Summary of Contents for Clevo M740S

  • Page 3 Preface Notebook Computer M740S/M741S/M745S/M760S/M765S/M766S/M767S Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.

  • Page 5: About This Manual

    This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the M740S/ M741S/M745S/M760S/M765S/M766S/M767S series notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 7: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...

  • Page 8: Power Safety

    Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 10: Related Documents

    Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. VIII...

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 Top without Fingerprint (M740S) ..........A-3 Top without Fingerprint (M741S/M745S) ........A-4 Overview ..................1-1 Bottom (M740S/M741S/M745S) ..........A-5 System Specifications ......... 1-2 LCD (M740S/M741S/M745S) ............A-6 External Locator - Top View with LCD Panel Open ......1-5 HDD (M740S/M741S/M745S) .............
  • Page 12 Preface Inverter, Bluetooth, Fan ............... B-14 968 PCI, IDE, MuTIOL, SPI 1/4 ..........B-15 968 PCIE, LAN, GPIO 2/4 ............B-16 968 USB SATA 3/4 ..............B-17 968 PWR, GND 4/4 ..............B-18 Clock Generator & Clock Buffer ..........B-19 PHY Realtek 8201CL ..............

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the M740S/M741S/M745S/M760S/M765S/M766S/ M767S series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about drivers (e.g. VGA & audio) is also found in User’s Manual. That manual is shipped with the computer.

  • Page 14: System Specifications

    1MB On-die L2 Cache & 533MHz FSB 530/ 540/ 550/ 560 1.73/ 1.86/ 2.0/ 2.13 GHz Core Logic SiS M672 + SiS968 Chipset M740S/M741S/M745S M760S/M765S/M766S/M767S 14.1" WXGA/ WXGA+ Glare Type TFT LCD 15.4" WXGA/ WXGA+/ WSXGA+ Glare Type TFT LCD Video Adapter...
  • Page 15 Introduction Feature Specification Storage One Changeable 12.7mm(h) PATA Optical Device (CD/DVD) Type Drive (see “Optional” on page 1 - 4) Easy Changeable 2.5" 9.5 mm (h) SATA (Serial) HDD Audio High Definition Audio (HDA) Direct Sound 3D™ Compatible Compliant with Microsoft UAA (Universal Audio 2 * Built-In Speakers Architecture) Built-In Microphone...
  • Page 16 C - 35 Operating: 20% - 80% Non-Operating: -20°C - 60°C Non-Operating: 10% - 90% Dimensions M740S/M741S/M745S M760S/M765S/M766S/M767S: & Weight 336mm (w) * 250mm (d) * 24.8-35.7mm (h) 359mm (w) * 268mm (d) * 24.8-37mm (h) 2.2 kg With 6 Cell Battery & ODD 2.5 kg With 6 Cell Battery &...

  • Page 17: External Locator - Top View With Lcd Panel Open

    1. Optional Built-In PC Camera 2. LCD 3. Speakers 4. Power Button 5. Hot Key Buttons 6. Keyboard 7. Built-In Microphone 8. Touchpad & Buttons 9. LED Indicators M740S/M741S/M745S M760S/M765S/M766S/M767S External Locator - Top View with LCD Panel Open 1 - 5...

  • Page 18: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right side Views Figure 2 Front Views 1. LED Power & Communication Indicators Figure 3 Right Side Views 1. S/PDIF-Out Jack 2. Microphone-In Jack 3. Headphone-Out Jack 4. USB 2.0 Port 5. Optical Device Drive Bay 6.

  • Page 19: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. DC-In Jack 2. External Monitor Port 3. RJ-45 LAN Jack 4. Vent/Fan Intake/ Outlet 5. 2 * USB 2.0 Ports 6. ExpressCard Slot 7. 7-in-1 Card Reader Figure 5 Rear View...

