- Page 3 Preface Notebook Computer M720S Service Manual...
- Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
- Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the M720S series notebook PC.
- Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
-
Page 7: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy... -
Page 8: Power Safety
Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals. -
Page 9: Battery Precautions
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire. - Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. VIII...
-
Page 11: Table Of Contents
Schematic Diagrams......... B-1 External Locator - Left & Right Side View ........1-7 External Locator - Bottom View .............1-8 SYSTEM BLOCK DIAGRAM ............B-2 M720S Mainboard Overview - Top (Key Parts) ......1-9 Merom(Socket-M)1/2 ..............B-3 M720S Mainboard Overview - Bottom (Key Parts) .....1-10 Merom(Socket-M)2/2 ..............B-4 M720S Mainboard Overview - Top (Connectors) ......1-11... - Page 12 Preface AUDIO AMP ................B-26 KBC-ITE IT8512E ............... B-27 SYSTEM POWER ............... B-28 VCORE ..................B-29 VDD3, VDD5 ................B-30 1.05VS, 1.2V, 1.5V ..............B-31 1.8V, 0.9VS .................. B-32 AC IN, CHARGER ..............B-33 CLICK BOARD ................B-34 MULTI I/O BOARD 1/2 .............. B-35 MULTI I/O BOARD 2/2 ..............
-
Page 13: Introduction
Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the M720S series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about driv- ers (e.g. -
Page 14: System Specifications
Introduction System Specifications Feature Specification Processor Intel® Core™2 Duo Processor 65nm (65 Nanometer) Process Technology (478-pin) Micro-FC-PGA Package 4MB On-die L2 Cache & 667MHz FSB T7200/ T7400/ T7600 2.0/ 2.16/ 2.33 GHz Intel® Core™2 Duo Processor 65nm (65 Nanometer) Process Technology (478-pin) Micro-FC-PGA Package 2MB On-die L2 Cache &... - Page 15 Introduction Feature Specification Storage One Changeable 12.7mm(h) Optical Device (CD/DVD) Type Drive (see “Optional” on page 1 - 4 for drive options) Easy Changeable 2.5" 9.5 mm (h) SATA (Serial) HDD Audio Intel High Definition Audio Compliant Interface A3D™ Compatible Compliant with Microsoft UAA (Universal Audio S/PDIF Digital Output Architecture)
- Page 16 Introduction Feature Specification Power Manage- Supports ACPI 3.0 ment Power Full Range AC/DC Adapter AC input 100 - 240V, 50 - 60Hz, DC Output 19V, 3.42A or 18.5V,3.5A (65 Watts) Battery 4 Cell Smart Lithium-Ion Battery Pack, 14.8V/2.4AH 4 Cell Smart Lithium-Ion Battery Pack, 14.4V/2.4AH (Option) 8 Cell Smart Lithium-Ion Battery Pack, 14.8V/4.4AH (Option) Environmental Temperature...
-
Page 17: External Locator - Top View With Lcd Panel Open
Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. Built-In PC Camera (Optional) 2. LCD 3. Speakers 4. Power Button 5. Hot Key Buttons 6. LED Status Indicators 7. Keyboard 8. Touchpad & Buttons 9. -
Page 18: External Locator - Front & Rear Views
Introduction External Locator - Front & Rear Views Figure 2 Front Views 1. LCD Latches 2. LED Power & Communication Indicators 3. 7-in-1 Card Reader 4. S/PDIF-Out Jack 5. Microphone-In Jack 6. Headphone-Out Jack Figure 3 Rear Views 1. Battery 1 - 6 External Locator - Front &... -
Page 19: External Locator - Left & Right Side View
Introduction External Locator - Left & Right Side View Figure 4 Left Side View 1. DC-In Jack 2. RJ-45 LAN Jack 3. External Monitor Port 4. Vent/Fan Intake/ Outlet 5. 2 * USB 2.0 Ports 6. Express Card Slot Figure 5 Right Side View 1. -
Page 20: External Locator - Bottom View
Introduction External Locator - Bottom View Figure 6 Bottom View 1. Battery 2. Hard Disk Bay Cover (3.5G Module Location) 3. RAM & CPU Bay Cover Overheating To prevent your com- puter from overheating make sure nothing blocks the vent/fan in- takes while the com- puter is in use. -
