Summary of Contents for Clevo M730SR

  • Page 3 Preface Notebook Computer M73XSR Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.

  • Page 5: About This Manual

    Preface About this Manual This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the M73XSR series notebook PC.

  • Page 6: Fcc Statement

    Preface FCC Statement (Federal Communications Commission) You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 7: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 8: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...

  • Page 9: Power Safety

    Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.

  • Page 10: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 Bottom ................... A-5 LCD ....................A-6 Overview ..................1-1 HDD ....................A-7 System Specifications ..............1-2 Combo .................... A-8 External Locator - Top View with LCD Panel Open ......1-6 DVD-DUAL-RW ................A-9 External Locator - Front & Rear Views ..........1-7 Schematic Diagrams.........
  • Page 12 Preface AUDIO AMP ................B-26 KBC-ITE IT8512E ............... B-27 SYSTEM POWER ..............B-28 VCORE ..................B-29 VDD3, VDD5 ................B-30 1.05VS, 1.2V, 1.5V ..............B-31 1.8V, 0.9VS .................. B-32 AC IN, CHARGER ..............B-33 CLICK BOARD ................B-34 MULTI I/O BOARD 1/2 .............. B-35 MULTI I/O BOARD 2/2 .............

  • Page 13: Introduction

    Introduction Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the M73XSR series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about driv- ers (e.g.

  • Page 14: System Specifications

    Introduction System Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/speeds and CD/DVD device types) may be changed, delayed or updated due to the manufacturer's release schedule. Check with your service center for details.
  • Page 15 Introduction Feature Specification Video Adapter SiS M672 Integrated Video High Performance 2D/3D Graphics Accelerator Shared Memory Architecture up to 256MB Supports Microsoft DirectX 9.0 Supports Vertex Shader 2.0 and Pixel Shader 2.0 Security Security (Kensington® Type) Lock Slot BIOS Password Fingerprint ID Reader Module (Factory Option) BIOS One 8Mb SPI Flash ROM...
  • Page 16 Introduction Feature Specification Communication 10M/100Mb Base-T Ethernet LAN 56K MDC Modem V.90 & V.92 Compliant Note: The Blue- 802.11 b/g Mini-Card USB Wireless LAN Module (Option) UMTS Modes tooth and 3.5G Op- 1.3M or 2.0M Pixel USB PC Camera Module (Factory Option) tional Modules Note that UMTS...
  • Page 17 Introduction Feature Specification Optional Optical Drive Module Options: Bluetooth 2.0 + EDR (Enhanced Data Rate) Module SATA DVD/CD-RW Combo Drive Module (Factory Option) Note: The Blue- SATA Super Multi Drive Module tooth and 3.5G Op- UMTS/HSPDA-based 3.5G Module with MiniCard tional Modules USB Floppy Disk Drive...

  • Page 18: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. Built-In PC Camera (Optional) 2. LCD 3. Built-In Microphone 4. Power Button 5. Hot-Key Buttons 6. LED Status Indicators 7. Keyboard 8. Touchpad & Buttons 9.

  • Page 19: External Locator - Front & Rear Views

    Introduction External Locator - Front & Rear Views Figure 2 Front View 1. LED Power & Communication Indicators 2. 7-in-1 Card Reader 3. S/PDIF-Out Jack 4. Microphone-In Jack Front 5. Headphone-Out Jack Figure 3 Rear View 1. Battery Rear External Locator - Front & Rear Views 1 - 7...

  • Page 20: External Locator - Left & Right Side Views

    Introduction External Locator - Left & Right Side Views Figure 4 Left Side View 1. DC-In Jack 2. RJ-45 LAN Jack Left 3. External Monitor Port 4. Vent 5. 2 * USB 2.0 Ports 6. ExpressCard/ 54(34) Slot Figure 5 Right Side View 1.

  • Page 21: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Battery 2. Hard Disk Bay Cover (3.5G Module) 3. RAM & CPU Bay Cover 4. Vent/Fan Intake/ Outlet 5. Speakers Overheating To prevent your com- puter from overheating make sure nothing blocks the vent/fan in-...

