  • Page 3 Preface Notebook Computer M72XR Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 Preface About this Manual This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the M72XR series notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 7: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...

  • Page 8: Power Safety

    Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
  • Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. VIII...

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 Top without Fingerprint (M720R) ..........A-4 Top with Fingerprint (M725R) ............A-5 Overview ..................1-1 Top without Fingerprint (M725R) ..........A-6 System Specifications ..............1-2 Bottom (M72XR) ................A-7 Model Differences ................1-5 LCD (M720R) ................A-8 External Locator - Top View with LCD Panel Open ......1-6 LCD (M725R) ................
  • Page 12 Preface ENE MR510, 7 IN 1 ..............B-23 PCI-E LAN RTL8111B ............... B-24 AUDIO CODEC ALC883 ............B-25 AUDIO AMP2056 ............... B-26 KBC-ITE IT8512E ............... B-27 3VS, 5VS ..................B-28 POWER GPU/1.25VS ..............B-29 POWER 3.3V/5V ................. B-30 POWER 1.5VS/ 1.05VS ............... B-31 POWER 1.8V/0.9V ..............

  • Page 13: Introduction

    Introduction Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the M72XR series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about driv- ers (e.g.

  • Page 14: System Specifications

    Introduction System Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/speeds and CD/DVD device types) may be changed, delayed or updated due to the manufacturer's release schedule. Check with your service center for details.
  • Page 15 Introduction Feature Specification BIOS One 8Mb SPI Flash ROM Phoenix™ BIOS Storage One Changeable 12.7mm(h) Optical Device (CD/DVD) Type Drive (see “Optional” on page 1 - 4) Easy Changeable 2.5" 9.5 mm (h) SATA (Serial) HDD Audio High Definition Audio (HDA) A3D™...
  • Page 16 Introduction Feature Specification Power Supports ACPI 3.0 Supports Wake on LAN Management Supports Wake on USB Supports Resume from Modem Ring Power Full Range AC/DC Adapter AC input 100 - 240V, 50 - 60Hz, DC Output 19V, 3.42A or 18.5V, 3.5A (65 Watts) Battery 4 Cell Smart Lithium-Ion Battery Pack, 14.8V/2.4AH 8 Cell Smart Lithium-Ion Battery Pack, 14.8V/4.4AH (Option)

  • Page 17: Model Differences

    Introduction Model Differences The models vary slightly in external cover design and color. Figure 1 Model Differences System Specifications 1 - 5...

  • Page 18: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 2 Top View 1. Built-In PC Camera (Optional) 2. LCD 3. Speakers 4. Power Button 5. Hot-Key Buttons 6. LED Status Indicators 7. Keyboard 8. Touchpad & Buttons 9. LED Power & Communication Indicators 10.

  • Page 19: External Locator - Front & Rear Views

    Introduction External Locator - Front & Rear Views Figure 3 Front View 1. LCD Latches 2. LED Power & Communication Indicators 3. 7-in-1 Card Reader 4. S/PDIF-Out Jack Front 5. Microphone-In Jack 6. Headphone-Out Jack Figure 4 Rear View 1. Battery Rear External Locator - Front &...

  • Page 20: External Locator - Left & Right Side Views

    Introduction External Locator - Left & Right Side Views Figure 5 Left Side View 1. DC-In Jack 2. RJ-45 LAN Jack 3. External Monitor Port 4. Mini-IEEE 1394 Left Port 5. Vent 6. 3 * USB 2.0 Ports 7. ExpressCard/ 54(34) Slot Figure 6 Right Side View...

  • Page 21: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 7 Bottom View 1. Battery 2. Hard Disk Bay Cover (3.5G Module/Intel Turbo Memory Module Location) 3. RAM & CPU Bay Cover Overheating To prevent your com- puter from overheating make sure nothing blocks the vent/fan in- takes while the com- puter is in use.

  • Page 22: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 8 Mainboard Top Key Parts 1. SC452 2. ITE 8512E 3. ExpressCard Assembly 1 - 10 Mainboard Overview - Top (Key Parts)

  • Page 23: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 9 Mainboard Bottom Key Parts 1. CPU Socket (no CPU installed) 2. PCI-E LAN RTL8111B 3. CLOCK GENERATOR ICS9LPR363 4. Northbridge-Intel GM965 5. Card Reader Controller ENE MR510 6. VIA VT6311S 7. Southbridge- ICH8-M 8.

  • Page 24: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 10 Mainboard Top Connectors 1. External Monitor Port 2. RJ-45 LAN Jack 3. CCD Cable Connector 4. LCD Cable Connector 5. Speaker Cable Connector 6. Touch Pad Cable Connector 7. Fingerprint Cable Connector 8.

