Short Parts List - Benchmark Alpha CD18S Installation And Servicing Instructions

11 SHORT PARTS LIST

Reference
Fig. 27
Fig. 27
Fig. 2A/2B, item 6/31
Fig. 2B, item 31
Fig. 32
Fig. 32
Fig. 24
Fig. 33
Fig. 28
Fig. 28
Fig. 33
Fig. 30
Fig. 28
Fig. 28
Fig. 28
Figs. 34 and 28
Fig. 20
Fig. 30
Fig. 28
Fig. 2A,2B, item 14
Fig. 33
Fig. 33
Fig. 33
Fig. 28
Fig. 28
Fig. 28
Fig. 28
Fig. 2A,2B, item 26/27
Fig. 27
Fig. 25
34 Alpha CD18S/24S/30S - Short Parts List
Description
Burner - CD18/24
Burner - CD30
Main injector 5.0 mm - CD18/24
Main injector 6.6 mm - CD30
Primary heat exchanger - CD18/24
Primary heat exchanger - CD30
Gas valve - Honeywell VK4115V
Pump
Fan assembly - CD18/24
Fan assembly - CD30
Primary pressure switch
PCB
Flue thermostat
Ignition generator
Transformer
Temperature sensor
Fuse F2A
PCB fuse F315mA
Overheat thermostat
Expansion vessel 8 Litre
Pressure relief valve 3 bar
Automatic air vent
Pressure gauge
Ignition electrode and lead
Ignition electrode
Flame sensing electrode and lead - CD18/24
Flame sensing electrode and lead - CD30
By-pass assembly
Combustion chamber insulation panel front
Condensate trap
Qty. British Gas GC No.
Alpha Pt. No.
1 1.013172
1 1.018956
1 1.011848
1 1.019247
1 1.018030
1 1.018593
1 1.011846
1 1.015610
1 1.010659
1 1.016623
1 1.017496
1 1.017788
1 1.012067
1 1.018162
1 1.012477
2 1.015970
1 1.6098
1 1.013931
1 1.018031
1 1.015394
1 1.011126
1 1.010771
1 1.016151
1 3.013626
1 1.016779
1 1.018163
1 1.019293
1 3.012801
1 1.014732
1 1.011844
E94-407
E96-565
E94-409
E96-566
E94-408
E96-567
E94-410
E57-666
E94-411
E96-569
E76-320
E94-412
E94-413
E94-414
E94-415
E76-317
E76-378
E96-571
E94-416
E57-702
E57-703
E57-709
E57-710
E94-417
E94-418
E94-419
E96-572
E65-498
E94-420
H01-874