Page 21: M720S Mainboard Overview - Top (Key Parts)
Introduction M720S Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. Buffer ICS 9P935 2. ITE 8512E 3. Express Card Assembly M720S Mainboard Overview - Top (Key Parts) 1 - 9... -
Page 22: M720S Mainboard Overview - Bottom (Key Parts)
2. LAN PHY RTL820ICL 3. Clock Generator ICS9LPR600CGL 4. Northbridge- SiSM671 5. 7-in-1 Card Reader Socket 6. Card Reader Controller ENE MR510 7. Southbridge- SiS968 8. Memory Slots DDRII So-DIMM 9. SiS307ELV 1 - 10 M720S Mainboard Overview - Bottom (Key Parts) -
Page 23: M720S Mainboard Overview - Top (Connectors)
2. RJ-45 LAN Jack 3. CCD Cable Connector 4. LCD Cable Connector 5. Speaker Cable Connector 6. Touch Pad Cable Connector 7. Fingerprint Cable Connector 8. Internal Microphone Cable Connector 9. Keyboard Cable Connector M720S Mainboard Overview - Top (Connectors) 1 - 11... -
Page 24: M720S Mainboard Overview - Bottom (Connectors)
7. Microphone-In Jack 8. Headphone-Out Jack 9. Optical Device Drive Connector 10. Mini PCle Socket 11. SATA HDD Connector 12. Battery Connector 13. Bluetooth/ 3.5G Cable Connector 14. Fan Cable Connector 1 - 12 M720S Mainboard Overview - Bottom (Connectors) -
Page 25: Disassembly
Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the M720S series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart. -
Page 26: Maintenance Tools
Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •... -
Page 27: Maintenance Precautions
Disassembly Maintenance Precautions The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged. -
Page 28: Disassembly Steps
Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Optical Device: 1. Remove the battery page 2 - 5 1. -
Page 29: Removing The Battery
Disassembly Removing the Battery Figure 1 1. Turn the computer off, and turn it over. Battery Removal Slide the latch in the direction of the arrow. Slide the latch in the direction of the arrow, and hold it in place. a. -
Page 30: Removing The Hard Disk Drive
Disassembly Removing the Hard Disk Drive The hard disk drive is mounted in a removable case and can be taken out to accommodate other 2.5" SATA hard disk Figure 2 drives with a height of 9.5mm (h). Follow your operating system’s installation instructions, and install all necessary driv- HDD Assembly ers and utilities (as outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk. - Page 31 Disassembly 4. Carefully grip the mylar cover tag and slide the hard disk in the direction of arrow. Figure 3 5. Lift the hard disk up Figure d in the direction of arrow. HDD Assembly 6. Remove the screws and separate the mylar cover from the hard disk Sequence Removal...
-
Page 32: Removing The System Memory (Ram)
Disassembly Removing the System Memory (RAM) Figure 4 RAM Module The computer has two memory sockets for 200 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDRII 533/677MHz. The main memory can be expanded up to 4GB. The SO-DIMM modules supported are 256MB, 512MB, 1024MB and 2048MB DDRII Modules. - Page 33 Disassembly 7. Gently pull the two release latches ( & on the sides of the memory socket in the direction indicated by the Figure 5 arrows (Figure Memory Removal 8. The RAM module(s) will pop-up Figure e , and you can then remove it Sequence d.
-
Page 34: Removing The Processor
Disassembly Removing the Processor Figure 6 Processor Removal 1. Turn off the computer, and remove the battery (page 2 - 5) and the CPU/RAM bay cover (page 2 - 2. The CPU heat sink will be visible at point on the mainboard. a. - Page 35 Disassembly 5. Turn the release latch towards the unlock symbol , to release the CPU (Figure 6. Carefully (it may be hot) lift the CPU up out of the socket (Figure 7. Reverse the process to install a new CPU. 8.