  • Page 20: External Locator - Bottom View

    Module Cover 3. RAM & CPU Bay Cover 4. Vent/Fan Intake/ Outlet 5. Hard Disk Bay Cover 6. 3.5G USIM Card Location M740S/M741S/M745S M760S/M765S/M766S/M767S Overheating To prevent your com- puter from overheating make sure nothing blocks the vent/fan in- takes while the com- puter is in use.

  • Page 21: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. Transformer 2. RTL8201CL 3. ExpressCard Connector 4. ENE MR510 5. KBC ITE IT8512E Mainboard Overview - Top (Key Parts) 1 - 9...

  • Page 22: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. CPU Socket (no CPU installed) 2. SiSM672 3. Memory Slots DDR2 SO-DIMM 4. ICS 9LPR600CGLF 5. Card Reader Socket 6. SiS307ELV 7. Audio Codec ALC62 8. Mini-Card Connector (WLAN Module) 9.

  • Page 23: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. USB Port 2. Inverter Connector 3. LCD Cable Connector 4. Keyboard Cable Connector 5. Audio Board Connector 6. Microphone Cable Connector 7. TouchPad Cable Connector Mainboard Overview - Top (Connectors) 1 - 11...

  • Page 24: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. BT Cable Connector 2. Multi Board Connector 3. CD-ROM Connector 4. HDD Connector 5. CMOS Bat. Connector 6. CPU Fan Cable Connector 7. DC-In Jack 1 - 12 Mainboard Overview - Bottom (Connectors)

  • Page 25: Disassembly

    Disassembly Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the M740S/M741S/M745S/M760S/M765S/M766S/ M767S series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Wireless LAN Module: 1. Remove the battery page 2 - 5 1.

  • Page 29: Removing The Battery

    Disassembly Removing the Battery 1. Turn the computer off, and turn it over. Figure 1 2. Slide the latch in the direction of the arrow. Battery Removal 3. Slide the latch in the direction of the arrow, and hold it in place. 4.

  • Page 30: Removing The Hard Disk Drive

    (page 2 - screw(s). 2. Locate the hard disk bay cover and remove screw & M740S/M741S/M745S M760S/M765S/M766S/M767S HDD System Warning New HDD’s are blank. Before you begin make sure: You have backed up any data you want to keep from your old HDD.
  • Page 31 Disassembly For M740S/M741S/M745S computers: Figure 3 3. Remove the hard disk bay cover HDD Assembly 4. Grip the tab and slide the hard disk in the direction of arrow Removal (cont’d.) 5. Lift the hard disk out of the bay 6.
  • Page 32 Disassembly For M760S/M765S/M766S/M767S computers: Figure 4 8. Remove the hard disk bay Cover HDD Assembly 9. Grip the tab and slide the hard disk in the direction of arrow Removal (cont’d.) 10. Lift the hard disk out of the bay 11.

  • Page 33: Removing The Optical (Cd/Dvd) Device

    1. Turn off the computer, and remove the battery (page 2 - Removal 2. M740S/M741S/M745S: (see over for M760S/M765S/M766S/M767S) Locate the component bay cover remove screws a. Remove the screws. 3. Carefully (a fan and cable are attached to the under side of the cover) lift up the bay cover.
  • Page 34 Disassembly 8. M760S/M765S/M766S/M767S: Locate the hard disk bay cover and loosen screws & Figure 6 9. Remove the hard disk bay cover Optical Device 10. Remove the screw at point , and use a screwdriver to carefully push out the optical device at point Removal (cont’d.) 11.

  • Page 35: Removing The System Memory (Ram)

    Even the clean- est hands have oils which can attract parti- cles, and degrade the module’s perfor- mance. M740S/M741S/M745S M760S/M765S/M766S/M767S Note: Only one model is pictured here, however the compo- 1. Component Bay nent locations are the same Cover for both models.
  • Page 36 Disassembly 5. Gently pull the two release latches ( & on the sides of the memory socket in the direction indicated by the Figure 8 arrows (Figure 8c). RAM Module Removal (cont’d.) c. Pull release latch(es). d. Remove the module(s). e.