  • Page 25: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 11 Mainboard Bottom Connectors 1. DC-In Jack 2. RJ-45 LAN Jack 3. External Monitor Port 4. Inverter Cable Connector 5. USB Port 6. S/PDIF-Out Jack 7. Microphone-In Jack 8. Headphone-Out Jack 9. Optical Device Drive Connector 10.
  • Page 26 Introduction 1 - 14...

  • Page 27: Disassembly

    Disassembly Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the M72XR series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart. Procedures such as upgrading/replacing the RAM, CD device and hard disk are included in the User’s Manual but are repeated here for your convenience.

  • Page 28: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 29: Maintenance Precautions

    Disassembly Maintenance Precautions The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 30: Remove The Battery

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Optical Device: 1. Remove the battery page 2 - 5 1.

  • Page 31: Removing The Battery

    Disassembly Removing the Battery Figure 1 1. Turn the computer off, and turn it over. Battery Removal 2. Slide the latches ( & ) the direction of the arrow, and hold latch in place. 3. Slide the battery in the direction of the arrow a.

  • Page 32: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm Figure 2 (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in HDD Assembly Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 33 Disassembly 4. Carefully grip the mylar cover tab and slide the hard disk in the direction of arrow. Figure 3 5. Lift the hard disk up Figure d in the direction of arrow. HDD Assembly 6. Remove the screws and separate the mylar cover from the hard disk Sequence Removal...

  • Page 34: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 4 RAM Module The computer has two memory sockets for 200 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDRII 533/667MHz. The main memory can be expanded up to 4GB. The SO-DIMM modules supported are 256MB, 512MB and 1024MB DDRII Modules.

  • Page 35: Remove The Battery

    Disassembly 7. Gently push the two release latches ( & on the sides of the memory socket in the direction indicated by the Figure 5 arrows (Figure Memory Removal 8. The RAM module(s) will pop-up Figure e , and you can then remove it. Sequence d.

  • Page 36: Removing The Processor

    Disassembly Removing the Processor Figure 6 Processor Removal 1. Turn off the computer, and remove the battery (page 2 - 6) and the CPU/RAM bay cover (page 2 - 2. The CPU heat sink will be visible at point on the mainboard. a.

  • Page 37: Removing The Processor

    Disassembly 5. Turn the release latch towards the unlock symbol , to release the CPU (Figure Figure 7 6. Carefully (it may be hot) lift the CPU up out of the socket (Figure Processor Removal 7. Reverse the process to install a new CPU. Sequence 8.

  • Page 38: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 8 Wireless LAN 1. Turn off the computer, remove the battery (page 2 - 6) and the CPU/RAM bay cover (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard.

  • Page 39: Removing The Bluetooth Module

    Disassembly Removing the Bluetooth Module Figure 9 Bluetooth Removal 1. Turn off the computer, remove the battery (page 2 - 6), and the CPU/RAM bay cover (page 2 - 2. The modem will be visible at point on the mainboard. a.

  • Page 40: Removing The Optical (Cd/Dvd) Device

    Disassembly Removing the Optical (CD/DVD) Device Figure 10 Optical Device 1. Turn off the computer, remove the battery (page 2 - 6), and the CPU/RAM bay cover (page 2 - Removal 2. Remove the screw at point , and use a screwdriver to carefully push out the optical device at point 3.

  • Page 41: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 11 Keyboard Removal 1. Turn off the computer, and remove the battery (page 2 - 2. Press the three keyboard latches at the top of the keyboard to elevate the keyboard from its normal position (you a.

  • Page 42: Removing The Modem Module

    Disassembly Removing the Modem Module Figure 12 Modem Removal 1. Turn off the computer, remove the battery (page 2 - 6) and the CPU/RAM bay cover (page 2 - 8) and the optical device (page 2 - 8) and the keyboard (page 2 - a.

  • Page 43: Removing The Modem Module

    Disassembly 6. Remove screws and disconnect the connectors from the mainboard. Figure 13 7. Separate the bottom case from the mainboard and turn it over. Modem Removal 8. Remove the screws and disconnect the connector from the modem. Sequence 9. Lift the modem up off the socket e.
  • Page 44 Disassembly 2 - 18...

  • Page 45: Part Lists

    Part Lists Appendix A:Part Lists This appendix breaks down the M72XR series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 46: Part List Illustration Location

    Table A - 1 Part List Illustration Part Pages# Location page A - 3 Top with Fingerprint - (M720R) page A - 4 Top without Fingerprint - (M720R) page A - 5 Top with Fingerprint - (M725R) page A - 6...