-
Page 36: Removing The Wireless Lan Module
Disassembly Removing the Wireless LAN Module Figure 8 Wireless LAN 1. Turn off the computer, and remove the battery (page 2 - 5) and the CPU/RAM bay cover (page 2 - Module Removal 1. The Wireless LAN module will be visible at point on the mainboard. -
Page 37: Removing The Bluetooth Module
Disassembly Removing the Bluetooth Module Figure 9 Bluetooth Removal 1. Turn off the computer, and remove the battery (page 2 - 5) and the CPU/RAM bay cover (page 2 - 2. The Bluetooth module will be visible at point on the mainboard. a. -
Page 38: Removing The Optical (Cd/Dvd) Device
Disassembly Removing the Optical (CD/DVD) Device Figure 10 Optical Device 1. Turn off the computer, and remove the battery (page 2 - 5) and the CPU/RAM bay cover (page 2 - Removal 2. Remove the screw at point , and use a screwdriver to carefully push out the optical device at point 3. -
Page 39: Removing The Keyboard
Disassembly Removing the Keyboard Figure 11 Keyboard Removal 1. Turn off the computer, and remove the battery (page 2 - 2. Press the three keyboard latches at the top of the keyboard to elevate the keyboard from its normal position (you a. -
Page 40: Removing The Modem
Disassembly Removing the Modem 1. Turn off the computer, and remove the battery (page 2 - 5) and the CPU/RAM bay cover (page 2 - 8) and the opti- Figure 12 cal device (page 2 - 14) and the keyboard (page 2 - 15). -
Page 41: Part Lists
Part Lists Appendix A:Part Lists This appendix breaks down the M720S series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation. -
Page 42: Part List Illustration Location
Table A - 1 Part List Illustration Part M720S Location page A - 3 Top with Fingerprint - (M720S) page A - 4 Top without Fingerprint - (M720S) page A - 5 Bottom - (M720S) page A - 6 LCD - (M720S) -
Page 43: Top With Fingerprint (M720S
Figure A - 1 Top with Finger- print (M720S) 黑色 無鉛 白色 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 Top with Fingerprint (M720S) A - 3... -
Page 44: Top Without Fingerprint (M720S
Figure A - 2 Top without Fin- gerprint (M720S) 黑色 無鉛 白色 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 A - 4 Top without Fingerprint (M720S) -
Page 45: Bottom (M720S
無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 藍天2 互億 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 Bottom (M720S) A - 5... -
Page 46: Lcd (M720S
無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 灰色 精乘 無鉛 黑色 精乘 無鉛 黑色 精乘 無鉛 無鉛 富佑鴻 無鉛 無鉛 無鉛 無鉛 無鉛 中性 無鉛 無鉛 無鉛 無鉛 無鉛 A - 6 LCD (M720S) -
Page 47: Combo
Part Lists COMBO Figure A - 5 COMBO 無 鉛 無 鉛 無 鉛 無 鉛 COMBO A - 7... -
Page 48: Dvd- Dual-Rw
Part Lists DVD- DUAL-RW Figure A - 6 DVD-DUAL-RW 無鉛 無鉛 無鉛 無鉛 A - 8 DVD- DUAL-RW... -
Page 49: Hdd
Part Lists Figure A - 7 無鉛 無折切痕(設變)(無鉛) HDD A - 9... - Page 50 Part Lists A - 10...
-
Page 51: Schematic Diagrams
Schematic Diagrams Appendix B:Schematic Diagrams This appendix has circuit diagrams of the M720S notebook’s PCB’s. The following table indicates where to find the ap- propriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1... -
Page 52: Schematic Diagrams