  • Page 37: Removing The Inverter Board

    Disassembly Removing the Inverter Board Figure 9 Inverter Board 1. Turn off the computer, and remove the battery (page 2 - Removal 2. Remove any rubber covers, screws (Figure 9a), then run your finger around the middle of the frame to carefully unsnap the LCD front panel module from the back.

  • Page 38: Removing And Installing The Processor

    Disassembly Removing and Installing the Processor Processor Removal Procedure Figure 10 Processor Removal 1. Turn off the computer, remove the battery (page 2 - 5) and the component bay cover (page 2 - 11). 2. The CPU heat sink will be visible at point on the mainboard.
  • Page 39 Disassembly 5. Turn the release latch towards the unlock symbol , to release the CPU (Figure 11a). Figure 11 6. Carefully (it may be hot) lift the CPU up out of the socket (Figure 11b). Processor Removal 7. See page 2 - 16 for information on inserting a new CPU.

  • Page 40: Processor Installation Procedure

    Disassembly Processor Installation Procedure Figure 12 Processor 1. Insert the CPU , pay careful attention to the pin alignment, it will fit only one way (DO NOT FORCE IT!), and turn Installation the release latch towards the lock symbol (Figure 12b).

  • Page 41: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 13 Wireless LAN 1. Turn off the computer, remove the battery (page 2 - 5) and the component bay cover (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard.

  • Page 42: Removing The Bluetooth Module

    Disassembly Removing the Bluetooth Module Figure 14 Bluetooth Module 1. Turn off the computer, remove the battery (page 2 - Removal 2. Locate the Bluetooth bay cover, and remove the screw and cover 3. Remove the screw and turn the module over. a.

  • Page 43: Removing The Keyboard

    Disassembly Removing the Keyboard 1. Turn off the computer, and remove the battery (page 2 - Figure 15 2. Press the four keyboard latches at the top of the keyboard to elevate the keyboard from its normal position (you Keyboard Removal may need to use a small screwdriver to do this).

  • Page 44: Removing The Modem

    (Figure 17b). remove the screws and 4. For M760S/M765S/M766S/M767S only - remove screws (Figure 17c) from the rear of the computer. disconnect the cable. c. Remove the screws. M740S/M741S/M745S M760S/M765S/M766S/M767S • 20 Screws (M740S/M741S/ M745S)/ 24 Screws (M760S/ M765S/M766S/ M767S)
  • Page 45 Remove the screws. M740S/M741S/M745S M760S/M765S/M766S/M767S f. Remove the screws and disconnect the connec- tor. g. Lift the modem out. M740S/M741S/M745S M760S/M765S/M766S/M767S 27. Top Case 34. Modem • 5 Screws (M740S/ M741S/M745S/ M760S/M765S/ M766S/M767S) Removing the Modem 2 - 21...
  • Page 46 Disassembly 2 - 22...

  • Page 47: Part Lists

    Part Lists Appendix A: Part Lists This appendix breaks down the M740S/M741S/M745S/M760S/M765S/M766S/M767S series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 48: Part List Illustration Location

    Part Lists Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A- 1 Part List Illustration Location Parts M740S M741S/M745S M760S M765S M766S/M767S Top without Fingerprint page A - 3 page A - 4...

  • Page 49: Top Without Fingerprint (M740S

    Part Lists Top without Fingerprint (M740S) Figure A - 1 Top without Fingerprint (M740S) 白色 (無鉛) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 Top without Fingerprint (M740S) A - 3...

  • Page 50: Top Without Fingerprint (M741S/M745S

    Part Lists Top without Fingerprint (M741S/M745S) Figure A - 2 Top without Fingerprint (M741S/M745S) 白色 (無鉛) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 A - 4 Top without Fingerprint (M741S/M745S)

  • Page 51: Bottom (M740S/M741S/M745S

    無鉛 無鉛 無鉛 無鉛 無電鍍 無鉛 無鉛 無鉛 無電鍍 無鉛 無鉛 無鉛 藍天3 互億 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無電鍍 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 道康宁 道康宁 無鉛 Bottom (M740S/M741S/M745S) A - 5...

