  • Page 3 Preface Notebook Computer M720T/M722T/M728T/M729T Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the M720T/ M722T/M728T/M729T series notebook PC.

  • Page 6: Fcc Statement

    Preface FCC Statement (Federal Communications Commission) You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 7 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 8: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...

  • Page 9: Power Safety

    Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.

  • Page 10: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 Part List Illustration Location ............A-2 Top with Fingerprint (M720T) ............A-3 Overview ..................1-1 Top without Fingerprint (M720T) ..........A-4 System Specifications ......... 1-2 Bottom (M720T) ................A-5 ........... 1-4 LCD (M720T) ................A-6 External Locator - Top View with LCD Panel Open ......1-5 HDD (M720T) ................
  • Page 12 Preface System Block Diagram ..............B-2 Multi I/O Board 1/2 ..............B-34 Intel Penryn (Socket-P) 1/2 ............B-3 Multi I/O Board 2/2 ..............B-35 Intel Penryn (Socket-P) 2/2 ............B-4 Finger Printer Board ..............B-36 Cantiga 1/6 - Host ................B-5 Click Board ...................B-37 Cantiga 2/6 - VGA, CRT ..............

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the M720T/M722T/M728T/M729T series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about drivers (e.g. VGA & audio) is also found in User’s Manual. That manual is shipped with the computer.

  • Page 14: System Specifications

    Introduction System Specifications Feature Specification Processor Intel® Core™2 Duo Processor 45nm (45 Nanometer) Process Technology 35W - (478-pin) Micro-FC-PGA Package - Socket-P 6MB On-die L2 Cache & 1006MHz FSB T9400/ T9600 2.53/ 2.8 GHz Intel® Core™2 Duo Processor 45nm (45 Nanometer) Process Technology 25W - (478-pin) Micro-FC-PGA Package - Socket-P 3MB On-die L2 Cache &...
  • Page 15 Introduction Feature Specification Interface Three USB 2.0 Ports One RJ-11 Modem Jack One Headphone-Out Jack One RJ-45 LAN Jack One Microphone-In Jack One DC-In Jack One S/PDIF Out Jack One External Monitor Port One Internal Microphone Card Reader Embedded 7-in-1 Card Reader (MS/ MS Pro/ SD/ Mini SD/ MMC/ RS MMC/ MS Duo) Note: MS Duo/ Mini SD/ RS MMC Cards require a PC adapter ExpressCard Slot One ExpressCard/34(54) Slot...
  • Page 16 Introduction Feature Specification Environmental Temperature Relative Humidity ° ° Spec Operating: C - 35 Operating: 20% - 80% Non-Operating: -20°C - 60°C Non-Operating: 10% - 90% Dimensions 299mm (w) * 219mm (d) * 26.5-35.7mm (h) & Weight 1.88 kg With 4 Cell Battery and ODD Optional Optical Drive Module Options: Fingerprint ID Reader Module (Factory Option)

  • Page 17: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. Optional Built-In PC Camera 2. LCD 3. Speakers 4. Power Button 5. Hot Key Buttons 6. LED Status Indicators 7. Keyboard 8. Touchpad & Buttons 9.

  • Page 18: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right side Views Figure 2 Front Views 1. LED Power & Communication Indicators 2. 7-in-1 Card Reader 3. S/PDIF-Out Jack 4. Microphone-In Jack 5. Headphone-Out Jack Figure 3 Right Side Views 1. Optical Device Drive Bay 2.

  • Page 19: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. DC-In Jack 2. RJ-45 LAN Jack 3. External Monitor Port 4. Vent/Fan Intake/ Outlet 5. 2 * USB 2.0 Ports 6. ExpressCard Slot Figure 5 Rear View 1.

  • Page 20: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Battery (M730T 8 Cell Battery Pictured) 2. Hard Disk Bay Cover (3.5G Module Location) 3. RAM & CPU Bay Cover Overheating To prevent your com- puter from overheating make sure nothing blocks the vent/fan in-...