Schematic Diagrams SYSTEM BLOCK DIAGRAM CLEVO M720S System Block Diagram SYSTEM POWER,2.5V AC-IN,CHARGER 14.318 MHz +VCORE MULTI I/O BOARD Colck Generator Intel Merom ICS9LPR600 Memory Termination SPK_R, RJ-11, LED 56pins TSSOP LID, HOT KEY, USB, 3G PROCESSOR VDD3,VDD5,3.3V,5V 17.1*8.1*1.2m m... -
Page 53: Merom(Socket
Schematic Diagrams Merom(Socket-M)1/2 J_SKT1A H_A#[31:3] H_A#3 J_SKT1B A[3]# ADS# H_ADS# 4 H_D#[63:0] H_D#[63:0] 4 H_A#4 H_D#0 AA23 H_D#32 H_BNR# 4 A[4]# BNR# D[0]# D[32]# H_A#5 H_D#1 AB24 H_D#33 H_BPRI# 4 A[5]# BPRI# D[1]# D[33]# H_A#6 H_D#2 H_D#34 A[6]# D[2]# D[34]# H_A#7 H_D#3 H_D#35... -
Page 54: Merom(Socket-M)2/2
Schematic Diagrams Merom(Socket-M)2/2 VCORE C 393 C392 C391 C373 C451 10U _6.3V_X5R _08 10U _6.3V_X5R_08 10U _6.3V_X5R_08 10U _6. 3V_X5R_08 10U_6.3V_X5R_08 J_SKT1D VSS[001] VSS[082] VSS[002] VSS[083] VCORE VC OR E VSS[003] VSS[084] VCORE J_SKT1C VSS[004] VSS[085] AB20 VC C[001] VC C[68] VSS[005] VSS[086] R 22... -
Page 55: Sism671 Host Pcie 1/5
Schematic Diagrams SiSM671 HOST PCIE 1/5 1.8VS C1XAVDD HCB1608KF-121T25 U30C H_D#[63:0] 2 H_D #0 C 1XAVDD C1XAVDD HD0# C113 C474 C478 H_D #1 C1XAVSS C1XAVSS HD1# H_D #2 HD2# 10U_10V_08 .1U_16V_04 .01U_16V_X7R_04 H_D #3 C 4XAVDD C4XAVDD HD3# H_D #4 C4XAVSS C4XAVSS HD4#... -
Page 56: Sism671 Dram 2/5
Schematic Diagrams SiSM671 DRAM 2/5 U30B 9,10 M_A_DQ[63:0] M_A_DQ0 AD31 MD0A M_A_DQ1 AD30 MD1A M_A_DQ2 AG34 MD2A D 1XAVDD D1XAVDD M_A_DQ3 AE29 MD3A D1XAVSS D1XAVSS M_A_DQ4 AE32 MD4A 1.8VS D1XAVDD M_A_DQ5 AF34 AP11 MD5A D 4XAVDD D4XAVDD M_A_DQ6 AF31 AP10 MD6A D4XAVSS D4XAVSS... -
Page 57: Sism671 Mutiol Vga 3/5
Schematic Diagrams SiSM671 MuTIOL VGA 3/5 3.3VS C199 1.8VS .1U_16V_04 U30A R101 33_04 R322 C528 AH10 NB_ENTEST 33_04 Z0618 DPRSTP#_INV Z_CLK0 ZCLK ENTEST Z0617 150_1%_04 .1U_10V_X7R_04 NB_TESTMODE0 ZDREQ ZDREQ TESTMODE0 NB_TESTMODE1 74LVC1G14GW C211 ZUREQ ZUREQ TESTMODE1 NB_TESTMODE2 Z_VREF TESTMODE2 Z0602 *100P_50V_04 ZSTB_D0 ZSTB0... -
Page 58: Sism671 Pwr 4/5
Schematic Diagrams SiSM671 PWR 4/5 U30E 1.8V 1.2VS VCCM Y 23 VCCM IVDD C206 C197 C539 C530 AA23 VCCM IVDD AB23 C114 C108 C111 VCCM IVDD 10U_10V_08 10U_10V_08 1U_10V_06 1U_10V_06 AC23 VCCM IVDD AC18 10U_10V_08 10U_10V_08 10U_10V_08 VCCM IVDD AC20 VCCM IVDD AC16... -
Page 59: Sism671 Gnd 5/5
Schematic Diagrams SiSM671 GND 5/5 H12, H13, H14 6-34-M52GS-020 C355B264D186 C355B264D186 C355B264D186 MTH315D111 MTH315D111 MTH315D111 H 12 U30F H16, H17, H18, H19 MTH315D111A MTH315D111A MTH315D111A 6-34-M52NS-020 C217D111 C237D91-A C217D91 H 11 U 14 C217D111 C237D91 O44X59D44X59 U 15 Sheet 8 of 37 U 16 U 17 U 18... -
Page 60: Ddrii So-Dimm 1
Schematic Diagrams DDRII SO-DIMM 1 SO-DIMM 1 1.8V J_DIM2 5,10 M_A_A[17:0] M_A_DQ[63:0] 5,10 M_A_A0 M_A_DQ0 M_A_A1 M_A_DQ1 M_A_A2 M_A_DQ2 M_A_A3 M_A_DQ3 M_A_A4 M_A_DQ4 M_A_A5 M_A_DQ5 M_A_A6 M_A_DQ6 M_A_A7 M_A_DQ7 M_A_A8 M_A_DQ8 M_A_A9 M_A_DQ9 M_A_A10 M_A_DQ10 A10/AP DQ10 M_A_A14 M_A_DQ11 DQ11 M_A_A15 M_A_DQ12 DQ12... - Page 61 Schematic Diagrams DDRII SO-DIMM 2 SO-DIMM 2 1.8V M_A_A[17:0] J_DIM1 Layout Note: Two pieces of 56 ohms must use one M_A_A[17:0] M_A_DQ[63:0] 5,9 M_A_A0 M_A_DQ0 0.1U bypass capacitor. M_A_A1 M_A_DQ1 M_A_A2 M_A_DQ2 0.9VS M_A_A3 M_A_DQ3 M_A_A4 M_A_DQ4 M_A_A5 M_A_DQ5 M_A_A6 M_A_DQ6 M_A_A16 C515...