  • Page 52: Lcd (M740S/M741S/M745S

    (不需重工高壓線)(無鉛) 無鉛 無鉛 無鋁箔 無鉛 無鉛 無鋁箔 無鉛 太極 無鉛 無鉛 精乘 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 精乘 無鉛 精乘 無鉛 無鉛 中性 電鑄薄膜鍍亮鉻） 無鉛 中性 無鉛 無鉛 無鉛 無鉛 無鉛 精乘 無鉛 A - 6 LCD (M740S/M741S/M745S)

  • Page 53: Hdd (M740S/M741S/M745S

    Part Lists HDD (M740S/M741S/M745S) Figure A - 5 (M740S/M741S/ M745S) 無鉛 (無鉛) HDD (M740S/M741S/M745S) A - 7...

  • Page 54: Combo (M740S/M741S/M745S

    Part Lists COMBO (M740S/M741S/M745S) Figure A - 6 COMBO (M740S/M741S/ *(非耐落) 無鉛 無鉛 M745S) 無鉛 無鉛 無鉛 無鉛 A - 8 COMBO (M740S/M741S/M745S)

  • Page 55: Dvd-Dual Drive (M740S/M741S/M745S

    Part Lists DVD-Dual Drive (M740S/M741S/M745S) Figure A - 7 DVD-Dual Drive *(非耐落) 無鉛 無鉛 (M740S/M741S/ 無鉛 無鉛 無鉛 M745S) DVD-Dual Drive (M740S/M741S/M745S) A - 9...

  • Page 56: Top Without Fingerprint (M760S

    Part Lists Top without Fingerprint (M760S) Figure A - 8 Top without Fingerprint (M760S) 白色 (無鉛) 黑色 無鉛 白色 無鉛 無鉛 無鉛 無鉛 白色 無鉛 無鉛 噴藍黑漆 設變 無鉛 無鉛 無鉛 無鉛(背膠變更) 無鉛 無鉛 無鉛 無鉛 無鉛 非耐落 無鉛 無鉛 無鉛...

  • Page 57: Top Without Fingerprint (M765S

    Part Lists Top without Fingerprint (M765S) Figure A - 9 Top without Fingerprint (M765S) 黑色 無鉛 無鉛 黑色 無鉛 無鉛 無鉛 黑色 未遮噴 無鉛 無鉛 無鉛 無鉛(背膠變更) 無鉛 無鉛 無鉛 無鉛 非耐落 無鉛 無鉛 無鉛 Top without Fingerprint (M765S) A - 11...

  • Page 58: Top Without Fingerprint (M766S/M767S

    Part Lists Top without Fingerprint (M766S/M767S) Figure A - 10 Top without Fingerprint (M766S/M767S) 黑色 無鉛 無鉛 無鉛 黑色 無鉛 無鉛 無鉛 黑色 未遮噴 無鉛 無鉛 無鉛 無鉛(背膠變更) 無鉛 無鉛 無鉛 無鉛 非耐落 無鉛 無鉛 無鉛 無鉛 A - 12 Top without Fingerprint (M766S/M767S)

  • Page 59: Bottom (M760S/M765S/M766S/M767S

    Part Lists Bottom (M760S/M765S/M766S/M767S) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 外 無鉛 無鉛 無鉛 無鉛 外 無鉛 無鉛 無鉛 Figure A - 11 無鉛 無鉛 無鉛 Bottom 無鉛 無鉛 (M760S/M765S/ 無鉛 無鉛 M766S/M767S) 無鉛 海華 無鉛...

  • Page 60: Lcd (M760S

    Part Lists LCD (M760S) Figure A - 12 無鉛 無鉛 無鉛 無鉛 (M760S) 無鉛 無鉛 (非耐落) 無鉛 無鉛 頭徑 頭厚 號穴 鍍白鎳 頭 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 精乘 無鉛 黑色 惠貿...