  • Page 47: Top With Fingerprint (M720R

    Top with Finger- print (M720R) 黑色 無鉛 白色 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 鋁箔 鋁箔 無鉛 Top with Fingerprint (M720R) A - 3...

  • Page 48: Top Without Fingerprint (M720R

    Figure A - 2 Top without Fin- gerprint (M720R) 黑色 無鉛 白色 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 鋁箔 鋁箔 無鉛 A - 4 Top without Fingerprint (M720R)

  • Page 49: Top With Fingerprint (M725R

    Part Lists Top with Fingerprint (M725R) Figure A - 3 Top with Finger- print (M725R) 黑色 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 鋁箔 鋁箔 無鉛 Top with Fingerprint (M725R) A - 5...

  • Page 50: Top Without Fingerprint (M725R

    Part Lists Top without Fingerprint (M725R) Figure A - 4 Top without Fin- gerprint (M725R) 黑色 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 鋁箔 鋁箔 無鉛 A - 6 Top without Fingerprint (M725R)

  • Page 51: Bottom (M72Xr

    Part Lists Bottom (M72XR) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 變更 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 (加長線長)無鉛 Figure A - 5 無鉛 無鉛 無鉛 Bottom (M72XR) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛...

  • Page 52: Lcd (M720R

    無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 灰色 精乘 無鉛 黑色 精乘 無鉛 黑色 精乘 無鉛 無鉛 富佑鴻 無鉛 無鉛 無鉛 無鉛 無鉛 中性 無鉛 無鉛 無鉛 無鉛 無鉛 A - 8 LCD (M720R)

  • Page 53: Lcd (M725R

    Part Lists LCD (M725R) Figure A - 7 LCD (M720R) 無鉛 無鉛 無鉛 無鉛 無鉛 欣日興 無鉛 無鉛 無鉛 無鉛 欣日興 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 灰色 精乘 無鉛 黑色 精乘 無鉛 黑色 精乘 無鉛 無鉛 富佑鴻 無鉛 無鉛...

  • Page 54: Combo (M720R

    Part Lists Combo (M720R) Figure A - 8 Combo (M720R) 無鉛 無鉛 無鉛 無鉛 A - 10...

  • Page 55: Dvd-Dual-Rw (M720R

    Part Lists DVD-DUAL-RW (M720R) Figure A - 9 DVD-DUAL-RW (M720R) 無鉛 無鉛 無鉛 無鉛 DVD-DUAL-RW (M720R) A - 11...
  • Page 56 Part Lists A - 12...
  • Page 57 Schematic Diagrams Appendix B:Schematic Diagrams This appendix has circuit diagrams of the M72XR notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1 Schematic SYSTEM BLOCK DIAGRAM - Page B - 2 ICH8-M 3/4 - Page B - 15 3VS, 5VS - Page B - 28...

  • Page 58: Schematic Diagrams

    Schematic Diagrams SYSTEM BLOCK DIAGRAM 3VS, 5VS CLEVO M720R System Block Diagram AC-IN,CHARGER 14.318 MHz POWER GPU, 1.25VS MULTI I/O BOARD Colck Generator Intel Merom ICS9LPR363 Memory Termination SPK_R, RJ-11, LED PROCESSOR LID, HOT KEY, USB, 3G VDD3,VDD5,3.3V,5V 478pins uFCBGA...

  • Page 59: Cpu-1

    Schematic Diagrams CPU-1 JSKT1A H_A#[35:3] H_A#3 H_ADS# A[3]# ADS# H_A#4 H_BNR# A[4]# BNR# H_A#5 JSKT1B A[5]# BPRI# H_BPRI# 4 H_D#[63:0] H_D#[63:0] 4 H_A#6 H_D#0 H_D#32 A[6]# D[0]# D[32]# H_A#7 H_D#1 AB24 H_D#33 A[7]# DEFER# H_DEFER# 4 D[1]# D[33]# H_A#8 H_D#2 H_D#34 A[8]# DRDY #...

  • Page 60: Cpu-2

    Schematic Diagrams CPU-2 PLACE NEAR CPU VCORE C373 C371 C369 C340 C338 C327 C385 C381 C325 10U_10V_08 10U_10V_08 10U_10V_08 10U_10V_08 10U_10V_08 10U_10V_08 10U_10V_08 10U_10V_08 10U_10V_08 10U_10V_08 VCORE VCORE JSKT1D VCORE JSKT1C VSS[001] VSS[082] AB20 VCC[001] VCC[068] VSS[002] VSS[083] VCC[002] VCC[069] VSS[003] VSS[084] VCC[003]...