-
Page 62: Sis307Elv
Schematic Diagrams SiS307ELV L1<=400mils 1.8VS VB_PCIEVD D Close to 307 side H CB1608KF-121T25 C 410 .1U_10V_X7R_04 HDVBN2_R HD VBN2 4 HDVBP2_R C 411 .1U_10V_X7R_04 HD VBP2 4 C 39 C 43 HDVBN1_R C 408 .1U_10V_X7R_04 HD VBN1 4 HDVBP1_R C 409 .1U_10V_X7R_04 HD VBP1 4 10U_10V_08... -
Page 63: Panel, Inverter, Crt
Schematic Diagrams PANEL, INVERTER, CRT 3.3VS C440 .1U_16V_04 C442 .1U_16V_04 R236 2.2K_04 3.3VS 3.3VS 2N7002W Zo=75 Ohm R233 R232 CRT_DDCADAT DAC_DDCADAT 6 390_06 390_06 Z1206 DAC_RED DAC_RED_R R240 4.7K_04 SCS751V-40 DAC_GREEN DAC_GREEN_R CRT_VSY NC CRT_HSY NC DAC_BLUE DAC_BLUE_R DAC_VSYNC 6 DAC_HSYNC 6 R237 4.7K_04... -
Page 64: Pci Ide Mutiol Spi 1/4
Schematic Diagrams 968 PCI IDE MuTIOL SPI 1/4 6-16-47238-45A 3.3VS RN25 8P4RX8.2K_04 PCI_AD[31:0] 22 PCI_INT#A PCI_INT#B PCI_INT#C PCI_INT#D PCI_REQ#0 R190 8.2K_04 RN26 8P4RX8.2K_04 PCI_REQ#1 PCI_REQ#0 PCI_REQ#2 U36A PCI_GNT#0 PCI_REQ#3 FOR MR510 PCI_REQ#4 IDE_AVDD AVDD_IDE PCI_REQ#4 PREQ4# AVSS_IDE IDE_AVSS PCI_REQ#3 RN28 PREQ3# PCI_REQ#2 8P4RX4.7K_04... -
Page 65: Pcie Lan Gpio 2/4
Schematic Diagrams 968 PCIE LAN GPIO 2/4 U36B R401 0_04 Z1404 C631 20P_50V_04 AVSS_GMACCMP18 AVSS_GMACCMP AVDD_GMACCMP18 AVDD_GMACCMP AC23 R397 H_INIT# INIT# AE26 Z1402 H_A20M# CPU_S A20M# OSC25MHO AD23 Z1403 *1M_04 25MHz H_SMI# SMI# OSC25MHI 3.3V AC22 H_INTR INTR RN23 8P4RX10K_04 AE25 GTXCLK_PHY _R H_NMI... -
Page 66: Usb Sata 3/4
Schematic Diagrams 968 USB SATA 3/4 USB0: NEW CARD U36C USB1: FINGER PRINTER D 26 USB_PP0 CLK_12M_USB 17 UV0+ OSC 12MHI USB2: PORT0 D 25 USB_PN0 UV0- Z1501 USB_PP1 UV1+ OSC12MH O R135 127_1%_04 USB3: BLUETOOTH USB_PN1 UV1- USBREF USB_PP2 UV2+ USBREF USB4:... -
Page 67: Pwr Gnd 4/4
Schematic Diagrams 968 PWR GND 4/4 1.05VS 1.8VS U36D 1.8VS VDDZ C243 C557 C552 C554 C271 C306 C298 C272 VDDZ AA25 VDDZ 10U_10V_08 10U_10V_08 1U_10V_06 1U_10V_06 .1U_16V_04 .1U_16V_04 .1U_16V_04 .1U_16V_04 VDDZ VDDZ VDDZ VDDZ VDDZ 3.3VS VDDZ VDDZ VDDZ VDDZ C624 C618 C315... -
Page 68: Clk Gen & Clk Buffer
Schematic Diagrams CLK GEN & CLK BUFFER C157 C152 C188 3.3VS CLKGEN_VDD H_CLK_CPU C182 *10P_50V_04 HCB2012KF-500T40 .1U_16V_04 .1U_16V_04 .1U_16V_04 H_CLK_CPU# C177 *10P_50V_04 H_CLK_NB_R RN21 VDDREF CPUT_L0F H_CLK_NB 4 H_CLK_NB#_R 4P2RX33_04 H_CLK_NB C191 *10P_50V_04 H_CLK_NB# 4 VDDPCI CPUC_L0F C134 C184 C164 C130 H_CLK_CPU_R RN20... -