  • Page 61: Lcd (M765S

    Part Lists LCD (M765S) Figure A - 13 (M765S) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 (非耐落) 無鉛 無鉛 頭徑 頭厚 號穴 鍍白鎳 頭 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 精乘 無鉛 黑色 惠貿 無鉛 無鉛...

  • Page 62: Lcd (M766S/M767S

    Part Lists LCD (M766S/M767S) Figure A - 14 (M766S/M767S) 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 (非耐落) 無鉛 無鉛 頭徑 頭厚 號穴 鍍白鎳 頭 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 無鉛 精乘 無鉛 黑色 惠貿 無鉛 無鉛...

  • Page 63: Hdd (M760S/M765S/M766S/M767S

    Part Lists HDD (M760S/M765S/M766S/M767S) Figure A - 15 (M760S/M765S/ M766S/M767S) 無鉛 (無鉛) HDD (M760S/M765S/M766S/M767S) A - 17...

  • Page 64: Combo (M760S/M765S/M766S/M767S

    Part Lists COMBO (M760S/M765S/M766S/M767S) Figure A - 16 COMBO (M760S/M765S/ M766S/M767S) *(非耐落) 無鉛 無鉛 無鉛 黑色 無鉛 無鉛 A - 18 COMBO (M760S/M765S/M766S/M767S)

  • Page 65: Dvd-Dual Drive (M760S/M765S/M766S/M767S

    Part Lists DVD-Dual Drive (M760S/M765S/M766S/M767S) Figure A - 17 DVD-Dual Drive (M760S/M765S/ M766S/M767S) *(非耐落) 無鉛 無鉛 無鉛 無鉛 黑色 無鉛 無鉛 DVD-Dual Drive (M760S/M765S/M766S/M767S) A - 19...
  • Page 66 Part Lists A - 20...
  • Page 67 Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the M740S/M741S/M745S/M760S/M765S/M766S/M767S notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Table B - 1 Diagram - Page Diagram - Page Diagram - Page...

  • Page 68: Schematic Diagrams

    Schematic Diagrams System Block Diagram CLEVO M740S System Block Diagram A C- IN ,CH AR GE R SY STE M PO WE R, GPU C OR E 14. 318 MHz +V COR E M UL TI I/ O BO AR D...

  • Page 69: Penryn (Socket

    Schematic Diagrams Penryn (Socket-P) 1/2 JS K T 1 A J S K T 1B H _ A # [ 35 : 3 ] H _ A # 3 A [ 3 ] # A D S # H _ A D S # 4 H _D # [ 63 : 0 ] H _ D # [ 63 : 0 ] 4 H _ A # 4...

  • Page 70: Penryn (Socket-P) 2/2

    Schematic Diagrams Penryn (Socket-P) 2/2 Check cap for santa rosa platform V C OR E PLACE NEAR CPU C 5 6 4 C 57 7 C 9 5 C 5 6 5 C 5 6 8 C 58 0 J S K T 1 D V C OR E V C O R E 10 U _ 6.

  • Page 71: Sism672 Host, Pcie 1/5

    S i S M 6 7 2 H D 4 6 # C 2 6 H _ D # 4 7 INTERNAL VGA( M740S ) : H D 4 7 # U 34 G 2 2 H _ D # 4 8...

  • Page 72: Sism672 Dram 2/5

    Schematic Diagrams SiSM672 DRAM 2/5 U 3 2 B 9 , 1 0 M_ A _ D Q [ 6 3: 0] M _A _D Q0 A D 3 1 M D 0 A M _A _D Q1 A D 3 0 M D 1 A M _A _D Q2 A G3 4...

  • Page 73: Sism672 Mutiol Vga 3/5

    Schematic Diagrams SiSM672 MuTIOL VGA 3/5 3 . 3 V S C 5 26 1. 8V S . 1 U _ 1 0V _ X 7 R _ 04 U 2 6 R 36 5 U 32 A R 3 5 2 3 3 _0 4 R 2 2 1 C 3 0 1...

