  5. BoilerMate BMA 125 OV
  6. Design, installation and servicing instructions

Benchmark BoilerMate BMA 125 OV Design, Installation And Servicing Instructions

A-class, an open vented central heating and mains pressure hot water supply system incorporating a thermal store
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
A - C L A S S
BoilerMate OV
DESIGN, INSTALLATION AND
SERVICING INSTRUCTIONS
Gas Council Approved Reference Numbers
89-317-09 / BMA 125 OV
89-317-10 / BMA 145 OV
89-317-11 / BMA 185 OV
89-317-12 / BMA 215 OV
89-317-13 / BMA 225 OV
benchmark
TM
AN OPEN VENTED CENTRAL HEATING
The code of practice for the installation,
AND MAINS PRESSURE HOT WATER SUPPLY
commissioning & servicing of central heating systems
SYSTEM INCORPORATING
A THERMAL STORE
ALL MODELS COMPLY WITH THE
WATER HEATER MANUFACTURERS
SPECIFICATION FOR INTEGRATED THERMAL
STORES