Page 69: Sata, 3G Power, Pci Debug
Schematic Diagrams SATA, 3G POWER, PCI DEBUG POWER MANAGMENT For NB control and Level shift 3.3V 3.3V 3.3V 3.3V C650 R432 R436 R435 *.1U_16V_04 *4.7K_04 *10K_04 *10K_04 KBC_SUSC# 26 R431 0_04 SB_SUSC# 14 Z1806 Z1807 R429 Z1808 *0_04 R503 Z1805 *2N7002W NB_S3AUXSW# 100K_04... -
Page 70: Multi I/O, Odd, Ccd, Bt
Schematic Diagrams MULTI I/O, ODD, CCD, BT IDE_PDD[15:0] IDE_PDD[15:0] J_ODD1 Z1901 Z1904 Z1902 5V_CCD R402 33_04 CD_RST# IDE_PDD8 NDS352AP_NL 48 mil 20,22,27 PCI_RST# IDE_PDD7 IDE_PDD9 HCB2012KF-500T40 IDE_PDD6 IDE_PDD10 IDE_PDD5 IDE_PDD11 J_CCD1 IDE_PDD12 IDE_PDD4 C370 .1U_16V_04 R206 C368 C369 IDE_PDD3 IDE_PDD13 Z1907 Z1908 IDE_PDD2... -
Page 71: New Card, Mini Pcie, Usb
Schematic Diagrams NEW CARD, MINI PCIE, USB NEW CARD 3.3VS C572 .1U_16V_04 LPC_RST# 3.3V J_NEW1 C575 .1U_16V_04 NC_RST# 74AHC1G08GW_SOT NC_PERST# AUXIN PERST# PERST# C247 .1U_16V_04 20 mil NC_3.3V 3.3VS AUXOUT +3.3VAUX 6-01-74108-Q61 C599 .1U_16V_04 40 mil C580 .1U_16V_04 3.3VIN NC_3.3VS C578 .1U_16V_04 3.3VIN... -
Page 72: Led, Fan, Pc Beep, Tp, Fp
Schematic Diagrams LED, FAN, PC BEEP, TP, FP FAN CONTROL VDD3 VDD3 R197 R192 R200 R201 220_04 220_04 470_04 470_04 D11,D12,D15 Z2101 Z2102 Z2109 Z2110 5VS_FAN HCB2012KF-500T40 AC IN/POWER ON LED WLAN/BT LED KPB-3025Y SGC KPB-3025YSGC C548 C549 .1U_16V_04 10U_10V_08 40MIL Z2103 Z2104... -
Page 73: Ene Mr510, 7
Schematic Diagrams ENE MR510, 7 IN 1 xD_BSY # MFUNC7 xDWP# SUSB# 17,18,20,27,30,31 VCC_CARD MS_D1 MFUNC6 MS_D0 MFUNC5 PCI_AD[31:0] MS_D2 MFUNC4 SD_CLK MS_CLK PCI_AD[31:0] MS_D3 PCI_RST# 19,20,27 MSCLK R437 *0_04 LPC_SIRQ LPC_SIRQ 14,26 MFUNC2 C616 C613 C612 C604 SD_WP 3.3VS SD_CD# MFUNC1 10P_50V_04... -
Page 74: Phy Realtek 8201Cl
Schematic Diagrams PHY REALTEK 8201CL PHY Address : 01 MDC_PHY PWFBOUT PWFBOUT MDIO_PHY MDIO_PHY MDIO AVDD33 V_LAN_3.3 TXD0_PHY TXD0 TXD1_PHY TXD1 TXD2_PHY TXD2 AGND TXD3_PHY TXD3 AGND R447 0_04 TXEN_PHY_R TXEN_PHY TXEN R448 22_04 TXCLK_PHY_R TXCLK_PHY R449 0_04 RXDV_PHY_R RXDV_PHY RXDV R450 0_04... -
Page 75: Audio Codec Alc883