  • Page 74: Sism672 Pwr 4/5

    Schematic Diagrams SiSM672 PWR 4/5 U32E 1.8V 664 mA 1.2V S 2 024mA V CCM V CCM IVD D C268 C277 C 298 C297 AA 23 V CCM IVD D AB 23 C257 C 280 C272 V CCM IVD D 10U_10V _08 10U_10V_08 1U _10V_06...

  • Page 75: Sism672 Gnd 5/5

    Schematic Diagrams SiSM672 GND 5/5 6- 34-M52GS-0 20 H 3 3 H 2 7 H 2 8 C 3 5 5 B 2 64 D 1 86 C 3 5 5 B 2 6 4D 1 8 6 C 3 55 B 2 6 4 D 1 8 6 H 2 0 H 19 M T H 3 1 5 D 1 1 1...

  • Page 76: Ddrii So-Dimm - 1

    Schematic Diagrams DDRII SO-DIMM - 1 SO-DIMM 1 1. 8 V J _ D I M 1 5 , 10 M _ A _A [ 17 : 0 ] M_ A _ D Q [ 6 3: 0 ] 5 , 1 0 M_ A _ A 0 1 0 2 M_ A _ D Q 5...
  • Page 77 Schematic Diagrams DDRII SO-DIMM - 2 SO-DIMM 2 1 . 8 V 5 , 9 M_ A _ A [ 1 7: 0 ] J_ D I M2 La yo ut N ot e: Two pieces o f 56 ohms must use one 5, 9 M _A _A [ 1 7 : 0 ] M _A _D Q[ 6 3 : 0 ] 5, 9...

  • Page 78: Sis307Elv

    Schematic Diagrams SiS307ELV L1<=400mils 1 . 8V S 4, 5 , 6 , 7 , 13 , 1 4 , 15 , 1 7 , 19 , 2 1 , 22 , 2 3 , 24 , 2 5 , 35 1.

  • Page 79: Panel, Crt

    Schematic Diagrams Panel, CRT 3 . 3 V S C 1 6 . 1U _1 0 V _X 7 R _ 0 4 C 14 . 1 U _ 1 0V _ X 7R _ 04 Q 22 R 3 99 2.

  • Page 80: Inverter, Bluetooth, Fan

    Schematic Diagrams Inverter, Bluetooth, Fan INVERTER CONNECTOR Bluetooth 3 . 3V 3. 3 V V I N _ I N V V I N 3 . 3 V 3V S _ B T L 53 H C B 1 6 08 K F -1 2 1T 2 5 H C B 1 00 5 K F -12 1 T2 0 50 mil R 3 9 8...

  • Page 81: Pci, Ide, Mutiol, Spi 1/4

    Schematic Diagrams 968 PCI, IDE, MuTIOL, SPI 1/4 P C I _ A D [ 3 1 : 0 ] 2 8 6 -1 6- 47 23 8- 45 A 3 . 3 V S R N 1 5 8 P 4R X 8. 2K _ 0 4 P C I _ I N T # A P C I _ I N T # B P C I _ I N T # C...

  • Page 82: Pcie, Lan, Gpio 2/4

    Schematic Diagrams 968 PCIE, LAN, GPIO 2/4 U 3 6 B R 50 9 *1 0 m i l _ sh o rt Z 2 0 04 C 7 3 6 2 2 P _5 0 V _ 04 A V S S _G MA C C M P A V S S _G MA C C MP 1 8 D 03 A A V D D _G MA C C MP 1 8...

  • Page 83: Usb Sata 3/4

    Schematic Diagrams 968 USB SATA 3/4 USB0: NEW CARD U 3 6 C USB1: MINI CARD D 26 A 2 2 U S B _P P 0 U V 0 + O S C 1 2 MH I C L K _ 12 M _U S B 2 5 D 25 USB2: FINGER PRINTE R...