  • Page 21: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. Transformer 2. VT6103L 3. ExpressCard Connector 4. ENE MR510 5. KBC ITE IT8512E Mainboard Overview - Top (Key Parts) 1 - 9...

  • Page 22: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. CPU Socket (no CPU installed) 2. Northbridge 3. Memory Slots DDR2 SO-DIMM 4. ICS 5. Card Reader Socket 6. Southbridge 7. Audio Codec 8. Mini-Card Connector (WLAN Module) 1 - 10 Mainboard Overview - Bottom (Key Parts)

  • Page 23: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. Hot-key Connector 2. LCD Cable Connector 3. Keyboard Cable Connector 4. Audio Board Connector 5. Microphone Cable Connector 6. TouchPad Cable Connector Mainboard Overview - Top (Connectors) 1 - 11...

  • Page 24: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. BT Cable Connector 2. Multi Board Connector 3. CD-ROM Connector 4. HDD Connector 5. CMOS Bat. Connector 6. CPU Fan Cable Connector 7. DC-In Jack 8. USB Port 1 - 12 Mainboard Overview - Bottom (Connectors)

  • Page 25: Disassembly

    Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the M720T/M722T/M728T/M729T series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Wireless LAN Module: 1. Remove the battery page 2 - 5 1.

  • Page 29: Removing The Battery

    Disassembly Removing the Battery 1. Turn the computer off, and turn it over. Figure 1 2. Slide the latch in the direction of the arrow. Battery Removal 3. Slide the latch in the direction of the arrow, and hold it in place. 4.

  • Page 30: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm Figure 2 (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in HDD Assembly Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 31 Disassembly 3. Remove the hard disk bay cover Figure 3 4. Grip the tab and slide the hard disk in the direction of arrow HDD Assembly 5. Lift the hard disk out of the bay Removal (cont’d.) 6. Remove the screw &...

  • Page 32: Removing The Optical (Cd/Dvd) Device

    Disassembly Removing the Optical (CD/DVD) Device Figure 4 Optical Device 1. Turn off the computer, and remove the battery (page 2 - Removal 2. Locate the component bay cover and remove screws 3. Carefully (a fan and cable are attached to the under side of the cover) lift up the bay cover. a.

  • Page 33: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 5 The computer has two memory sockets for 200 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting RAM Module DDR2 667/800MHz. The main memory can be expanded up to 4GB. The SO-DIMM modules supported are 1024MB, Removal and 2048MB and DDRII Modules.
  • Page 34 Disassembly 5. Gently pull the two release latches ( & on the sides of the memory socket in the direction indicated by the Figure 6 arrows (Figure 6c). RAM Module Removal (cont’d.) c. Pull release latch(es). d. Remove the module(s). 6.

  • Page 35: Removing The Inverter Board

    Disassembly Removing the Inverter Board Figure 7 Inverter Board 1. Turn off the computer, and remove the battery (page 2 - Removal 2. Remove any rubber covers, screws (Figure 7a), then run your finger around the middle of the frame to carefully unsnap the LCD front panel module from the back.

  • Page 36: Removing The Processor

    Disassembly Removing the Processor Figure 8 Processor Removal 1. Turn off the computer, and remove the battery (page 2 - 5) and the CPU/RAM bay cover (page 2 - 2. The CPU heat sink will be visible at point on the mainboard. a.
  • Page 37 Disassembly 5. Turn the release latch towards the unlock symbol , to release the CPU (Figure Figure 9 6. Carefully (it may be hot) lift the CPU up out of the socket (Figure Processor Removal 7. Reverse the process to install a new CPU. Sequence 8.

  • Page 38: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 10 Wireless LAN 1. Turn off the computer, remove the battery (page 2 - 5) and the component bay cover (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard.

  • Page 39: Removing The Bluetooth Module

    Disassembly Removing the Bluetooth Module Figure 11 Bluetooth Removal 1. Turn off the computer, remove the battery (page 2 - 2. The Bluetooth module will be visible at point on the mainboard. a. Remove the cover and 3. Remove screw and carefully disconnect the cable and separate the module from the connector locate...