  • Page 22: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. Clock Buffer ICS9P935 2. ITE 8512E 3. ExpressCard Assembly 1 - 10 Mainboard Overview - Top (Key Parts)

  • Page 23: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. CPU Socket (no CPU installed) 2. LAN PHY RTL8201CL 3. CLOCK GENERATOR ICS9LPR600 4. Northbridge- SiSM672 5. 7-in-1 Card Reader Controller 6. Card Reader Controller ENE MR510 7.

  • Page 24: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. External Monitor Port 2. RJ-45 LAN Jack 3. CCD Cable Connector 4. LCD Cable Connector 5. Speaker Cable Connector 6. Touch Pad Cable Connector 7. Fingerprint Cable Connector 8.

  • Page 25: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. DC-In Jack 2. RJ-45 LAN Jack 3. External Monitor Port 4. Inverter Cable Connector 5. USB Port 6. Optical Device Drive Connector 7. Mini PCIe Socket 8. SATA HDD Connector 9.
  • Page 26 Introduction 1 - 14...

  • Page 27: Disassembly

    Disassembly Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the M73XSR series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart. Procedures such as upgrading/replacing the RAM, CD device and hard disk are included in the User’s Manual but are repeated here for your convenience.

  • Page 28: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 29: Maintenance Precautions

    Disassembly Maintenance Precautions The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 30: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Optical Device: 1. Remove the battery page 2 - 5 1.

  • Page 31: Removing The Battery

    Disassembly Removing the Battery Figure 1 1. Turn the computer off, and turn it over. Battery Removal 2. Slide the latches ( & ) the direction of the arrow, and hold latch in place. 3. Slide the battery in the direction of the arrow a.

  • Page 32: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm Figure 2 (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in HDD Assembly Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 33 Disassembly 4. Carefully grip the mylar cover tab and slide the hard disk in the direction of arrow. Figure 3 5. Lift the hard disk up Figure d in the direction of arrow. HDD Assembly 6. Remove the screws and separate the mylar cover from the hard disk Sequence Removal...

  • Page 34: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 4 The computer has two memory sockets for 200 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting RAM Module Removal DDRII 667MHz. The main memory can be expanded up to 2GB. The SO-DIMM modules supported are 1024MB and 2048MB DDRII Modules.
  • Page 35 Disassembly 7. Gently push the two release latches ( & on the sides of the memory socket in the direction indicated by the Figure 5 arrows (Figure Memory Removal 8. The RAM module(s) will pop-up Figure e , and you can then remove it. Sequence d.

  • Page 36: Removing The Processor

    Disassembly Removing the Processor Figure 6 Processor Removal 1. Turn off the computer, and remove the battery (page 2 - 5) and the CPU/RAM bay cover (page 2 - 2. The CPU heat sink will be visible at point on the mainboard. a.
  • Page 37 Disassembly 5. Turn the release latch towards the unlock symbol , to release the CPU (Figure Figure 7 6. Carefully (it may be hot) lift the CPU up out of the socket (Figure Processor Removal 7. Reverse the process to install a new CPU. Sequence 8.

  • Page 38: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 8 Wireless LAN 1. Turn off the computer, remove the battery (page 2 - 5) and the CPU/RAM bay cover (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard.

  • Page 39: Removing The Bluetooth Module

    Disassembly Removing the Bluetooth Module Figure 9 Bluetooth Removal 1. Turn off the computer, remove the battery (page 2 - 5), and the CPU/RAM bay cover (page 2 - 2. The Bluetooth module will be visible at point on the mainboard. a.

  • Page 40: Removing The Optical (Cd/Dvd) Device

    Disassembly Removing the Optical (CD/DVD) Device Figure 10 Optical Device 1. Turn off the computer, remove the battery (page 2 - 5), and the CPU/RAM bay cover (page 2 - Removal 2. Remove the screw at point , and use a screwdriver to carefully push out the optical device at point 3.

  • Page 41: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 11 Keyboard Removal 1. Turn off the computer, and remove the battery (page 2 - 2. Press the three keyboard latches at the top of the keyboard to elevate the keyboard from its normal position (you a.