  • Page 61: Crestline 1/5

    Schematic Diagrams Crestline 1/5 U13A H_A#[35:3] 2 H_A#3 H_D#[63:0] H_A#_3 H_D#0 H_A#4 H_D#_0 H_A#_4 H_D#1 H_A#5 H_D#_1 H_A#_5 H_D#2 H_A#6 H_D#_2 H_A#_6 H_D#3 H_A#7 H_D#_3 H_A#_7 H_D#4 H_A#8 H_D#_4 H_A#_8 H_D#5 H_A#9 H_D#_5 H_A#_9 H_D#6 H_A#10 H_D#_6 H_A#_10 H_D#7 H_A#11 CK505 H_D#_7 H_A#_11...

  • Page 62: Crestline 2/5, Dram

    Schematic Diagrams Crestline 2/5, DRAM 0410 DMI X2 select 3.3VS U13B 24.9_1%_04 1.05VS MCH_CFG_5 R284 2.2K_04 Z0501 R279 2.2K_04 U13C RSVD1 Z0502 AV29 M_CLK_DDR0 9 RSVD2 SM_CK_0 Z0503 BB23 L_BK_CTRL M_CLK_DDR1 9 BLON RSVD3 SM_CK_1 L_BKLT_CTRL Z0504 BA25 Z05139 Zdiff= M_CLK_DDR2 10 RSVD4 SM_CK_3...

  • Page 63: Crestline 3/5

    Schematic Diagrams Crestline 3/5 U13E M_B_DQ[63:0] U13D M_B_DQ0 AP49 AY 17 M_A_DQ[63:0] SB_DQ_0 SB_BS_0 M_B_BS0# 10 M_A_DQ0 AR43 BB19 Zo= 55O? 5% M_B_DQ1 AR51 BG18 SA_DQ_0 SA_BS_0 M_A_BS0# 9 SB_DQ_1 SB_BS_1 M_B_BS1# 10 Zo= 55O? 5% M_A_DQ1 AW44 BK19 M_B_DQ2 AW50 BG36 SA_DQ_1...

  • Page 64: Crestline 4/5

    Schematic Diagrams Crestline 4/5 NEAR NB VGFX_CORE 0_04 GPUVCCSENSE 28 1.05VS U13I VGFX_C ORE U13G 0_04 GPUVSSSEN SE 28 AW24 U13J VSS_1 VSS_100 AT35 1.05VS AW29 VCC_1 VSS_2 VSS_101 VSS_199 VSS_287 AT34 AW32 VCC_2 VCC_AXG_NCTF_1 VSS_3 VSS_102 VSS_200 VSS_288 AH28 U13F VCC_3 VCC_AXG_NCTF_2...

  • Page 65: Crestline 5/5

    Schematic Diagrams Crestline 5/5 3.3VS HCB1608KF-121T25 1.05VS 1 0 mils 3.3VS VCCA_CRT_DAC C389 C145 C393 C458 C457 3.3VS_VCCSYNC U13H 10U_10V_08 10U_10V_08 10U_10V_08 10U_10V_08 100U_4V_B 1 0 m ils 22U_6.3V_X5R_08 .1U_10V_X7R_04 0_04 VCCSYNC VTT_1 VTT_2 C113 VCCA_CRT_DAC_1 VTT_3 VCCA_CRT_DAC VCCA_CRT_DAC_2 VTT_4 3.3VS .1U_10V_X7R_04 C390...

  • Page 66: Ddrii So-Dimm 0

    Schematic Diagrams DDRII SO-DIMM 0 SO-DIMM 0 +VTT_MEM RESISTORS VTT_MEM 16-56034-45A M_CS0# RN28 C455 .1U_10V_X7R_04 M_A_RAS# 4P2RX56_04 J DIMM_1A C461 .01U_16V_X7R_04 M_A_A[13:0] M_A_DQ[63:0] 6 M_A_A0 M_A_DQ0 M_ODT1 M_A_A1 M_A_DQ1 M_CS1# 4P2RX56_04 M_A_A2 M_A_DQ2 C112 .1U_10V_X7R_04 M_A_A3 M_A_DQ3 M_A_A13 RN25 M_A_A4 M_A_DQ4 M_ODT0 4P2RX56_04...
  • Page 67 Schematic Diagrams DDRII SO- DIMM 1 SO-DIMM 1 +VTT_MEM RESISTORS VTT_MEM 16-56034-45A M_CS2# C161 .1U_10V_X7R_04 JDIMM_2A M_B_RAS# 4P2RX56_04 M_B_A[13:0] M_B_DQ[63:0] 6 M_B_A0 M_B_DQ0 C488 .1U_10V_X7R_04 M_B_A1 M_B_DQ1 M_B_BS1# M_B_A2 M_B_DQ2 M_B_A0 4P2RX56_04 M_B_A3 M_B_DQ3 C492 .1U_10V_X7R_04 M_B_A4 M_B_DQ4 M_B_A5 RN37 M_B_A5 M_B_DQ5 M_B_A8...