  • Page 40: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 12 Keyboard Removal 1. Turn off the computer, and remove the battery (page 2 - 2. Press the three keyboard latches at the top of the keyboard to elevate the keyboard from its normal position (you a.

  • Page 41: Removing The Modem

    Disassembly Removing the Modem Figure 13 1. Turn off the computer, remove the battery (page 2 - 5), HDD (page 2 - 6), component bay cover (page 2 - 9), opti- Modem Removal cal device (page 2 - 8), CPU (page 2 - 12), bluetooth (page 2 -...
  • Page 42 Disassembly 6. Remove screws and disconnect the connectors from the mainboard. Figure 14 7. Separate the bottom case from the mainboard and turn it over. Modem Removal 8. Remove the screws and disconnect the connector from the modem. Sequence 9. Lift the modem up off the socket e.

  • Page 43: Part Lists

    Part Lists Appendix A: Part Lists This appendix breaks down the M720T/M722T/M728T/M729T series notebook’s construction into a series of illustra- tions. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 44: Part List Illustration Location

    Part Lists Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A- 1 Part List Illustration Location Parts M720T M722T M728T M729T Top with Fingerprint page A - 3 page A - 10...

  • Page 45: Top With Fingerprint (M720T

    白色 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 型 無鉛 型 無鉛 型 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 鋁箔 無鉛 材質 無鉛 設變材質 無鉛 Top with Fingerprint (M720T) A - 3...

  • Page 46: Top Without Fingerprint (M720T

    黑色 無鉛 白色 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 型 無鉛 型 無鉛 型 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 鋁箔 無鉛 材質 無鉛 設變材質 無鉛 A - 4 Top without Fingerprint (M720T)

  • Page 47: Bottom (M720T

    無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 側壁加肉 無鉛 無鉛 無鉛 拉帶加長 無鉛 無鉛 藍天3 互億 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 Bottom (M720T) A - 5...

  • Page 48: Lcd (M720T

    無鉛 無鉛 無鉛 灰色 精乘 無鉛 黑色 精乘 無鉛 黑色 精乘 無鉛 無鉛 富佑鴻 無鉛 無鉛 無鉛 無鉛 無鉛 中性 無鉛 無鉛 無鉛 無鉛 無鉛 黑色 精乘 無鉛 無鉛 無鉛 無鉛 硬式保護膜 透明 無鉛 無鉛 A - 6 LCD (M720T)

  • Page 49: Hdd (M720T

    Part Lists HDD (M720T) Figure A - 5 (M720T) 無鉛 無折切痕(設變)(無鉛) HDD (M720T) A - 7...

  • Page 50: Combo (M720T

    Part Lists COMBO (M720T) Figure A - 6 COMBO (M720T) 無鉛 無鉛 無鉛 無鉛 觸點高度降低 (世華)無鉛 A - 8 COMBO (M720T)

  • Page 51: Dvd-Dual Drive (M720T

    Part Lists DVD-Dual Drive (M720T) Figure A - 7 DVD-Dual Drive (M720T) 無鉛 無鉛 無鉛 無鉛 觸點高度降低 (世華)無鉛 DVD-Dual Drive (M720T) A - 9...

  • Page 52: Top With Fingerprint (M722T

    Part Lists Top with Fingerprint (M722T) Figure A - 8 Top with Fingerprint (M722T) 黑色 無鉛 白色 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 型 無鉛 型 無鉛 型 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛...

  • Page 53: Top Without Fingerprint (M722T

    Part Lists Top without Fingerprint (M722T) Figure A - 9 Top without Fingerprint (M722T) 黑色 無鉛 白色 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 型 無鉛 型 無鉛 型 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛...

  • Page 54: Bottom (M722T

    Part Lists Bottom (M722T) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 凱碩 無鉛 無鉛 無鉛 無鉛 無鉛 Figure A - 10 無鉛 無鉛 Bottom 無鉛 無鉛 (M722T) 無鉛 無鉛 無鉛 無鉛 無鉛 海華 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 側壁加肉...