  • Page 42: Removing The Modem Module

    Disassembly Removing the Modem Module Figure 12 Modem Removal 1. Turn off the computer, remove the battery (page 2 - 5) and the CPU/RAM bay cover (page 2 - 8) and the CPU heat sink (page 2 - 10) and the Wireless LAN (page 2 - 12) and the optical device (page 2 -...
  • Page 43 Disassembly 6. Remove screws and disconnect the connectors from the mainboard. Figure 13 7. Separate the bottom case from the mainboard and turn it over. Modem Removal 8. Remove the screws and disconnect the connector from the modem. Sequence 9. Lift the modem up off the socket e.
  • Page 44 Disassembly 2 - 18...

  • Page 45: Part Lists

    Part Lists Appendix A:Part Lists This appendix breaks down the M73XSR series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 46: Part List Illustration Location

    Part Lists Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration Part Pages# Location page A - 3 Top with Fingerprint page A - 4 Top without Fingerprint page A - 5 Bottom page A - 6...

  • Page 47: Top With Fingerprint

    Part Lists Top with Fingerprint Figure A - 1 Top with Fingerprint 黑色 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 Top with Fingerprint A - 3...

  • Page 48: Top Without Fingerprint

    Part Lists Top without Fingerprint Figure A - 2 Top without Fingerprint 黑色 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 A - 4 Top without Fingerprint...

  • Page 49: Bottom

    Part Lists Bottom 無鉛 兩個孔徑尺寸由 改為 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 Figure A - 3 無鉛 凱碩 無鉛 Bottom 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛...

  • Page 50: Lcd

    Part Lists Figure A - 4 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 黑色 惠貿 無鉛 無鉛 無鉛 黑色 惠貿 無鉛 無鉛 無鉛 無鉛 黑色 惠貿 無鉛 無鉛 中性 電鑄薄膜鍍亮鉻 無鉛 無鉛 無鉛...

  • Page 51: Hdd

    Part Lists Figure A - 5 無鉛 無折切痕(設變)(無鉛) HDD A - 7...

  • Page 52: Combo

    Part Lists Combo Figure A - 6 Combo 無鉛 無鉛 無鉛 無鉛 無鉛 A - 8 Combo...

  • Page 53: Dvd-Dual-Rw

    Part Lists DVD-DUAL-RW Figure A - 7 DVD-DUAL-RW 無鉛 無鉛 無鉛 無鉛 無鉛 DVD-DUAL-RW A - 9...
  • Page 54 Part Lists A - 10...

  • Page 55: Schematic Diagrams

    Schematic Diagrams Appendix B:Schematic Diagrams This appendix has circuit diagrams of the M73XSR notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Table B - 1 Diagram - Page Diagram - Page Diagram - Page Schematic SYSTEM BLOCK DIAGRAM - Page B - 2 968 PCIE LAN GPI0 2/4 - Page B - 15 SYSTEM POWER - Page B - 28...

  • Page 56: Schematic Diagrams

    Schematic Diagrams SYSTEM BLOCK DIAGRAM CLEVO M730SR System Block Diagram A C- IN ,CH AR GE R SY STE M PO WE R, 2.5 V M UL TI I/ O BO AR D 14. 318 MHz +V COR E S PK _R, R J- 11, L ED...

  • Page 57: Meron (Socket

    Schematic Diagrams Meron (Socket-P) 1/2 J S K T 1 A H _ A # [ 35 : 3 ] H _ A # 3 JS K T1 B A [ 3 ] # A D S # H _ A D S # H _ D # [ 6 3 : 0] H _ D # [ 6 3 : 0] H _ A # 4...
  • Page 58 Schematic Diagrams Meron (Socket-P) 2/2 Check cap for santa rosa platform V C OR E PLACE NEAR CPU 5/17 C 3 9 3 C 39 2 C 3 91 C 3 7 3 C 4 5 1 C 68 7 J S K T 1 D V C OR E V C O R E...