Schematic Diagrams AUDIO CODEC ALC883 *SCS551V-30 MIC1-VREFO-L MIC1-VREFO-R HCB1608KF-121T25 R169 R168 3.3VS 3.3VS_AUD 5VS_AUD 2.2K_04 2.2K_04 HCB1608KF-121T25 MIC1-L MIC1-R C601 C619 C301 C623 C648 C329 C644 C643 SHDN# C338 C337 .1U_16V_04 10U_10V_08 .1U_16V_04 .1U_16V_04 .1U_16V_04 .1U_16V_04 10U_10V_08 10U_10V_08 Z2433 C366 BY P 680P_50V_04 680P_50V_04... -
Page 76: Audio Amp
Schematic Diagrams AUDIO AMP Z2501 R162 13K_04 5VS_AMP C325 6P_50V_04 HCB2012KF-500T40 5VS_AMP C345 1U_10V_06 Mini 20 Mil Z2506 R421 10K_04 C359 C626 C625 C328 C331 C639 FRONT-R RLINEIN LVdd Z2502 RHPIN RVdd .1U_16V_04 10U_10V_08 10U_10V_08 .1U_16V_04 .1U_16V_04 .1U_16V_04 Z2503 R177 100K_04 RBY PASS Z2508... -
Page 77: Kbc-Ite It8512E
R117 C586 Z2603 U 12 100K_04 Z2608 .1U_16V_04 KBC_AGND Z2609 KBC_WR ESET# 3.3VS RESET# MODEL_ID J_KB1 C558 J_KB1 C241 2N7002W M720S 85202-24051 1U_10V_06 .1U _16V_04 AAT3510IGV-2.93-C-C-T1 KB-SI0 3IN1 14,18 LPC_AD0 LAD0 KSI0/STB# KB-SI1 14,18 LPC_AD1 LAD1 KSI1/AFD# KB-SI2 14,18 LPC_AD2... -
Page 78: System Power
Schematic Diagrams SYSTEM POWER 1.2VS,1.5VS,1.8VS,3.3VS,5VS PQ51 SYS15V 1.2V 1.2VS PQ24 PQ26 AO4468 SYS15V VDD5 SYS15V VDD3 3.3VS AO4468 AO4468 PR131 PR57 PR59 PC129 PC131 PR132 PC124 PC123 PR127 PC121 PC57 PR125 1M_04 1M_04 1M_04 .1U_16V_04 10U_10V_08 100K_04 .1U_16V_04 10U_10V_08 100K_04 .1U_16V_04 10U_10V_08 100K_04... -
Page 79: Vcore
Schematic Diagrams VCORE VCORE FOR MEROM AND SANTA ROSA CPU V-RC1 PC 110 PC 115 PD 12 1U_10V_06 1000P_50V_04 FM0540-N PR 103 ? ? ? Santa Rosa CPU ? ? ? ? ? ? 10_06 BST1 PC24 PC 23 PC 22 PC92 PR107 *0_04... -
Page 80: Vdd3, Vdd5
Schematic Diagrams VDD3, VDD5 VIN2 Z2929 PR136 0_06 Z2901 PR141 10_04 Z2902 PR139 10_04 Z2915 PR137 VIN1 SY S5V VDD5 1M_04 INTVCC2 PQ54 PD15 PQ55 Z2916 AO4468 FM5822 AO4468 4.7UH_7*7*3.5 PR133 .022U_16V_04 PC154 RUN_SS1 Z2917 RUN/SS1 PGOOD PC157 PC160 *180P_50V_04 PC150 10m_12 SENSE1+... -
Page 81: Vs, 1.2V, 1.5V
Schematic Diagrams 1.05VS, 1.2V, 1.5V Z3001 PC135 PC133 PC137 PC136 PR123 0_06 PR126 10_06 Z3011 PC122 1U_10V_06 PC146 PC138 PC130 .1U_50V_06 10U_25V_12 10U_25V_12 *10U_25V_12 .1U_50V_06 10U_25V_12 *10U_25V_12 PR55 10_06 Z3012 PC53 1U_10V_06 SGND1 SGND2 FM0540-N FM0540-N PR118 10K_04 PC120 1000P_50V_04 3.3V 1.05VS_PWRGD PGOOD1... -
Page 82: V, 0.9Vs
Schematic Diagrams 1.8V, 0.9VS 3.3V PR26 PR24 PR22 100K_04 1M_04 10_06 V1.8 FM0540-N PR97 10_06 Z3101 1.8V_PWRGD 27 VDDQS PC91 PR94 PC18 PC94 PR99 Z3102 0_06 Z3123 Z3111 100P_50V_04 2.2K_1%_04 1U_10V_06 1U_10V_06 Z3103 Z3104 PC98 PC29 PC26 PC31 PR95 Z3105 .1U_25V_X7R_06 10U_25V_12 10U_25V_12... -