  • Page 84: Pwr, Gnd 4/4

    Schematic Diagrams 968 PWR, GND 4/4 1. 05 V S 2 2m A 1. 8V S U 3 6 D N 11 V S S U 2 6 N 12 1 . 8 V S V D D Z V S S W 2 6 N 13 C 4 4 8...

  • Page 85: Clock Generator & Clock Buffer

    Schematic Diagrams Clock Generator & Clock Buffer C 4 0 2 C 3 9 8 C 37 6 3. 3V S C L K GE N _ V D D H _ C L K _ C P U C 3 7 5 * 10 P _ 5 0V _0 4 .

  • Page 86: Phy Realtek 8201Cl

    Schematic Diagrams PHY Realtek 8201CL PH Y Addres s : 01 Close to RTL8201CL M D C_P HY M DC P W F BO UT P WF B OU T M DIO_P H Y M DIO _PH Y M DIO AV D D33 V _LA N_3.3 T X D0 _PH Y...

  • Page 87: Kbc Ite8512E

    Schematic Diagrams KBC ITE8512E K B C _ A V D D L 3 6 R 3 3 1 1 0 K _ 04 W D T _E N V D D 3 H C B 10 0 5 K F -12 1 T2 0 V D D 3 P J 7 V D D 3...

  • Page 88: Ene Mr510, Card Reader

    Schematic Diagrams ENE MR510, Card Reader X D _ B S Y # M F U N C 7 X D W P # S U S B # 12 , 2 5 , 3 1, 3 3 , 3 5, 39 , 4 0 V C C _C A R D MS _D 1 M F U N C 6...

  • Page 89: Audio Codec Alc662

    Schematic Diagrams Audio Codec ALC662 * S C S 5 5 1 V -3 0 L 4 3 H C B 1 0 05 K F - 12 1 T 2 0 3 . 3 V S 3 . 3 V S _ A U D 5 V S _A U D 5V S U 2 3...

  • Page 90: Audio Amp

    Schematic Diagrams Audio AMP 5 V S 5 V S _A MP L 7 6 H C B 1 6 0 8 K F -1 2 1 T 25 C 7 85 C 79 5 C 7 9 1 C 7 9 2 C 7 96 C 7 83 D 03A...

  • Page 91: Sata Hdd, Pwr, Lid

    Schematic Diagrams SATA HDD, PWR, LID POWER MANAGMENT POWER GOOD & RESET For NB con trol an d Le vel shi ft 3. 3 V 3. 3V 3 . 3 V 3. 3V 3 . 3V 3 . 3V VCO RE P owe r Go od dela y an d N otic e S B U 2 5 A A ll P owe r Go od and...

  • Page 92: Multi I/O, Odd, 3G, Click Bd For M74

    3. SIM hold ? ? ? ? ? G ND? ? 4.S IM CO NN ? ? M INI CARD CO NN C LIC K BO A RD RIGHT For M740S S W 7 J _ TP 1 T JG -5 33 -S -T / R...

  • Page 93: New Card, Mini Pcie, Usb

    Schematic Diagrams New Card, Mini PCIE, USB NEW CARD 3. 3V S C 7 17 *. 1 U _ 10 V _ X 7R _0 4 D0 3A L P C _ R S T # 3 . 3 V U 3 4 U 3 5 J_ N E W 1...

  • Page 94: Led, Pc Beep, Tp, Fp

    Schematic Diagrams LED, PC Beep, TP, FP 5 V S 5V S SCR OLL 3 . 3V S LOC K R 3 8 4 R 38 5 V D D 3 V D D 3 R 3 91 47 0 _0 4 4 7 0_ 0 4 22 0 _0 4 Z 3 2 09...

  • Page 95: System/Ext-Vga Power

    Schematic Diagrams System/Ext-VGA Power 1.2VS,1.5VS,1.8VS,3.3VS,5VS P Q5 8 P Q2 6 P Q2 3 S Y S 1 5V V D D 5 5V S S Y S 15 V V D D 3 3 . 3 V S S Y S 15 V 1 .