  • Page 55: Lcd (M722T

    Part Lists LCD (M722T) Figure A - 11 (M722T) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 灰色 精乘 無鉛 黑色 精乘 無鉛 黑色 精乘 無鉛 無鉛 富佑鴻 無鉛 無鉛 無鉛 無鉛 無鉛 中性...

  • Page 56: Hdd (M722T

    Part Lists HDD (M722T) Figure A - 12 (M722T) 無鉛 無折切痕(設變)(無鉛) A - 14 HDD (M722T)

  • Page 57: Combo (M722T

    Part Lists COMBO (M722T) Figure A - 13 COMBO (M722T) 無鉛 無鉛 無鉛 無鉛 觸點高度降低 (世華)無鉛 COMBO (M722T) A - 15...

  • Page 58: Dvd-Dual Drive (M722T

    Part Lists DVD-Dual Drive (M722T) Figure A - 14 DVD-Dual Drive (M722T) 無鉛 無鉛 無鉛 無鉛 觸點高度降低 (世華)無鉛 A - 16 DVD-Dual Drive (M722T)

  • Page 59: Top With Fingerprint (M728T

    Part Lists Top with Fingerprint (M728T) Figure A - 15 Top with Fingerprint (M728T) 黑色 無鉛 無鉛 無鉛 無鉛 型 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 鋁箔 無鉛 Top with Fingerprint (M728T) A - 17...

  • Page 60: Top Without Fingerprint (M728T

    Part Lists Top without Fingerprint (M728T) Figure A - 16 Top without Fingerprint (M728T) 黑色 無鉛 無鉛 無鉛 無鉛 型 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 鋁箔 無鉛 A - 18 Top without Fingerprint (M728T)

  • Page 61: Bottom (M728T

    Part Lists Bottom (M728T) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 凱碩 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 Figure A - 17 無鉛 無鉛 Bottom 無鉛 無鉛 (M728T) 無鉛 無鉛 無鉛 無鉛 海華 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 側壁加肉...

  • Page 62: Lcd (M728T

    Part Lists LCD (M728T) Figure A - 18 (M728T) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 灰色 精乘 無鉛 黑色 精乘 無鉛 黑色 精乘 無鉛 無鉛 富佑鴻 無鉛 無鉛 無鉛 無鉛 無鉛 中性...

  • Page 63: Hdd (M728T

    Part Lists HDD (M728T) Figure A - 19 (M728T) 無鉛 無折切痕(設變)(無鉛) HDD (M728T) A - 21...

  • Page 64: Combo (M728T

    Part Lists COMBO (M728T) Figure A - 20 COMBO (M728T) 無鉛 無鉛 無鉛 無鉛 觸點高度降低 (世華)無鉛 A - 22 COMBO (M728T)

  • Page 65: Dvd-Dual Drive (M728T

    Part Lists DVD-Dual Drive (M728T) Figure A - 21 DVD-Dual Drive (M728T) 無鉛 無鉛 無鉛 無鉛 觸點高度降低 (世華)無鉛 DVD-Dual Drive (M728T) A - 23...

  • Page 66: Top With Fingerprint (M729T

    Part Lists Top with Fingerprint (M729T) Figure A - 22 Top with Fingerprint (M729T) 黑色 無鉛 無鉛 無鉛 無鉛 型 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 鋁箔 無鉛 A - 24 Top with Fingerprint (M729T)

  • Page 67: Top Without Fingerprint (M729T

    Part Lists Top without Fingerprint (M729T) Figure A - 23 Top without Fingerprint (M729T) 黑色 無鉛 無鉛 無鉛 無鉛 型 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 鋁箔 無鉛 Top without Fingerprint (M729T) A - 25...

  • Page 68: Bottom (M729T

    Part Lists Bottom (M729T) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 凱碩 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 Figure A - 24 無鉛 無鉛 Bottom 無鉛 無鉛 (M729T) 無鉛 無鉛 無鉛 無鉛 海華 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 側壁加肉...