  • Page 59: Sism672 Host Pcie 1/5

    Schematic Diagrams SiSM672 HOST PCIE 1/5 EMI 1/3 1 . 8 V S L 40 C 1X A V D D H C B 1 0 0 5K F -12 1 T 2 0 U 3 0 C H _ D # [ 6 3 : 0] H _ D #0 B 1 6 N 2 9...

  • Page 60: Sism672 Dram 2/5

    Schematic Diagrams SiSM672 DRAM 2/5 U 3 0 B 9 , 1 0 M_ A _ D Q [ 6 3 : 0] M _ A _D Q0 A D 31 M D 0 A M _ A _D Q1 A D 30 M D 1 A M _ A _D Q2...

  • Page 61: Sism672 Mutiol Vga 3/5

    Schematic Diagrams SiSM672 MuTIOL VGA 3/5 3 . 3 V S C 1 9 9 1. 8V S . 1U _ 16 V _ 0 4 R 9 2 U 30 A R 1 01 3 3_ 0 4 R 3 2 2 C 5 2 8 A H 1 0 F 15...

  • Page 62: Sism672 Pwr 4/5

    Schematic Diagrams SiSM672 PWR 4/5 U30E 1. 8V 1.2VS V CCM V CCM IV DD C206 C197 C539 C530 A A23 V CCM IV DD A B23 C114 C108 C11 1 V CCM IV DD 10U_10V_08 10U_1 0V _08 1U_10V_06 1U_1 0V _06 AC23 V CCM...

  • Page 63: Sism672 Gnd 5/5

    Schematic Diagrams SISM672 GND 5/5 H12, H13, H14 6-34-M52GS-020 H 1 4 H 1 6 H 1 8 C 3 5 5B 26 4 D 1 8 6 C 3 55 B 2 6 4 D 1 8 6 C 3 5 5B 2 6 4 D 1 8 6 MT H 3 1 5 D 1 1 1 MT H 3 1 5 D 1 1 1 M TH 3 15 D 11 1...

  • Page 64: Ddrii So-Dimm 1

    Schematic Diagrams DDRII SO-DIMM 1 SO-DIMM 1 1 . 8V J _ D I M2 5 , 1 0 M _ A _ A [ 17 : 0 ] M_ A _ D Q [ 6 3 : 0] 5, 1 0 M_ A _ A 0 1 0 2 M_ A _ D Q 0...
  • Page 65 Schematic Diagrams DDRII SO- DIMM 2 SO-DIMM 2 1 . 8 V 5, 9 M _A _A [ 1 7 : 0 ] J _ D I M 1 L ay ou t No te : Two pieces of 56 oh ms m ust use on e 5 , 9 M _A _ A [ 1 7 : 0 ] M_ A _ D Q [ 6 3: 0 ] 5 , 9...

  • Page 66: Sis307Elv

    Schematic Diagrams SiS307ELV EMI 1/3 L1<=400mils 1 . 8V S V B _P C I E V D D C lo se to 30 7 s ide H C B 1 0 0 5K F -12 1 T 20 H D V B N 2 _ R C 4 10 .

  • Page 67: Panel, Inverter, Crt

    Schematic Diagrams PANEL, INVERTER, CRT 3 . 3 V S C 4 4 0 . 1 U _ 16 V _ 0 4 C 44 2 . 1 U _ 1 6V _0 4 Q 2 1 R 2 3 6 2 . 2K _ 0 4 D A C _ R E D L 7 1 F C M 10 0 5 K F -12 1 T0 3...
  • Page 68 Schematic Diagrams 968 PCI IDE MuTIOL SPI 1/4 6- 16 -4 72 38 -4 5A 3 . 3V S R N 25 8P 4 R X 8. 2 K _ 0 4 P C I _ A D [ 3 1 : 0 ] 2 2 P C I _ I N T # A P C I _ I N T # B P C I _ I N T # C...
  • Page 69 Schematic Diagrams 968 PCIE LAN GPI0 2/4 U 3 6B R 4 0 1 * 10 m i l _ s h ort Z 1 4 0 4 C 63 1 27 P _ 5 0 V _0 4 A V S S _G MA C C M P 1 8 A V S S _G MA C C M P A V D D _ G MA C C MP 4 /16...
  • Page 70 Schematic Diagrams 968 USB SATA 3/4 USB0: NEW CARD U 3 6 C USB1: FINGER PRINTER D 2 6 A 2 2 U S B _ P P 0 U V 0 + O S C 1 2 MH I C L K _1 2 M_ U S B 1 7 D 2 5 USB2:...
  • Page 71 Schematic Diagrams 968 PWR GND 4/4 1 . 05 V S 1 . 8V S U 3 6 D N 1 1 V S S U 2 6 N 1 2 1 . 8 V S V D D Z V S S W 2 6 N 1 3...