Page 83: Ac In, Charger
Schematic Diagrams AC IN, CHARGER PQ31 AM4835P Charge Current 2.0A Charge Voltage 16.8V J_DC-JACK1 Total Power 60W 2DC-G213-B200 HCB4532KF-800T60 SBM1040 PQ32A Z3201 Z3202 V_BAT SP8K10SFD 5TB PR77 PR14 30m_20 4.7UH_7*7* 3.5 30m _20 Z3216 GND 1 PR75 GND 2 GND 3 100K_04 GND 4 Z3214... -
Page 84: Click Board
Schematic Diagrams CLICK BOARD CJ_TP1 Z3301 .1U_16V_04 CTPBUTTON_R CJ_TP1 CTPBUTTON_L Z3302 Z3303 CGND CJ_TP2 Z3304 CJ_TP2 CGND CTP_DATA CTP_CLK CTP_CLK CTP_DATA 85201-04051_R CGND 6-20-94A20-112 87152-12071 .1U_16V_04 CGND CSW1~2 LIFT RIGHT CSW1 CSW2 Sheet 33 of 37 TJG-533-S-T/R TJG-533-S-T/R CTPBUTTON_L CTPBUTTON_R CLICK BOARD CGND CGND... -
Page 85: Multi I/O Board 1/2
Schematic Diagrams MULTI I/O BOARD 1/2 LID SWITCH IC SPEAKER CONNECTOR USB PORT M_USBVCC M_USBVCC2 HCB3216KF-800T30 60 mil 4/13 MC13 MC12 M_3.3V MJ_SPK1 100U_6.3V_B2 .1U_16V_04 MR12 10K_04 MDD-SPKR+ FCM1608K-121T06 Z3411 Z3412 MDD-SPKR- FCM1608K-121T06 MJ_USB1 MLID_SW# 88266-02001 MC10 MC11 PCB Footprint = 88266-2L MUSB_PN4 MUSB_PN4_R DATA_L... - Page 86 Schematic Diagrams MULTI I/O BOARD 2/2 MJ_SIM1 MC14 LOCK 20 mil 220U_4V_D2 (TOP VIEW) MGND MJ_3G1 MUIM_CLK MUIM_DATA UIM_CLK UIM_DATA MUIM_RST MUIM_VPP WAKE# 3.3V_0 M_3.3VS UIM_RST UIM_VPP MUIM_PWR BT_DATA 1.5V_0 UIM_PWR UIM_GND MUIM_PWR BT_CHCLK UIM_PWR MUIM_DATA UIM_DATA OPEN MUIM_CLK MGND CLKREQ# UIM_CLK MUIM_RST...
-
Page 87: Bios Board
Schematic Diagrams BIOS BOARD B_3.3VS B_3.3VS *.1U_16V_04 *.1U_16V_04 *0_04 B_3.3VS BJ_BIOS2 BJ_BIOS1 Z3601 BGND NC(VPP) B_LPC_RST# *100_04 Z3602 B_PCLK_LPCROM RST# BJBIOS? B_LPC_AD0 Z3603 Z3607 A9(FGPI3) A10(FGPI4) B_LPC_AD1 BRN1 Z3604 Z3608 *0_04 A8(FGPI2) MODE(IC) B_LPC_AD2 *8P4RX10K Z3605 BGND A7(FGPI1) GNDA B_LPC_AD3 Z3606 A6(FGPI0) NC(VCCA) -
Page 88: Fingerprint Board
Schematic Diagrams FINGERPRINT BOARD F3.3V FGPIO0/INT FR19 1.5K_04 FTC_VDD FJ_FP1 FUSB_PP1_R FR21 27.4_1%_04 FUSB_PP1 FUSB_PP1 FMISO/MOD E3 FUSB_PN1 FMOSI FC20 FMCS FMCLK 85201-04051 47P_50V_04 FGND .1U_16V_04 FGND HOLD# M95128WMN6TP FGND FGND FUSB_PN1_R FR20 27.4_1%_04 FUSB_PN1 TCS4B 33P_50V_04 FESD_RIN G EXT_RING2 FR18 FC19 TCS4C... - Page 89 www.s-manuals.com...