  • Page 69: Lcd (M729T

    Part Lists LCD (M729T) Figure A - 25 (M729T) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 灰色 精乘 無鉛 黑色 精乘 無鉛 黑色 精乘 無鉛 無鉛 富佑鴻 無鉛 無鉛 無鉛 無鉛 無鉛 中性...

  • Page 70: Hdd (M729T

    Part Lists HDD (M729T) Figure A - 26 (M729T) 無鉛 無折切痕(設變)(無鉛) A - 28 HDD (M729T)

  • Page 71: Combo (M729T

    Part Lists COMBO (M729T) Figure A - 27 COMBO (M729T) 無鉛 無鉛 無鉛 無鉛 觸點高度降低 (世華)無鉛 COMBO (M729T) A - 29...

  • Page 72: Dvd-Dual Drive (M729T

    Part Lists DVD-Dual Drive (M729T) Figure A - 28 DVD-Dual Drive (M729T) 無鉛 無鉛 無鉛 無鉛 觸點高度降低 (世華)無鉛 A - 30 DVD-Dual Drive (M729T)
  • Page 73 Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the M720T/M722T/M728T/M729T notebook’s PCB’s. The following table indi- cates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1...

  • Page 74: Schematic Diagrams

    Schematic Diagrams System Block Diagram A C- IN ,Ch ar ge r Sy st em Po we r CLEVO M720T System Block Diagram M ul ti I/ O Bo ar d VD D3 ,VD D5 14. 318 MHz Sy ste m Me mo ry...

  • Page 75: Intel Penryn (Socket-P) 1/2

    Schematic Diagrams Intel Penryn (Socket-P) 1/2 CP U ON LY S UPPO RT TO 3 5W U 9 B [ 4 ] H _ D # [ 6 3: 0 ] H _D # [ 63 : 0 ] [ 4 ] H _ D # 0 E 2 2 Y 2 2...

  • Page 76: Intel Penryn (Socket-P) 2/2

    Schematic Diagrams Intel Penryn (Socket-P) 2/2 V C O R E V C OR E V C OR E U 9 D U 9 C V S S [ 0 0 1] V S S [ 0 82 ] A B 2 0 P 2 1 V C C [ 0 0 1] V C C [ 06 8 ]...

  • Page 77: Cantiga 1/6 - Host

    Schematic Diagrams Cantiga 1/6 - Host U15A H _A# [ 3 5: 3 ] A 14 H_A #3 H _D#[63:0] H_ A#_3 H_D #0 H_A #4 H_D #_0 H_ A#_4 H_D #1 F 16 H_A #5 H_D #_1 H_ A#_5 H_D #2 H_A #6 H_D #_2...

  • Page 78: Cantiga 2/6 - Vga, Crt

    Schematic Diagrams Cantiga 2/6 - VGA, CRT 1. 0 5 V M_ P E G U 15 B M3 6 U 1 5C R S V D 1 N 3 6 A P 2 4 R 6 4 R S V D 2 S A _ C K _0 M _C LK _D D R 0 [ 10 ]...

  • Page 79: Cantiga 3/6 -Ddr

    M1 4 M1 3 6-34 -M52 NS-0 20 6-3 6-12 181- 20E 6-3 4-D9 0C0- 021 For M720T M -MA R K 1 M-MA R K 1 M-M A R K 1 M-M A R K 1 M -MA R K 1...

  • Page 80: Cantiga 4/6 - Power

    Schematic Diagrams Cantiga 4/6 - Power 1.8V 1.05V S U15G U1 5F 1 . 0 5VS AP 33 W 28 V CC_ SM _1 V CC _AX G_NC T F _1 A N33 V 28 V CC_ SM _2 V CC _AX G_NC T F _2 B H32 W 26 A G3 4...

  • Page 81: Cantiga 5/6 - Power

    Schematic Diagrams Cantiga 5/6 - Power 1. 0 5 V S 10m ils 3 . 3V S _A T V D A C L2 7 C 61 6 C 3 9 4 C 39 3 U 1 5H H C B 10 0 5K F -12 1 T 20 4 .

