hz Safety symbols in this Instruction Manual are used to flag possible dangers. The safety symbols and their explanations require your full understanding. The safety warnings do not, by themselves,... - Page 4 054-8363-0 | contact us 1.800.689.9928 eLeCTRICAL SAfeTy • Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety • Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter measures reduce the risk of starting the power tool accidentally. plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of • Store idle power tools out of the reach of children and do not allow persons unfamiliar with the...
- Page 5 054-8363-0 | contact us 1.800.689.9928 fURTHeR SAfeTy INSTRUCTIONS fOR ALL SAwS • The lower guard may be retracted manually only for special cuts, such as “plunge cuts” and “compound cuts”. Raise the lower guard by retracting the handle and then, as soon as blade enters the material, the lower guard must be released. For all other sawing, the lower guard should operate KICKbACK CAUSeS ANd ReLATed wARNINgS automatically.
-
Page 6: Key Parts Diagram
054-8363-0 | contact us 1.800.689.9928 PACKAge CONTeNTS • Always check the tool for damaged parts. Before further use of the tool, a guard or other part that is damaged should be carefully checked to determine if it will operate properly and perform its intended Circular saw, blade wrench, blade, edge guide and instruction manual function. -
Page 7: Important Information
054-8363-0 | contact us 1.800.689.9928 IMPORTANT INfORMATION Part Part Before attempting to use this tool, become familiar with all of its operating features and safety requirements. On/off trigger switch Bevel adjustment locking knob For optimum performance and safety, read the following operating instructions carefully before using. - Page 8 054-8363-0 | contact us 1.800.689.9928 SAw bLAdeS TO LeSSeN THe CHANCe Of fig 5 KICKbACK, fOLLOw THeSe All saw blades need to be kept clean, sharp and properly set in order to cut efficiently. Using a dull blade dIReCTIONS: places a heavy load on the saw and increases the danger of kickback.
-
Page 9: Assembly Instructions
054-8363-0 | contact us 1.800.689.9928 ASSeMbLy INSTRUCTIONS TO AdjUST beVeL SeTTINg (fig 8) fig 8 0–45° bevel setting dePTH Of CUT AdjUSTMeNTS 1. Unplug the circular saw from the power supply. Always keep the correct blade-depth setting. The correct blade-depth setting for all cuts should not exceed 1/4 2. - Page 10 054-8363-0 | contact us 1.800.689.9928 TO CHeCK 0° beVeL STOP (fig 9) CHANgINg THe fig 9 fig 11 bLAde (fig 11) 1. Unplug the circular saw from the power supply. Carpenter’s square Blade 1. Unplug the circular saw from 2.
-
Page 11: Operating Instructions
054-8363-0 | contact us 1.800.689.9928 OPeRATINg INSTRUCTIONS TO MAKe THe beST POSSIbLe CUT: 1. ALWAYS use your saw with your hands positioned correctly, with one hand on the main handle and TURNINg THe SAw ON ANd Off (fig 12) operating the trigger switch and the other hand on the front assist handle (Fig. - Page 12 054-8363-0 | contact us 1.800.689.9928 INSTALLINg ANd USINg THe edge MAKINg CROSS CUTS ANd RIP CUTS fig 13 fig 14 Line of cut gUIde (fig 13) (fig 14) 0° indicator Always use an edge guide when making long or wide rip When making a cross cut or rip cut, align your line of cut cuts with your saw.
-
Page 13: Maintenance
054-8363-0 | contact us 1.800.689.9928 MAKINg A beVeL CUT (fig 16) MAINTeNANCe 1. Secure workpiece with clamps. befORe eACH USe 2. Draw a line of cut on the workpiece. 1. Inspect the circular saw, the trigger switch, the cord and the accessories for damage. -
Page 14: Troubleshooting
054-8363-0 | contact us 1.800.689.9928 TROUbLeSHOOTINg exPLOded VIew Problem Possible Causes Solution The tool is not connected to a power Connect the tool to a power The motor does not start source source 1. Teeth are dull. This is caused by hitting a hard object such as a nail, dulling 1. - Page 15 054-8363-0 | contact us 1.800.689.9928 Part No. description Part No. description Part No. description Part No. description 5680009000 Rivet 4870530000 Trigger Switch 5620398000 Flange Bolt 5700048000 Ball Bearing 3704593000 Support 3700367000 Cord Anchorge 3550222000 Clamp 5610048000...
-
Page 16: Operating Instructions
BY MaSTerCraFT CaNada ToroNTo, CaNada M4S 2B8 This Mastercraft product is guaranteed for a period of 3 years from the date of original retail purchase against defects in workmanship and materials, except for the following components:...
Need help?
Do you have a question about the 054-8363-0 and is the answer not in the manual?
Questions and answers
where can I purchase brushes for the motor of my 05483630 7 1/4 inch circular saw