  • Page 72: Clk Gen & Clk Buffer

    Schematic Diagrams CLK GEN & CLK BUFFER EM I 1/3 C 1 5 7 C 1 5 2 C 1 8 8 3. 3 V S C L K GE N _V D D H _ C L K _ C P U C 1 82 *1 0 P _5 0 V _0 4 H C B 1 0 05 K F -1 2 1T 2 0...

  • Page 73: Sata, 3G Power, Pci Debug

    SAT A SI NGA L FR OM SB T O J ODDB 1 1 2/2 5 END OF JOD D1 FOR M720SR FOR M730SR SI S? ? ? ? ? ? ? ? ? J _ OD D _ 72...

  • Page 74: Multi I/O, Odd, Ccd, Bt

    Schematic Diagrams MULTI I/O, ODD, CCD, BT 12 /25 E MI 1/ 3 L 31 Q1 9 5 V _C C D H C B 1 0 0 5K F -1 2 1T 2 0 N D S 35 2 A P _ N L 48 mi l J_ CCD 1 C 37 0 .

  • Page 75: New Card, Mini Pcie, Usb

    Schematic Diagrams NEW CARD, MINI PCIE, USB NEW CARD 3 . 3V S C 5 72 . 1U _1 6 V _ 04 L P C _ R S T# 3 . 3 V U 3 3 U 3 5 J _N E W 1 C 57 5 .

  • Page 76: Led, Fan, Pc Beep, Tp, Fp

    Schematic Diagrams LED, FAN, PC BEEP, TP, FP FAN CONTROL V D D 3 V D D 3 5V S 5 V S R 19 7 R 1 92 R 2 00 R 2 01 2 20 _ 04 22 0 _0 4 4 70 _ 0 4 47 0 _0 4 EM I 1/3...

  • Page 77: Ene Mr510, 7

    P C I _A D 2 3 R 3 9 6 *1 0 0_ 0 4 P C M_ I D S E L For M730SR P C I _A D 2 0 R 4 8 6 1 00 _ 04...

  • Page 78: Phy Realtek 8201Cl

    Schematic Diagrams PHY REALTEK 8201CL PHY Ad dress : 01 U 4 3 Close to RTL8201CL M D C _ P H Y M D C P W F B O U T P W F B O U T MD I O_ P H Y MD I O _ P H Y M D I O...

  • Page 79: Audio Codec Alc883

    Schematic Diagrams AUDIO CODEC ALC883 D 37 *S C S 55 1 V -3 0 MI C 1- V R E F O -L M I C 1 -V R E F O -R E MI 1/ 3 E MI 1/ 3 L 5 9 H C B 10 0 5K F -12 1 T 20 R 1 6 9...

  • Page 80: Audio Amp

    1 0 U _ 1 0V _ 0 8 . 1U _ 16 V _ 0 4 . 1 U _ 1 6V _ 0 4 . 1 U _ 1 6 V _ 04 For M730SR 1 2/ 25 A U D G L 67...

  • Page 81: Kbc-Ite It8512E

    10 K _ 0 4 LP C _F R A ME # L F R A M E # K S I 5 FOR M730SR K B -S I 6 S MC _B A T M OD E L _ I D...

  • Page 82: System Power

    Schematic Diagrams SYSTEM POWER 1.2VS,1.5VS,1.8VS,3.3VS,5VS P Q 51 S Y S 15 V 1 . 2V 1 . 2V S P Q2 4 P Q2 6 A O 44 6 8 S Y S 1 5 V V D D 5 A O4 46 8 5V S S Y S 1 5V...