  • Page 82: Cantiga 6/6 - Gnd

    Schematic Diagrams Cantiga 6/6 - GND U 1 5I U 1 5 J DMI X2 Sele ct A H 8 R 2 2 8 * 2. 2 K _ 1 %_ 0 4 MC H _ C F G 5 [ 5 ] V S S _2 9 7 A U 48...

  • Page 83: Ddrii Channel A

    Schematic Diagrams DDRII CHANNEL A SO-DIMM 1 JDIMM_1 Terminator J D I MM_ 1 A [ 6 ] M_ A _ A [ 1 4: 0 ] M _A _ D Q [ 63 : 0 ] [ 6 ] M _ A _A 0 1 02 M_ A _D Q0...

  • Page 84: Ddrii Channel B

    Schematic Diagrams DDRII CHANNEL B SO-DIMM 2 La yo ut no te : JDIMM_2 is placed farther JDIMM_2 Terminator from the GMCH than JDIMM_1 0 . 9 V S M 16 -5 603 4-4 5A JD I MM _2 A [ 6 ] M_ B _ A [ 1 4: 0 ] M _B _ D Q[ 6 3: 0 ]...

  • Page 85: Panel, Inverter, Crt

    Schematic Diagrams Panel, Inverter, CRT 5 V S 5V S Zo=5 5 O hm R 1 8 8 2 . 2 K _0 4 L 6 3 F C M1 0 05 K F -1 2 1T 0 3 3. 3 V S Q1 6 C R T_ H S Y N C C R T _ H S Y N C _ R...

  • Page 86: Ich9-M 1/5 - Sata

    Schematic Diagrams ICH9-M 1/5 - SATA R TC V C C U 2 3 A R T C _ X 1 C 23 LP C _ A D 0 [ 1 9 , 2 6] R TC X1 F W H 0/ L A D 0 R T C _ X 2 C 24 R TC X2...

  • Page 87: Ich9-M 2/5 - Pcie, Pci, Usb

    Schematic Diagrams ICH9-M 2/5 - PCIE, PCI, USB B oot BIO S St rap U 23 D N 2 9 V 27 [ 2 0] P C I E _ R XN 1_ W L A N P E R N 1 D MI 0 R XN D MI _ R XN 0 [ 5 ]...

  • Page 88: Ich9-M 3/5 - Gpio, Pwr Management

    Schematic Diagrams ICH9-M 3/5 - GPIO, PWR Management 3. 3 V U 2 3C I C H _S MB C L K 0 G1 6 A H 2 3 S A T A 0 GP [ 1 0 , 1 1, 1 8 ] I C H _ S MB C L K 0 S MB C LK S A T A 0 GP / G P I O2 1...

  • Page 89: Ich9-M 4/5 - Power

    Schematic Diagrams ICH9-M 4/5 - Power 2 0m ils U23 F A 23 RTCV CC VCCRT C VCC1_05[ 1] VCC1_05[ 2] C20 0 C201 C211 V5REF VCC1_05[ 3] VCC1_05[ 4] 0. 1U_10V_X 7R_04 0.1U_10V_X 7R_0 4 10U_10V_08 AE 1 V5REF_SUS VCC1_05[ 5] 1.7 A VCC1_05[ 6]...

  • Page 90: Ich9-M 5/5 - Gnd

    Schematic Diagrams ICH9-M 5/5 - GND U2 3E AA 2 6 V SS[1] VSS [ 107 ] AA 2 7 V SS[2] VSS [ 108 ] V SS[3] VSS [ 109 ] V SS[4] VSS [ 110 ] A C 22 V SS[5] VSS [ 111 ] AA 2 3...

  • Page 91: Clock Generator

    Schematic Diagrams Clock Generator CLOCK GENERATOR Layou t no te: Insat lled : Di ffer enti al c lock 3 . 3 V S 3 . 3 V M_ C L K level is high er L 3 9 R 29 6 C L K _ MC H _ B C L K C 49 2 *1 0P _ 5 0 V _0 4...