  • Page 68: Panel, Inverter, Crt

    Schematic Diagrams PANEL, INVERTER, CRT Zo=75 Ohm 3.3VS C376 .1U_16V_04 C375 .1U_16V_04 R203 2.2K_04 3.3VS 3.3VS 2N7002W R201 R200 CRT_DDCADAT DAC_DDCADATA 5 390_06 390_06 Z1108 3.3VS R207 4.7K_04 SCS751V-40 CRT_VSYNC CRT_HSY NC DAC_RED DAC_RED_R DAC_VSYNC 5 DAC_HSYNC 5 DAC_GREEN DAC_GREEN_R R204 4.7K_04 DAC_BLUE...

  • Page 69: Ich8-M 1/4, Sata

    Schematic Diagrams ICH8-M 1/4, SATA RTCVCC 2 0 m ils C553 15P_50V_04 2 0 m ils R323 0403 C209 32.768KHz 10M_04 U22A 1U_6.3V_04 VDD3 RTC_X1 AG25 Zo= 50O? 5% LPC_AD0 17,26 RTCX1 FWH0/LAD0 C560 15P_50V_04 RTC_X2 AF24 RTCX2 FWH1/LAD1 LPC_AD1 17,26 0403 LPC_AD2 17,26 FWH2/LAD2...
  • Page 70 Schematic Diagrams ICH8-M 2/4, PCI, USB ICH8M Boot BIOS select PCI_GNT#0 U22D Strap SPI_CS#1 PCIE_RXN1_WLAN PERN1 DMI0RXN DMI_RXN0 5 PCIE_RXP1_WLAN PERP1 DMI0RXP DMI_RXP0 5 FWH(default) Stuff Stuff C548 .1U_10V_X7R_04 PCIE_TXN1_C PCIE_TXN1_WLAN PETN1 DMI0TXN DMI_TXN0 5 C549 .1U_10V_X7R_04 PCIE_TXP1_C PCIE_TXP1_WLAN DMI_TXP0 5 PETP1 DMI0TXP Stuff...

  • Page 71: Ich8-M 3/4

    Schematic Diagrams ICH8-M 3/4 3.3VS 9,10,16 ICH_SMBCLK0 DDR2, CLK GEN LCDID0 R438 10K_04 9,10,16 ICH_SMBDAT0 U22C LCDID1 R439 10K_04 ICH_SMBCLK0 AJ26 AJ12 SB_GPIO21 SMBCLK SATA0GP/GPIO21 ICH_SMBDAT0 AD19 AJ10 SB_GPIO19 SMBDATA SATA1GP/GPIO19 CL_RST#1 AG21 AF11 LCDID0 SB_GPIO21 R440 10K_04 Zo= 55O? 5% CL_RST#1 LINKALERT# SATA2GP/GPIO36...

  • Page 72: Ich8-M 4/4

    Schematic Diagrams ICH8-M 4/4 RTCVCC U22F U22E Layout note: AD25 1.05VS VCCRTC VCC1_05[01] VSS[001] VSS[099] VCC1_05[02] VSS[002] VSS[100] Place within 100 mils C234 C230 C538 C265 C248 C259 V5REF[1] VCC1_05[03] VSS[003] VSS[101] VCC5REF of pin A16 and T7 of V5REF[2] VCC1_05[04] VSS[004] VSS[102]...

  • Page 73: Clock Generator

    Schematic Diagrams CLOCK GENERATOR Layout note: CLOCK GENERATOR 3.3VS Insatlled: Differential clock level is higher 3.3VS C163 CLK_MCH_BCLK C467 *10P_50V_04 1U_6.3V_04 3.3VS CLK_MCH_BCLK# C471 *10P_50V_04 HCB1608KF-121T25 3.3VS_CLK 4 0mils R286 CLK_ICH14 C444 *10P_50V_04 3.3VS 1K_1%_04 Layout note: C504 C144 C157 C174 Z1708 R285...

