10 SHORT PARTS LIST

Reference Description
Spark generator
Diverter valve cartridge assembly
Seasonality valve
12 L fl w regulator (red - 24X)
Pressure gauge
Condensate trap assembly
Flue sensor
DHW sensor
Overheat thermostat
Flame sensing electrode
Inlet mesh filte
Flue turret (30C - 34C - 28X)
Flue turret (26C - 24X)
DHW fl w switch
Ignition electrode
Pump head
Filling loop
Flue turret foam seal
14L fl w regulator (pink - 28X)
Primary heat exchanger (26C - 24X)
Primary heat exchanger (30C - 28X)
Primary heat exchanger (34C)
Burner (34C)
Burner (26C - 24X)
Burner (30C - 28X)
Diverter valve motor
Pressure switch
DHW heat exchanger plus seals - 12 plate (26C - 24X)
DHW heat exchanger plus seals -14 plate (30C - 28X)
DHW heat exchanger plus seals - 18 plate (34C)
PCB
Condensate trap bowl
Primary NTC sensor
Injector 5.1 mm (26C, 24X - NG)
Injector 6.8 mm (30C, 28X - NG)
Injector 3.8 mm (26C, 24X - LPG)
Injector 4.8 mm (30C, 28X - LPG)
Injector 5.8 mm (34C - LPG)
Pressure relief valve 3 bar
Gas valve
Automatic air vent with 'O' ring
Drip tray/flue connectio
Expansion vessel 8L
Fan (34C)
Fan (26C - 30C - 24X - 28X)
Flue turret (30C - 34C - 28X)
Flue turret (26C - 24X)
Complete boiler seal kit
Hydraulic circuit seal kit
Primary H/E seal kit
Air/flue system seal ki
Qty. Alpha Pt. No.
1
1.018162
1
3.020380
1
3.017106
1
1.020412
1 1.023551
1 3.017281
1 1.024296
1
1.025380
1
1.025797
1
1.032007
1
1.8403
1
1.030738
1
1.030636
1
1.028570
1 3.017477
1 3.022793
1 3.020960
1
1.030666
1
1.032198
1
1.031447
1
1.031448
1
1.031449
1
1.031824
1 1.023999
1 1.019622
1 1.028572
1
1.027277
1
3.021692
1
3.022783
1
3.022784
1
1.030267
1
1.019228
1
1.021762
1 1.022472
1 1.031471
1
1.022050
1
1.022052
1
1.022049
1
1.028643
1
1.031823
1
1.027110
1
1.030667
1 1.030996
1 1.029719
1 1.027178
1
3.022546
1
3.022544
1
3.022652
1
3.022653
1
3.022654
1
3.022655
Alpha InTec C and X - Short Parts List
