Short Parts List - Benchmark mCHP BoilerMate Design, Installation And Servicing Instructions

Table 7.1 Specification of main components and Parts List
Description
1 PHE pump
2 Plate heat exchanger (PHE)
3 PHE pump isolating valve - inlet
4 PHE Pump isolating valve - oulet
5 CW inlet Y-line strainer
6 Boiler pump
7 Central heating pump
8 Boiler pump isolating valves
9 Central heating pump isolating
valves
10 2 x 3kW switch immersion heater
11 Main PCB controller
12 Bottom store sensor
13 Middle store sensor
14 Top (OHT) sensor
15 Front panel display
16 Front panel display wiring harness
17 Internal fuses/circuit protection
18 Switch contactor
19 DIN Rail terminals
20 Complete DIN rail assembly
21 Complete wiring harness
22 On-Off switch (part or panel)
23 Programmer
24 3-Port diverter valve-body
25 3-Port diverter valve-actuator
26 Automatic bypass valve
27 Pump relay
Supplied By www.heating spares.co Tel. 0161 620 6677
Supplier & model
Grundfos, UPR 15-50 (modulating)
SWEP, 24 Plate heat exchanger
Martin Orgee, 90° valve
Martin Orgee, Straight valve with NRV
Grundfos, UPS 15-60 (1½" - standard)
Grundfos, UP 15-60 (1½" modulating)
Vemco, 22mm ball type (Inlet &
Outlet)
Martin Orgee, 90° valve - INLET
Martin Orgee, Straight valve - OUTLET
Backer
Pijnenburg, 147/3GS controller
Tasseron, Single sensor
Tasseron, Single sensor
Tasseron, Duplex sensor
RH Technical, Membrane overlay
RH Technical, Membrane harness
Control circuit: 1 x 6A MCB
Switch circuit: 2 x 16A MCB
Telemecanique, 1 x 25A contactor
Wago, Part of DIN rail assembly
W a g o , B e s p o k e t e r m i n a l &
components
Arcoelectric, Green illuminated rocker
switch
Grasslin Electromechanical
Honeywell
Honeywell
Page 37
SERVICING 7.0
Part Stock
number Code
59505432 GT089
E8T/24 GT017
7308123 GT135
GT133
XB314
XB241
59505432 GT089 Type-N only
XB121
7308123 GT135 Type-N only
--- GT133 Type-N only
147/3GS GT103
TSK10B4 GT198
TSK10B4 GT198
TSK11B4 GT199
GC2520-M5 XB014
51002318 XB140
NSI
C5503- CA006
ALNAK
XB215
Type-R only
Type-R only
Type-R only
Models
All
All
All
All
All
All
All
All
All
All
All
All
All
All
All
All
All
All
All
All
All
All
All