  • Page 74: Power, Tpm

    Schematic Diagrams 3G POWER, TPM 3.3VS VCORE PWRGD R345 100K_04 2N7002W C579 Z1701 CLKEN# *.1u_X7R_04 VRM_PWRGD Sheet 17 of 37 3G POWER, TPM TPM 1.2 12,26 LPC_AD0 3.3VS LAD0 VDD1 12,26 LPC_AD1 LAD1 VDD2 C311 C293 C312 C305 12,26 LPC_AD2 LAD2 VDD3 12,26...

  • Page 75: Ieee 1394 Vt6311S

    Schematic Diagrams IEEE 1394 VT6311S PVA_1394 3.3VS IEEE1394 C617 C629 C313 C317 0521 10U_10V_08 .1U_10V_X7R_04 .1U_10V_X7R_04 .1U_10V_X7R_04 C632 .33U_X7R_06 R454 R401 1394_TPBIAS0 R415 54.9_1%_04 6-13-54R91-28B 0_08 0_08 HCB1608KF-121T25 R414 54.9_1%_04 13,22,26 PME# GND1 Z1801 1394_TPA0+ ? ? ? X7R? ? shield TPA+ GND2...

  • Page 76: Multi 1/O, Odd, Ccd, Bt

    Schematic Diagrams MULTI 1/O, ODD, CCD, BT IDE_PDD[15:0] IDE_PDD[15:0] J_ODD1 Z1901 Z1904 MULTI I/O CONN Z1902 R123 33_04 CD_RST# IDE_PDD8 13,18,23 PCIRST# IDE_PDD7 IDE_PDD9 IDE_PDD6 IDE_PDD10 3.3VS IDE_PDD5 IDE_PDD11 IDE_PDD4 IDE_PDD12 INTEL? ? ? PLT_RST#, 3.3VS=4A IDE_PDD3 IDE_PDD13 ? M540R? PCIRST# IDE_PDD2 IDE_PDD14 J_MFB1...

  • Page 77: New Card, Mini Pcie, Usb

    Schematic Diagrams NEW CARD, MINI PCIE, USB 3.3VS C530 .1U_16V_04 NEW CARD BUF_PLT_RST# 3.3V J_NEW1 C525 .1U_16V_04 NC_RST# 74LVC1G08GW NC_PERST# AUXIN PERST# PERST# C228 .1U_16V_04 20 mil NC_3.3V 3.3VS AUXOUT +3.3VAUX 6-01-74108-Q61 C528 .1U_16V_04 40 mil C237 .1U_16V_04 3.3VIN NC_3.3VS C527 .1U_16V_04 3.3VIN...

  • Page 78: Led, Fan, Pc Beep, Tp, Fp

    Schematic Diagrams LED, FAN, PC BEEP, TP, FP FAN CONTROL VDD5 VDD5 R167 R166 R169 R170 470_06 470_06 470_06 470_06 Z2101 Z2102 Z2109 Z2110 5VS_FAN HCB2012KF-500T40 KPB-3025YSGC KPB-3025YSGC C522 C523 .1U_16V_04 40MIL 10U_10V_08 Z2111 Z2112 POWER ON LED WLAN/BT LED 0409 R303 4.99K_1%_06...

  • Page 79: Ene Mr510, 7

    Schematic Diagrams ENE MR510, 7 IN 1 xD_BSY # MFUNC7 xDWP# SUSB# 14,20,26,29 MS_D1 MFUNC6 3.3VS MS_D0 MFUNC5 MS_D2 MFUNC4 R390 47K_04 MS_INS# MS_D3 PCIRST# MSCLK R357 *0_04 SERIRQ 14,17,26 R317 47K_04 SD_CD# MFUNC2 VCC_CARD R326 47K_04 SD_WP SD_WP 3.3VS SD_CD# MFUNC1 R351...

  • Page 80: Pci-E Lan Rtl8111B

    Schematic Diagrams PCI-E LAN RTL8111B 3.3V LAN_VDD3 LANVDD15 60 mil 40 mil CTRL18 HCB2012KF-500T40 3.3V LANVDD18 2SB1188* 40 mil 10U_10V_08 .1U_16V_04 .1U_16V_04 .1U_16V_04 .1U_16V_04 .1U_16V_04 .1U_16V_04 .01U_50V_04 .1U_16V_04 .01U_50V_04 .1U_16V_04 10U_10V_08 100U_4V_B 10U_10V_08 10U_10V_08 .1U_16V_04 3.3V LAN_AVDD3 40 mil HCB2012KF-500T40 LANVDD18 C397 CTRL15...