  • Page 96: Ac-In, Charger

    Schematic Diagrams AC-IN, Charger P Q3 1 V I N A M4 83 5 P Ch arg e Cu rre nt 2. 0A Ch arg e Vo lta ge 12 .6 V J_ D C -J A C K 1 P L 1 To tal P ow er 60 W 2D C -G 21 3 -B 2 00...

  • Page 97: Vcore

    Schematic Diagrams VCORE VCORE FOR PENRYN CPU V I N V -R C 1 P C 8 1 P C 8 4 P D 8 1 U _ 1 0 V _ 0 6 10 0 0 P _ 5 0V _0 4 F M0 5 4 0-N P R 6 V I N...

  • Page 98: Vdd3, Vdd5

    Schematic Diagrams VDD3, VDD5) P C 1 70 S Y S 5V . 0 1 U _ 5 0V _X 7 R _ 0 4 V I N 1 Z 3 61 9 Z 3 62 5 P D 2 2 F M 05 4 0 -N I N T V C C 2 P R 1 5 8 1 0 _ 06...

  • Page 99: 1.05Vs, 1.2V, 1.5V

    Schematic Diagrams 1.05VS, 1.2V, 1.5V P R 123 1 0_0 6 Z 370 1 VI N P C 133 . 1U _ 25V _ X7R _ 06 V I N PD 1 4 PR 1 26 PD 1 2 V I N PC 1 31 FM0 54 0-N 100 K _04...

  • Page 100: 1.8V, 0.9Vs

    Schematic Diagrams 1.8V, 0.9VS V I N 3 . 3 V P R 70 P R 1 4 8 P R 7 4 P D 1 3 10 0 K _ 04 1 M_ 0 4 1 0_ 0 6 V 1 .

  • Page 101: Click Bd, Finger Bd For M76

    Schematic Diagrams Click BD, Finger BD for M76 C L I C K B O A R D F I N G E R B O A R D C J _F P 1 C T A V D D C GN D C C 1 3 C T MU X OU T...

  • Page 102: Multi Function Board

    Schematic Diagrams Multi Function Board M _5 V M5 V _C C D SPEAKER CONNECTOR MULTI I/O CONN MC 9 MC 1 0 1U _ 6. 3 V _ 04 1U _6 . 3 V _0 4 MGN D M GN D M_ 5 V M5 V _C C D A O 34 0 9...

  • Page 103: Audio Board

    Schematic Diagrams Audio Board USB PORT A _ U S B V C C A _ U S B V C C 2 A L 5 H C B 16 0 8K F -12 1 T2 5 60 m il A _ U S B V C C A C 1 A C 7...

  • Page 104: Power Switch Board For M74

    Schematic Diagrams Power Switch Board for M74 POWER SW & POWER LED FOR M74 POWER S M_3. 3V S SWITCH POWER BUTTON 20mil S MS W 1 S MR 1 TJ G- 533- S -T/R Sheet 37 of 48 220_04 SM _BTN # S M_3.

  • Page 105: External Odd Board For M76

    Schematic Diagrams External ODD Board for M76 O J_ODD1 OJ_ODD2 Z4401 Z4404 Z4401 Z4404 Z4402 Z4402 OCD_RST# O IDE_PDD8 O CD_RST# O IDE_PDD8 OIDE_P DD7 O IDE_PDD9 O IDE_PDD7 O IDE_PDD9 OIDE_P DD6 O IDE_PDD10 O IDE_PDD6 O IDE_PDD10 OIDE_P DD5 O IDE_PDD11 O IDE_PDD5 O IDE_PDD11...

  • Page 106: Power Switch Board For M76

    Schematic Diagrams Power Switch Board for M76 POWER SW & POWER LED FOR M76 POWER SH _3. 3VS SWITCH POWER BUTTON 20mil S H S W 1 S H R 1 TJ G- 533- S -T/R Sheet 39 of 48 220_04 SH _BTN # 20mil...