  • Page 92: Multi I/O, Odd, Ccd, Bt, Tpm

    LA D 1 V D D 2 C 5 8 7 C 26 6 C 26 9 C 2 65 FOR M720T FOR M730T [ 1 3 , 26 ] LP C _A D 2 LA D 2 V D D 3...

  • Page 93: New Card, Mini Pcie

    Schematic Diagrams New Card, Mini PCIE NEW CARD 3 . 3 V S C 4 46 *0 . 1 U _ 1 6V _ 0 4 B U F _ P L T_ R S T # 3 . 3 V U 1 9 U 1 8 J_ N E W 1...

  • Page 94: Led, Fan, Tp, Fp, Usb

    Schematic Diagrams LED, FAN, TP, FP, USB FAN CONTROL V D D 3 V D D 3 3. 3 V S 3 . 3 V S 5V S R 15 8 R 1 57 R 1 60 R 1 61 2 20 _ 04 22 0 _0 4 2 20 _ 0 4...

  • Page 95: Jmb385 Card Reader

    La yout note: Layout no te: Layout note: M720T Card Reader M730T Card Reader Ve ry cl os ed b et wee n V er y clo se d to pi n 5( Tr ac e w id th /l eng th :...

  • Page 96: Pci-E Lan Rtl8111C

    Schematic Diagrams PCI-E LAN RTL8111C LA N _ V D D 3 60 mil R 4 0 0 0_ 0 4 M A 1 / E E D I R 4 5 3. 6 K _ 0 6 Q2 8 *A O 3 40 9 60mi l E N _ LA N 1 2...

  • Page 97: Audio Codec Alc662

    Schematic Diagrams Audio Codec ALC662 L ayo ut N ote : Lay out Not e: Clo se to co dec p in 25 C los e t o cod ec pi n 3 8 3 . 3V S 3. 3 V S _ A U D 5 V S _A U D 5V S _ A U D L 4 5...

  • Page 98: Audio Amp2056

    R _ H P _ O Z 2 5 10 C 6 2 1 6 8P _5 0 V _ 0 4 L _ H P _O For M720T For M730T 5V S _ A MP 5 V S L 3 7...

  • Page 99: Kbc-Ite It8512E

    3 . 3V S M R # 35 mil Z 2 6 0 9 K B C _ W R E S E T # FOR M720T FOR M730T R E S E T# C 2 0 3 V C C...

  • Page 100: System Power, Led Bklt

    Schematic Diagrams System Power, LED BKLT 5VS,3.3VS P Q2 9 S Y S 15 V V D D 3 3 . 3V S A O4 4 68 V D D 5 P Q 27 S Y S 1 5 V V D D 5 A O 44 6 8 5 V S...

  • Page 101: Power Vdd3, Vdd5

    Schematic Diagrams Power VDD3, VDD5 VDD3,VDD5 35m il V I N S Y S 5 V 25 mil P C 1 8 8 5mi l P R 1 6 9 1 0 _0 4 V I N 2 V I N 1 P Q 2 1 P C 2 1 0 P C 2 1 1...

  • Page 102: Power 1.5Vs, 1.05Vs, 3.3V, 5V

    Schematic Diagrams Power 1.5VS, 1.05VS, 3.3V, 5V 1.05VS V I N P C 2 12 P D 2 4 P R 7 8 1 00 K _ 04 E N _ 1. 0 5 V S P R 2 0 1 5 .

  • Page 103: Power 1.8V, 0.9Vsm

    Schematic Diagrams Power 1.8V, 0.9VSM 1.8V,0.9VSM V I N 3 . 3 V P R 39 P R 4 7 P R 5 0 P D 1 2 1 M_ 0 4 10 _ 0 6 F M 0 5 40 -N 1 0 0 K _ 04 V 1 .

  • Page 104: Power Vcore

    Schematic Diagrams Power VCORE VCORE V I N V -R C 1 P C 24 P C 1 2 8 P D 1 1 1 U _ 1 0V _ 0 6 1 00 0 P _ 50 V _ X 7R _ 04 F M0 5 4 0-N P R 2 4 V I N...