  • Page 81: Audio Codec Alc883

    Schematic Diagrams AUDIO CODEC ALC883 *SCS551V-30 HCB1608KF-121T25 3.3VS 3.3VS_AUD 5VS_AUD HCB1608KF-121T25 C577 C583 C262 C263 C284 C621 C619 C626 SHDN# .1U_16V_04 10U_10V_08 .1U_16V_04 .1U_16V_04 .1U_16V_04 .1U_16V_04 10U_10V_08 10U_10V_08 Z2433 C644 C642 *G924 1U_10V_06 AUDG *.1U_16V_04 FCM2012VF-121T08 EAPD_MODE GPIO0 Z2401 Z2412 C627 10U_10V_08 GPIO1...

  • Page 82: Audio Amp2056

    Schematic Diagrams AUDIO AMP2056 5VS_AMP 3.3VS 40 mils C598 .1U_10V_X7R_04 0409 Low mute! R384 C587 R129 C291 C308 C301 SB_MUTE# .1U_10V_X7R_04 SCS355V 10K_04 1U_10V_06 .1U_16V_04 .1U_16V_04 OPMUTEAPM# 100K_04 EAPD_MODE *SCS355V MUTEAPM# KBC_MUTE# C607 .1U_16V_04 Z2520 74AHC1G08GW APUDG 0412 APUDG R406 4.7K_04 Z2501 C302...

  • Page 83: Kbc-Ite It8512E

    KBC_WRESET# KB-SO0 VER. MODEL_ID VOLTAGE WRST# KSO0/PD0 KB-SO1 KSO1/PD1 VDD3 0409 H8_GA20 KB-SO2 0403 V1.0 HIGH 3.3V M720R GA20/GPB5 KSO2/PD2 KB-SO3 LED_ACIN# KBRST#/GPB6( PU ) KSO3/PD3 KB-SO4 AC_IN# PWUREQ#/GPC7( PU ) KSO4/PD4 KB-SO5 R432 10K_04 THERM_ALERT# L80LLAT/GPE7( PU ) KSO5/PD5...

  • Page 84: 3Vs, 5Vs

    Schematic Diagrams 3VS, 5VS Power Plane PQ24 SI4800BDY VDD5 0403 SY S3V VDD5 R295 PR142 PR119 10_08 0403 PJ12 330K_04 PC121 10K_04 PQ28 PR116 40mil DIS_5VS_3VS 3900P_50V_04 2N7002W PQ43 47K_04 2N7002W PC139 PQ27 PQ26 *.1u_10V_04 SI4800BDY Power Plane 29,30,31 SUSBL 2N7002W 0522 3.3VS...

  • Page 85: Power Gpu/1.25Vs

    Schematic Diagrams POWER GPU/1.25VS PC83 PC80 PC74 PC180 PC178 PC76 PC81 PC82 .01U_50V_04 .01U_50V_04 .01U_50V_04 FM0540-N 10U_25V_12 10U_25V_12 .1U_50V_06 *1U_25V_08 1U_25V_08 PR82 0_04 PR80 PC87 PJ14 VGFX_CORE 0_04 1U_25V_08 1uH _7*7*3.5 OPEN_8A 3.3VS 0521 PR75 PR74 PD14 18.2K_1%_06 33K_1%_06 PR90 FM5822 3.3VS PC90...

  • Page 86: Power 3.3V/5V

    Schematic Diagrams POWER 3.3V/5V RU N/SS2 PR171 0_06 PR167 10_04 PR168 10_04 PR163 VIN1 1M_04 SY S5V VDD 5 PQ52 PD 19 SI4800BDY FM5822 4.7uH_6.8* 7.3*3.5 PR161 PJ19 PC 230 .01U_50V_06 RU N_SS1 R UN /SS1 PGOOD PC233 PC 229 * 180p_50V_04 10m_12 PC 221...

  • Page 87: Power 1.5Vs/ 1.05Vs

    Schematic Diagrams POWER 1.5VS/ 1.05VS 0614 PC209 PC213 PC215 15U_25V_D PR141 0_06 PR153 10_04 PC204 1U_10V_06 .1U_50V_06 .1U_50V_06 VDD5 0614 PR144 10K_04 PR147 10_04 PC198 1U_10V_06 3.3V VCCP_PWRGD VCCP_PWRGD SGND1 SGND2 PC208 PC217 PC218 PD15 PD16 FM0540-N FM0540-N .1U_50V_06 .1U_50V_06 .1U_50V_06 PC203 1000p_50V_04...

