GO-SOUND series User manual
Note: If you happen to lose the AC linecord, always use a three-pin
plug with a ground pin.
6
5
4
3
2
2) POWER Switch
Switch up to turn the spekaer on, and switch down to turn it off. Make sure the
level control is down before you turn it on.
3) MIC/LINE In INPUT Section
There is a female XLR-type connector and a 1/4" Jack plug that accept a bal-
anced or unbalanced mic- or line-level signal. The switch Line/Mic has to be
pressed in case of microphone level signals. There is no phantom power for
a microphone, so you should use a dynamic mic, or use a condenser type if it
has its own battery power.
WARNING: Pressing MIC/LINE switch on line level signals may cause
digital media player
level level
0 10 0 10
LINE
L R
MIC
MIC/LINE LINE
INput INput
GO-SOUND 12AM
ON
OFF
Power
level level
0 10 -10 +10
HIGH
aux in
-10 +10
POWER
low
CLIP
-10 +10
MIX
master
out
AC INPUT
AC 230V 50HZ
T1.0A/250V
ENGLISH
7
8
9
10
11
12
13
1