  • Page 105: Power Ac-In, Charger

    Schematic Diagrams Power AC-IN, Charger AC IN & CHARGER P R 1 0 5 * 10 m i l _ s ho rt Ch arg e Cur re nt 2.0 A P Q 34 V I N A M 48 3 5P Ch arg e Vol ta ge 16.

  • Page 106: Multi I/O Board 1/2

    Schematic Diagrams Multi I/O Board 1/2 SPEAKER For M720T LID SWITCH HOT KEY & POWER SWITCH SW 8 M J_S PK R_7 2 MS W 1 MS W 2 T JG -5 33 -S -V -T / R T JG -5 33 -S -V -T / R...
  • Page 107 M TH 3 15 D 1 1 1 MT H 3 1 5D 1 11 M T H 3 15 D 1 1 1 MT H 2 37 D 11 1 FOR M720T FOR M720T FOR M730T M GN D...

  • Page 108: Finger Printer Board

    Schematic Diagrams Finger Printer Board Finger Printer F 3 . 3 V F T C _ V D D F J _ F P 1 F G P I O0 / I N T F R 1 9 1 . 5 K _ 04 F U S B _ P P 1 F U S B _ P P 1 _R F R 2 1...

  • Page 109: Click Board

    MT H23 7D91 MTH237 D91 MTH2 37D9 1 CG ND CGND CGND CGND CG ND CGND For M720T For M730T CR 1 0 _04 *0_04 CTPB U TTON_ L CTPBT N_L _72 CT PBUTTON_L C TPB TN _L_7 3 CR 3...

  • Page 110: M730T Odd Bridge Board

    Schematic Diagrams M730T ODD Bridge Board M730T ODD BRIDGE BOARD Sheet 37 of 40 M730T ODD Bridge Board BJ_ SATA1 BSATA_TX P1 BJ ODD 2 BSATA_TX N 1 BSATA_TXP1 BSATA_R X N 1 BSATA_TXN1 BSATA_R X P1 BSATA_RXN1 BSATA_RXP1 BOD D_DETECT# BGND BODD _D ETEC T# B5VS...

  • Page 111: M730T Audio Board

    Schematic Diagrams M730T Audio Board M730T AUDIO BRIDGE BOARD A JS PD IF1 AS P DIF O A L4 *F C M 1005K F - 1 02T 02 A C1 *0.01U _16V _X 7R_04 AR 2 A C5 *C 12103-10609 - L Sheet 38 of 40 *220_04 *100 0P_5 0V_X 7R_04...

  • Page 112: Power Sequence Diagram

    Schematic Diagrams Power Sequence Diagram M720T V0.0 BOOT BLOCK DIAGRAM CL _P WR OK G FX _V RE N NORTH BRIDGE PW R_ SW # M ULT I I/ O BO AR D GFX VR DE LA Y_ PW RG D...

  • Page 113: Power Sequence V3.0

    Schematic Diagrams Power Sequence v3.0 M720T V3.0 POWER ON SEQUENCE 5 60ms PWR_SW# 164 .7m s DD_ON 370 us 515 .4u s V5REF_SUS 56 8.0u s 3.3V 6 .215 ms 1.8V 76.4 ms RSMRST# 206. 4ms 12 0.8 ms 85.6 ms...
  • Page 114 Schematic Diagrams B - 42...

  • Page 115: Updating The Flash Rom Bios

    Download the BIOS computer model. 1. Go to www.clevo.com.tw and point to E-Services and click E-Channel. Note that BIOS versions 2. Use your user ID and password to access the appropriate download area (BIOS), and download the latest BIOS files...

  • Page 116: Use The Flash Tools To Update The Bios

    BIOS Update Use the flash tools to update the BIOS 1. Make sure you are not loading any memory management programs such as HIMEM by holding the F8 key as you see the message “Starting MS-DOS”. You will then be prompted to give “Y” or “N” responses to the programs being loaded by DOS.
  • Page 117 www.s-manuals.com...

This manual is also suitable for:

M722tM729tM728t

Table of Contents