  • Page 88: Power 1.8V/0.9V

    Schematic Diagrams POWER 1.8V/0.9V 3.3V VDDQ PR57 PR68 PD11 PR69 1.5M_04 10_06 100K_04 FM0540-N PR137 10_06 1.8V_PWRGD VDDQS 1.8V_PWRGD 14 PC66 PC174 PC170 PR138 0614 100P_50V_04 2.2K_1%_06 1U_10V_06 1U_10V_06 PR43 PC85 PC182 PC177 PR70 0_06 PC47 15U_25V_D COMP .1U_50V_06 .1U_50V_06 PQ37 10_04 PC67...

  • Page 89: Ac In, Charge

    Schematic Diagrams AC IN, CHARGE PQ30 AM4835P Charge Current 2.0A Charge Voltage 16.8V J_DC-JACK1 Total Power 60W 2DC-G213-B200 HCB4532KF-800T60 PQ31A 0614 V_BAT Z3201 Z3202 0614 SP8K10SFD5TB PR22 30m_20 4.7UH 5.5A 6.8*7.3*3.5 Z3216 GND1 FM1040-T1 PR121 GND2 PR123 GND3 100K_04 30m_20 GND4 PC141 PC140...

  • Page 90: Vcore For Merom Cpu

    Schematic Diagrams VCORE FOR MEROM CPU VCORE FOR MEROM CPU V-RC1 PC32 PC30 0614 1U_25V_08 FM0540-N PR38 1000p_50V_04 10_06 BST1 PC149 PC17 PC16 PC154 PC147 PC148 PC33 PR28 *0_04 PR23 15U_25V_D .1U_50V_06 *10U_25V_12 .1U_50V_06 .01U_50V_06 .1U_50V_06 1U_25V_08 PQ32 SGND3 0_04 PC34 IRF7413ZPBF PR29...

  • Page 91: Multi Board, Lid, Led, Sw, Usb

    Schematic Diagrams MULTI BOARD, LID, LED, SW, USB LID SWITCH IC SPEAKER CONNECTOR USB PORT M_3.3V 10K_04 M_USBVCC M_USBVCC2 FCM1608K-121T06 MJ_SPK1 MDD-SPKR- MDD-SPKR-_R HCB3216KF-800T30 60 mil MLID_SW# MDD-SPKR+ MDD-SPKR+_R FCM1608K-121T06 88266-02001 PCB Footprint = 88266-2L EC2648-B3-F PSU1, PSU2 100U_6.3V_B2 .1U_16V_04 MJ_USB1 .1U_16V_04 0413...

  • Page 92: Multi Board 3G, Mdc, Rj11

    Schematic Diagrams MULTI BOARD 3G, MDC, RJ11 MC15 20 mil 220U_4V_D2 MJ_SIM1 MGND LOCK (TOP VIEW) 0413 MUIM_CLK MUIM_DATA UIM_CLK UIM_DATA MJ_3G1 MC25 .1U_16V_04 MUIM_RST MUIM_VPP UIM_RST UIM_VPP MUIM_PWR MPCIE_WAKE# M_3.3VS WAKE# 3.3V_0 UIM_PWR UIM_GND M_1.5VS BT_DATA 1.5V_0 MUIM_PWR BT_CHCLK UIM_PWR OPEN MUIM_DATA...

  • Page 93: Fingerprint Board

    Schematic Diagrams FINGERPRINT BOARD F3.3V F3.3V FJ_FP1 FC 21 FC22 FUSB_PP1 FUSB_PN1 FCM1608K-121T06 1U_10V_06 .1U_16V_04 FGPIO0/INT FR19 1.5K_04 85201-04051 FUSB_PP1_R FR21 27.4_1%_04 FUSB_PP1 FGND FESD_GND FGND FC20 47P_50V_04 FTC_VD D FGN D FDATA2 FR13 47K_04 FDATA1 FR11 47K_04 FUSB_PN1_R FR20 27.4_1%_04 FUSB_PN 1 FESD_RING...

  • Page 94: Click Board

    Schematic Diagrams CLICK BOARD CJ_TP1 .1U_16V_04 CTPBUTTON_R CJ_TP1 CTPBUTTON_L CGND CJ_TP2 CJ_TP2 CGND CTP_DATA CTP_CLK CTP_CLK CTP_DATA 85201-04051_R CGND 6-20-94A20-112 87152-12071 .1U_16V_04 CGND CSW1~2 LIFT RIGHT CSW1 CSW2 TJG-533-S-V-T/R TJG-533-S-V-T/R Sheet 37 of 37 CTPBUTTON_L CTPBUTTON_R CLICK BOARD CGND CGND MTH237D91 MTH237D91 MTH237D91...