  • Page 83: Vcore

    Schematic Diagrams VCORE VCORE FOR MEROM AND SANTA ROSA CPU V I N V -R C 1 P C 1 1 0 P C 1 1 5 P D 1 2 1 U _1 0 V _ 0 6 1 00 0 P _ 5 0V _ 0 4 F M0 5 4 0- N P R 1 0 3 V I N...

  • Page 84: Vdd3, Vdd5

    Schematic Diagrams VDD3, VDD5 4 /16 V IN2 Z2 929 PR 136 *32m i l _short Z 2901 P R141 10 _04 Z 2902 P R139 10 _04 Z291 5 PR 137 1M _04 V IN1 7/11 S YS 5V V DD5 INT V CC2 P Q54...

  • Page 85: Vs, 1.2V, 1.5V

    Schematic Diagrams 1.05VS, 1.2V, 1.5V V I N Z 3 0 0 1 P C 1 35 P C 1 3 3 P C 13 7 P C 1 3 6 P R 12 6 1 0 _0 6 Z 30 1 1 P C 12 2 1 U _1 0 V _ 06 P C 1 4 6...

  • Page 86: 1.8V, 0.9Vs

    Schematic Diagrams 1.8V, 0.9VS V I N 3. 3 V P R 2 6 P R 24 P R 22 P D 2 1 00 K _ 0 4 1 M_ 0 4 1 0 _0 6 V 1 . 8 F M 0 54 0 -N P U 4 P R 9 7...

  • Page 87: Ac In, Charger

    Schematic Diagrams AC IN, CHARGER P Q3 1 V I N A M4 8 3 5P Ch arg e Cu rr en t 2. 0A Ch arg e Vo lt ag e 16 .8 V J _ D C -J A C K 1 P L 1 To tal P ow er 6 0W 2 D C -G 21 3 -B 2 0 0...

  • Page 88: Click Board

    TJ G -53 3-S -T/ R C TP B U TTO N _L C TPB U TTO N _R C G N D C GN D For M720SR For M730SR 12/25 12/25 C R 1 *0_04 C R 2 0_0 4...

  • Page 89: Multi I/O Board 1/2

    . 1U _ 16 V_ 04 MGN D MGN D MGN D MGN D MGN D HDD /CD -RO M FOR M730SR M_ 3. 3 VS NUM LO CK CAP S L OC K SC ROL L TH ROT TLE M_3 . 3 V S M_3 .
  • Page 90 Schematic Diagrams MULTI I/O BOARD 2/2 MR 1 5 * 4. 7 K _ 0 4 MJ _ S I M1 MC 14 LO CK 2 2 0 U _ 4V _ D 2 20 mil ( TOP VI EW ) MGN D M J_ 3 G1 MU I M_ C L K...

  • Page 91: Fingerprint Board

    Schematic Diagrams FINGERPRINT BOARD F 3 . 3 V F G P I O 0/ I N T F R 1 9 1 . 5K _0 4 F T C _ V D D F J _F P 1 F U S B _ P P 1 _ R F R 2 1 2 7.

  • Page 92: Audio Board

    Schematic Diagrams AUDIO BOARD AUDIO BRIDGE BOARD A JS PD IF1 AS P DIF O A L4 F CM 10 05KF -102T 02 A C1 0.01U_16V _X 7R _04 AR 2 A C5 C121 03-10609-L 220_04 1000P _50V _X 7R_ 04 SP DIF OUT Sheet 37 of 38 BLA CK...

  • Page 93: Odd Bridge Board

    Schematic Diagrams ODD BRIDGE BOARD ODD BRIDGE BOARD Sheet 38 of 38 ODD BRIDGE BOARD BJ_SATA1 BJ ODD 2 BSATA_TX P1 BSATA_TX N 1 BSATA_TXP1 BSATA_R X N 1 BSATA_TXN1 BSATA_R X P1 BSATA_RXN1 BSATA_RXP1 BOD D_DETECT# BGND BODD _D ETEC T# 1.6A B5VS B 5VS...
  • Page 94 Schematic Diagrams B - 40...
